NISSAN LATIO 2011 Service Repair Manual
Manufacturer: NISSAN, Model Year: 2011, Model line: LATIO, Model: NISSAN LATIO 2011Pages: 3787, PDF Size: 78.35 MB
Page 1791 of 3787
![NISSAN LATIO 2011 Service Repair Manual PREPARATIONEC-497
< PREPARATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000005930164
NOTE:
The actual shapes of Kent-Moore tools may differ f](/img/5/57357/w960_57357-1790.png "NISSAN LATIO 2011 Service Repair Manual PREPARATIONEC-497
< PREPARATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000005930164
NOTE:
The actual shapes of Kent-Moore tools may differ f")
PREPARATIONEC-497
< PREPARATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000005930164
NOTE:
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsINFOID:0000000005930165
Tool number
(Kent-Moore No.)
Tool name
Description
(J-44321)
Fuel pressure gauge
kit Checks fuel pressure
(J-44321-6)
Fuel pressure adapter Connects fuel pressure gauge to quick connector
type fuel lines.
KV10118400
Fuel tube adapter Measures fuel pressure
LEC642
LBIA0376E
PBIB3043E
Tool name
(Kent-Moore No.)
Description
Leak detector
i.e.: (J-41416) Locates the EVAP leak
EVAP service port
adapter
i.e.: (J-41413-OBD) Applies positive pressure through EVAP service
port
S-NT703
S-NT704
Revision: May 2010
2011 Versa
Page 1792 of 3787
![NISSAN LATIO 2011 Service Repair Manual EC-498
< PREPARATION >[HR16DE]
PREPARATION
Fuel filler cap adapter
i.e.: (MLR-8382)Checks fuel tank vacuum relief valve opening
pressure
Socket wrench Removes and installs engine coolant temperature](/img/5/57357/w960_57357-1791.png "NISSAN LATIO 2011 Service Repair Manual EC-498
< PREPARATION >[HR16DE]
PREPARATION
Fuel filler cap adapter
i.e.: (MLR-8382)Checks fuel tank vacuum relief valve opening
pressure
Socket wrench Removes and installs engine coolant temperature")
EC-498
< PREPARATION >[HR16DE]
PREPARATION
Fuel filler cap adapter
i.e.: (MLR-8382)Checks fuel tank vacuum relief valve opening
pressure
Socket wrench Removes and installs engine coolant temperature
sensor
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12) Reconditions the exhaust system threads before
installing a new oxygen sensor. Use with anti-
seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for Zirco-
nia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for Tita-
nia Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL specifica-
tion MIL-A-907) Lubricates oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
Tool name
(Kent-Moore No.)
Description
S-NT815
S-NT705
AEM488
S-NT779
Revision: May 2010
2011 Versa
Page 1793 of 3787
![NISSAN LATIO 2011 Service Repair Manual FUEL PRESSUREEC-499
< ON-VEHICLE MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON-VEHICLE MAINTENANCE
FUEL PRESSURE
InspectionINFOID:0000000005930166
FUEL PRESSURE RELEASE
With CONSULT-III
1](/img/5/57357/w960_57357-1792.png "NISSAN LATIO 2011 Service Repair Manual FUEL PRESSUREEC-499
< ON-VEHICLE MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON-VEHICLE MAINTENANCE
FUEL PRESSURE
InspectionINFOID:0000000005930166
FUEL PRESSURE RELEASE
With CONSULT-III
1")
FUEL PRESSUREEC-499
< ON-VEHICLE MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON-VEHICLE MAINTENANCE
FUEL PRESSURE
InspectionINFOID:0000000005930166
FUEL PRESSURE RELEASE
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “FUEL PRESSURE RELEASE” in
“WORK SUPPORT” mode with CONSULT-III.
