MITSUBISHI OUTLANDER 2020 Owner's Manual (in English)

Multi Around Monitor (if so equipped) 5-150 Features and controls
5
N00587400086
Two different types of views are displayed on the left side and the ri
ght side respectively.
Views of the surroundings of the vehicle and behind the vehicle are displayed.
Views of the passenger’s side of the vehicle and behind the vehicle are displayed. Views of the surroundings of the vehicle and the front of the vehicle are displayed.
Views of the passenger’s side of the vehicle and the front of the vehicle are displayed.
Types of views of the Multi Around Monitor

Bird’s eye-view/Rear-view mode

Side-view/Rear-view mode

Bird’s eye-view/Front-view mode

Side-view/Front-view mode

CAUTION The camera uses a special lens. As a result, images and distances shown on the screen are not exact.NOTE
 Because the cameras have a special lens, the lines on the ground between parking spaces may not look parallel on the screen.  Under certain circumst
ances, it may become
difficult to see an image on the screen, even when the system is functioning correctly. • In a dark area, such as at night.
BK0278200US.book 150 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Around Monitor (if so equipped)
Features and controls 5-151
5
N00587500090
The Multi Around Monitor can only be used when the operation mode is put in ON. When you move the selector lever to the “R” (REVERSE) position, the bird’s eye- view/rear-view is disp
layed on the screen of
the DISPLAY AUDIO or the SDA. When you move the selector
lever to any other posi-
tion, the display disappears.
When the camera switch (A) is pressed, the bird’s eye-view/front-view is displayed.
If the camera switch is pressed, the mode of Multi Around Monitor is switched, Bird’s eye-view/Rear-view mode
 Side-
view/Rear-view mode If the camera switch is pressed, the mode of Multi Around Monitor is switched, Bird’s eye-view/Front-view mode
 Side-
view/Front-view mode
 OFF
• When water drops or
condensation are on
the lens. • When sun light or he
adlights shine directly
into the lens. • When a fluorescent li
ght shines directly
into the lens.
 If the atmospheric temperature is extremely hot or extremely cold, the camera images may not be clear.There is no abnormality.  If a wireless device is installed near the cam- era, the camera images may cause electrical system interference and the system may stop functioning properly.
How to use the Multi Around Monitor

Operation with the selector lever

NOTE
NOTE
 The passenger’s side sc
reen can be switched
to the side-view by pressing the cameraswitch.
Operation with the switch

NOTE
 If there is no operation for 3 minutes after the Multi Around Monitor is displayed by pressing the switch with
the selector lever in
other than “R” (REVERSE), the display dis-appears.
Switching of the screen (Selector lever is “R” (REVERSE))

Switching of the screen (Selector lever is other than “R” (REVERSE))

NOTE
 When you move the sele
ctor lever to the “R”
(REVERSE) position with the front-view mode displayed on the driver’s side screen, the driver’s side screen switches to the rear-view mode. When you shif
t the selector lever
to any other position, th
e driver’s side screen
switches to the front-view mode.  When the camera switch is pressed at the vehicle speed of approximately 6 mph (10km/h) or higher, only
the side-view can be
displayed on the passenger’s side screen.
BK0278200US.book 151 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Around Monitor (if so equipped) 5-152 Features and controls
5
N00587600075
In any mode other than the Bird’s eye-view mode, the lines in the screen give the follow- ing information. Use them only as a guide. Reference lines for the distance and the vehi- cle width and upper surface of the front bum-per (A) are displayed on the screen.  The Red line (B) indicates approximately 20 inches (50 cm) from the front edge of the front bumper.
 The Two Green lines (C) indicate the approximate vehicle width. The Orange lines (D) indicates an expected course when the vehicle moves forward with the stee
ring wheel turned. It
disappears when the steering wheel is in the neutral position.  The approximate distance from the vehi- cle body is as follows:
N00587700050
Reference lines for the distance and the vehi-cle width and upper surface of the rear bum-per (A) are displayed on the screen.  The Red line (B) indicates approximately 20 inches (50 cm) behind the rear edge of the rear bumper. The Two Green lines (C) indicate the approximately vehicle width.  The Orange line (D) indicates an expected course when the vehicle is reserved with the steering wheel turned. It disappears when the steering wheel is in the neutralposition.  The approximate distance from the vehi- cle body is as follows:
 The front-view will not
be displayed when
the vehicle speed exceeds approximately 6mph (10 km/h).  The display of the view
may be delayed dur-
ing switching of the screen.
How to read the screen

