NISSAN ALTIMA HYBRID 2008 L32A / 4.G Quick Reference Guide

BLUETOOTHHANDS-FREE PHONE SYSTEM (Navigation System
only – if so equipped)
With anoverhead microphone andsound
transmitted through the audio system speaker,
the Bluetooth Hands-Free PhoneSystem
utilizes Bluetooth wireless technology,
touch-screen, andvoice recognition topro-
vide hands-free cellularphonecommunica-
tion.
SYSTEM OPERATING TIPS
 Close allwindows. Surrounding noises
may interfere withsystem operation and
performance.
 Press the
button on the steering wheel to activate voice recognition.
 Wait for the “Please say a command” prompt and the listening tone before speaking.
 Begin speaking a command within 1.5 seconds of the listening tone.
 To cancel a voice recognition session, press and hold the
button or press the
button.
 To increase ordecrease thevolume ofthe voice prompts, pushthe+or –(volume)
control buttons on the steering wheel or turn the VOL(volume) knob on the audio system
while the system is responding.
 Speak in a clear and natural voice without pausing between words.
 Some commands are not available while the vehicle is in motion.
 The “Help” command will bring up the voice recognition command list.
 For recommended phones and detailed instructions, please visit
www.nissanusa.com/bluetooth.
PAIRING YOUR PHONE
Before using the hands-free feature, you need to set-up, or pair, the system to recognize your
cellular phone(s) . Up to 5 Bluetooth -enabled phones can be paired to this system. After the
initial one-time set-up,thesystem automatically connectswithapaired phone whenthe
ignition switch is in the ACC or ON position, as long as the phone is in range and within the
vehicle cabin.
PAIRING PROCEDURE
NOTE: Thevehicle mustbestationary whenpairing
the phone.
INITIAL PAIRING
NOTE: Thisprocedure canonly beused topair the
first phone to the system.
1.Press the
button on the steering wheel.
2. A message is displayed. Press the
button again.
19

3.The system will direct you to SETUP –> Phone –> Bluetooth Setup –> Pair Phone
menu.
4. Touch one of the “None (Add New)” keys.
5. Initiate pairing from the phone.
 The pairing procedure forcellular phones variesaccording toeach cellular phone
model. Fordetailed pairinginstructions andcompatible phones,pleasevisit
www.nissanusa.com/bluetooth.
 The PINcode willappear onthe screen; enter“1234” from thehandset. (ThePIN
code is assigned by NISSAN and cannot be changed.)
6. When the pairing is complete, the screen will show the phone’s listed name on the
paired phone list screen.
PAIRING ADDITIONAL PHONES/INITIAL PAIRING
NOTE: This procedure can be used to pair the first phone and other additional phones to the
system.
1.Press the SETUPbutton on the control panel.
2. Touch the “Phone” key on the touch-screen.
3. Scroll to the bottom of the list and touch the “Bluetooth Setup” key.
4. Touch the “Pair Phone” key, then touch one of the “None (Add New)” keys.
5. Initiate pairing from the phone.
 The pairing procedure forcellular phones variesaccording toeach cellular phone
model. Fordetailed pairinginstructions andcompatible phones,pleasevisit
www.nissanusa.com/bluetooth.
 The PINcode willappear onthe screen, enter“1234” from thehandset. (ThePIN
code is assigned by NISSAN and cannot be changed.)
6. When the pairing is complete, the screen will show the phone’s listed name on the
paired phone list screen.
SETTING UP YOUR PHONEBOOK - ADDING NEW ENTRIES
Up to70 phone numbers canbestored inthe phone-
book.
NOTE: Thevehicle mustbestationary whenadding
new entries.
1.Press the SETUP button,thentouch the
“Phone” key.
2. Touch the “Phonebook” key.
3. Touch oneofthe “None (AddNew)” keys from
the name list of the phonebook. There are differ-
ent methods toinput aphone number. Select
one of the following options:
 Enter DatabyKeypad -Input thename and
phone number manually.
 Downloaded Phonebook - Select an entry from a
list of phone numbers you have already transferred from your phone to your vehicle.
20

