Page 25 of 1501
![MITSUBISHI MONTERO 1998 Service Manual ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
"A" ABBREVIATION TABLE
"A" ABBREVIATION TABLE \
\](/img/19/57333/w960_57333-24.png "MITSUBISHI MONTERO 1998 Service Manual ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
\"A\" ABBREVIATION TABLE
\"A\" ABBREVIATION TABLE \
\")
ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
"A" ABBREVIATION TABLE
"A" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
A Amperes
A/C Air Conditioning
A/T Automatic Transmission/Transaxle
AAP Auxiliary Accelerator Pump
AB Air Bleed
ABCV Air Bleed Control Valve
ABDC After Bottom Dead Center
ABRS Air Bag Restraint System
ABS Anti-Lock Brake System
AC Alternating Current
ACC A/C Clutch Compressor
ACCS A/C Cycling Switch
ACCUM Accumulator
ACCY Accessory
ACT Air Charge Temperature Sensor
ACV Thermactor Air Control Valve
ADJ Adjust or Adjustable
ADV Advance
AFS Airflow Sensor
AI Air Injection
AIR or A.I.R. Air Injection Reactor
AIS Air Injection System
ALCL Assembly Line Communications Link
ALDL Assembly Line Diagnostic Link
ARC Automatic Ride Control
ASCD Automatic Speed Control Device
ASCS Air Suction Control Solenoid
ASD Auto Shutdown
ASDM Air Bag System Diagnostic Module
ASV Air Suction Valve
ATC Automatic Temperature Control
ATDC After Top Dead Center
ATF Automatic Transmission Fluid
ATS Air Temperature Sensor
AXOD Automatic Transaxle Overdrive
Abs. Absolute
Accy. Accessory
Alt. Alternator or Altitude
Amp. Ampere
Assy. Assembly
Auto. Automatic
Aux. Auxiliary
Avg. Average
\
\
\
\
\
\
\
\f
"B" ABBREVIATION TABLE
"B" ABBREVIATION TABLE
Page 26 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
ABBREVIATION DEFINITION](/img/19/57333/w960_57333-25.png "MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
ABBREVIATION DEFINITION")
\
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
B/P Backpressure
BAC By-Pass Air Control
BAP Barometric Absolute Pressure Sensor
BARO Barometric
BBDC Before Bottom Dead Center
BCM Body Control Module
BDC Bottom Dead Center
BHP Brake Horsepower
BLK Black
BLU Blue
BMAP Barometric & Manifold Absolute Pressure Sensor
BOO Brake On-Off Switch
BP Barometric Pressure sensor
BPS Barometric Pressure Sensor
BPT Backpressure Transducer
BRN Brown
BTDC Before Top Dead Center
BTU British Thermal Unit
BVSV Bimetallic Vacuum Switching Valve
Baro. Barometric
Batt. Battery
Bbl. Barrel (Example: 4-Bbl.)
Blst. Ballast
Blwr. Blower
Brkr. Breaker
\
\
\
\
\
\
\
\f
"C" ABBREVIATION TABLE
"C" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
C Celsius (Degrees)
C(3) I Computer Controlled Coil Ignition
C(4) Computer Controlled Catalytic Converter
CANP Canister Purge solenoid
CARB California Air Resources Board
CAT Catalytic Converter
CB Circuit Breaker
CBD Closed Bowl Distributor
CBVV Carburetor Bowl Vent Valve
cc Cubic Centimeter
CCC Computer Command Control
CCD Computer Controlled Dwell
CCM Central Control Module
CCO Converter Clutch Override
CCOT Cycling Clutch Orifice Tube
CCW Counterclockwise
CDI Capacitor Discharge Ignition
CEC Computerized Engine Control
CFI Central Fuel Injection
CID Cubic Inch Displacement
CID Cylinder Identification sensor
CIS Continuous Injection System
CIS-E Continuous Injection System-Electronic
CKT Circuit
CLR Clear
CNG Compressed Natural Gas
Page 28 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\b\
