WATER OUTLET AND WATER CONTROL VALVECO-51
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
CVT MODELS
Removal and InstallationINFOID:0000000005930821
REMOVAL
1. Drain engine coolant from radiator. Refer to
CO-36, "Changing Engine Coolant".
CAUTION:
• Perform this step when engine is cold.
• Never spill engine coolant on drive belt.
2. Remove battery and battery tray. Refer to SC-7, "
Removal and Installation".
3. Remove air cleaner and air duct. Refer to EM-135, "
Component".
4. Remove radiator hose (lower) from engine. Refer to CO-40, "
Component".
5. Remove heater hoses and water hoses.
6. Remove CVT warmer hose (CVT models only).
7. Remove water outlet.
8. Remove water control valve.
9. Remove engine coolant temperature sensor from the water outlet, if necessary. CAUTION:
• Handle carefully to avoid any shock to engine coolant temperature sensor.
• Replace the gasket with a new one.
INSPECTION AFTER REMOVAL
AWBIA0962ZZ
1. Engine coolant temperature sensor 2. Rubber ring 3. Water control valve
4. Gasket 5. Water hose 6. Gasket
7. Water hose 8. Water outlet 9. Heater hose
10. Heater hose 11. CVT warmer hose 12. Radiator hose (upper)
Front A. To heater B. To electric throttle control actuator
C. To radiator D. To CVT fluid warmer
Revision: May 2010 2011 Versa
Page 1052 of 3787
![NISSAN LATIO 2011 Service Repair Manual CO-52
< SERVICE INFORMATION >[MR18DE]
WATER OUTLET AND WATER CONTROL VALVE
• Place a thread (A) so that it is c
aught in the valves of water control
valve (1). Immerse fully in a container (B) fille](/img/5/57357/w960_57357-1051.png "NISSAN LATIO 2011 Service Repair Manual CO-52
< SERVICE INFORMATION >[MR18DE]
WATER OUTLET AND WATER CONTROL VALVE
• Place a thread (A) so that it is c
aught in the valves of water control
valve (1). Immerse fully in a container (B) fille")
CO-52
< SERVICE INFORMATION >[MR18DE]
WATER OUTLET AND WATER CONTROL VALVE
• Place a thread (A) so that it is c
aught in the valves of water control
valve (1). Immerse fully in a container (B) filled with water. Heat
while stirring.
• The valve opening temperature is the temperature at which the valve opens and falls from the thread.
• Continue heating. Check the full-open valve lift amount.
NOTE:
The full-open valve lift amount standard temperature for water con-
trol valve is the reference value.
• After checking the full-open valve lift amount, lower the water tem- perature and check the valve closing temperature.
• If out of the specification, replace water control valve.
INSTALLATION
Installation is in the reverse order of removal.
• Use the following procedure to install the water control valve.
- Install water control valve making sure rubber ring (1) groove fits
securely to water control valve flange (A).
CAUTION:
Replace the rubber ring with a new one.
- While the mark (A) points to up, install water control valve (2) with frame center (B) facing straight upward into water outlet (1).
• Use the following procedure to install the water outlet.
- Install the water outlet to the cylinder head without disp lacing the water control valve from the valve position.
• Use the following procedure to install the water hoses. Standard : Refer to
CO-55, "
Standard and Limit"
PBIC3314J
PBIC3317J
PBIC4700E
Revision: May 2010 2011 Versa
Page 1053 of 3787
![NISSAN LATIO 2011 Service Repair Manual WATER OUTLET AND WATER CONTROL VALVECO-53
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
- Install water hoses (3),(5) as shown.
• Electric throttle control actuator (1)
• Clamp](/img/5/57357/w960_57357-1052.png "NISSAN LATIO 2011 Service Repair Manual WATER OUTLET AND WATER CONTROL VALVECO-53
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
- Install water hoses (3),(5) as shown.
• Electric throttle control actuator (1)
• Clamp")
WATER OUTLET AND WATER CONTROL VALVECO-53
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
- Install water hoses (3),(5) as shown.
• Electric throttle control actuator (1)
• Clamp (2)
• Water outlet (4)
• Paint mark (A)
• Clamp shall not interfere with the bulged area (B)
• : Engine front
- Water Hoses (CVT Models)
- Install water hoses (3),(5) as shown.
