NISSAN LATIO 2007 Service Repair Manual

BL-2Revision: June 20062007 Versa Door Lock Actuator Check (Front RH and Rear LH/
RH) ......................................................................... 49
Front Door Key Cylinder Switch LH Check ............. 50
Passenger Select Unlock Relay Circuit Check (With
Intelligent Key) ........................................................ 51
REMOTE KEYLESS ENTRY SYSTEM ..................... 54
Component Parts and Harness Connector Location ... 54
System Description ................................................. 55
INPUTS ............................................................... 55
OPERATED PROCEDURE ................................. 56
CAN Communication System Description .............. 56
Schematic ............................................................... 57
Wiring Diagram — KEYLES — ............................... 58
............................................................................. 58
Terminals and Reference Values for BCM .............. 61
How to Perform Trouble Diagnoses ........................ 61
Preliminary Check .................................................. 61
CHECK BCM CONFIGURATION ........................ 61
CONSULT-II Function (BCM) .................................. 61
CONSULT-II START PROCEDURE .................... 61
CONSULT-II APPLICATION ITEMS .................... 61
Work Flow ............................................................... 64
Trouble Diagnosis Symptom Chart ......................... 64
Keyfob Battery and Function Check ....................... 66
ACC Switch Check ................................................. 67
Door Switch Check ................................................. 68
Key Switch (Insert) Check ...................................... 70
Hazard Function Check .......................................... 71
Horn Function Check .............................................. 71
Interior Lamp and Ignition Keyhole Illumination
Function Check ....................................................... 72
Remote Keyless Entry Receiver Check .................. 73
Keyfob Function (Lock) Check ............................... 75
Keyfob Function (Unlock) Check ............................ 75
ID Code Entry Procedure ....................................... 76
KEYFOB ID SET UP WITH CONSULT-II ............ 76
KEYFOB ID SET UP WITHOUT CONSULT-II ..... 77
Keyfob Battery Replacement .................................. 78
Removal and Installation of Remote Keyless Entry
Receiver ................................................................. 79
REMOVAL ........................................................... 79
INSTALLATION .................................................... 79
INTELLIGENT KEY SYSTEM ................................... 80
Component Parts and Harness Connector Location ... 80
System Description ................................................. 82
DOOR LOCK/UNLOCK FUNCTION ................... 83
KEY REMINDER FUNCTION .............................. 85
REMOTE KEYLESS ENTRY FUNCTIONS ......... 86
ENGINE START FUNCTION ............................... 89
WARNING CHIME/BUZZER/LAMPS FUNC-
TION .................................................................... 90
CHANGE SETTINGS FUNCTION ....................... 93
INTELLIGENT KEY REGISTRATION .................. 93
STEERING LOCK SOLENOID REGISTRATION ... 93
CAN Communication System Description .............. 93
Schematic ............................................................... 94
Wiring Diagram — I/KEY — ................................... 96
Intelligent Key Unit Harness Connector Terminal
Layout ...................................................................106Terminals and Reference Values for Intelligent Key
Unit ........................................................................ 106
Steering Lock Solenoid Harness Connector Termi-
nal Layout ............................................................. 108
Terminals and Reference Values for Steering Lock
Solenoid ................................................................ 108
Terminals and Reference Values for BCM ............ 108
Trouble Diagnosis Procedure ................................ 109
PRELIMINARY CHECK ..................................... 109
WORK FLOW ....................................................110
CONSULT-II Functions (INTELLIGENT KEY) ....... 111
CONSULT-II Start Procedure ................................ 111
BASIC OPERATION .......................................... 111
CONSULT-II Application Items .............................. 111
SELF-DIAGNOSTIC RESULTS ......................... 111
DATA MONITOR ................................................ 111
ACTIVE TEST ....................................................112
WORK SUPPORT .............................................113
Trouble Diagnosis Symptom Chart .......................114
KEY WARNING LAMP (GREEN) ILLUMINATES .114
KEY WARNING LAMP (RED) ILLUMINATES ...114
KEY WARNING LAMP DOES NOT ILLUMINATE .115
NON DTC ITEM .................................................115
ENGINE START CONDITION CHECK ..............116
ALL FUNCTIONS OF INTELLIGENT KEY SYS-
TEM DO NOT OPERATE ..................................116
DOOR LOCK/UNLOCK FUNCTION MALFUNC-
TION ..................................................................116
REMOTE KEYLESS ENTRY FUNCTION MAL-
FUNCTION ........................................................118
HAZARD AND BUZZER REMINDER FUNC-
TION MALFUNCTION .......................................119
WARNING CHIME/BUZZER FUNCTION MAL-
FUNCTION ........................................................ 120
WARNING LAMP FUNCTION MALFUNCTION . 122
CAN Communication System Check .................... 122
Power Supply and Ground Circuit Check ............. 123
Key Switch (Intelligent Key Unit Input) Check ....... 124
Key Switch (BCM Input) Check ............................. 126
Ignition Knob Switch Check .................................. 127
Door Switch Check ............................................... 129
Door Request Switch Check ................................. 132
Back Door Request Switch Check ........................ 134
Unlock Sensor Check ........................................... 136
Intelligent Key Warning Buzzer (Driver Door) Check . 138
Outside Key Antenna (Driver Side and Passenger
Side) Check .......................................................... 139
Outside Key Antenna (Rear Bumper) Check ........ 141
Inside Key Antenna Check .................................... 143
Steering Lock Solenoid Check .............................. 144
Key Interlock Solenoid (With M/T) Check ............. 147
Ignition Switch Position Check .............................. 148
Stop Lamp Switch Check (With CVT) ................... 148
Stop Lamp Switch Check (With M/T) .................... 149
Check CVT Device (Park Position Switch) Check . 151
“P-SHIFT” Warning Lamp (With CVT) Check ....... 153
“LOCK” Warning Lamp (With M/T) Check ............. 154
“KEY” Warning Lamp (RED) Check ...................... 155
“KEY” Warning Lamp (GREEN) Check ................. 156