Outgoing Calls-Store thename andphone number fromtheoutgoing calllist.
 Incoming Calls - Store the name and phone number from the incoming call list.
 Bluetooth -Transfers anentry fromyourcellular phonetothe Downloaded Phone-
book inthe vehicle. Thememory sending procedure fromthecellular phonevaries
according to each cellular phone model. See the cellular phone owner’s manual for
more details.
MAKING A PHONE CALL
1. Press thebutton on the steering wheel.
2. After the tone, do one of the following:
 Say “Phone Dial” then follow the voice prompts
to input the phone number. After the phone num-
ber has been said, say “Dial.”
 Say “Phonebook .” For example, say
“Phonebook Michelle.”
 Say “Phone Redial” to redial the previous phone number called by the system.
RECEIVING/ENDING A PHONE CALL
When youreceive aphone call,aring tone sounds
through the audio system (if enabled) .
 To accept thecall, press the
button onthe
steering wheel or touch the “Answer” key. To reject
the call, touch the “Reject Call” key.
 To hang upthe phone atthe end ofacall orto
disconnect duringcallplacement, pressthe
button.
HOW TO SAY NUMBERS
NISSAN Voice Recognition permits numbers to be spoken in a variety of ways.
 Say “zero” or “oh” for “0”. Example: 1-800-662-6200 – Say “One eight zero zero six six
two six two oh oh.”
 Say “Pound” for “#”. Say “star” for “*”. Example: 1-555-1212*123 – Say “One five five
five one two one two star one two three.”
NISSAN VOICE RECOGNITION SYSTEM (Navigation System only)
The NISSAN VoiceRecognition systemallowshands-
free operation of the systems equipped on this vehicle,
such as the phone and navigation systems.
To operate NISSAN VoiceRecognition, pressthe
button located onthe steering wheel.Thenspeak the
command for the system you wish to activate. The com-
mand givenispicked upbythe microphone, anditis
performed whenitis properly recognized. Atthis time, NISSAN VoiceRecognition will
provide a voice and message (in the center display) to inform you of the command results. To
cancel the voice recognition, press the
button or press and hold thebutton.
21

VOICE RECOGNITION COMMAND LIST
The following table lists some common voice recognition commands. For a complete list of
commands, say “Help.”
DestinationMap Settings
Destination Phone Number Birdview Map
Destination Address Book Planview Map
Destination Home North Up
Destination Nearby Places Heading Up
Destination < Voicetag > Zoom Level < 1-10 >
Destination Previous Destinations
Route Settings Phone
Recalculate Route Phone Dial
Cancel Route Phone Redial
Shortest Distance Route Phonebook
Phone Select
Phonebook < voicetag >
NAVIGATION SYSTEM (if so equipped)
GETTING STARTED
The Navigation System begins when the ignition switch is in the ACC or ON position. To help
ensure safe driving, some functions are grayed out, or muted, while driving. Park the vehicle
in a safe location and then operate the Navigation System.
BASIC FUNCTIONS
START-UP SCREEN
 Read the precautions carefully, and touch the
“I agree” key to accept.
22

NAVIGATION DISPLAY SCREEN
Displays navigation features and map.
DISABLED WHILE DRIVING
Not allfeatures canbemanually operated
while the vehicle is in motion. The text for these
restricted features turns from white to gray and
cannot beselected. Alternatively, thevoice
recognition systemmayhave arelated com-
mand that can be used at any time.
DAY/NIGHT BUTTON
 Press thebuttontoswitch be-
tween theday screen (bright) andthenight
screen (dark) . Within 10 seconds of pressing
the
button, you can adjust the
brightness of the map display screen by touch-
ing the
key or thekey.
USING THE TOUCH-SCREEN
 To maneuver aroundthenavigation display
screen, touch the screen to select the item or
key displayed. Tomove around themap
screen, touch and hold to scroll around.
SETUP BUTTON
 Press theSETUP buttontochange or
set navigation preferences.
DEST (DESTINATION) BUTTON
 Press theDEST buttontodisplay the
address bookandalternative waysofpro-
gramming a destination.
23

