NISSAN 350Z 2005 Z33 Navigation Manual

10. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.When the stored “avoid area” is selected, it can
be renamed or deleted.
RENAMING THE AVOID AREAS1. Press the SETTING button.
2. Select the
Navigation key.
INV2450
INV1466
SETTINGWITH THE SELECTED
LOCATION KEY
How do I use the avoid area feature?
8-5


04.7.6/Z33-N


3. The display shows the [NAVIGATION SET-
TINGS] screen.
Select the
Avoid Area Setting key.4. The display shows the [AVOID AREA SET-
TING] screen.
Select a key which is set as an “avoid area”.5. Select the
Rename key.
INV2448
INV2451
INV2452
8-6
How do I use the avoid area feature?


04.7.6/Z33-N


6. The display shows the keyboard.
Enter the area name using the keyboard.
When the
Set key is selected, the “avoid area”
is renamed, and the screen returns to the previ-
ous screen.
INFO:
When theBack Space key is selected, the
cursor moves back to the previous letter. When
the
Space key is selected, the cursor proceeds
to make one space.
DELETING THE AVOID AREAS1. Select the
Delete key on the screen in step
5 under “Renaming the avoid areas”.2. Select the
Yes key.
The “avoid area” is deleted.
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.
INFO:
When the
No key is selected, the “avoid area”
will not be deleted, and the screen returns to the
previous screen.
INV2453
INV2454
INV2455
How do I use the avoid area feature?
8-7


04.7.6/Z33-N


3. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.
SETTING WITH THE
Map
KEY
When the stored “avoid area” is selected, it can
be adjusted or deleted.
Press the SETTING button.
Adjusting the stored avoid areas1. Select the
Navigation key.
INV2456
INV1466
8-8
How do I use the avoid area feature?


04.7.6/Z33-N


2. The display shows the [NAVIGATION SET-
TINGS] screen.
Select the
Avoid Area Setting key.3. The display shows the [AVOID AREA SET-
TING] screen.
Select the
Map key of stored “avoid areas”.4. Use the joystick to adjust the location.
INV2448
INV2457
INV1671
How do I use the avoid area feature?
8-9


04.7.6/Z33-N


5. Press the PUSH ENTER button.
The display shows the keys on the right of the
screen.
Select the
Set key.
INFO:

If you want to avoid the freeway in that area,
select the
key to turn on the green
indicator on the key. (Indicator ON: avoid,
OFF: do not avoid)

When altering the size of the avoid area,
select the
Area key. The area size is in-
creased or decreased by three scales.6. The “avoid area” is set, and the grid is
displayed on the screen.
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.7. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.
INV1672
INV1673
INV2456
8-10
How do I use the avoid area feature?


04.7.6/Z33-N


Deleting the stored avoid areas1. Select the
Delete key on the screen shown
in step 5 under “Adjusting the stored avoid
areas”.2. Select the
Yes key when asked if you are
sure you want to delete the “avoid area”.
The “avoid area” is deleted.
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.
INFO:
When the
No key is selected, the “avoid area”
will not be deleted, and the screen returns to the
previous one.3. Please refer to “Making the system guide the
route with detailed options” on page 5-32.
If the route guidance is not set, the display
shows the current vehicle location.
INV1675
INV1676
INV2456
How do I use the avoid area feature?
8-11


04.7.6/Z33-N


MEMO8-12
How do I use the avoid area feature?


04.7.6/Z33-N


9 How do I use the automatic rerouting
feature?Rerouting when the vehicle is off the suggested
route .......................................................................................... 9-2
Automatic rerouting ......................................................... 9-2
Detouring from the route temporarily .............................. 9-3


04.7.6/Z33-N


When you have strayed from the suggested
route during the route guidance, you can request
a reroute from the current location using the
automatic rerouting function.AUTOMATIC REROUTINGThis setting will reroute the vehicle automatically
when the driver deviates from the suggested
road. You will have to set the system for auto-
matic rerouting to enable this function.
1. Press the SETTING button.
2. Select the
Navigation key. 3. The display shows the [NAVIGATION SET-
TINGS] screen.
Select the
Auto Re-route On/Off key.
INV1466
INV2460
REROUTINGWHEN THE VEHICLE
IS OFF THE SUGGESTED ROUTE9-2
How do I use the automatic rerouting feature?


04.7.6/Z33-N
