NISSAN LEAF 2016 1.G Navigation Manual


> (GLW    0RGHO (1-1 (91$01&*. @
*8:
Push to open the monitor to access the CD
slot.
*9CD slot:
Insert a CD with the label side facing up.
*10<>:
Push to eject a CD.
STEERING WHEEL MOUNTED
AUDIO CONTROL BUTTONS
ENJN1502-8D8B77B0-542F-4040-8910-08948E84EDF4
5GA0115X
*1:
Push the switch to change the mode to
available audio source.
*2<>/<>:
Tilting the switch up/down while the audio
system is turned on can operate the audio system such as changing tracks and radio
preset stations or channels.
*3<-+ >
(Volume control):
Push + or - side of the switch to adjust the
volume.
AUDIO OPERATIONSENJN1502-8910DA01-FA52-4035-BC56-AEEA46A2B06E
AUDIO MAIN OPERATIONENJN1502-120906-21A3D1F2-D88E-4CCE-B170-B9485A368E7F
Turning audio system on/offENJN1502-120906-DEC1D39C-0B79-4535-9FBF-86BD31187CDDThe power switch must be pushed to the ACC or
ON position to turn on the audio system. Push
<
> to turn on the last audio source that was
playing immediately before the system was
turned off. Touching [Audio] on the Launch Bar
will also turn on the audio system and the
corresponding audio screen will be displayed for
operation. To turn off the audio system, push
<
> again.
INFO:
Even when the audio system is turned off,
operating the buttons/keys for audio may turn
on the audio system.
&RQGLWLRQ
4-11
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
Selecting audio sourceENJN1502-120906-2A84B441-03C2-4E17-9A89-AC3DD54D9273
5GA0116X
1. Touch [Audio] on the Launch Bar when theaudio screen is displayed.
2. Select an item from the audio source menu screens.
INFO:
. Touching [Source] on the upper left corner of
the audio screen will also display the audio
source menu screen.
. Pushing switches on the control panel and
the steering wheel can also be used to
change audio sources.
ªAudio main buttonsº (page 4-10)
ªSteering wheel mounted audio con-
trol buttonsº (page 4-11)
RADIOENJN1502-120906-952EDDB7-2BDB-4ADF-BF9F-C1407C8FAA3E
How to view radio screenENJN1502-120906-C7E211CC-F05B-44A2-86A6-770B8278B318
5GA0061X
&RQGLWLRQ
4-12
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
The radio screen can be viewed and operated on
the touch screen display.
*1[AM Menu]/[FM Menu]/[SXM Menu]:
Touch to display the radio menu screen.
ªRadio Menuº (page 4-15)
*2[Source]:
Touch to display the audio source screen to
select the other audio source.
ªSelecting audio sourceº (page 4-12)
*3Preset number:
A preset number is displayed if the current
frequency is stored as a preset station or
channel.
*4Audio source indicator:
Indicates the currently selected audio
source.
*5Reception information display:
Reception information currently available
such as frequency, station, or channel name,
etc. are displayed.
*6Turn direction indicator:
When a route to the destination is set,
turning direction and the distance to the
next turn is displayed.
*7TAG indicator (for U.S.):
TAG indicator is displayed if the iTunes


> (GLW    0RGHO (1-1 (91$01&*. @
To tune channels manually, tilt and hold
<
>/<>on the steering wheel.
Seek tuning (AM and FM):
Pushing and holding for 0.5
seconds or more will seek tune the stations and
stop at the frequency where a broadcast is
detected. The stations will be skipped until the
button is released.
Tilt and hold <
>/<>on the steering
wheel to seek up/down to the next receivable
broadcast station.
Scan tuning:
To scan tune the stations/channels, touch [FM
Menu], [AM Menu] or [SXM Menu] on the radio
screen and then touch [SCAN]. The stations/
channels will be tuned from low to high
frequencies and stop at each broadcasting
station/channel for several seconds. Touching
[SCAN] again during this period of several
seconds will stop scan tuning and the radio will
remain tuned to that station/channel.
