Page 28 of 1552

could affect the proper operation
of the TPMS.
. Do not inject any tire liquid or
aerosol tire sealant into the tires,
as this may cause a malfunction
of the tire pressure sensors.
NOTE:
. You can check the pressure of all
four tires on the touch screen dis-
play. See the separate Multi Func-
tion Display Owner’s Manual.
. The tires of this vehicle are filled
with nitrogen gas. When the tire
pressure is low, fill the tires with
nitrogen. It is recommended you
contact a GT-R certified NISSAN
dealer for information on filling the
tires with nitrogen.
. If nitrogen is not available, com-
pressed air may be safely used
under normal driving conditions.
However, NISSAN recommends re-
filling with nitrogen for maximum
tire performance.
Page 60 of 1552

.You can also check the pressure of all
tires on the touch screen display.
Refer to the separate Multi Function
Display Owner’s Manual.
. The tire pressure sensor should be
reset anytime the wheels or tires are
removed or replaced.
. If the tire is removed in order to
replace the tire pressure sensor bat-
tery, it may not be possible to reuse
the removed tire from the wheel. To
replace the tire pressure sensor bat-
tery, it is recommended you contact a
GT-R certified NISSAN dealer.
NOTICE
.The TPMS may not function prop-
erly when the wheels are
equipped with tire chains or the
wheels are buried in snow.
. The TPMS may not function prop-
erly if the TPMS sensor is not
reset and when wheels/tires from
Page 84 of 1552

Seat belt maintenance .................................... 1-12
Map lights ......................................................................... 2-65
Measurement of weights ..................................... 9-16
Meters and gauges ....................................................... 2-6
Mirror Inside mirror ............................................................ 3-27
Mirrors ........................................................................... 3-27
Outside mirrors ..................................................... 3-28
Vanity mirror ........................................................... 3-29
Vanity mirror lights ............................................ 2-67
Most common factors contributing to
vehicle corrosion ............................................................. 7-9
Multi Function Display Owner’s Manual ....... 4-2
N
NCCB (NISSAN Carbon
Ceramic Brake) ........................................... GTR-6, 8-25
Replacing brake pads and brake
disc rotors ................................................................. 8-26
NISSAN Advanced Air Bag System ................ 1-40
NISSAN Vehicle Immobilizer System ............ 2-49
No key warning ............................................................ 2-44
Noises are heard while driving .................. GTR-25
Normal mode ................................................................. 5-25
O
Page 87 of 1552

TransmissionDual clutch transmission ............................... 5-15
Transmission clutch high
temperature warning ....................................... 2-38
Transmission oil .................................. GTR-4, 8-14
Transmission oil high
temperature warning ....................................... 2-38
Transmission position indicator .............. 2-10
Transmission system check display ..... 2-15
Transmission system warning .................. 2-37
VDC, transmission and suspension
setup switches ....................................................... 5-25
Transmission
operation characteristics ............................... GTR-30
Transmission settings .......................................... GTR-9
Treadwear ........................................................................ 9-17
Troubleshooting guide ........................................... 3-17
Trunk .................................................................................... 3-20
Trunk lid release switch ........................................ 3-20
Trunk open request switch ................................ 3-20
Trunk release power cancel switch ............. 3-21
Turbocharger system .............................................. 5-31
Turning off the heaters ......................................... 2-56
Turning on the heaters ......................................... 2-56
Types of tires ................................................................. 8-41
U
Page 155 of 1552

GT-R Overview
GTR
Illustrated table of contents
0
Safety — Seats, seat belts and supplemental restraint
systemInstruments and controlsPre-driving checks and adjustmentsDisplay screen, heater, air conditioner and audio systemsStarting and drivingIn case of emergencyAppearance and careMaintenance and do-it-yourselfTechnical and consumer information
123456789
Index
10
Page 250 of 1552

ways use run-flat tires of the specified
size on all four wheels. Mixing tire sizes or
construction may reduce vehicle handling
stability. If necessary, contact a GT-R
certified NISSAN dealer for assistance.
Frequently check the tire pressure infor-
mation on the touch screen display and
adjust pressure of each tire properly. See
the separate Multi Function Display Own-
er’s Manual.
It can be difficult to tell if a run-flat tire is
under-inflated or flat. Check the tire
pressures as described earlier in this
section. If the tire becomes under-inflated
while driving, the low tire pressure warn-
ing light will come on. If the tire becomes
flat while driving, the low tire pressure
warning light and the run-flat tire warn-
ing display will come on.
Low tire pressure:
Page 390 of 1552