3. Start engine.
4. After engine stalls, crank it two or three times to release all fuel pressure.
5. Turn ignition switch OFF.
Without CONSULT-III
1. Remove fuel pump fuse located in IPDM E/R.
2. Start engine.
3. After engine stalls, crank it two or three times to release all fuel pressure.
4. Turn ignition switch OFF.
5. Reinstall fuel pump fuse after servicing fuel system.
FUEL PRESSURE CHECK
CAUTION:
Before disconnecting fuel line, release fuel pressure from fuel line to eliminate danger.
NOTE:
• Prepare pans or saucers under the disconnected fuel line because the fuel may spill out. The fuel
pressure cannot be completely released because C11 models do not have fuel return system.
• The fuel hose connection method used when taking fuel pressure check must not be used for other
purposes.
• Be careful not to scratch or put debris around connection area when servicing, so that the quick
connector maintains seal abil ity with O-rings inside.
• Do not perform fuel pressure check with electrical systems operating (i.e. lights, rear defogger, A/C,
etc.) Fuel pressure gauge may indicate false readin gs due to varying engine load and changes in
manifold vacuum.
1. Release fuel pressure to zero. Refer to "FUEL PRESSURE RELEASE".
2. Prepare fuel hose for fuel pressure check B and fuel tube adapter (KV10118400) D, then connect fuel pressure gauge A.
• : To quick connector
• : To fuel tube (engine side)
• C: Clamp
• Use suitable fuel hose for fuel pressure check (genuine
NISSAN fuel hose without quick connector).
• To avoid unnecessary force or tension to hose, use moder-
ately long fuel hose for fuel pressure check.
• Do not use the fuel hose for checking fuel pressure with dam- age or cracks on it.
• Use Pressure Gauge to check fuel pressure.
3. Remove fuel hose. Refer to EM-154, "
Removal and Installation".
• Do not twist or kink fuel hose because it is plastic hose.
PBIB2982E
Revision: May 2010 2011 Versa
Page 1794 of 3787
![NISSAN LATIO 2011 Service Repair Manual EC-500
< ON-VEHICLE MAINTENANCE >[HR16DE]
FUEL PRESSURE
4. Connect fuel hose for fuel pressure check (1) to fuel tube
(engine side) with clamp (2) as shown in the figure.
• No.2 spool (5)
• Wipe o](/img/5/57357/w960_57357-1793.png "NISSAN LATIO 2011 Service Repair Manual EC-500
< ON-VEHICLE MAINTENANCE >[HR16DE]
FUEL PRESSURE
4. Connect fuel hose for fuel pressure check (1) to fuel tube
(engine side) with clamp (2) as shown in the figure.
• No.2 spool (5)
• Wipe o")
EC-500
< ON-VEHICLE MAINTENANCE >[HR16DE]
FUEL PRESSURE
4. Connect fuel hose for fuel pressure check (1) to fuel tube
(engine side) with clamp (2) as shown in the figure.
• No.2 spool (5)
• Wipe off oil or dirt from hose insertion part using cloth moist-ened with gasoline.
• Apply proper amount of gasoline between top of the fuel tube
(3) and No.1 spool (4).
• Insert fuel hose for fuel pressure check until it touches the No.1 spool on fuel tube.
• Use NISSAN genuine hose clamp (part number: 16439 N4710 or 16439 40U00).
• When reconnecting fuel line, always use new clamps.
• Use a torque driver to tighten clamps.
• Install hose clamp to the position within 1 - 2 mm (0.04 - 0.08 in).
• Make sure that clamp screw does not contact adjacent parts.
5. Connect fuel tube adapter to quick connector. • A: Fuel pressure gauge
• B: Fuel hose for fuel pressure check
6. After connecting fuel hose for fuel pressure check, pull the hose with a force of approximately 98 N (10 kg, 22 lb) to confirm fuel
tube does not come off.
7. Turn ignition switch ON and check for fuel leakage.
8. Start engine and check for fuel leakage.
9. Read the indication of fuel pressure gauge. • Do not perform fuel pressure check with system operating.
Fuel pressure gauge may indicate false readings.