• Electric throttle control actuator (1)
• Clamp (2)
• Water outlet (4)
• Paint mark (A)
• Clamp shall not interfere with the bulged area (B)
• : Engine front
InspectionINFOID:0000000006413350
INSPECTION AFTER INSTALLATION
• Before starting engine, check oil/fluid levels incl
uding engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-14, "
Fluids and Lubricants".
• Use procedure below to check for fuel leakage.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak- age at connection points.
• Start engine. With engine speed increased, check again for fuel leakage at connection points.
• Run engine to check for unusual noise and vibration.
PBIC4703E
WBIA0821E
Revision: May 2010 2011 Versa
Page 1054 of 3787
![NISSAN LATIO 2011 Service Repair Manual CO-54
< SERVICE INFORMATION >[MR18DE]
WATER OUTLET AND WATER CONTROL VALVE
• Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gas, or any oils/fluids including
engine oil](/img/5/57357/w960_57357-1053.png "NISSAN LATIO 2011 Service Repair Manual CO-54
< SERVICE INFORMATION >[MR18DE]
WATER OUTLET AND WATER CONTROL VALVE
• Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gas, or any oils/fluids including
engine oil")
CO-54
< SERVICE INFORMATION >[MR18DE]
WATER OUTLET AND WATER CONTROL VALVE
• Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gas, or any oils/fluids including
engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec-
ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc. Item
Before starting engine Engine runningAfter engine stopped
Engine coolant LevelLeakage Level
Engine oil LevelLeakage Level
Transmission/
transaxle fluid A/T and CVT Models
LeakageLevel/Leakage Leakage
M/T Models Level/Leakage LeakageLevel/Leakage
Other oils and fluids* LevelLeakage Level
Fuel LeakageLeakage Leakage
Exhaust gas —Leakage —
Revision: May 2010 2011 Versa
Page 1055 of 3787
![NISSAN LATIO 2011 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)CO-55
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000005930822
CAPACITY
Uni](/img/5/57357/w960_57357-1054.png "NISSAN LATIO 2011 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)CO-55
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000005930822
CAPACITY
Uni")
SERVICE DATA AND SPECIFICATIONS (SDS)CO-55
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000005930822
CAPACITY
Unit: (US qt, lmp qt)
THERMOSTAT
WATER CONTROL VALVE
RADIATOR
Unit: kPa (bar, kg/cm2, psi)
Engine coolant capacity (with reservoir tank at “MAX” level)
Approx. 6.8 (7 1/4, 6)
Valve opening temperature80.5 - 83.5°C (177 - 182 °F)
Full-open valve lift amount 8 mm/ 95°C (0.315 in/ 203 °F)
Valve closing temperature 77°C (171 °F)
Valve opening temperature 93.5 - 96.5°C (200 - 206 °F)
Full-open valve lift amount 8 mm/ 108°C (0.315 in/ 226 °F)
Valve closing temperature 90°C (194 °F)
Cap relief pressure Standard
78 - 98 (0.78 - 0.98, 0.8 - 1.0, 11- 14)
Limit 59 (0.59, 0.6, 9)
Leakage test pressure 157 (1.57, 1.6, 23)
Revision: May 2010 2011 Versa
Page 1056 of 3787
CVT-1
TRANSMISSION/TRANSAXLE
DE
F
G H
I
J
K L
M
SECTION CVT
A
B
CVT
N
O P
CONTENTS
CVT
RE0F08B
SERVICE INFORMATION .. ..........................
5
INDEX FOR DTC ............................................ .....5
Alphabetical Index ............................................... ......5
DTC No. Index ..........................................................5
PRECAUTIONS ...................................................7
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
7
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ............................... ......
7
Precaution for On Board Diagnosis (OBD) System
of CVT and Engine ....................................................
8
Service After Replacing TCM and Transaxle As-
sembly .......................................................................
8
Removal and Installation Procedure for CVT Unit
Connector ............................................................ ......