CAUTION If the camera and/or its surrounding area have experienced an impact, the MultiAround Monitor system may not function correctly. Have the
vehicle inspected by an
authorized Mitsubishi Motors dealer.
Front-view mode

NOTE
1- Approximately 39 inches (100 cm) from
the front edge of the front bumperNOTE
 When the expected course lines are dis- played in the front-view, the expected course lines are also displayed in the bird’s eye- view (Front: solid line
, Rear: broken line).
Rear-view mode

NOTE
BK0278200US.book 152 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Around Monitor (if so equipped)
Features and controls 5-153
5
1- Approximately 39 inches (100 cm)
from the rear edge of the rear bumper
2- Approximately 79 inches (200 cm)
from the rear edge of the rear bumperCAUTION The rear-view camera uses a wide-angle lens. As a result, imag
es and distances shown
on the screen are not exact. Never rely solely on th
e reference lines. The
reference lines indicati
ng distance and vehi-
cle width are based on a
level, flat road sur-
face. Actual distance may be different from dis- tance indicated by the
lines on the screen,
depending on the loadi
ng condition of the
vehicle and road surface condition. Also, your vehicle wi
dth indicated by the
reference lines may be different from the actual vehicle width.For example;
In the following cases, objects shown on the screen will appear to be farther off than theyactually are.• When the rear of the vehicle is weigheddown with the weight of passengers andluggage in the vehicle. A: Actual objects B: Objects show
n on the screen
• When there is an upw
ard slope behind the
vehicle. A: Actual objects B: Objects show
n on the screen
CAUTION
• When there is a downward slope behind the vehicle, objects shown on the screen willappear to be closer than they actually are. A: Actual objects B: Objects shown on the screenCAUTION
BK0278200US.book 153 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Around Monitor (if so equipped) 5-154 Features and controls
5
• When the vehicle is
approaching a truck,
the reference lines indi
cate that your vehi-
cle will clear the truck. In reality, the truckis in your path.CAUTION
• When there is an obj
ect behind the vehicle
that has upper sections projecting in thedirection of the vehicl
e, the reference lines
on the screen will indicate that point A is the farthest point and
point B is the closest
point to the vehicle.
In reality, point A and
B are actually the same distance from the vehicle, and point C is
farther off than point
A and B.CAUTION
NOTE
 When the expected course lines are dis- played in the rear-view, the expected courselines are also displayed in the bird’s eye-view (Front: broken li
ne, Rear: solid line).
BK0278200US.book 154 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Around Monitor (if so equipped)
Features and controls 5-155
5
N00587900023
Reference lines for the
vehicle width and the
front end of the vehicle are displayed on the screen.
N00588000021
An overhead view in which the vehicle is looked down is displaye
d so that you can eas-
ily identify the location of your vehicle andthe course to enter the parking space.
Side-view mode

1- Approximate vehi
cle width including
the door mirror.
2- Approximate location of the axle center
of the front wheel.
3- Approximate 20 inches (50 cm) from the
front edge of the front bumper.
Bird’s eye-view mode

