Page 141 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Tire pressure monitoring system
Features and controls 5-79
5
Type 1 Type 2Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure reco

Page 142 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Tire pressure monitoring system 5-80 Features and controls
5
TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle

Page 143 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Rear-view camera (if so equipped)
Features and controls 5-81
5
 Wheels other than Mitsubishi genuine wheels are being used.  Wheels that are not fitted with tire infla- tion pressure sensors ar

Page 144 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Rear-view camera (if so equipped) 5-82 Features and controls
5
The rear-view camera (A) is in the liftgate, at the left side of the liftgate handle.
Reference lines and upper surface of the rear bump

Page 145 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Instrument cluster
Features and controls 5-83
5
N00519000388
• When there is an upward slope at the back. (Case 2)CAUTION
Case 1 A- Actual objects B- Objects shown on the screenCase 2 A- Actual obj

Page 146 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Instrument cluster 5-84 Features and controls
5
N00519100259
The speedometer shows the vehicle speed in miles per hour (mph) or kilometers per hour (km/h).
N00519200289
The tachometer shows engine rev

Page 147 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Multi-information display
Features and controls 5-85
5
N00555000265
The multi-information display displays warnings, the odometer, tr
ip odometer, service reminder, engine coolant temperature, fue
l

Page 148 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Multi-information display 5-86 Features and controls
5
With ignition switch or operation  mode is in OFF
With ignition switch or operation mode is in  ON (CVT)
With ignition switch or
operation mo

Page 149 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Multi-information display
Features and controls 5-87
5
N00555100149
The multi-information meter switch is a but- ton marked “INFO” on the left side of thedash. Each time the multi-information met

Page 150 of 398

MITSUBISHI OUTLANDER SPORT 2016 3.G Owners Manual Multi-information display 5-88 Features and controls
5
N00555400113
Each time you lightly press the multi-infor- mation meter switch, the display screenswitches. Odometer/trip odometer
 Odome-
