CONSTRUCTION DESCRIPTION
FOUR-WHEEL ANTI-LOCK BRAKE SYSTEM (4ABS)35B-11
NOTE: .
•*1 This diagnostic trouble code is not set within
the vehicle speed of 20 km/h (12 mph) or less.
•*2 Turns ON when two or more wheels are faulty.
•*3 Stays ON until the vehicle speed reaches 10
km/h (6 mph) when the ignition switch is turned to
ON next time.
DIAGNOSTIC FUNCTION
ABS-ECU has the following functions for easier sys-
tem checks. The following items can be diagnosed
using scan tool.
•Diagnostic trouble code set
•Service data output
•Actuator test.
DIAGNOSTIC TROUBLE CODE SET
There are 43 diagnosis items. Since all the diagnos-
tic results are recorded in volatile memory
(EEPROM*), they are stored in the memory even
though the battery terminals are disconnected.
NOTE: .
•*EEPROM (Electrical Erasable & Programmable
ROM): Special type of memory that can be pro
-
grammed or erased electrically
•For each diagnosis item, refer to Service Manual.
.
SERVICE DATA OUTPUT
Using scan tool, the input data sent from the sensors
and switches can be read.
NOTE: For service data items, refer to Service Man-
ual.
.
C2116Abnormality in pump motor
power supply voltageExecutedProhibitedExtinguishedIlluminated*3
C1000Abnormality in stop light switch
circuitExecutedExecutedExtinguishedExtinguished
C2200Abnormality in ABS-ECUProhibitedProhibitedIlluminatesIlluminates
C2100Battery
voltage
problem (low
voltage)9.7 ± 0.3 V or
less
*1
ExecutedProhibitedExtinguishedIlluminates
8.0 ± 0.5 V or
less
*1
ProhibitedProhibitedIlluminatesIlluminates
C2101Battery
voltage
problem (high
voltage)18.0 ± 1.0 V or
moreProhibitedProhibitedIlluminatesIlluminates
C1395Brake fluid filling not completedExecutedExecutedExtinguishedFlashes (1 Hz)
C2203VIN not writtenExecutedExecutedExtinguishedIlluminates
C1608Implausible diagnosis dataExecutedExecutedExtinguishedExtinguished
U0001Bus offExecutedExecutedExtinguishedExtinguished
U0100Engine time-out errorExecutedExecutedExtinguishedExtinguished
U0141ETACS time-out errorExecutedExecutedExtinguishedExtinguished
U1415Variant coding not implementedExecutedProhibitedExtinguishedIlluminates
U1417Invalid variant coding value
(including wrong assembly)ExecutedProhibitedExtinguishedIlluminates
DTC
No.Item Countermeasures for failure
EBD control ABS control Brake
warning lightABS warning
light

OIL PUMP
POWER STEERING37-6
Secondary collision
When the driver's body falls against the steering wheel via the
deployed air bag, the column bracket moves forward by
deforming the rivet pin of the one-way capsule, and simulta
-
neously the steering column assembly frees from the pin of col-
umn bracket to move forward and downwards.
OIL PUMPM2370004000373
The oil pump is a vane type with a fluid flow control
system which functions so the steering wheel turning
effort will be reduced at low engine speeds and
increase at higher speeds. The oil pump is essentially the same as the conven-
tional one in construction.
AC611053AB
AA
BB
One way
capsule
Section B - BSection A - A Column
bracketRivet pin
Column pipe Before collision
After collision
AC607645AB
A
AColumn
bracket
Column pipe
Pin Section A - A
