MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual

Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) 5-34 Features and controls
5
4. Insert the valid F.A.S.T.-key into the emergency key. 5. Turn the emergency key with F.A.S.T.- key to the “ON” position. (Perform the following procedure within 30 seconds)6. Remove the F.A.S.T.-key from the emer- gency key. 7. With the first valid F.A.S.T.-key, press theUNLOCK button (2) and the LOCK but-ton (1) simultaneously for 4 to 10 sec- onds. 8. Release in sequence the LOCK andUNLOCK buttons within 10 seconds of pressing the LOCK button in step 7. (Per- form the following procedure within 30seconds) 9. With the second valid F.A.S.T.-key, press the UNLOCK button for 4 to 10 secondsand press the LOCK button during this time.
10. Release in sequence the LOCK and
UNLOCK buttons within 10 seconds of pressing the LOCK button in step 9, and the immobilizer display will blink on theinformation screen in the multi-informa- tion display. (Perform the following pro- cedure within 60 seconds)
11. Press the LOCK button twice with the
blank F.A.S.T.-key and the immobilizer display will come on for 30 seconds onthe information screen in the multi-infor-mation display.
12. This completes the registration of the
F. A . S . T. - k e y.
N00562001075
Your F.A.S.T.-key operates on a radio fre-quency subject to Federal CommunicationsCommission (FCC) Rules (For vehicles sold in U.S.A.) and Industry Canada Rules (For vehicles sold in Canada). This device com-
NOTE
 The indicator light (4) comes on each time a button is pressed.  The keyless entry system does not work if the key is in the ignition switch.  The F.A.S.T.-key can be used from about 40 feet (12 m) away. However, this distance may change if your vehicle is near a TVtransmitting tower, a power station, or a radio station.  If the UNLOCK button (2) is pressed when all doors and the rear hatch are locked and nodoors or rear hatch are opened within about 30 seconds, the doors and the rear hatch will automatically re-lock.
 If the following conditions are observed after pressing the buttons on the remote control transmitter, the battery in the remote control transmitter may need to be replaced. • The doors and the rear hatch cannot be locked or unlocked. • The panic alarm cannot be operated. • The indicator light (4) is dim or does not come on.
 If you lose your F.A.S.T.-key, please contact an authorized Mitsubishi Motors dealer for a replacement.  If you wish to obtain an
additional F.A.S.T.-
key, please contact an authorized Mitsubishi Motors dealer. A maximum of four F.A.S.T.-key can be programmed for your vehicle.  To use the new remote control transmitters, it is necessary to register the key with both the electronic immobilizer and keyless entry sys- tem.Also refer to “Electr
onic immobilizer (Anti-
theft starting system): Customer F.A.S.T.- key programming” on page 5-29.
General information

NOTE
BK0200700US.bo
ok 34 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Free-hand Advanced Security Transmit
ter (F.A.S.T.-key) (if so equipped)
Features and controls 5-35
5
plies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two con- ditions.  This device may not cause harmful inter- ference.  This device must accept any interference received, including interference that maycause undesired operation.
N00562100053
1. Before replacing the battery, remove static electricity from your body by touching a metal grounded object.
2. With the Mitsubishi mark facing you, insert the cloth-covered tip of a flat blade screwdriver into the notch in the remote control transmitter case and use it to openthe case. 3. Remove the old battery.
4. Install a new battery with the + side (A) up. 5. Close the remote control transmitter case firmly. 6. Check the keyless entry system to see thatit works.
CAUTION Changes or modifications not expressly approved by the manufacturer for compli- ance could void the user’s authority to oper-ate the equipment.
Procedure for replacing the remote control transmitter bat- tery

NOTE
 Be sure to perform the procedure with the Mitsubishi mark facing you. If the Mitsubi- shi mark is not facing you when you open theremote control transmitter case, the transmit- ter may come out.