9
Precaution ...............................................................10
Service Notice or Precaution ...................................11
ATFTEMP COUNT Conversion Table ....................11
PREPARATION .............................................. ....13
Special Service Tool ........................................... ....13
Commercial Service Tool ........................................13
CVT FLUID .........................................................14
Checking CVT Fluid ............................................ ....14
Changing CVT Fluid ................................................15
CVT Fluid Cooler Cleaning .....................................15
CVT SYSTEM ................................................. ....19
Cross-Sectional View - RE0F08B ....................... ....19
Control System .................................................... ....20
Hydraulic Control System ........................................21
TCM Function ...................................................... ....21
CAN Communication ...............................................22
Input/Output Signal of TCM .....................................22
Line Pressure and Secondary Pressure Control .....23
Shift Control ............................................................23
Lock-up and Select Control .....................................25
Control Valve ....................................................... ....25
ON BOARD DIAGNOSTIC (OBD) SYSTEM ....27
Introduction ..............................................................27
OBD-II Function for CVT System ............................27
One or Two Trip Detection Logic of OBD-II .............27
OBD-II Diagnostic Trouble Code (DTC) ..................27
Malfunction Indicator Lamp (MIL) ............................28
TROUBLE DIAGNOSIS ....................................30
DTC Inspection Priority Chart ..................................30
Fail-Safe ..................................................................30
How to Perform Trouble Diagnosis for Quick and
Accurate Repair .......................................................
31
CVT Electrical Parts Location ..................................36
Circuit Diagram ........................................................37
Inspections before Trouble Diagnosis .....................37
Road Test ................................................................41
Check before Engine Is Started ...............................42
Check at Idle ............................................................42
Cruise Test ..............................................................43
Vehicle Speed When Shifting Gears .......................45
TCM Terminal and Reference Value .......................46
CONSULT-III Function (TRANSMISSION) .......... ....48
Diagnosis Procedure without CONSULT-III ............55
U1000 CAN COMM CIRCUIT ...........................56
Description ........................................................... ....56
On Board Diagnosis Logic .......................................56
Possible Cause ........................................................56
DTC Confirmation Procedure ..................................56
Wiring Diagram - CVT - CAN ...................................57
Diagnosis Procedure ...............................................58
U1010 CONTROL UNIT (CAN) .........................59
Description ...............................................................59
On Board Diagnosis Logic .......................................59
Possible Cause ........................................................59
DTC Confirmation Procedure ..................................59
Diagnosis Procedure ...............................................59
Revision: May 2010 2011 Versa
Page 1057 of 3787
CVT-2
P0703 BRAKE SWITCH B ............................. ...60
Description ........................................................... ...60
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
60
On Board Diagnosis Logic ......................................60
Possible Cause .......................................................60
DTC Confirmation Procedure .................................60
Diagnosis Procedure ..............................................60
P0705 TRANSMISSION RANGE SWITCH A ....62
Description ..............................................................62
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
62
On Board Diagnosis Logic ......................................62
Possible Cause .......................................................62
DTC Confirmation Procedure .................................62
Wiring Diagram - CVT - TR/SW ..............................63
Diagnosis Procedure ..............................................64
Component Inspection ............................................65
P0710 TRANSMISSION FLUID TEMPERA-
TURE SENSOR A ..............................................