• During fuel pressure check, confirm for f uel leakage from fuel connection every 3 minutes.
10. If result is unsatisfactory, go to next step.
11. Check the following. • Fuel hoses and fuel tubes for clogging
• Fuel filter for clogging
• Fuel pump
• Fuel pressure regulator for clogging
If OK, replace fuel pressure regulator. Refer to FL-6, "
Removal and Installation".
If NG, repair or replace.
12. Before disconnecting Fuel Pressure Gauge and Fuel Pressure Adapter J-44321-6, release fuel pressure to zero. Refer to "FUEL PRESSURE RELEASE".Tightening torque: 1 - 1.5 N·m (0.1 - 0.15 kg-m, 9 - 13 in-lb)
At idling: Approximately 350 kPa (3.57 kg/cm
2, 51 psi)
PBIB2983E
PBIB2984E
Revision: May 2010
2011 Versa
Page 1795 of 3787
![NISSAN LATIO 2011 Service Repair Manual EVAP LEAK CHECKEC-501
< ON-VEHICLE MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
EVAP LEAK CHECK
InspectionINFOID:0000000005930167
CAUTION:
• Do not use compressed air or a high pressure pu](/img/5/57357/w960_57357-1794.png "NISSAN LATIO 2011 Service Repair Manual EVAP LEAK CHECKEC-501
< ON-VEHICLE MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
EVAP LEAK CHECK
InspectionINFOID:0000000005930167
CAUTION:
• Do not use compressed air or a high pressure pu")
EVAP LEAK CHECKEC-501
< ON-VEHICLE MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
EVAP LEAK CHECK
InspectionINFOID:0000000005930167
CAUTION:
• Do not use compressed air or a high pressure pump.
• Do not exceed 4.12 kPa (0.042 kg/cm
2, 0.6 psi) of pressure in EVAP system.
NOTE:
• Do not start engine.
• Improper installation of EVAP service port adapter [commercial service tool: (J-41413-OBD)] to the EVAP service port may cause a leak.
WITH CONSULT-III
1. Install EVAP service port adapter [commercial service tool: (J- 41413-OBD)] and pressure pump to EVAP service port.
2. Turn ignition switch ON.
3. Select the “EVAP SYSTEM CLOSE” of “WORK SUPPORT” mode with CONSULT-III.
4. Touch “START”. A bar graph (Pressure indicating display) will appear on the screen.
5. Apply positive pressure to the EVAP system until the pressure indicator reaches the middle of the bar graph.
6. Remove EVAP service port adapter [commercial service tool: (J- 41413-OBD)] and hose with pressure pump.
7. Locate the leak using a leak detector [commercial service tool: (J-41416)]. Refer to EC-79, "
System Description".
WITHOUT CONSULT-III
1. Install EVAP service port adapter [commercial service tool: (J-
41413-OBD)] and pressure pump to EVAP service port.
2. Apply battery voltage between the terminals of EVAP canister vent control valve to make a closed EVAP system.
3. To locate the leak, deliver positive pressure to the EVAP system until pressure gauge points reach 1.38 to 2.76 kPa (0.014 to
0.028 kg/cm
2, 0.2 to 0.4 psi).
4. Remove EVAP service port adapter [commercial service tool: (J- 41413-OBD)] and hose with pressure pump.
SEF462UA
SEF200U
SEF462UA
Revision: May 2010 2011 Versa
Page 1796 of 3787
![NISSAN LATIO 2011 Service Repair Manual EC-502
< ON-VEHICLE MAINTENANCE >[HR16DE]
EVAP LEAK CHECK
5. Locate the leak using a leak detector [commercial service tool:
(J-41416)]. Refer to EC-79, "
System Description".