\
\
\
\
\
EAC Electric Assist Choke](/img/19/57333/w960_57333-27.png "MITSUBISHI MONTERO 1998 Service Manual \
\b\
\
\
\
\
\
EAC Electric Assist Choke")
\
\b\
\
\
\
\
\
EAC Electric Assist Choke
EACV Electric Air Control Valve
EBCM Electronic Brake Control Module
ECA Electronic Control Assembly
ECAT Electronically Controlled Automatic Transaxle
ECM Electronic Control Module
ECT Engine Coolant Temperature Sensor
ECU Electronic Control Unit or Engine Control Unit
EDF Electric Drive Fan relay assembly
EDIS Electronic Distributorless Ignition System
EEC Electronic Engine Control
EECS Evaporative Emission Control System
EEPROM Electronically Erasable PROM
EFE Early Fuel Evaporation
EFI Electronic Fuel Injection
EGO Exhaust Gas Oxygen sensor (see HEGO)
EGR Exhaust Gas Recirculation system
EGRC EGR Control solenoid or system
EGRV EGR Vent solenoid or system
EMR Emission Maintenance Reminder Module
ESA Electronic Spark Advance
ESC Electronic Spark Control
EST Electronic Spark Timing
ETR Emergency Tensioning Retractor
EVAP Fuel Evaporative System
EVIC Electronic Vehicle Information Center
EVO Electronic Variable Orifice
EVP EGR Valve Position Sensor
EVR EGR Valve Regulator
EVRV Electronic Vacuum Regulator Valve
Elect. Electronic
Eng. Engine
Evap. Evaporative
Exc. Except
\
\
\
\
\
\
\
\f
"F" ABBREVIATION TABLE
"F" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
F Fahrenheit (Degrees)
F/B Fuse Block
FBC Feedback Carburetor
FI Fuel Injector or Fuel Injection
FICD Fast Idle Control Device
FIPL Fuel Injector Pump Lever
FP Fuel Pump
FPM Fuel Pump Monitor
FPR-VSV Fuel Pressure Regulator Vacuum Switching Valve
FWD Front Wheel Drive
Fed. Federal
Ft. Lbs. Foot Pounds
\
\
\
\
\
\
\
\f
"G" ABBREVIATION TABLE
"G" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
Page 32 of 1501
![MITSUBISHI MONTERO 1998 Service Manual "P" ABBREVIATION TABLE
"P" ABBREVIATION TABLE \
\
\
\
\
\
\](/img/19/57333/w960_57333-31.png "MITSUBISHI MONTERO 1998 Service Manual \"P\" ABBREVIATION TABLE
\"P\" ABBREVIATION TABLE \
\
\
\
\
\
\")
"P" ABBREVIATION TABLE
"P" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
"P" Park
P/C Printed Circuit
P/N Park/Neutral
P/S Power Steering
PAV Pulse Air Valve
PC-SOL Purge Control Solenoid
PCM Powertrain Control Module
PCS Purge Control Solenoid
PCSDM Passenger Compartment Sensor/Diagnostic Module
PCV Positive Crankcase Ventilation
PFE Pressure Feedback EGR sensor or circuit
PFI Port Fuel Injection (see MA SEFI)
PGM-CARB Programmed Carburetor
PGM-FI Programmed Fuel Injection
PIP Profile Ignition Pickup
PNK Pink
PPL Purple
PRNDL Park Reverse Neutral Drive Low
PROM Programmable Read-Only Memory
psi Pounds Per Square Inch
PSPS Power Steering Pressure Switch
PTC Positive Temperature Coefficient
PTO Power Take-Off
PWR GND Power Ground circuit
Pkg. Package
Press. Pressure
Prog. Programmed or Programmable
Pts. Pints
Pwr. Power
\
\
\
\
\
\
\
\f
"Q" ABBREVIATION TABLE
"Q" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
Qts. Quarts
\
\
\
\
\
\
\
\f
"R" ABBREVIATION TABLE
"R" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
RABS Rear Anti-Lock Brake System
RAC Remote Accessory Control
RAM Random Access Memory
RAP Retained Accessory Power
RECIRC Recirculation
RED Red
RH Right Hand
ROM Read Only Memory
RPM Revolutions Per Minute
Page 33 of 1501