MAP BUTTON
Press theMAP buttontodisplay the
current location map screen.
INFO BUTTON
 Press theINFO buttontoview various
information including real-time traffic informa-
tion (requires asubscription toXM NavTraf-
fic™ service) and other navigation information.
ROUTE KEY
 Press the MAPbuttonto show the cur-
rent location mapscreen. Touchthe“Route”
key while inacurrent location mapscreen to
display theRoute menuscreen. TheRoute
menu screen displays variouswaystomodify
the route to a destination.
ZOOM OUT/IN KEYS
 Touch the“ZOOM OUT”keyorthe “ZOOM
IN” key to increase or decrease the scale of the
map display.
BACK KEY
 Touch the “Back” key to return to the previous
function shown on the navigation display.
24

VOICE KEY
Touch the “Voice” key to hear the current navi-
gation instructions.
SWITCHING THE MAP VIEW
 Press the MAPbutton. The current loca-
tion map screen is displayed.
 Touch the “Menu” key.
 Touch the “Map view” key.
 Touch eitherthe“2D” key orthe “3D” key, to
select themap view. Press the MAP
button
or the “Back” keytoaccept the
changes.
2D PLAN VIEW
 Displays themap ina2-dimensional environ-
ment similar to a road map.
3D BIRDVIEW™
 Displays the map in an elevated perspective.
25

SELECTING A MENU SCREEN
1.To select a preferred menu key, touch the corresponding key on the screen.
2. Depending on the key you selected, a detailed menu screen, a character input screen
or asetting screen, etc.isdisplayed. Onthe screen displayed, makeadjustments,
input information, etc. accordingly.
3. Touch the “Back” key to return to the previous screen without applying any changes;
in some cases pressing the “Back” key will accept the changes you made.
4. Press the MAP button
toreturn tothe current location mapscreen without
applying any changes.
NOTE: Depending on the menu selected, pressing the MAPbutton
may not return you
to the current location map screen.
STORING YOUR HOME IN YOUR ADDRESS BOOK
 Press the DESTbutton.
 Touch the “Home (Add New)” key. If you have
already storedyourhome, thiskeymay not
appear.
 When you touch the “Home (Add New)” key, a
confirmation message is displayed. Touch the
“Yes” key.
 Touch the“Street Address” key.Acharacter
input screen is displayed.
 Enter theaddress ofyour home, touchthe
“OK” key. A list is displayed.
 Touch thepreferred homeaddress keyfrom
the list. You may need totouch thescroll
orkey to find the preferred home address
key.
26

Your home isdisplayed atthe center ofthe
map. Aconfirmation messageisdisplayed,
and the system sets your home as the destina-
tion.
 Press theMAP button
toreturn tothe
current location map screen. The home icon is
displayed on the screen.
SETTING A STREET ADDRESS AS A DESTINATION
 Press the DESTbutton.
 Touch the“Street Address” key.Acharacter
input screen is displayed.
 Enter the house number; when finished touch
the “OK” key.Ifyou donot know thehouse
number, touch the “No House #” key.
 Enter the name of the street. After finishing the
entry, touch the“OK” key.Alist ofpossible
street addresses is displayed.
 Touch thecorrect address ofthe destination
from thelist. You might needtotouch the
scroll
orkey to find the preferred home
key.
 The selected destination isdisplayed atthe
center of the map. Touch the “Start” key after
confirming the location of the displayed desti-
nation. The system sets the destination to the
selected locationandstarts calculating a
route.
27

MOVING AROUND WITHIN A MAP
You can manually move across the map to view the surrounding area or to view a preferred
location.  Touch the screen in the direction that you want to move across the map. Once you begin
moving on the map, the cross pointer appears.
 Press the MAPbutton
or touch the “Back” key to return to the current location map
screen. The cross pointer disappears.
SETTING A POINT OF INTEREST
 Press the DESTbutton.
 Touch the “Points of Interest” key.
 Touch oneofthe category keys;the“Travel”
key is used in this example.
 Touch a sub-category key; the “Airport” key is
used in this example.
 You canfind aPoint ofInterest (POI)three
ways:
● Nearby POI - lists POIs in order of proximity.
● By Name (used in this example) .
● By City.
 Touch oneofthe preferred airportkeysfrom
the list.
 The selected destination isdisplayed atthe
center of the map. Touch the “Start” key after
confirming the location of the displayed desti-
nation. The system sets the destination to the
selected locationandstarts calculating a
route.
28
