NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual DUCTS AND GRILLES
ATC-121
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
Removal of Defroster Nozzle, Ducts and Ventilator Ducts
1. Remove instrument panel. Refer to IP-10, "INSTRUMENT P

Page 122 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual ATC-122
DUCTS AND GRILLES
Revision: 2006 November2007 350Z
Removal of Foot Ducts
1. Remove heater & cooling unit assembly. Refer to AT C - 11 2 ,  "HEATER & COOLING UNIT ASSEMBLY" .
2. Remove evaporat

Page 123 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual REFRIGERANT LINES
ATC-123
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
REFRIGERANT LINESPFP:92600
HFC-134a (R-134a) Service ProcedureNJS0001U
SETTING OF SERVICE TOOLS AND EQUIPMENT
Dis

Page 124 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual ATC-124
REFRIGERANT LINES
Revision: 2006 November2007 350Z
*1ATC-21, "LUBRICANT RETURN
OPERATION"
*2ATC-138, "Checking for Refrigerant
Leaks"
*3ATC-140, "CHECKING PROCE-
DURE"
*4ATC-83, "PERFORMANCE

Page 125 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual REFRIGERANT LINES
ATC-125
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
ComponentsNJS0001V
Refer to AT C - 7 ,  "Precautions for Refrigerant Connection" .
Removal and Installation of Co

Page 126 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual ATC-126
REFRIGERANT LINES
Revision: 2006 November2007 350Z
3. Remove engine cover (1), (2). Refer to EM-17, "INTAKE MANIFOLD COLLECTOR" .
4. Remove air cleaner case (LH) and air duct (LH). Refer to EM

Page 127 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual REFRIGERANT LINES
ATC-127
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
Removal and Installation of Low-pressure Flexible Hose and Pipe 2NJS0001Y
REMOVAL
1. Use a refrigerant collecting

Page 128 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual ATC-128
REFRIGERANT LINES
Revision: 2006 November2007 350Z
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of low-pressure flexible hose and low-pressure

Page 129 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual REFRIGERANT LINES
ATC-129
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of high-pressure f

Page 130 of 142

NISSAN 350Z 2007 Z33 Automatic Air Conditioner Workshop Manual ATC-130
REFRIGERANT LINES
Revision: 2006 November2007 350Z
Removal and Installation of High-pressure Pipe 1 (Engine Compartment)NJS00020
REMOVAL
1. Remove low-pressure flexible hose and pipe 2. Refer
Trending: oil capacity, clutch, ignition, engine oil capacity, air conditioning, radiator, drain bolt