SEF200U
Revision: May 2](/img/5/57357/w960_57357-1795.png "NISSAN LATIO 2011 Service Repair Manual EC-502
< ON-VEHICLE MAINTENANCE >[HR16DE]
EVAP LEAK CHECK
5. Locate the leak using a leak detector [commercial service tool:
(J-41416)]. Refer to EC-79, \"
System Description\".
SEF200U
Revision: May 2")
EC-502
< ON-VEHICLE MAINTENANCE >[HR16DE]
EVAP LEAK CHECK
5. Locate the leak using a leak detector [commercial service tool:
(J-41416)]. Refer to EC-79, "
System Description".
SEF200U
Revision: May 2010 2011 Versa
Page 1797 of 3787
![NISSAN LATIO 2011 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EC-503
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS](/img/5/57357/w960_57357-1796.png "NISSAN LATIO 2011 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EC-503
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS")
SERVICE DATA AND SPECIFICATIONS (SDS)EC-503
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:0000000005930171
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Ignition TimingINFOID:0000000005930172
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Calculated Load ValueINFOID:0000000005930173
Mass Air Flow SensorINFOID:0000000005930174
*: Engine is warmed up to normal operating temperature and running under no load. Transmission
ConditionSpecification
A/T No load* (in P or N position) 700 ± 50 rpm
M/T No load* (in Neutral position) 650 ± 50 rpm
Transmission ConditionSpecification
A/T No load* (in P or N position) 6 ± 5 °BTDC
M/T No load* (in Neutral position) 6 ± 5 °BTDC
Condition Specification (Using CONSULT-III or GST)
At idle 10 – 35 %
At 2,500 rpm 10 – 35 %
Supply voltageBattery voltage (11 – 14 V)
Output voltage at idle 0.9 – 1.3V*
Mass air flow (Using CONSULT-III or GST) 1.0 – 4.0 g/s at idle*
2.0 – 10.0 g/s at 2,500 rpm*
Revision: May 2010 2011 Versa
Page 1798 of 3787
![NISSAN LATIO 2011 Service Repair Manual EC-504
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
SERVICE INFORMATION
INDEX FOR DTC
U0101-U1001INFOID:0000000006341677
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by S](/img/5/57357/w960_57357-1797.png "NISSAN LATIO 2011 Service Repair Manual EC-504
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
SERVICE INFORMATION
INDEX FOR DTC
U0101-U1001INFOID:0000000006341677
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by S")
EC-504
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
SERVICE INFORMATION
INDEX FOR DTC
U0101-U1001INFOID:0000000006341677
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
P0011-P0075INFOID:0000000006341678
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0101-P0128INFOID:0000000006341679
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
U0101 0101*4LOST COMM (TCM) EC-639
U0140
0140*4LOST COMM (BCM) EC-641
U1001
1001*4CAN COMM CIRCUIT EC-643
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0011 0011 INT/V TIM CONT-B1 EC-645
P00310031 A/F SEN1 HTR (B1) EC-649
P00320032 A/F SEN1 HTR (B1) EC-649
P00370037 HO2S2 HTR (B1) EC-654
P00380038 HO2S2 HTR (B1) EC-654
P00750075 INT/V TIM V/CIR-B1 EC-659
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0101 0101 MAF SEN/CIRCUIT-B1 EC-664
P01020102 MAF SEN/CIRCUIT-B1 EC-672
P01030103 MAF SEN/CIRCUIT-B1 EC-672
P01120112 IAT SEN/CIRCUIT-B1 EC-679
P01130113 IAT SEN/CIRCUIT-B1 EC-679
P01160116 ECT SEN/CIRC EC-683
