MITSUBISHI OUTLANDER 2020 Owner's Manual (in English)

Indicator light, warning light, and information screen display list 5-180 Features and controls
5
 You have forgotten to remove the F. A. S. T. -key from the key slot.
 Remove the F. A. S. T. -key from the key slot.
 The steering wheel is locked.
Press the engine switch while turning steering wheel. Refer to “Steering wheel lock” on page 5-25.
 The engine switch is presse
d to stop the engine while
the selector lever is in a
position other than the “P”
(PARK) position.
 Place the selector lever in the “P” (PARK) position to put the operation mode in OFF.
 The driver’s door is opened with the steering wheel unlocked.
 Refer to “Steering wheel lock” on page 5-25.
 There is a fault in the EPS.
Have the vehicle inspected by an authorized Mit- subishi Motors dealer or
a repair facility of your
choice as soon as possible. Refer to “Electric power steering system (EPS)” on page 5-99.
 There is a fault in the Anti-lock braking system.
Avoid sudden braking and high-speed driving, park the vehicle in a safe place, and take corrective mea- sures. Refer to “Anti-lock
braking system warning”
on page 5-98.
Screen
Cause
Do this (Reference)
BK0278200US.book 180 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list
Features and controls 5-181
5
 The tire pressure in one of the tires (except spare tire) is low.
Refer to “Tire Pressure
Monitoring System” on page
5-141.
 There is a fault in the Tire Pressure Monitoring Sys- tem.
Refer to “Tire Pressure
Monitoring System” on page
5-141.
 One of the doors or the liftgate is not completely closed.The open door is displayed.
 Close the door or liftgate. Refer to “Door ajar warni
ng display screen” on page
5-163.
 The engine hood is open.
Close the engine hood. Refer to “Engine hood” on page 9-3.
 There is a fault in the electronic immobilizer (Anti- theft starting system).
 Put the operation mode in OFF, and then start the engine again. If the warning is not cancel
led, please contact an
authorized Mitsubishi Motors
dealer or a repair facil-
ity of your choice.
Screen
Cause
Do this (Reference)
BK0278200US.book 181 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list 5-182 Features and controls
5
 The driver's door is open when the operation mode is in any mode other than OFF.
 Put the operation mode in OFF. Refer to “Operation mode
ON reminder system” on
page 5-38.
 An attempt was made to lock all the doors and the liftgate when the operati
on mode is in any mode
other than OFF.
 Put the operation mode in OFF. Refer to “Operation mode
OFF reminder system” on
page 5-22.
 There is a fault in the steering wheel lock.
Park your vehicle in a safe place as soon as possible and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.
 There is a fault in the electrical system.
Park your vehicle in a safe place as soon as possible and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.
 The engine is overheated.
Park the vehicle in a safe place and take corrective measures. Refer to “Engine overheating” on page 8-4.
 The automatic transaxle or CVT fluid temperature is increased.
 Park the vehicle in a safe place and take corrective measures. Refer to “Automatic tr
ansaxle” on page 5-70.
Refer to “Continuously
variable transmission
(CVT)” on page 5-76.
Screen
Cause
Do this (Reference)
BK0278200US.book 182 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list
Features and controls 5-183
5
 The seat belt is not fastened when the ignition switch or operation mode is in ON.
 Wear your seat belt properly. Refer to “Driver’s seat be
lts reminder/warning light
and display” on page 4-23.
 There is a fault in the fuel system.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.
 The vehicle is being driven with the parking brake still applied.
 Release the parking brake.
Refer to “Brake warning
display” on page 5-198.
 The brake fluid level is low.  There is a fault in the brake system.
 Park the vehicle in a sa
fe place and inspect it.
 If the light still illuminates after the inspection, con- tact an authorized Mitsubishi Motors dealer or a repair facility of your
choice for assistance.
Refer to “Brake warning display” on page 5-198.
 There is a fault in the Electric parking brake.
Immediately have your ve
hicle inspected at an
authorized Mitsubishi Motors dealer. Refer to “Electric parki
ng brake” on page 5-57.
 The parking brake cannot be applied temporarily due to repeated operation of the Electric parking brake switch within a short time.
Refer to “Electric parki
ng brake” on page 5-57.
Screen
Cause
Do this (Reference)
BK0278200US.book 183 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list 5-184 Features and controls
5
 You try to release the Electric parking brake switch without depressing the brake pedal.
Refer to “Electric parkin
g brake” on page 5-57.
 The Electric parking brake has been automatically applied.
Refer to “Brake auto hold” on page 5-93.
 The brake auto hold is automatically canceled
. Refer to “Brake auto hold” on page 5-93.
 The brake auto hold is not available. Re
fer to “Brake auto hold” on page 5-93.
 The Electric parking brake is not automatically applied because there is a fa
ult in the Electric park-
ing brake system.
 When the ignition switch is
turned off or the opera-
tion mode is put in OFF, place the selector lever in the “P” (PARK) position and depress the brake pedal more firmly than usual with the right foot. Then, operate the ignition
switch or the engine
switch.  We recommend you to have the brake auto hold sys- tem inspected by a MITSUBISHI MOTORS Autho- rized Service Point. Refer to “Brake auto hold” on page 5-93.