TransmissionDual clutch transmission ............................... 5-15
Transmission clutch high
temperature warning ....................................... 2-38
Transmission oil .................................. GTR-4, 8-14
Transmission oil high
temperature warning ....................................... 2-38
Transmission position indicator .............. 2-10
Transmission system check display ..... 2-15
Transmission system warning .................. 2-37
VDC, transmission and suspension
setup switches ....................................................... 5-25
Transmission
operation characteristics ............................... GTR-30
Transmission settings .......................................... GTR-9
Treadwear ........................................................................ 9-17
Troubleshooting guide ........................................... 3-17
Trunk .................................................................................... 3-20
Trunk lid release switch ........................................ 3-20
Trunk open request switch ................................ 3-20
Trunk release power cancel switch ............. 3-21
Turbocharger system .............................................. 5-31
Turning off the heaters ......................................... 2-56
Turning on the heaters ......................................... 2-56
Types of tires ................................................................. 8-41
U
Page 432 of 1552

ways use run-flat tires of the specified
size on all four wheels. Mixing tire sizes or
construction may reduce vehicle handling
stability. If necessary, contact a GT-R
certified NISSAN dealer for assistance.
Frequently check the tire pressure infor-
mation on the touch screen display and
adjust pressure of each tire properly. See
the separate Multi Function Display Own-
er’s Manual.
It can be difficult to tell if a run-flat tire is
under-inflated or flat. Check the tire
pressures as described earlier in this
section. If the tire becomes under-inflated
while driving, the low tire pressure warn-
ing light will come on. If the tire becomes
flat while driving, the low tire pressure
warning light and the run-flat tire warn-
ing display will come on.
Low tire pressure:
Page 502 of 1552

is used.
. Objects in the RearView Monitor
will appear visually opposite
compared to when viewed in the
rearview and outside mirrors.
. Use the displayed lines as a re-
ference. The lines are highly af-
fected by the number of
occupants, fuel level, vehicle po-
sition, road conditions and road
grade.
. Make sure that the trunk lid is
securely closed when backing up.
. Do not put anything on the rear-
view camera. The rearview cam-
era is installed above the license
plate.
. When washing the vehicle with
high-pressure water, be sure not
to spray it around the camera.
Otherwise, water may enter the
camera unit causing water con-
densation on the lens, a malfunc-
tion, fire or an electric shock.
. Do not strike the camera. It is a
precision instrument. Otherwise,
it may malfunction or cause da-
mage resulting in a fire or an
electric shock. The following are operating limitations
and do not represent a system malfunc-
tion:
.
When the temperature is extremely
high or low, the screen may not clearly
display objects.
. When strong light is directly coming
on the camera, objects may not be
displayed clearly.
. Vertical lines may be seen in objects
on the screen. This is due to strong
reflected light from the bumper.
. The screen may flicker under fluores-
cent light.
. The colors of objects on the RearView
Monitor may differ somewhat from
the actual color of objects.
. Objects on the monitor may not be
clear in a dark environment.
. There may be a delay when switching
to the RearView Monitor screen.
. If dirt, rain or snow accumulates on
the camera, the RearView Monitor
may not display objects clearly. Clean
the camera.
. Do not use wax on the camera win-
dow. Wipe off any wax with a clean
cloth dampened with mild detergent
diluted with water.
Page 516 of 1552

.You can also check the pressure of all
tires on the touch screen display.
Refer to the separate Multi Function
Display Owner’s Manual.
. The tire pressure sensor should be
reset anytime the wheels or tires are
removed or replaced.
. If the tire is removed in order to
replace the tire pressure sensor bat-
tery, it may not be possible to reuse
the removed tire from the wheel. To
replace the tire pressure sensor bat-
tery, it is recommended you contact a
GT-R certified NISSAN dealer.
NOTICE
.The TPMS may not function prop-
erly when the wheels are
equipped with tire chains or the
wheels are buried in snow.
. The TPMS may not function prop-
erly if the TPMS sensor is not
reset and when wheels/tires from