NOTE
 You may purchase a replacement battery at an electric appliance store.  Your authorized Mitsubishi Motors dealer can replace the battery for you if you prefer.CAUTION When the remote control transmitter case is opened, be careful to keep water, dust, etc. out. Also, do not touch the internal compo- nents.
+ side - side Coin type battery CR2032
BK0200700US.bo
ok 35 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Door locks 5-36 Features and controls
5
N00509200521
Turn the key toward the front of the vehicle to lock the door. After checking that the door is
locked, turn the key back to the center and remove it.
Door locks
WA R N I N G Make sure all doors are tightly closed and locked while driving.• Locked doors, in combination with theuse of seat belts, can help reduce the risk of ejection in an accident.• Locked doors can help keep passengers,especially small chil
dren, from opening
doors and falling out of moving vehicles.• Locked doors can help prevent outsidersfrom gaining access to your vehicle whenyou slow or come to a stop.
 Lock your vehicle whenever you leave it. Children who get into unlocked vehicles may not be able to get out. Children trapped inside vehicles can quickly beovercome by heat and suffer serious injury or death due to heat stroke. Never leave children unattended inside a vehicle. In addition to the risk of heat stroke, children can activate switches andcontrols, resulting in an injury or fatal accident.
NOTE
 When locking or unlocking with the key, only the driver’s door will be locked or unlocked. To lock or unlock all doors and rear hatch, use the power door lock switches, the key-less entry system, the F.A.S.T.-key opera- tion. Refer to “Power door locks” on page 5-38,“Keyless entry system” on page 5-7and 5-30, and “To operate using the F.A.S.T.-key” on page 5-14.  In vehicles equipped with the F.A.S.T.-key, the driver’s door can be locked and unlockedusing the emergency key. Refer to “Emergency key” on page 5-22.
To lock or unlock the doors with the key (driver’s door)
1- Insert or remove the key 2- Lock 3- Unlock
BK0200700US.bo
ok 36 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Door locks
Features and controls 5-37
5
Move the lock knob to the lock position to lock the door.All doors should be kept locked while driv- ing. The driver’s door can be unlocked without using the lock knob by pulling on the inside door handle. 1. Move the inside lock knob to the locked position.
2. Be sure the keys are not inside the vehi- cle. Close the door.
N00549600208
Type 1 Type 2
If the ignition switch is turned off and the driver’s door is opened with the key in the ignition switch, the key reminder buzzer will sound intermittently to remind you to removethe key. The warning display will be displayed on the information screen in the multi-informationdisplay.
N00517300039
When you push the lock knob forward or lockthe door with the power door lock switch inboth of the following conditions, the lock knob will automatically return to the unlocked position.  The key is in the ignition switch or the ignition switch is in the “ACC” or “ON” position.  Driver’s door or front passenger door is opened.
To lock or unlock the door from the inside 1- Lock 2- Unlock To lock the door without using the key
Key reminder system When a key was used to start the engine
Lock out protection
BK0200700US.bo
ok 37 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Power door locks 5-38 Features and controls
5
N00503800134
Ty p e 1 Ty p e 2 If the driver’s door is opened while the igni- tion switch is in a position other than “LOCK” (PUSH OFF), the ignition switch return reminder buzzer will sound intermit-tently to remind you to return the ignition switch to the “LOCK” (PUSH OFF) position. The warning display will be displayed on theinformation screen in the multi-information display.
N00509300593
All of the doors and the rear hatch can belocked or unlocked by pressing the power door lock switch on the driver’s or the frontpassenger’s door.
Ignition switch return reminder system When the F.A.S.T.-key was used to start the engine
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door will lock or unlock.  Repeated continuous operation between lock and unlock could activate the power door locking systems built-in protection circuitand prevent the system from operating. If this occurs, wait about one minute before operating the power door lock switch.