67
Description ........................................................... ...67
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
67
On Board Diagnosis Logic ......................................67
Possible Cause .......................................................67
DTC Confirmation Procedure .................................67
Wiring Diagram - CVT - FTS ...................................68
Diagnosis Procedure ..............................................69
Component Inspection ............................................70
P0715 INPUT SPEED SENSOR A ....................72
Description ........................................................... ...72
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
72
On Board Diagnosis Logic ......................................72
Possible Cause .......................................................72
DTC Confirmation Procedure .................................72
Wiring Diagram - CVT - PRSCVT ...........................73
Diagnosis Procedure ..............................................74
P0720 OUTPUT SPEED SENSOR ....................76
Description ........................................................... ...76
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
76
On Board Diagnosis Logic ......................................76
Possible Cause .......................................................76
DTC Confirmation Procedure .................................76
Wiring Diagram - CVT - SESCVT ...........................77
Diagnosis Procedure ........................................... ...78
P0725 ENGINE SPEED .....................................81
Description ........................................................... ...81
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
81
On Board Diagnosis Logic ......................................81
Possible Cause .......................................................81
DTC Confirmation Procedure .................................81
Diagnosis Procedure ..............................................81
P0730 INCORRECT GEAR RATIO ...................83
Description ........................................................... ...83
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
83
On Board Diagnosis Logic ......................................83
Possible Cause .......................................................83
DTC Confirmation Procedure ..................................83
Diagnosis Procedure ...............................................83
P0740 TORQUE CONVERTER .........................84
Description ........................................................... ...84
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
84
On Board Diagnosis Logic ......................................84
Possible Cause .......................................................84
DTC Confirmation Procedure ..................................84
Wiring Diagram - CVT - TCV ..................................85
Diagnosis Procedure ...............................................86
Component Inspection ............................................87
P0744 TORQUE CONVERTER .........................89
Description ........................................................... ...89
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
89
On Board Diagnosis Logic ......................................89
Possible Cause .......................................................89
DTC Confirmation Procedure ..................................89
Diagnosis Procedure ...............................................89
P0745 PRESSURE CONTROL SOLENOID A ...91
Description ........................................................... ...91
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
91
On Board Diagnosis Logic ......................................91
Possible Cause .......................................................91
DTC Confirmation Procedure ..................................91
Wiring Diagram - CVT - LPSV ................................92
Diagnosis Procedure ............................................ ...93
Component Inspection ............................................94
P0746 PRESSURE CONTROL SOLENOID A ...96
Description ........................................................... ...96
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
96
On Board Diagnosis Logic ......................................96
Possible Cause .......................................................96
DTC Confirmation Procedure ..................................96
Diagnosis Procedure ...............................................96
P0776 PRESSURE CONTROL SOLENOID B ...98
Description ........................................................... ...98
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
98
On Board Diagnosis Logic ......................................98
Possible Cause .......................................................98
DTC Confirmation Procedure ..................................98
Diagnosis Procedure ...............................................98
P0778 PRESSURE CONTROL SOLENOID B ..100
Description ........................................................... .100
Revision: May 2010 2011 Versa
Page 1058 of 3787
CVT-3
DE
F
G H
I
J
K L
M A
B
CVT
N
O
P
N
CONSULT-III Refe
rence Value in Data Monitor
Mode ................................................................... ..
100
On Board Diagnosis Logic ....................................100
Possible Cause .....................................................100
DTC Confirmation Procedure ................................100
Wiring Diagram - CVT - SECPSV ....................... ..101
Diagnosis Procedure ........................................... ..102
Component Inspection ..........................................103
P0840 TRANSMISSION FLUID PRESSURE
SEN/SW A ........................................................
105
Description ............................................................105
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
105
On Board Diagnosis Logic ....................................105
Possible Cause .....................................................105
DTC Confirmation Procedure ................................105
Wiring Diagram - CVT - SECPS ............................106
Diagnosis Procedure .............................................107
P0841 TRANSMISSION FLUID PRESSURE
SEN/SW A ........................................................
109
Description ............................................................109
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
109
On Board Diagnosis Logic ....................................109
Possible Cause .....................................................109
DTC Confirmation Procedure ................................109
Diagnosis Procedure .............................................109
P0868 TRANSMISSION FLUID PRESSURE ...111
Description .......................................................... ..111
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
111
On Board Diagnosis Logic ....................................111
Possible Cause .....................................................111
DTC Confirmation Procedure ................................111
Diagnosis Procedure .............................................111
P1701 TCM .......................................................113
Description .......................................................... ..113
On Board Diagnosis Logic ....................................113
Possible Cause .....................................................113
DTC Confirmation Procedure ................................113
Wiring Diagram - CVT - POWER ..........................114
Diagnosis Procedure .............................................115
P1705 TP SENSOR ..........................................117
Description .......................................................... ..117
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
117
On Board Diagnosis Logic ....................................117
Possible Cause .....................................................117
DTC Confirmation Procedure ................................117
Diagnosis Procedure .............................................117
P1722 VEHICLE SPEED ..................................119
Description ............................................................119
CONSULT-III Reference Value in Data Monitor
Mode ................................................................... ..