Screen
Cause
Do this (Reference)
BK0278200US.book 184 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list
Features and controls 5-185
5
 The brake auto hold system does not turn on because the driver’s seat be
lt is not fastened.
 Press the brake auto hold switch after fastening the driver’s seat belt.Refer to “Brake auto hold” on page 5-93.
 The brake auto hold system does not turn off because the brake pedal
is not pressed.
 Depress the brake pedal more firmly than usual with the right foot. Then, press the brake auto hold switch. Refer to “Brake auto hold” on page 5-93.
 There is a fault in the engi
ne oil circul
ation system.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked. Refer to “Oil pressure
warning display” on page
5-199.
 There is a fault in the charging system.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice for assistance.
Refer to “Charging system
warning display” on page
5-199.
 There is a fault in the SRS airbag or the pre-tensioner system.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked, immediately.Refer to “SRS warning li
ght/display” on page 4-41.
Screen
Cause
Do this (Reference)
BK0278200US.book 185 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list 5-186 Features and controls
5
 There is a fault in the Active stability control (ASC).
Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “Active stability control (ASC)” on page 5-100.
 There is a fault in the Hill start assist.
Have the vehicle checked at
an authorized Mitsubi-
shi Motors dealer or a repa
ir facility of your choice.
Refer to “Hill start assist” on page 5-96.
 There is a fault in the electronically controlled 4WD system.
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “Electronically c
ontrolled 4WD system” on
page 5-83.
 There is a fault in the S-AWC system.
Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked.Refer to “S-AWC (Super-All Wheel Control)” on page 5-85.
 There is a fault in the automatic transaxle or CVT.
Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “Automatic tr
ansaxle” on page 5-70.
Refer to “Continuously
variable transmission
(CVT)” on page 5-76.
Screen
Cause
Do this (Reference)
BK0278200US.book 186 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list
Features and controls 5-187
5
 The electronically controll
ed 4WD system is hot. Refer to “Elect
ronically controlled 4WD system” on
page 5-83.
 The S-AWC system is hot. Refer to “S-AWC (Super-All Wheel Control)” on page
5-85.
 The fuel is running low.
Refuel as soon as possible. Refer to “Fuel remaining
display screen” on page
5-164.
 The outside temperature is 37 °F (3 °C) or less.
Be careful driving on frozen ground.  The ground may be frozen even when this warning is not displayed, so
drive carefully.
 The Adaptive Cruise Control System (ACC) has detected the approach of
the vehicles in front.
 Increase the following distance by depressing the brake pedal or marking ot
her decelerating control.
Refer to “Adaptive Cruise Control System (ACC): Approach alarm” on page 5-112.
 The Forward Collision Mi
tigation System (FCM)
has detected the danger of collision.
 Take appropriate action such as depressing the brake to avoid collision.Refer to “Forward collis
ion warning function” on
page 5-120.
 The Adaptive Cruise Control System (ACC) detected a stop of the ve
hicle in front and stopped
your vehicle, but the brak
e will be re
leased soon.
 Depress the brake pedal
as soon as your vehicle
comes to a stop. Refer to “When ACC dete
cts a vehicle in front
within the set dist
ance” on page 5-111.
 The Electric parking brak
e cannot be applied auto-
matically.
 Depress the brake pedal as soon as possible. Refer to “Brake auto hold” on page 5-93.
Screen
Cause
Do this (Reference)
BK0278200US.book 187 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list 5-188 Features and controls
5
 The Adaptive Cruise Control System (ACC) control is automatically canceled and the system is placed in the ‘standby’ state.
Refer to “How to use ACC” on page 5-109.
 Conditions for the start of control are not met, the Adaptive Cruise Control
System (ACC) cannot start
the control.  The Adaptive Cruise Control System (ACC) cannot start the control because th
e speed is out of speed
range.  The Adaptive Cruise Control System (ACC) cannot start the control because not
detected the approach of
the vehicles in front.  The Adaptive Cruise Control System (ACC) is tem- porarily unavailable due to conditions such as the adhesion of contaminants to the sensor. This is not a malfunction.  There is a fault in the Adaptive Cruise Control Sys- tem (ACC).
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “When ACC dete
cts a vehicle in front
within the set distance” on page 5-111.
Screen
Cause
Do this (Reference)
BK0278200US.book 188 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Indicator light, warning light, and information screen display list
Features and controls 5-189
5
 There is a fault in the Forward Collision Mitigation System (FCM).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “System
problem warning:
FCM deactiva-
tion due to fault” on page 5-125.
 FCM braking function of the Forward Collision Mit- igation System (FCM) has been activated.
Refer to “FCM braking
function” on page 5-120.
 The Forward Collision Mitig
ation System (FCM) is
temporarily unavailable for some reason. This is not a malfunction.  The Lane Departure Warning system (LDW) has detected that your vehicle is
about to leave or has left
the lane.
Refer to “Lane Departure
Warning system (LDW)” on
page 5-137.
 There is a fault in the La
ne Departure Warning sys-
tem (LDW).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “Lane Departure
Warning system (LDW)”
on page 5-137.
Screen
Cause
Do this (Reference)
BK0278200US.book 189 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