Presetting:
Up to 6 for AM, 12 for FM and 18 for SXM
stations/channels can be registered in the preset
list. 1. Select a radio band (AM, FM or SXM) .
2. Tune to the station/channel you wish to store
in the preset list.
3. Touch and hold one of the preset numbers in the preset list.
4. The information such as frequency (AM/FM) , channel number (SXM) , etc. will be dis-
played on the preset list.
To select and listen to the preset stations/
channels, tilt <>/<>on the steering
wheel briefly or touch a preferred station/channel
on the preset list on the radio screen.
&RQGLWLRQ
4-14
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
Radio MenuENJN1502-D950716C-9E53-45AA-A4AF-8EC5B4A2CD6ETouch [FM Menu], [AM Menu], and [SXM Menu] on the FM, AM or SXM screen to display the corresponding screen.
The following items are available.
[FM Menu]/[AM Menu]:
[Scan]Touch to scan tune the stations.ªRadio operationº (page 4-13)
[Tag]
(HD Radio broadcasts only) Touch to register the tag information for iTunes


> (GLW    0RGHO (1-1 (91$01&*. @
[Categories/Genres]Touch to display the category/genre list.
[Customize Channel List] Touch to customize the channel list. Only the selected channels will be tuned in to when you seek
or scan the channels. You can select each item or select [All Select]/[All Clear].
[Favorite Artists] Touch to display a list of saved artists. Up to 8 artists can be stored. To turn on alerts for a favorite
artist, select the artist and touch [Turn all alerts ON]. Touch [Delete All Favorites] to delete all the
registered favorite artists.
[Favorite Songs] Touch to display a list of saved songs. Up to 8 songs can be stored. To turn on alerts for a favorite
song, select the song and touch [Turn all alerts ON]. Touch [Delete All Favorites] to delete all the
registered favorite songs.
[Direct Tune] Touch to display the keypad to enter the frequency and directly tune to the channel. Touch [Now
Playing] to return to the SXM screen.
[Artist Alert History] Touch to display the artist alert history.
[Song Alert History] Touch to display the song alert history. Touch [Now Playing] to return to the SXM screen.
[Alert Settings] [Alerts for Artists]Touch to turn on/off the alert notice.
Favorite artists and songs can be registered to receive an alert notice when a song of the
registered conditions is on the radio. To tune to the respective channel, touch [Tune] on the alert
screen. The alert can be ignored by touching [Cancel].
[Alerts for Songs]
[Alerts on non-Audio
screens]
[Channel Lock Settings]* [Use Channel Lock] Turn this item on to activate the channel lock function. [Passcode Change] Touch to display the keyboard screen to change the passcode.
[Lock Channel Setting] Touch to display the Lock Channel setting screen. Touch and turn on the indicator of the channelson the list you wish to lock out.
*: The default passcode is ª1234º.
&RQGLWLRQ
4-16
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
INFO:
. SiriusXM services require a subscription after trial period and are sold separately or as a package. The satellite service is available only in the 48
contiguous USA and DC. SiriusXM satellite service is also available in Canada; see www.siriusxm.ca.
. It may take some time to receive the activation signal after the initiation of the SiriusXM Satellite Radio subscription. After receiving the activation signal,
an available channel list will automatically be updated in the radio. Change the position of the power switch from LOCK to ACC to update the SiriusXM
channel list.
&RQGLWLRQ
4-17
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
COMPACT DISC (CD) PLAYERENJN1502-120906-A28D720F-2D75-4FE8-83A3-198D5B21527C
How to view CD screenENJN1502-120906-E902B692-E481-4875-91FE-430C4B4967C6
5GA0062X
*1[CD Menu]:
Touch to display the CD Menu screen.
ªCD Menuº (page 4-20)
*2[Source]:
Touch to switch to the source select screen.
ªSelecting audio sourceº (page 4-12)
*3Track information:
Track information such as the song title,
artist name and album name are displayed.