119
On Board Diagnosis Logic ................................... ..119
Possible Cause ......................................................119
DTC Confirmation Procedure ................................119
Diagnosis Procedure .............................................119
P1723 SPEED SENSOR .................................121
Description .............................................................121
On Board Diagnosis Logic .....................................121
Possible Cause ......................................................121
DTC Confirmation Procedure ................................121
Diagnosis Procedure .............................................121
P1726 THROTTLE CONTROL SIGNAL .........123
Description .............................................................123
On Board Diagnosis Logic .....................................123
Possible Cause ......................................................123
DTC Confirmation Procedure ................................123
Diagnosis Procedure .............................................123
P1740 SELECT SOLENOID ...........................124
Description .............................................................124
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
124
On Board Diagnosis Logic .....................................124
Possible Cause ......................................................124
DTC Confirmation Procedure ................................124
Wiring Diagram - CVT - L/USSV ...........................125
Diagnosis Procedure .............................................126
Component Inspection ...........................................127
P1745 LINE PRESSURE CONTROL ..............128
Description .............................................................128
On Board Diagnosis Logic .....................................128
Possible Cause ......................................................128
DTC Confirmation Procedure ................................128
Diagnosis Procedure .............................................128
P1777 STEP MOTOR ......................................129
Description .............................................................129
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
129
On Board Diagnosis Logic .....................................129
Possible Cause ......................................................129
DTC Confirmation Procedure ................................129
Wiring Diagram - CVT - STM .................................130
Diagnosis Procedure .............................................131
Component Inspection ...........................................132
P1778 STEP MOTOR ......................................133
Description .............................................................133
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
133
On Board Diagnosis Logic .....................................133
Possible Cause ......................................................133
DTC Confirmation Procedure ................................133
Diagnosis Procedure .............................................134
OVERDRIVE CONTROL SWITCH ..................135
Description .............................................................135
Revision: May 2010 2011 Versa
Page 1059 of 3787
CVT-4
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
135
Wiring Diagram - CVT - ODSW .............................136
Diagnosis Procedure .............................................136
Component Inspection ...........................................138
SHIFT POSITION INDICATOR CIRCUIT ........140
Description ........................................................... ..140
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
140
Diagnosis Procedure .............................................140
TROUBLE DIAGNOSIS FOR SYMPTOMS .....141
Wiring Diagram - CVT - NONDTC ....................... ..141
O/D OFF Indicator Lamp Does Not Come On .......143
Engine Cannot Be Started in "P" and "N" Position ..145
In "P" Position, Vehicle Moves Forward or Back-
ward When Pushed ...............................................
145
In "N" Position, Vehicle Moves ............................ ..146
Large Shock "N" → "R" Position .......................... ..146
Vehicle Does Not Creep Backward in "R" Position ..147
Vehicle Does Not Creep Forward in "D" or "L" Po-
sition ......................................................................
148
Vehicle Speed Does Not Change in "L" Position ...149
Vehicle Speed Does Not Change in overdrive-off
mode ......................................................................
150
Vehicle Speed Does Not Change in "D" Position ..151
Vehicle Does Not Decelerate by Engine Brake .....151
CVT SHIFT LOCK SYSTEM ........................... .153
Description ........................................................... ..153
Shift Lock System Electrical Parts Location ..........154
Wiring Diagram - CVT - SHIFT ..............................155
Diagnosis Procedure .............................................155
TCM ..................................................................159
Removal and Installation ..................................... ..159
SHIFT CONTROL SYSTEM ............................160
Removal and Installation ..................................... ..160
CVT Shift Selector Disassembly and Assembly ....163
Shift Selector Handle Removal and Installation ....163
Adjustment of CVT Position ................................. ..164
Checking of CVT Position ......................................164
KEY INTERLOCK CABLE ...............................166
Removal and Installation ..................................... ..166
PRIMARY SPEED SENSOR ...........................169
Exploded View ..................................................... ..169
Removal and Installation .......................................169
Inspection ............................................................. .169
SECONDARY SPEED SENSOR ......................170
Exploded View ..................................................... .170
Removal and Installation .......................................170
Inspection ............................................................. .170
AIR BREATHER HOSE ....................................171
Removal and Installation .......................................171
OIL PAN .......................................................... ..172
Exploded View ..................................................... .172
Removal and Installation .......................................172
Inspection ............................................................. .173
DIFFERENTIAL SIDE OIL SEAL .....................174
Removal and Installation .......................................174
CVT OIL WARMER SYSTEM ......................... ..175
WATER HOSE ........................................................ .175
WATER HOSE : Exploded View ...........................175
WATER HOSE : Removal and Installation ...........175
WATER HOSE : Inspection ..................................176
CVT FLUID COOLER HOSE .................................. .176
CVT FLUID COOLER HOSE : Exploded View .....177
CVT FLUID COOLER HOSE : Removal and In-
stallation ................................................................