RVB Rear Vacuum Break
RWAL Rear Wheel Anti-Lock Brake
RWD Rear Wheel Drive
Recirc. Recirculate or Recirculation
Reg. Regulator
Rly. Relay
\
\
\
\
\
\
\
\f
"S" ABBREVIATION TABLE
"S" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
SAW Spark Angle Word
SBC Single Bed Converter
SBEC Single Board Engine Controller
SC Super Charged
SCC Spark Control Computer
SCS Air Suction Control Solenoid
SDM Supplemental Restraint System Diagnostic Module
SDU SRS Diagnostic Unit
SEN Sensor
SES Service Engine Soon
SFI Sequential (Port) Fuel Injection
SIG RTN Signal Return circuit
SIL Shift Indicator Light
SIR Supplemental Inflatable Restraint
SMEC Single Module Engine Controller
SOHC Single Overhead Cam
SOL or Sol. Solenoid
SPFI Sequential Port Fuel Injection
SPK Spark Control
SPOUT Spark Output Signal
SRS Supplemental Restraint System (Air Bag)
SS 3/4-4/3 Shift Solenoid circuit
SSI Solid State Ignition
STAR Self-Test Automatic Readout
STI Self Test Input circuit
STO Self-Test Output
SUB-O2 Sub Oxygen Sensor
Sen. or Sens. Sensor
Sol. Solenoid
Sprchg. Supercharger
Strg. Steering
Susp. Suspension
Sw. Switch
Sys. System
\
\
\
\
\
\
\
\f
"T" ABBREVIATION TABLE
"T" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
T.V. Throttle Valve
TAB Thermactor Air By-Pass
TAC Thermostatic Air Cleaner
TAD Thermactor Air Diverter
TAN Tan
TBI Throttle Body Injection
Page 45 of 1501
HEATER HOSES
HIGH PRESSURE RELIEF VALVES (HPRV)
IDLERS
IN-LINE FILTERS
METAL FITTINGS
METAL LINES
MIX AND AIR CONTROL DOORS (BLEND DOORS)
O-RINGS
ORIFICE TUBES
PILOT-OPERATED ABSOLUTES (POAS)
PLENUMS
PRESSURE CONTROL VALVES
PRESSURE SENSORS
PULLEYS
RADIATORS
RECEIVER-DRIERS
REFRIGERANT
REFRIGERANT OIL
RELAYS
SEALS
SERVICE PORTS
SPRING LOCK COUPLINGS
SUCTION THROTTLING VALVES (STVS)
SWITCHES (ELECTRICAL)
TENSIONERS
THERMISTORS AND PRESSURE SENSORS
THERMOSTATS AND HOUSINGS
VACUUM HOSES AND TUBES
VACUUM RESERVOIRS
VACUUM TUBES
VALVES IN RECEIVER (VIRS)
WATER PUMPS (ELECTRIC AUXILIARY)
WIRING HARNESSES AND CONNECTORS
MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
(1) a Pledge of Assurance to their Customers and (2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
Page 127 of 1501
ANTI-LOCK BRAKE SAFETY PRECAUTIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
Anti-Lock Brake Safety Precautions
* PLEASE READ THIS FIRST *
This article is intended for general information purposes
only. This information may not apply to all makes and models. If
vehicle is equipped with Anti-Lock Brake System (ABS), refer to
appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES section for
description, operation, depressurizing, testing, system bleeding,
trouble shooting and servicing of specific system.
WARNING: Failure to depressurize ABS could lead to physical injury.
ANTI-LOCK BRAKE SAFETY PRECAUTIONS
WARNING: Failure to depressurize ABS could lead to physical injury.
* NEVER open a bleeder valve or loosen a hydraulic line
while ABS is pressurized.
* NEVER disconnect or reconnect any electrical connectors
while ignition is on. Damage to ABS control unit may result.
* DO NOT attempt to bleed hyudarulic system without first
referring to the appropriate ANTI-LOCK BRAKE SYSTEM article
in the BRAKES section.
* Only use specially designed brake hoses/lines on ABS equipped
vehicles.
* DO NOT tap on speed sensor components (sensor, sensor rings).
