COLUMN SWITCH
CHASSIS ELECTRICAL54A-21
COLUMN SWITCH
GENERAL INFORMATIONM2546100200058
Column switch has a function to ensure the driver's
safety during frontal collision of vehicle..
Function
If the column switch is moved to the front of the vehi-
cle and hit on the instrument panel or meter bezel by
the frontal collision of vehicle, the steering wheel is
moved to the front of the vehicle because the right
and left levers fall down, ensuring the driver's safety.
In addition, the column switch secures the rigidity
that the levers do not fall down by the normal opera
-
tion, however, it cannot be reused after the deforma-
tion.
RADIO AND CD PLAYER
GENERAL INFORMATIONM2544900200218
•Two types of audio, CD player with radio or 6-disk CD
changer with radio, have been established. The audio was
designed to create a uniformity impression with the instru
-
ment panel. Also, a new function automatically corrects the
sound quality and volume during driving.
AC603959AB
Collision load Collision load
Column switch Column switch Front of vehicle
AC608345AB

RADIO AND CD PLAYER
CHASSIS ELECTRICAL54A-22
•For the vehicles with Rockford Fosgate ® premium sound
system, the 8-ch high-power audio amplifier with integrated
DSP (total maximum output of 650 W) has been established
under the driver's seat. The clear treble without distortion is
available.
•For the vehicles with Rockford Fosgate ® premium sound
system, the audio adapter has been established onto the
center tray. With this modification, portable music player
can be connected.
NOTE: .
•*1: CD-R/CD-RW may not be played.
•*2: Some may not be played.
STEERING WHEEL AUDIO REMOTE CONTROL SWITCH
The concentrated switch has been established onto
the steering wheel spoke for allowing the remote
control of audio.
AC608321AB
Driver's seatAudio amplifier
Rear seat
AC608417
AB
Audio adapter
ItemCD player with radio6-disk CD changer with
radio
Electronic tuning radioEquippedEquipped
SIRIUS satellite radio −Equipped (Only the vehicles
with the satellite radio tuner)
CD player*1 (compatible with MP3*2)EquippedEquipped
6-disk CD autochanger*1 (compatible with
MP3
*2)
−Equipped
Audio integrated 4-ch power amplifier with 4 speakers, 6 speakers>General 140 WGeneral 140 W
Audio amplifier-integrated 8-ch power amplifier
and digital signal processor (DSP) Fosgate
® premium sound system>
−General 650 W (maximum)
AC606795
AF
Steering wheel
audio remote control
switch

RADIO AND CD PLAYER
CHASSIS ELECTRICAL54A-23
AUDIO OPERATION TONE ALARM
To prevent an audio operational error, the audio
operation tone alarm confirms the audio operation
which sounds a tone alarm in the combination meter
when the audio is operated. The details are as
described in the following table:
Usage categoryConfirmation tone alarm sounding condition (with conditions below, tone alarm
sounds for 0.08 seconds)
Radio usePress and hold "1", "2", "3", "4", "5" or "6" button.
Press and hold "SCAN" button.
CD usePress and hold the "LOAD" button.
Press and hold the "DISC" button.
Press and hold the "RPT" button.
Press and hold the "RDM" button.
Press and hold the CD eject button
Audio adjustmentWith "BASS", "MID", "TREBLE", "BALANCE", or "FADER" selected, adjust the
adjustment level to zero.
Select "NORMAL" of "SOUND FIELD".
Select "NORMAL" of "MUSIC TYPE".
OthersPress and hold the "TUNE" knob.
Press and hold the "MODE" switch of steering remote control switch.

SPEAKER
CHASSIS ELECTRICAL54A-24
SPEAKER
GENERAL INFORMATIONM2545000200177
The following three types of speakers are available.
•4 speakers (Front door: 16 cm, rear door: 16 cm)
•6 speakers (tweeter: 3.5 cm, front door: 16 cm,
rear door: 16 cm)
•9 speakers (tweeter: 3.5 cm, front door: 16 cm,
rear door: 2-way coaxial 16 cm, subwoofer: 25
cm) ® premium sound sys-
tem>
TWEETER
For the front door sash trim, two types of tweeters,
the balance dome tweeter -
ers> and soft dome tweeter ers (Rockford Fosgate ® premium sound system)>,
have been established. The soft dome tweeter can
play clearer treble with less distortion compared to
the balance dome tweeter. For the better treble, two
types of front sash garnish, resin type 6 speakers> and punching metal type Fosgate
® premium sound system>, has been
established. With the punching metal type, the metal
has been adopted for the punching part to enlarge
the punching opening, enabling the playback of
cleaner treble.
AC608693
Front door
speaker
Rear door
speakerFront door
speaker
Rear door
speaker
Tweeter
Front door
speaker
Rear door
speakerTweeter
Subwoofer
AB
<4 speakers> <6 speakers> <9 speakers>
AC608346
ABTweeter
Front door sash trim