BL-3
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa Check Warning Chime in Combination Meter ...... 156
Hazard Function Check ........................................ 157
Horn Function Check ........................................... 157
Headlamp Function Check ................................... 158
Intelligent Key Battery Replacement .................... 159
DISASSEMBLY AND ASSEMBLY OF INTELLI-
GENT KEY ........................................................ 159
INTELLIGENT KEY BATTERY INSPECTION ... 159
Remote Keyless Entry Function ........................... 159
Removal and Installation of Intelligent Key Unit ... 160
REMOVAL ......................................................... 160
INSTALLATION ................................................. 160
DOOR ..................................................................... 161
Fitting Adjustment ................................................ 161
FRONT DOOR .................................................. 161
REAR DOOR .................................................... 163
BACK DOOR ..................................................... 164
Removal and Installation ...................................... 165
FRONT DOOR .................................................. 165
REAR DOOR .................................................... 166
BACK DOOR ..................................................... 167
FRONT DOOR LOCK ............................................. 169
Component Parts Location ................................... 169
Removal and Installation ...................................... 169
REMOVAL ......................................................... 169
INSTALLATION ................................................. 171
REAR DOOR LOCK ............................................... 172
Component Parts Location ................................... 172
Removal and Installation ...................................... 172
REMOVAL ......................................................... 172
INSTALLATION ................................................. 174
BACK DOOR LOCK ............................................... 175
Component Parts and Harness Connector Location . 175
System Description .............................................. 176
Wiring Diagram — TLID — .................................. 177
WITHOUT INTELLIGENT KEY SYSTEM ......... 177
WITH INTELLIGENT KEY SYSTEM ................. 178
Terminals and Reference Values for BCM ........... 179
Terminals and Reference Values for Intelligent Key
Unit ....................................................................... 179
CONSULT-II Function (BCM) ............................... 179
CONSULT-II START PROCEDURE .................. 179
CONSULT-II APPLICATION ITEMS .................. 180
Work Flow ............................................................ 180
Trouble Diagnosis Chart by Symptom .................. 180
BCM Power Supply and Ground Circuit ............... 180
Check Back Door Opener Switch Circuit (Without
Intelligent Key or Power Windows) ...................... 181
Check Back Door Opener Switch Circuit (Without
Intelligent Key, With Power Windows) .................. 184
Check Back Door Opener Switch Circuit (With Intel-
ligent Key) ............................................................ 187
Check Back Door Lock Assembly (Actuator) Circuit . 189
Removal and Installation ...................................... 190
BACK DOOR LOCK .......................................... 190
BACK DOOR HANDLE ..................................... 191FUEL FILLER LID OPENER ...................................192
Removal and Installation of Fuel Filler Lid Opener .192
REMOVAL .........................................................192
INSTALLATION .................................................192
VEHICLE SECURITY (THEFT WARNING) SYSTEM .193
Component Parts and Harness Connector Location .193
System Description ...............................................194
DESCRIPTION ..................................................194
POWER SUPPLY AND GROUND ....................194
INITIAL CONDITION TO ACTIVATE THE SYS-
TEM ...................................................................195
VEHICLE SECURITY SYSTEM ALARM OPER-
ATION ................................................................195
VEHICLE SECURITY SYSTEM DEACTIVATION .195
PANIC ALARM OPERATION ............................195
CAN Communication System Description ............196
Schematic .............................................................197
Wiring Diagram — VEHSEC — ............................198
..........................................................................198
Terminals and Reference Values for BCM ............202
Terminals and Reference Values for Intelligent Key
Unit .......................................................................202
CONSULT-II Function (BCM) ...............................202
CONSULT-II START PROCEDURE ..................202
CONSULT-II APPLICATION ITEM ....................202
Trouble Diagnosis .................................................204
WORK FLOW ....................................................204
Preliminary Check ................................................205
Symptom Chart .....................................................206
Diagnostic Procedure 1 ........................................207
Diagnostic Procedure 2 ........................................210
Diagnostic Procedure 3 ........................................211
Diagnostic Procedure 4 ........................................211
Diagnostic Procedure 5 ........................................211
Diagnostic Procedure 6 ........................................211
NATS (NISSAN ANTI-THEFT SYSTEM) ................212
Component Parts and Harness Connector Location .212
System Description ...............................................213
DESCRIPTION ..................................................213
SECURITY INDICATOR ....................................213
System Composition .............................................213
ECM Re-communicating Function ........................214
Wiring Diagram — NATS — .................................215
Terminals and Reference Values for BCM ............216
CONSULT-II Function ...........................................216
CONSULT-II INSPECTION PROCEDURE ........216
CONSULT-II DIAGNOSTIC TEST MODE FUNC-
TION ..................................................................217
HOW TO READ SELF-DIAGNOSTIC RESULTS .217
NATS SELF-DIAGNOSTIC RESULTS ITEM
CHART ..............................................................218
Trouble Diagnosis Procedure ...............................219
PRELIMINARY CHECK .....................................219
WORK FLOW ....................................................220
Trouble Diagnoses ...............................................222
SYMPTOM MATRIX CHART 1 ..........................222
SYMPTOM MATRIX CHART 2 ..........................222
Diagnostic Procedure 1 ........................................223
Diagnostic Procedure 2 ........................................225