Sensor rings must be pressed into hubs, NOT hammered into
hubs. Striking these components can cause demagnetization or
a loss of polarization, affecting the accuracy of the speed
signal returning to the ABS control unit.
* DO NOT mix tire sizes. Increasing the width, as long as tires
remain close to the original diameter, is acceptable. Rolling
diameter must be identical for all 4 tires. Some
manufacturers recommend tires of the same brand, style and
type. Failure to follow this precaution may cause inaccurate
wheel speed readings.
* DO NOT contaminate speed sensor components with grease. Only
use recommended coating, when system calls for an
anti-corrosion coating.
* When speed sensor components have been removed, ALWAYS check
sensor-to-ring air gaps when applicable. These specifications
can be found in each appropriate article.
* ONLY use rocommended brake fluids. DO NOT use silicone brake
fluids in an ABS equipped vehicle.
* When instlling transmittion devices (CB's, telephones, etc.)
on ABS equipped vehicles, DO NOT locate the antenna near the
ABS control unit (or any control unit).
* Disconnect all on-board computers, when using electric
welding equipment.
* DO NOT expose the ABS control unit to prolonged periods of
high heat (185
F/85 C for 2 hours is generally considered a
maximum limit).
Page 128 of 1501
ANTI-LOCK BRAKE SYSTEM
1998 Mitsubishi Montero
1997-98 BRAKES
Mitsubishi - Anti-Lock
Montero
DESCRIPTION
CAUTION: See ANTI-LOCK BRAKE SAFETY PRECAUTIONS article in GENERAL
INFORMATION.
NOTE: For more information on brake system, see BRAKE SYSTEM
article.
The Anti-Lock Brake System (ABS) is designed to prevent wheel\
lock-up during heavy braking. This allows operator to maintain
steering control while stopping vehicle in shortest distance possible.
Major components are a hydraulic unit, wheel speed sensors, "G"
sensor, ABS Electronic Control Unit (ECU) and ANTI-LOCK warning light.\
ABS has a self-diagnostic system to indicate a system malfunction and
for use in system trouble shooting.
OPERATION
Each wheel sensor sends an AC electrical signal to the ECU.
The ECU reads this information as wheel speed. When any decelerating
wheel speed rate is determined to be excessive in comparison to other
monitored wheels, the hydraulic unit cycles hydraulic brake pressure
to each wheel to equalize speed of all wheels. ABS turns itself off
when vehicle drops to 4 MPH. Minor lock-up may occur at this point.
With engine running and vehicle speed greater than 4 MPH,
pump motor will operate for a short period of time and may be heard
inside vehicle. During pump motor operation, ABS system is completing
a self-check. During ABS system operation, a pulsing brake pedal and
vibration in steering wheel and vehicle body may be experienced. These
conditions are normal.
BLEEDING BRAKE SYSTEM
BLEEDING PROCEDURES
CAUTION: When adding brake fluid, ensure filter is properly fitted on
reservoir tank.
ABS system is bled using conventional method. With engine
running, manually bleed system using an assistant. For bleeding order,
see BRAKE LINE BLEEDING SEQUENCE table. Ensure Load Sensing
Proportioning Valve (LSPV) is bled in sequence. Remove all air from
brake system. Refill brake fluid reservoir after bleeding procedure is
complete.
BRAKE LINE BLEEDING SEQUENCE
\
\
\
\
\
\
\
Application Sequence
Montero ....................................... RR, LR, LSPV, RF, LF
\
\
\
\
\
\
\
Page 129 of 1501
ADJUSTMENTS
* PLEASE READ FIRST *
NOTE: For adjustment information on brake pedal height, free play,
parking brake and stoplight switch, see BRAKE SYSTEM article.
WHEEL SPEED SENSOR (WSS)
NOTE: Rear WSS gap adjustment information is not available from
manufacturer.
Front WSS-To-Rotor Gap Adjustment
1) Raise and support vehicle. Remove wheel(s). Inspect senso\
r
pole piece for damage. Repair if necessary. If sensor pole piece is
okay, check WSS-to-rotor gap.