SPEAKER
CHASSIS ELECTRICAL54A-25
DOOR SPEAKER
NOTE: The parts with "*" are installed exclusively to
the vehicles with Rockford Fosgate
® premium sound
system.
For the front door speaker, two types of speakers, 16
cm paper cone speaker speakers> and PP (polypropylene) cone speaker
® premium sound system>, are
available. For the rear door speaker, two types of
speakers, 16 cm paper cone speaker 4 speakers, 6 speakers> and PP (polypropylene)
cone 2-way coaxial speaker -
ers (Rockford Fosgate® premium sound system)>,
are available. Compared to the paper cone speakers,
the PP (polypropylene) cone speakers can playback
crisper bass. The door opening of the vehicles with 9
speaker (Rockford Fosgate
® premium sound sys-
tem) is blocked by using the sheet metal cover and
the urethane integrated resin sheet (resin cover and
water proof film) to make the door into a speaker
box, thus improving the sound quality. As an advan
-
tage of the sheet metal cover, the rigidity of the areas
around the speaker has been increased, and the
higher sound pressure, suppression of high har
-
monic, and suppression of dumping are achieved to
improve sound quality.
The one-touch installable speaker (with 3 tabs, fixed
by rotating) has been adopted to improve service
-
ability.
AC608347
Front door speaker
Rear door speaker
Sheet metal
cover*
Resin cover*
Resin cover*
AB
Front door water
proof film
Rear door water
proof film
Urethane integrated
resin sheet*
Urethane integrated
resin sheet*
AC507245AB

ANTENNA
CHASSIS ELECTRICAL54A-26
SUBWOOFER Fosgate
® PREMIUM SOUND SYSTEM>
The 25 cm dual voice coil subwoofer has been installed to the
trunk room, enabling the playback of dynamic deep bass.
ANTENNA
GENERAL INFORMATIONM2545100200163
The pole antenna has been adopted for the radio.
The antenna base incorporates the radio amplifier.
When the satellite radio tuner is installed, the
antenna base that also corresponds to the satellite
radio is installed.
CONSTRUCTION DIAGRAM
AC608344ABSubwoofer
Trunk room
AC608360
Pole antenna (for radio)
AB
Satellite radio tuner (Vehicles with satellite radio)
Antenna base

MITSUBISHI MULTI COMMUNICATION SYSTEM (MMCS)
CHASSIS ELECTRICAL54A-27
MITSUBISHI MULTI COMMUNICATION SYSTEM (MMCS)
GENERAL INFORMATIONM2544800200084
Mitsubishi multi-communication system (audio visual naviga-
tion unit) with built-in hard disk drive (30 gigabyte) has been
installed. Also, a 7-inch liquid crystal display of wide 2 DIN size
has been adopted.
The audio and video adapter has been established to the cen-
ter tray in order to connect visual equipment such as game
machine and video player.
Operation part
AC608322AB
Audio visual navigation unit
AC608418ABAudio and video adapter
AC505475
MODE
AUDIO
VOL
PWRINFO
NAVI
SCALE
MENU
Mitsubishi Multi Communication System
ENTSET
OPEN
AB
Display (function)Contents
Navigation screenDisplays the navigation functions including the map display, search, guidance,
information search.
Vehicle position information
screenDisplays the position information of current location. (Longitude and latitude,
altitude, GPS reception status)
CD screenPlays back the disc inserted to the CD drive (CD-R/CD-RW).
MP3/WMA screenPlays back the MP3/WMA.
DVD screenPlays back the disc inserted to the DVD drive.
Music server functionPlays back the music data on hard disk drive, and records the music CD.
Radio screenDisplays the receiving station information. Also, the operation of receiving
channel can be performed.

MITSUBISHI MULTI COMMUNICATION SYSTEM (MMCS)
CHASSIS ELECTRICAL54A-28
Navigation function
The storage of very large map data is now possible,
and the following contents have been adopted.
•Map type navigation
•NAVTEQ map database
•Map data stored in hard disc drive
•U.S. English, French, and Spanish are available
to select.
Audio and visual function
The following functions are in addition to the naviga-
tion function:
•Music server function
•DVD drive unit
•FM/AM radio
•MP3/WMA playback function
•Control by steering wheel audio remote comtrol
switch
•Integrated 4-ch power amplifier (MAX: 180 W)
•Correspond to Rockford Fosgate® premium
sound system
•Output of DVD video 5.1 channel data
•Connect with satellite radio tuner
Other function
The following functions are in addition to the naviga-
tion, audio and visual function:
•Clock display
•Connect with hands free unit
•A/C information display
•Outside temperature display
•Trip information display (Average fuel consump-
tion etc.)
•Function customize
SYSTEM BLOCK DIAGRAM
AC505476
AC608750 ZC3050180000
Audio and video
adopter Antenna
Steering wheel
audio remote control
switch
Speaker
*1: Controller Area Network Note:
*2: Universal Asynchronous Receiver Transmitter UART
communicationn
Sound Sound Voice Sound
Audio amplifierCAN box unitETACS-ECU Combination
meter
Audio visual navigation unitA/C-ECU
Hands-free
module
CAN
communication
AB

AUDIO SYSTEM
TSB Revision
CIRCUIT DIAGRAMS90-168
AUDIO SYSTEM AMPLIFIER>
M1901015602949
FUSIBLE
LINK34FUSIBLE
LINK36
REFER TO
POWER
DISTRIBUTION
SYSTEM
CENTER PANEL UNIT
ETACS-
ECU
AUDIO SWITCH PANELLCD PANEL (AUDIO)
RADIO AND CD PLAYER OR CD CHANGER RELAY BOX
ENGINE
COMPARTMENT
HANDS FREE
SYSTEM
JOINT
CONNECTOR
(3)