BL-4Revision: June 20062007 Versa Diagnostic Procedure 3 ........................................227
Diagnostic Procedure 4 ........................................228
Diagnostic Procedure 5 ........................................229
How to Replace NATS Antenna Amp. ..................230
BODY REPAIR ........................................................231
Body Exterior Paint Color .....................................231
Body Component Parts .........................................232
UNDERBODY COMPONENT PARTS ...............232
BODY COMPONENT PARTS ...........................235
Corrosion Protection .............................................237
DESCRIPTION ..................................................237
ANTI-CORROSIVE WAX ...................................238
UNDERCOATING ..............................................239
Body Sealing ........................................................240
DESCRIPTION ..................................................240
Body Construction ................................................243
BODY CONSTRUCTION ..................................243
Body Alignment ....................................................244
BODY CENTER MARKS ...................................244
PANEL PARTS MATCHING MARKS .................245
DESCRIPTION ..................................................245
ENGINE COMPARTMENT ................................247
UNDERBODY ....................................................249
PASSENGER COMPARTMENT ........................251
REAR BODY .....................................................253Handling Precautions for Plastics ......................... 255
HANDLING PRECAUTIONS FOR PLASTICS .. 255
LOCATION OF PLASTIC PARTS ...................... 256
Precautions in Repairing High Strength Steel ....... 258
HIGH STRENGTH STEEL (HSS) USED IN NIS-
SAN VEHICLES ................................................. 258
Foam Repair ......................................................... 262
URETHANE FOAM APPLICATIONS ................. 262
FILL PROCEDURES ......................................... 262
Replacement Operations ...................................... 264
DESCRIPTION .................................................. 264
RADIATOR CORE SUPPORT ........................... 267
HOODLEDGE LH .............................................. 269
HOODLEDGE RH .............................................. 271
FRONT SIDE MEMBER .................................... 273
FRONT SIDE MEMBER LH (PARTIAL) ............. 275
FRONT PILLAR ................................................. 277
DASH SIDE ........................................................ 281
CENTER PILLAR ............................................... 283
OUTER SILL ...................................................... 286
OUTER SILL REINFORCEMENT ...................... 287
REAR FENDER ................................................. 288
REAR PANEL .................................................... 290
REAR FLOOR REAR ......................................... 291
REAR SIDE MEMBER EXTENSION ................. 293