P01170117 ECT SEN/CIRC EC-683
P01180118 ECT SEN/CIRC EC-683
P01220122 TP SEN 2/CIRC-B1 EC-691
P01230123 TP SEN 2/CIRC-B1 EC-691
P01250125 ECT SENSOR EC-696
Revision: May 2010 2011 Versa
Page 1799 of 3787
![NISSAN LATIO 2011 Service Repair Manual INDEX FOR DTCEC-505
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagno](/img/5/57357/w960_57357-1798.png "NISSAN LATIO 2011 Service Repair Manual INDEX FOR DTCEC-505
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagno")
INDEX FOR DTCEC-505
< SERVICE INFORMATION > [MR18DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0130-P0183INFOID:0000000006341680
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescri bed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0222-P0420INFOID:0000000006341681
P0127 0127 IAT SENSOR-B1 EC-699
P01280128 THERMSTAT FNCTN EC-702
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
DTC*1 Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0130 0130 A/F SENSOR1 (B1) EC-704
P01310131 A/F SENSOR1 (B1) EC-710
P01320132 A/F SENSOR1 (B1) EC-716
P01370137 HO2S2 (B1) EC-722
P01380138 HO2S2 (B1) EC-731
P01390139 HO2S2 (B1) EC-741
P014C014C A/F SENSOR1 (B1) EC-750
P014D014D A/F SENSOR1 (B1) EC-750
P01710171 FUEL SYS-LEAN-B1 EC-758
P01720172 FUEL SYS-RICH-B1 EC-764
P01810181 FTT SENSOR EC-770
P01820182 FTT SEN/CIRCUIT EC-774
P01830183 FTT SEN/CIRCUIT EC-774
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0222 0222 TP SEN 1/CIRC-B1 EC-778
P02230223 TP SEN 1/CIRC-B1 EC-778
P03000300 MULTI CYL MISFIRE EC-783
P03010301 CYL 1 MISFIRE EC-783
P03020302 CYL 2 MISFIRE EC-783
P03030303 CYL 3 MISFIRE EC-783
P03040304 CYL 4 MISFIRE EC-783
P03270327 KNOCK SEN/CIRC-B1 EC-789
P03280328 KNOCK SEN/CIRC-B1 EC-789
P0335 0335 CKP SEN/CIRCUIT EC-793
Revision: May 2010 2011 Versa
Page 1800 of 3787
![NISSAN LATIO 2011 Service Repair Manual EC-506
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnosti](/img/5/57357/w960_57357-1799.png "NISSAN LATIO 2011 Service Repair Manual EC-506
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnosti")
EC-506
< SERVICE INFORMATION >[MR18DE]
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0441-P0463INFOID:0000000006341682
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
P0500-P0643INFOID:0000000006341683
P0340 0340 CMP SEN/CIRC-B1 EC-799
P04200420 TW CATALYST SYS-B1 EC-805
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
DTC*1 Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0441 0441 EVAP PURG FLOW/MON EC-810
P04420442 EVAP SMALL LEAK EC-815
P04430443 PURG VOLUME CONT/V EC-822
P04440444 PURG VOLUME CONT/V EC-830
P04450445 PURG VOLUME CONT/V EC-830
P04470447 VENT CONTROL VALVE EC-836
P04480448 VENT CONTROL VALVE EC-842
P04510451 EVAP SYS PRES SEN EC-848
P04520452 EVAP SYS PRES SEN EC-851
P04530453 EVAP SYS PRES SEN EC-858
P04550455 EVAP GROSS LEAK EC-866
P04560456 EVAP VERY SML LEAK EC-873
P04600460 FUEL LEV SEN SLOSH EC-881
P04610461 FUEL LEVEL SENSOR EC-883
P04620462 FUEL LEVL SEN/CIRC EC-885
P04630463 FUEL LEVL SEN/CIRC EC-885
DTC*1
Items
(CONSULT-III screen terms) Reference
CONSULT-III
GST*
2ECM*3
P0500 0500 VEH SPEED SEN/CIRC EC-887
P05060506 ISC SYSTEM EC-889
P05070507 ISC SYSTEM EC-891
P050A050A COLD START CONTROL EC-893
P050B050B COLD START CONTROL EC-893
P050E050E COLD START CONTROL EC-893
P06050605 ECM EC-895
Revision: May 2010 2011 Versa