2) Using a feeler gauge, check clearance between sensor pole
and rotor tooth surface. See Fig. 1. Front WSS sensor clearance should
be .008-.390" (0.2-1.0 mm). If clearance is not as specified, loosen
sensor mounting bolt. Adjust sensor position until clearance is within
specification. Tighten sensor mounting bolt to specification. See
TORQUE SPECIFICATIONS .
Fig. 1: Checking Front WSS-To-Rotor Gap
Courtesy of Mitsubishi Motor Sales of America.
TROUBLE SHOOTING
ANTI-LOCK WARNING LIGHT
1) Turn ignition on. ANTI-LOCK warning light should come on
Page 130 of 1501
for one second, and then go out. Turn ignition switch to START
position. Warning light should come on and stay on.
2) When ignition switch is turned from START to ON position,
warning light should come on for one second, and then go out. If
warning light functions as specified, go to step 3). If warning light
does not function as specified, see appropriate trouble shooting test:
* IGNITION SWITCH IN ON POSITION (ENGINE NOT RUNNING),
ANTI-LOCK WARNING LIGHT INOPERATIVE
* AFTER ENGINE STARTS, ANTI-LOCK WARNING LIGHT REMAINS ON
* IGNITION SWITCH IN START POSITION, ANTI-LOCK WARNING LIGHT
INOPERATIVE
* IGNITION SWITCH IN ON POSITION, ANTI-LOCK WARNING LIGHT
BLINKS TWICE. IN START POSITION, LIGHT STAYS ON. WHEN
IGNITION SWITCH IS CYCLED FROM START TO ON POSITION, LIGHT
BLINKS ONCE, THEN TURNS OFF
3) Test drive vehicle. If ANTI-LOCK warning light does not
come on at low speed, go to next step. If light comes on at low speed,
motor relay, solenoid valve or Wheel Speed Sensor (WSS) malfunction is\
indicated. Go to step 6). If insufficient braking force or ABS
malfunction exists, go to next step. If none of listed symptoms exist,
go to step 6).
4) Check conventional brake system components for proper
operation. Check for mechanical lock of hydraulic unit solenoid valve.
Check for plugged hydraulic line in hydraulic unit. Repair or replace
as necessary. If hydraulic unit is okay, go to next step.
5) Ensure WSS rotor gap is correct. See WHEEL SPEED SENSOR
(WSS) under ADJUSTMENTS. Check for faulty wheel speed sensor. See
WHEEL SPEED SENSOR (WSS) under COMPONENT TESTS. Replace sensor as
necessary. See WHEEL SPEED SENSOR (WSS) under REMOVAL & INSTALLATION.
Inspect ECU connectors and related wiring harness. See WIRING DIAGRAMS
. If testing indicates no mechanical or electrical failures,
substitute ECU with known-good unit and retest.
6) Enter ABS self-diagnostics and retrieve Diagnostic Trouble
Codes (DTCs). See RETRIEVING DTCs under SELF-DIAGNOSTIC SYSTEM. If no
DTCs are displayed, fault may be intermittent. Attempt to make
malfunction reoccur. If no diagnostic output exists, check and repair
wiring harness between ECU and data link connector. See
WIRING DIAGRAMS .
NOTE: Trouble shoot ANTI-LOCK warning light in following sequence:
instrument cluster circuit, ECU and valve relay.
Ignition Switch In ON position (Engine Not Running),
ANTI-LOCK Warning Light Inoperative
1) If all other warning lights come on with ignition on, go
to step 3). If other warning lights do not come on, check fuse No. 11
in main fuse panel. If fuse is blown, correct cause of blown fuse, and
replace fuse. If fuse is okay, go to next step.
2) Remove instrument cluster. Turn ignition on. Using DVOM,
check voltage between vehicle ground and instrument cluster ANTI-LOCK
warning light terminal No. 28. See Fig. 2. If light does not come on,
go to next step. If light comes on, check and repair connectors and
related wiring harness between instrument cluster, ABS valve relay and
ECU. See WIRING DIAGRAMS .
3) Turn ignition off. Check for faulty warning light bulb.
Replace bulb as necessary. If bulb is okay, check and repair
connectors and related wiring harness between instrument cluster and
ECU. See WIRING DIAGRAMS . If connectors and wiring are okay, replace
instrument cluster.