177
CVT FLUID COOLER HOSE : Inspection .............179
CVT OIL WARMER ................................................ .179
CVT OIL WARMER : Exploded View ....................179
CVT OIL WARMER : Removal and Installation ....179
CVT OIL WARMER : Inspection .......................... .179
TRANSAXLE ASSEMBLY ...............................180
Removal and Installation .......................................180
SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................. ..
183
General Specification ........................................... .183
Vehicle Speed When Shifting Gears .....................183
Stall Speed ............................................................183
Line Pressure ........................................................183
Solenoid Valves ....................................................184
CVT Fluid Temperature Sensor ............................184
Primary Speed Sensor ..........................................184
Secondary Speed Sensor .................................... .184
Removal and Installation .......................................184
Revision: May 2010 2011 Versa
Page 1060 of 3787
![NISSAN LATIO 2011 Service Repair Manual INDEX FOR DTCCVT-5
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
SERVICE INFORMATION
INDEX FOR DTC
Alphabetical IndexINFOID:0000000005928718
NOTE:
If DTC “U1000” is displayed](/img/5/57357/w960_57357-1059.png "NISSAN LATIO 2011 Service Repair Manual INDEX FOR DTCCVT-5
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
SERVICE INFORMATION
INDEX FOR DTC
Alphabetical IndexINFOID:0000000005928718
NOTE:
If DTC “U1000” is displayed")
INDEX FOR DTCCVT-5
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
SERVICE INFORMATION
INDEX FOR DTC
Alphabetical IndexINFOID:0000000005928718
NOTE:
If DTC “U1000” is displayed with other DTCs, fi rst perform the trouble diagnosis for DTC “U1000”.
Refer to CVT-56
.
*1: These numbers are prescribed by SAE J2012.
*2: Models without ABS does not indicate.
DTC No. IndexINFOID:0000000005928719
NOTE:
If DTC “U1000” is displayed with other DTCs, fi rst perform the trouble diagnosis for DTC “U1000”.
Refer to CVT-56
.
Items
(CONSULT-III screen terms) DTC
Reference page
OBD-II
Except OBD-II
CONSULT-III GST*
1 CONSULT-III only
“TRANSMISSION”
BRAKE SWITCH B —P0703 CVT-60
CAN COMM CIRCUIT U1000 U1000 CVT-56
CONTROL UNIT (CAN)—U1010 CVT-59
ENGINE SPEED —P0725 CVT-81
FLUID PRESS LOW —P0868C V T- 111
FLUID PRESS SEN/SW A P0840P0840CVT-105
FLUID PRESS SEN/SW A —P0841CVT-109
FLUID TEMP SENSOR A P0710P0710CVT-67
INCORRECT GR RATIO —P0730 CVT-83
INPUT SPEED SENSOR A P0715P0715CVT-72
LINE PRESS CONTROL —P1745CVT-128
OUTPUT SPEED SENSOR P0720P0720CVT-76
PC SOLENOID A P0745P0745CVT-91
PC SOLENOID A P0746P0746CVT-96
PC SOLENOID B P0776P0776CVT-98
PC SOLENOID B P0778P0778CVT-100
SLCT SOLENOID P1740P1740CVT-124
SPEED SENSOR —P1723CVT-121
STEP MOTOR P1777P1777CVT-129
STEP MOTOR P1778P1778CVT-133
TCM —P1701CVT-113
THROTTLE CONTROL SIG —P1726CVT-123
T/M RANGE SENSOR A P0705P0705CVT-62
TORQUE CONVERTER P0740P0740CVT-84
TORQUE CONVERTER P0744 P0744 CVT-89
TP SENSOR —P1705CVT-117
VEHICLE SPEED*2— P1722CVT-119
Revision: May 2010 2011 Versa
