3. CHECK INTAKE SENSOR
Refer to ATC-101, "
Intake Sensor" .
OK or NG
OK >> 1. Replace unified meter and A/C amp.
2. Go to self-diagnosis AT C - 4 6 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2.
NG >> 1. Replace intake sensor.
2. Go to self-diagnosis AT C - 4 6 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2.
4. CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector
M255 terminal 2 and unified meter and A/C amp. harness con-
nector M50 terminal 41.
4. Check continuity between intake sensor harness connector
M255 terminal 2 and ground.
OK or NG
OK >> 1. Replace unified meter and A/C amp.
2. Go to self-diagnosis AT C - 4 6 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2.
NG >> Repair harness or connector.
COMPONENT INSPECTION
Intake Sensor
After disconnecting intake sensor connector M255, measure resis-
tance between terminals 1 and 2 at sensor side. Refer to the table
below.
If NG, replace intake sensor.2 – 41 : Continuity should exist.
2 – Ground : Continuity should not exist.
RJIA2033E
Temperature °C (°F) Resistance kΩ
−15 (5) 12.34
−10 (14) 9.62
−5 (23) 7.56
0 (32) 6.00
5 (41) 4.80
10 (50) 3.87
15 (59) 3.15
20 (68) 2.57
25 (77) 2.12
30 (86) 1.76
35 (95) 1.47
40 (104) 1.23
45 (113) 1.04
RJIA1462E
Page 102 of 142
ATC-102
A/C CONTROLLER
Revision: 2006 November2007 350Z
A/C CONTROLLERPFP:27500
Removal and InstallationNJS0001E
REMOVAL
1. Remove console finisher (A/T) or console boot (M/T). Refer to IP-10, "INSTRUMENT PANEL ASSEM-
BLY" .
2. Remove mounting screws (A) and clips (B), and then remove A/
C controller (1) from console finisher (A/T) or console boot (M/
T).
INSTALLATION
Installation is basically the reverse order of removal.
Disassembly and AssemblyNJS000CT
NOTE:
When disassembling controller, wind gummed tape around each dial assembly and pull out the dial assembly
together with switch from the A/C controller assembly.
SJIA1084J
1. A/C controller assembly 2. Mode control dial 3. Rear window defogger switch
4. Intake switch 5. A/C switch 6. Fan control dial
7. Temperature control dial
SJIA1903E
Page 103 of 142
AUTO AMP
ATC-103
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
AUTO AMPPFP:27760
Removal and Installation of Unified Meter and A/C Amp.NJS0001F
REMOVAL
1. Remove console finisher (A/T) or console boot (M/T). Refer to IP-10, "INSTRUMENT PANEL ASSEM-
BLY" .
2. Remove mounting screws, and then remove unified meter and
A/C amp.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA1409E
Page 104 of 142
ATC-104
AMBIENT SENSOR
Revision: 2006 November2007 350Z
AMBIENT SENSORPFP:27722
Removal and InstallationNJS0001G
REMOVAL
1. Disconnect ambient sensor connector.
2. Remove ambient sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA1398E
Page 105 of 142
IN-VEHICLE SENSOR
ATC-105
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
IN-VEHICLE SENSORPFP:27720
Removal and InstallationNJS0001H
REMOVAL
1. Remove instrument driver panel lower. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove mounting screw (A), and then remove in-vehicle sensor
(1).
INSTALLATION
Installation is basically the reverse order of removal.
PJIA0170E
Page 106 of 142
ATC-106
SUNLOAD SENSOR
Revision: 2006 November2007 350Z
SUNLOAD SENSORPFP:27721
Removal and InstallationNJS0001I
REMOVAL
1. Pull out sunload sensor from instrument panel.
2. Disconnect sunload sensor connector, and then remove sunload
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA1404E
Page 107 of 142
INTAKE SENSOR
ATC-107
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
INTAKE SENSORPFP:27723
Removal and InstallationNJS0001J
REMOVAL
1. Remove low-pressure pipe 1 and high-pressure pipe 2. Refer to ATC-131, "Removal and Installation of
Low-pressure Pipe 1 and High-pressure Pipe 2" .
CAUTION:
Cap or wrap the joint of evaporator, low-pressure pipe 1, 2 and high-pressure pipe 1, 2 with suit-
able material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of low-pressure pipe 1, 2 and high-pressure pipe 1, 2 with new ones, and then
apply compressor oil to it when installing it.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sen-
sor can be located in the same position.
Female-side piping connection is thin and easy to deform. Slowly insert the male-side piping
straight in axial direction.
Insert piping securely until a click is heard.
After piping connection is completed, pull male-side piping by hand to make sure that connection
does not come loose.
When recharging refrigerant, check for leaks.
RJIA1406E
Page 108 of 142
ATC-108
BLOWER UNIT
Revision: 2006 November2007 350Z
BLOWER UNITPFP:27200
Removal and InstallationNJS0001K
REMOVAL
1. Remove remote keyless entry receiver. Refer to BL-92, "Removal and Installation of Remote Keyless
Entry Receiver" .
2. Remove mounting nuts (A), and then remove ECM (1) with
bracket attached.
3. Disconnect intake door motor and blower motor connector (B).
4. Remove mounting screws (C) and bolt (D), and then remove
blower unit (2).
CAUTION:
Move blower unit rightward, and remove location pin (1
part) and joint. Then remove blower unit downward.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Make sure location pin (1 part) and joint are securely inserted.
PJIA0171E
RJIA1414E
Page 109 of 142
BLOWER UNIT
ATC-109
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: 2006 November2007 350Z
Disassembly and AssemblyNJS0001L
1. Intake upper case 2. Intake bell mouth 3. Intake lower case
4. Blower motor assembly 5. Intake door lever 2 6. Intake door motor
7. Intake door link 8. Intake door lever 3 9. Intake door 2
10. Intake door lever 1 11. Intake door 1
RJIA1415E
Page 110 of 142
ATC-110
BLOWER MOTOR
Revision: 2006 November2007 350Z
BLOWER MOTORPFP:27226
Removal and InstallationNJS0001M
REMOVAL
1. Remove instrument passenger panel lower. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect blower motor connector.
3. Remove mounting screws, and then remove blower motor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA0946E