CAUTION The bird’s eye-view is a composite image from images captured by the “Front-viewcamera”, “Side-view cameras (right andleft)” and “Rear-view camera”. As a result, objects may appear to
be farther away than
they actually are. Also, an object may appearto be in a direction a
nd/or location different
from actual. In addition, blind spots exist in proximity of the vehicle.Even if the screen indicates that there is a space between your ve
hicle and an object,
there may actually be less or no space.Always check visually
behind and all around
your vehicle. The view at a section near each corner on the Bird's eye-view is combined from the edge of the view captured by each camera. Asresult, an object indica
ted in the section may
be unclear, and it may
disappear/reappear on
the screen.NOTE
 In the Bird’s eye-view mode, since the views captured by the four cameras, “Front-viewcamera”, “Side-view cameras (right and left)” and “Rear-view camera” are processed based on a level flat road surface, an imagemay be displayed as follows: • An object appears to
have fallen down and
looks longer or larger.
BK0278200US.book 155 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Instrument cluster 5-156 Features and controls
5
N00519001473
N00519101272
The speedometer shows the vehicle speed in miles per hour (mph) or kilometers per hour (km/h).
N00519201303
The tachometer shows e
ngine revolutions per
minute. This allows the driver to determine the most efficient selector position and engine speed combinations.This gauge also assists in evaluating engine performance.
• An object having a height from the road surface may seem to appear from the jointof the view composition processingregions.
 The brightness of the views from each cam- era may vary depending on the illuminance conditions.  An object above the came
ra is not displayed.
 The object displayed in the Front-view mode or the Rear-view mode may not be displayed in the Bird’s eye-view mode.  The view in the Bird’s eye-view mode may be displaced from its true position when the mounting location and a
ngle of each camera
are changed.  The lines on the road may appear to be dis- placed or bent at th
e joint of the views.
Instrument cluster 1- Tachometer
 P.5-156
NOTE
2- Multi Information display
 P.5-157
Information screen display list  P.5-177
3- Speedometer
P.5-156
4- Rheostat illu
mination button
 P.5-157
Speedometer Type A
Tachometer Type B
BK0278200US.book 156 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Information display
Features and controls 5-157
5
N00554901323
Each time you press this button, there is a sound and the brightness
of the instruments
changes.
N00555001477
The multi information display displays warn- ings, the odometer, trip odometer, service reminder, engine cool
ant temperature, fuel
remaining, outside temper
ature, selector lever
position, average and momentary fuel con- sumption, driving range
, average speed, etc.
It is also possible to change elements such as the language and units used on the multiinformation display. [With ignition switch
or operation mode in
OFF]
CAUTION The red zone indicates an engine speed beyond the range of safe operation. Select the correct select
or position to control
the engine speed so that
the tachometer indi-
cator does not enter the red zone.
Meter illumination control 1- Brightness level 2- Rheostat illumination button
NOTE
 You can adjust to 8 different levels for when the front side-marker
lights are illuminated
and when they are not.  If the vehicle is equippe
d with the automatic
light control, the light
switch is in a position
other than the “OFF” pos
ition and it is suffi-
ciently dark outside th
e vehicle, the meter
illumination switches automatically to theadjusted brightness.  The brightness level
of the instruments is
stored when the ignition switch is turned to the “OFF” or “LOCK”
position or the opera-
tion mode is put in OFF.  If you press and hold the button for longer than approximately 2 second when the frontside-marker lights ar
e illuminated, the
brightness level changes to the maximum level. Pressing and holding the button forlonger than approximately 2 second again returns the brightness
level to the previous
level.
Multi Information display
1-
Warning display screen
 P.5-163
2- Information screen
 P.5-159
Interrupt display screen
 P.5-162
3- Door ajar warning display screen
 P.5-163
4- Odometer
 P.5-164
5-
“ ” or “ ” mark indicator
 P.5-162
BK0278200US.book 157 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Information display 5-158 Features and controls
5
[With ignition switch or operation mode in ON]
N00555101205
Each time the multi information display switch is operated, th
e buzzer sounds and the
multi information display changes between
1- Drive mode display screen (if so
equipped)
 P.5-84
2- S-AWC drive mode display screen (if
so equipped)
 P.5-87
3-
Warning display screen
 P.5-163
4- Lane Departure Warning (LDW) sys-
tem display screen (if so equipped)  P.5-137
5- ECO mode indicator display screen
 P.5-209
6- Information screen
 P.5-159
7- Selector lever position display
 P.5-72, 5-79
8- Engine coolant te
mperature display
 P.5-163
9- Odometer
 P.5-164
10- Cruise control display screen (if so
equipped)
 P.5-103
11- Adaptive Cruise Control System (ACC)
display screen (if so equipped)  P.5-107
12- ECO indicator
 P.5-168
13-
“ ” or “ ” mark indicator
 P.5-162
14- Fuel remaining display screen
 P.5-164
15- Outside temperature display screen
 P.5-164
NOTE
The fuel units, outside temperature units, display language, and ot
her settings can be
changed. Refer to “Changing th
e function settings” on
page 5-169.
Multi information display switch
BK0278200US.book 158 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Multi Information display
Features and controls 5-159
5
information such as wa
rnings, trip odometer,
average and momentary fuel consumption,distance range, etc. It is also possible to change elements such as the language and units used on the multiinformation display by operating the multi information display switch.
N00555301177
Each time you lightly press the multi in
formation display switch, th
e display screen switches
in the following order.
Information screen (With the igniti
on switch in “OFF” or “LOCK” po
sition or the operation mode in
OFF) *: When there is a warning display
BK0278200US.book 159 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
