WARNING
Be sure the ignition key is in the OFF or
LOCK position. The engine could rotate
unexpectedly.
1. Power steering oil pump
2. Idler pulley
3. Alternator
4. Crankshaft pulley
5. Air conditioner compressor
: Tension checking pointsVisually inspect each belt for signs of unusual
wear, cuts, fraying, oil adhesion or looseness. If
the belt is in poor condition or loose, have it
replaced or adjusted by a NISSAN dealer.
Have the belts checked regularly for condition
and tension.
WARNING
Be sure the engine and ignition switch
are off and that the parking brake is
engaged securely.
CAUTION
Be sure to use the correct socket to
remove the spark plugs. An incorrect
socket can damage the spark plugs.
SDI0141B
DRIVE BELTS SPARK PLUGS8-16
Maintenance and do-it-yourself
06.7.5/Z50-D/V5.0
Page 282 of 345
REPLACING SPARK PLUGS
Platinum-tipped spark plugsIt is not necessary to replace the platinum-tippedAspark plugs as frequently as the conventional
type spark plugs since they will last much longer.
Follow the maintenance log, but do not reuse
them by cleaning or regapping.
If replacement is required, see a NISSAN dealer
for servicing.
Always replace with recommended
platinum-tipped spark plugs.To remove the filter from the air cleaner, push
down the lock pins
1
and pull the unit upward
2.
The filter element should not be cleaned and
reused. Replace it according to the maintenance
log shown in the separate Service and Mainte-
nance Guide. When replacing the filter, wipe the
inside of the air cleaner housing and the cover
with a damp cloth.
WARNING
Operating the engine with the aircleaner removed can cause you or
others to be burned. The air cleaner
not only cleans the air, it stops the
flame if the engine backfires. If it isn’t
there, and the engine backfires, you
could be burned. Do not drive with
the air cleaner removed, and be care-
ful when working on the engine with
the air cleaner removed.
Never pour fuel into the throttle body
or attempt to start the engine with
the air cleaner removed. Doing so
could result in serious injury.
SDI0145C
SDI1495
AIR CLEANER
Maintenance and do-it-yourself
8-17
06.7.5/Z50-D/V5.0
Page 283 of 345
CAUTION
After wiper blade replacement, return
the wiper arm to its original position.
Otherwise it may be damaged when
the engine hood is opened.
Make sure the wiper blade contact
the glass, otherwise the arms may be
damaged from wind pressure.
Worn windshield wiper blades can
damage the windshield and impair
driver vision.CLEANINGIf your windshield is not clear after using the
windshield washer or if a wiper blade chatters
when running, wax or other material may be on
the blade or windshield.
Clean the outside of the windshield with a
washer solution or a mild detergent. Your wind-
shield is clean if beads do not form when rinsing
with clear water.
Clean the blade by wiping it with a cloth soaked
in a washer solution or a mild detergent. Thenrinse the blade with clear water. If your wind-
shield is still not clear after cleaning the blades
and using the wiper, replace the blades.
REPLACINGReplace the wiper blades if they are worn.
1. Turn the ignition switch to the ON position
and the windshield wiper switch ON. Turn the
ignition switch OFF when the wiper is in the
fully up position. The wiper will stop as
illustrated.
The wiper should be in the fully up position
to avoid scratching the engine hood or
wiper arm.
2. Pull the wiper arm up.
Hold the wiper arm to avoid hitting the
SDI1503
WINDSHIELD WIPER BLADES8-18
Maintenance and do-it-yourself
06.7.5/Z50-D/V5.0
Page 284 of 345
windshield and damaging the glass.
3. Push the release tab
A, and then move the
wiper blade down the wiper arm
1
while
pushing the release tabto remove.
4. Insert the new wiper blade to the wiper arm
until a click sounds.
If you wax the surface of the hood, be
careful not to let wax get into the washer
nozzle. This may clog the nozzle
A
that
could cause improper windshield washer
operation. If wax gets into the nozzle, un-
clog it with a needle or small pin
B.
SDI2040
SDI1496
Maintenance and do-it-yourself
8-19
06.7.5/Z50-D/V5.0
Page 285 of 345
Contact a NISSAN dealer if checking or replace-
ment is required.
SELF-ADJUSTING BRAKESYour vehicle is equipped with self-adjusting
brakes.
The disc-type brakes self-adjust every time the
brake pedal is applied.
WARNING
See a NISSAN dealer and have it
checked if the brake pedal height does
not return to normal.BRAKE PAD WEAR INDICATORSThe disc brake pads on your vehicle have au-
dible wear indicators. When a brake pad re-
quires replacement, it will make a high pitched
scraping or screeching sound when the vehicle
is in motion whether or not the brake pedal is
depressed. Have the brakes checked as soon as
possible if the wear indicator sound is heard.