PRECAUTIONS
BL-5
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EIS009DU
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WA RN ING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions Necessary for Steering Wheel Rotation After Battery DisconnectEIS009CG
NOTE:

This procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).

Remove and install all control units after disconnecting both battery cables with the ignition in the ″LOCK″
position.

Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.

BL-6
PRECAUTIONS
Revision: June 20062007 Versa
Precautions for Procedures without Cowl Top CoverEIS0090H
When performing the procedure after removing cowl top cover, cover
the lower end of windshield.
Precautions for WorkEIS0090I

After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check
their operation.

Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.
PIIB3706J

PREPARATION
BL-7
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
PREPARATIONPFP:00002
Special service toolEIS0090K
Commercial Service ToolsEIS009D3
Tool number
(Kent-Moore No.)
Tool nameDescription
—
(J-39570)
Chassis earLocating the noise
—
(J-43980)
NISSAN Squeak and Rat-
tle KitRepairing the cause of noise
—
(J-43241)
Remote Keyless Entry
TesterUsed to test key fobs
SIIA0993E
SIIA0994E
LEL946A
Tool name Description
Engine ear Locating the noise
SIIA0995E

BL-8
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: June 20062007 Versa
SQUEAK AND RATTLE TROUBLE DIAGNOSESPFP:00000
Work FlowEIS009DG
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to BL-12, "
Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.

The customer may not be able to provide a detailed description or the location of the noise. Attempt to
obtain all the facts and conditions that exist when the noise occurs (or does not occur).

If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
is concerned about. This can be accomplished by test driving the vehicle with the customer.

After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
are provided so the customer, service adviser and technician are all speaking the same language when
defining the noise.

Squeak —(Like tennis shoes on a clean floor)
Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
faces = higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping.

Creak—(Like walking on an old wooden floor)
Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
dependent on materials/often brought on by activity.

Rattle—(Like shaking a baby rattle)
Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
clip or fastener/incorrect clearance.

Knock —(Like a knock on a door)
Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.

Tick—(Like a clock second hand)
Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
action or road conditions.

Thump—(Heavy, muffled knock noise)
Thump characteristics include softer knock/dead sound often brought on by activity.

Buzz—(Like a bumble bee)
Buzz characteristics include high frequency rattle/firm contact.

Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
judge as acceptable may be very irritating to the customer.

Weather conditions, especially humidity and temperature, may have a great effect on noise level.
SBT 8 42

SQUEAK AND RATTLE TROUBLE DIAGNOSES
BL-9
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle “twist”.
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.

Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.

If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1. Narrow down the noise to a general area.To help pinpoint the source of the noise, use a listening tool
(Chassis Ear: J-39570, Engine Ear: J-39565 and mechanic's stethoscope).
2. Narrow down the noise to a more specific area and identify the cause of the noise by:

removing the components in the area that you suspect the noise is coming from.