To lock and unlock the doors and rear hatch Using the power door lock switch 1- Lock 2- Unlock
BK0200700US.bo
ok 38 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

“Child safety locks” for rear door
Features and controls 5-39
5
N00563401148
All doors and the rear hatch will unlock when the ignition switch is turned to the “LOCK” position. All doors and the rear hatch will unlock when the selector lever (CVT) or the gearshift lever(Twin Clutch SST) is moved to the “P”
(PARK) position with the ignition switch in the “ON” position.
N00509400204
Child safety locks help prevent rear passen-gers, especially children, from opening the rear door using the inside door handle. A lock lever for the chil
d safety lock is pro-
vided on each rear door. When the lever is in the lock position (1), the rear door cannot be opened using the insidedoor handle. To open the rear door when the child safety lock lever is in the lock position, pull the out-side door handle.When the lever is in th
e release position (2),
the child safety lock is released and the rear door can be opened using the inside door han-dle.
To unlock the doors and rear hatch You can select the functions to unlock the doors and rear hatch either using the igni- tion switch position or using the selector lever {continuously variable transmission (CVT)} position or the gearshift lever (Twin Clutch SST) position.These functions are not activated when the vehicle is shipped from the factory. To acti- vate or deactivate these functions, please contact your authorized Mitsubishi Motors dealer.Using the ignition switch position Using the selector lever {continu- ously variable trans- mission (CVT)} position or the gearshift lever (Twin Clutch SST) position
“Child safety locks” for rear door 1- To lock 2- To releaseVehicles with CVT
Vehicles with Twin Clutch SST
WA R N I N G Always keep the doors tightly closed and locked when driving. An unlocked door may be accidentally opened by a passen- ger, especially by a child who could fallout. Also, if the doors are not locked, there is a greater risk of someone being thrown from the vehicle in an accident.
BK0200700US.bo
ok 39 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Rear hatch 5-40 Features and controls
5
N00510000066
After unlocking, lift the rear hatch.
Pull the rear hatch grip (A) downward as illustrated and release it before the rear hatchcloses completely. Gently slam the rear hatch from the outside so that it is completely closed.
Rear hatch
WA R N I N G It is dangerous to drive with the rear hatch open since carbon monoxide (CO) gas can enter the passenger compartment. CO is an invisible, odorless gas that cancause unconsciousness and even death. When opening and closing the rear hatch, make sure that there are no people nearby and be careful not to hit your head or pinch your hands, neck, etc.CAUTION Do not stand behind the exhaust pipe when loading and unloading luggage. Heat from the exhaust could lead to burns.NOTE
 Locking and unlocking the doors by using the power door locks (driver and front pas- senger side), keyless entry system, or F.A.S.T.-key operation (if so equipped) also locks and unlocks the rear hatch.
To open
CAUTION Make sure there is no one standing nearby when opening the rear hatch.NOTE
 The rear hatch cannot be raised if it is not raised immediately after pressing the rearhatch OPEN switch. If this happens, raise the rear hatch again after pressing the rear hatch OPEN switch.  It is not possible to open the rear hatch while the battery is disconnected. If necessary, usethe inside rear hatch release.  When the battery is reconnected, all doors and the rear hatch will be locked. Unlock them before trying to open the rear hatch.
To close
CAUTION To avoid injuring your hand or arm, do not attempt to close the rear hatch without releasing the rear hatch grip (A). Before starting the vehicle, be sure to con- firm that the rear hatch is locked. If the rearhatch opens while driving the vehicle, objects stored in the luggage compartment could fall out into the road.
BK0200700US.bo
ok 40 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Inside rear hatch release
Features and controls 5-41
5
N00523100058
The inside rear hatch release is designed to provide a way to open the rear hatch if the battery is dead or disconnected. The rear hatch release lever (see illustration)is mounted on the rear hatch.
You and your family should familiarize your- selves with the location and operation of the rear hatch release lever. 1. Open the lid (A) inside of the rear hatch.