*4Audio source indicator:
Indicates that CD is currently selected
among available sources.
*5Turn direction indicator:
When a route to the destination is set, the
turn direction and the distance to the next
turn are displayed.
*6Play time and progress bar:
The play time of the track is displayed. The
bar indicates the progress in playing the
current track.
*7CD operation keys:
Touch an icon for operations.
&RQGLWLRQ
4-18
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
[] Each time [] is touched, the
repeat mode changes.
ªChanging play modeº
(page 4-19)
[
] Touch once to return to the begin- ning of the current track. Touch again
to select the previous track. Touch
and hold to rewind the current track.
[
] Touch to pause the track.
[
] Touch to play the track.
[
] Touch to select the next tack. Touch and hold to fast-forward the track.
[
] Each time [] is touched, the
random mode changes.
ªChanging play modeº
(page 4-19)
*8Track and folder number:
Indicates the track number and the folder
number.
*9Data type indicator:
Indicates the type of data currently playing.
CD player operationENJN1502-28CAF061-63D9-4EF3-8A20-5A9D2E94AB19
Loading:
Push to open the monitor to
access the CD slot.
Insert a CD into the slot with the label side facing
up. The CD will be guided automatically into the
slot and start playing.
After loading the CD, the CD screen will appear
on the display.
Push again to close the monitor
or wait till the monitor closes automatically.
Activation and playing:
The CD mode can be also selected from the
source list with a CD loaded.
ªSelecting audio sourceº (page 4-12)
Skipping tracks:
To skip the tracks, push ,
touch [
]/[] on the screen, or tilt up/down
<
>/<> on the steering wheel repeatedly
until preferred track is selected.
INFO:
Depending on the condition, skipping to the
previous track may require pushing the button or
touching the key twice. Pushing the button or
touching the key once may only restart the
currently track from the beginning.
Changing folders:
To change folders, touch [CD Menu] and touch
[Folder List].
ªCD Menuº (page 4-20)
Fast-forwarding/rewinding:
The following operation methods are available for
rewinding and fast-forwarding the track.
Control panel operation: . Push and hold .
. Touch and hold [
]/[].
Steering wheel switch operation: . Tilt and hold <
>/<>on the steering
wheel.
Changing play mode:
Repeat mode
Touch [
] on the CD screen to change the
repeat mode as follows.
&RQGLWLRQ
4-19
4. Audio system


> (GLW    0RGHO (1-1 (91$01&*. @
.CD:
[Disc] Û[1 Track]
. CD with compressed audio files:
[All] ?[1 Track] ?[1 Folder] ?[All]
Random mode
Touch [
] on the CD screen to change the
random mode as follows.
. CD:
(off) Û[Disc]
. CD with compressed audio files:
(off) ?[1 Folder] ?[All] ?(off)
Ejecting CD:
Push to open the monitor to
access the CD slot.
Push <
>to eject a CD. If the CD is ejected
and left unremoved, it will be reloaded into the
slot for protection.
Push again to close the monitor
or wait till the monitor closes automatically.
INFO:
The power switch must be pushed to the ACC or
ON position in order for the CD to eject.
CD MenuENJN1502-BD38972D-E8A7-43E7-A28D-CE746107BE8DTouch [CD Menu] on the CD screen to display
the CD menu screen.
The following items are available.
[Now Playing] Touch to return to the CD screen.
[SCAN] Touch to scan the tracks on the CD. During scanning, the first
several seconds of all the tracks
will be played. Touching [Scan]
again will cancel the scanning
mode and the CD will return to
play normally from the track
which is playing.
[Folder List]* Touch to display the folder list. Touch an item on the list to
select the folder.
Touch [
] and go back to the
previous screen to select tracks
in the folder.
Track List A list of the tracks on the CD is displayed. Touch an item on the
list to select the track.
*: Displayed only when available.
&RQGLWLRQ
4-20
4. Audio system