2. Move the lever (B) to open the rear hatch. 3. Push out on the rear hatch to open it.
N00510200215
The theft-alarm system is designed to provide protection from unauthorized entry into the vehicle. This system is operated in three stages: the first is the “armed” stage, the sec-ond is the “alarm” stage,
and third is the “dis-
armed” stage. If triggered, the system provides both audible and visual alarm sig-nals.
NOTE
 Gas struts (B) are installed in the locations illustrated in order to support the rear hatch. Please observe the following in order to pre- vent damage or faulty operation. • Do not touch, push or pull the gas struts when closing the rear hatch. • Do not attach any plastic material, tape, etc., to the gas struts. • Do not tie string, etc., around the gas struts. • Do not hang objects
on the gas struts.
Inside rear hatch release
To open
CAUTIONAlways keep the release lever lid on rear hatch closed when driving so that your lug- gage cannot accidentally bump the lever and open the rear hatch.
Theft-alarm system
BK0200700US.bo
ok 41 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Theft-alarm system 5-42 Features and controls
5
N00510301196
Park the vehicle and stop the engine. Arm the system as described below. 1. Turn the ignition switch to the “LOCK” position. Also, if a key was used to start the engine, remove the key from the ignition switch.2. Make sure that the engine hood is closed.
3. Lock all doors and the rear hatch by using the keyless entry system or the F.A.S.T.- key operation. At this time, the theft-alarm indicator (A) on the audio panel flashes for confirma- tion.
4. The system has entered the armed stage after about 20 seconds, when the theft- alarm indicator (A) flashing becomes slower.The theft-alarm indicator (A) continues to flash while the system is in the armed stage.
CAUTION Do not modify or add parts to the theft-alarm system. Doing so could cause the theft-alarm to malfunction.
Armed stage
Arm the system and leave
NOTE
 If the engine hood is open, the theft-alarm indicator (A) illuminates and the system can-not enter the armed stage. The system enters the armed stage about 20 seconds after the engine hood is closed.  The system will be disarmed if, while the theft-alarm indicator (A) is illuminated, alldoors and rear hatch are unlocked by using the keyless entry system or the F.A.S.T.-key operation.  The system will be disarmed if, while the theft-alarm indicator is illuminated, the igni-tion switch is turned to the “ON” position.  The system will not be
armed if a door or the
rear hatch or the engine hood is not com- pletely closed. If this happens, rearm the sys- tem as described above.  The theft-alarm system can be activated when people are riding inside the vehicle or when the windows are open. To prevent acci- dental activation of the alarm, do not set thesystem to the system armed mode while peo- ple are riding in the vehicle.
BK0200700US.bo
ok 42 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Theft-alarm system
Features and controls 5-43
5
N00510401201
The alarm will be activated if any of the fol- lowing occur while the vehicle is parked andthe system is armed.  One of the doors and the rear hatch is opened without using the keyless entry system or the F.A.S.T.-key operation. The engine hood is opened.
When the alarm is activated: 1. The headlights blink on and off for 3 min- utes.After 3 minutes the headlights automati- cally shut off. 2. The horn will sound intermittently for 3minutes.
Type 1
Type 2 The alarm can be deactivated in the following ways.  By using the keyless entry system or the F.A.S.T.-key operation to lock or unlock the door or rear hatch. Turn the ignition switch to the “ON” posi- tion.
N00510501185
The system will be disarmed if the followingoperation is performed.  The ignition switch is turned to the “ON” position. All doors and the rear hatch are unlocked by the keyless entry system or the F.A.S.T.-key operation.
Alarm stage Type of alarm
NOTE
 The alarm will continue to operate for 3 min- utes. At the end of that period, the alarm will automatically shut off to save battery power. The system will then
be rearmed until the
proper disarming step is taken.  The alarm will resume if unauthorized actions are taken again, even if the alarm has stopped.  While the alarm is operating, a warning is displayed on the information screen in the multi-information display.Horn sounds! Headlights blink on and off!
Alarm deactivation Disarmed stage
BK0200700US.bo
ok 43 ページ ２０１３年２月１５日　金曜日　午後１２時１７分