Under some driving or climate conditions, occa-
sional brake squeak, squeal or other noise may
be heard. Occasional brake noise during light to
moderate stops is normal and does not affect
the function or performance of the brake system.
Proper brake inspection intervals shouldbe followed.For additional information, see the
separate Service and Maintenance Guide.
REAR WINDOW WIPER BLADE BRAKES8-20
Maintenance and do-it-yourself
06.7.5/Z50-D/V5.0
Page 286 of 345
Some vehicles are equipped with engine com-
partment and passenger compartment fuse
boxes that use only type
A
fuses. Other ve-
hicles are equipped with typeA
fuses in the
engine compartment fuse box and type
Bfuses
in the passenger compartment fuse box.
Type
Afuses are provided as spare fuses. They
are stored in the passenger compartment fuse
box.
Type
A
fuses can be installed in the engine
compartment and passenger compartment fuse
boxes.If a type
A
fuse is used to replace a type
B
fuse, the type
A
fuse will not be level with the
fuse pocket as shown in the illustration. This will
not affect the performance of the fuse. Make
sure the fuse is installed in the fuse box securely.
Type
B
fuses cannot be installed in the under-
hood fuse boxes. Only use type
A
fuses in the
underhood fuse boxes.
ENGINE COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
SDI1751
SDI1752
SDI1504
FUSES
Maintenance and do-it-yourself
8-21
06.7.5/Z50-D/V5.0
Page 287 of 345
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and headlight
switch are OFF.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open
A, replace it with a new
fuse
B.
6. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
Fusible linksIf any electrical equipment does not operate and
fuses are in good condition, check the fusible
links. If any of these fusible links are melted,
replace only with genuine NISSAN parts.
SDI1753
Type A
SDI1754
Type B
8-22
Maintenance and do-it-yourself
06.7.5/Z50-D/V5.0
Page 288 of 345
PASSENGER COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and the headlight
switch are OFF.2. Pull to open the fuse box lid
1.
3. Pinch the fuse perpendicularly with the fuse
puller
A
and pull it out.
4. If the fuse is open, replace it with a new fuse
B.
5. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
KEYFOBReplace the battery as follows:
1. Open the lid using a suitable tool.
2. Replace the battery with a new one.
SDI1505
SPA1374
BATTERY REPLACEMENT
Maintenance and do-it-yourself
8-23
06.7.5/Z50-D/V5.0
Page 289 of 345
Recommended battery: Sanyo CR2025 or
equivalent
Make sure that the
⊕
side faces the
bottom case.
3. Close the lid securely.
4. Push the keyfobbutton two or three times to
check its operation.
See a NISSAN dealer if you need any assistance
for replacement.
If the battery is removed for any reason
other than replacement, perform step 4
above.
Be careful not to touch a circuit board
and a battery terminal.
An improperly disposed battery can
harm the environment. Always confirm
local regulations for battery disposal.
The keyfob is water-resistant; however,
if it does get wet, immediately wipe
completely dry.
When changing batteries, do not let
dust or oil get on the keyfob.
FCC Notice:
Changes or modifications not expressly
approved by the party responsible for com-pliance could void the user’s authority to
operate the equipment. This device com-
plies with Part 15 of the FCC Rules and
RSS-210 of Industry Canada. Operation is
subject to the following two conditions: (1)
This device may not cause harmful interfer-
ence, and (2) this device must accept any
interference received, including interfer-
ence that may cause undesired operation
of the device.
SDI1792
8-24
Maintenance and do-it-yourself
06.7.5/Z50-D/V5.0
Page 290 of 345
INTELLIGENT KEY
CAUTION
Be careful not to allow children to swal-
low the battery and removed parts.
Replace the battery as follows:
1. Release the lock knobat the back of the
intelligent key and remove the mechanical
key.
2. Insert a flat-blade screwdriver
A
wrapped
with a cloth into the slit
B
of the corner and
twist it to separate the upper part from the
lower part.
3. Replace the battery with a new one.
Do not touch the internal circuit and electric
terminals as it could cause a malfunction.
Recommended battery: CR2025 or equiva-
lent
Make sure that the⊕side faces the
bottom of the case.
4. Close the lid securely as illustrated
12.
5. Push the buttons two or three times to check
its operation.See a NISSAN dealer if you need any assistance
for replacement.
If the battery is removed for any reason
other than replacement, perform step 5
above.
Be careful not to touch the circuit board
and the battery terminal.
An improperly disposed battery can
harm the environment. Always confirm
local regulations for battery disposal.
When changing batteries, do not let
dust or oil get on the Intelligent Key.
FCC Notice:
This equipment has been tested and found
to comply with the limits for a Class B
digital device pursuant to part 15 of the
FCC Rules (the certification number).
These limits are designed to provide rea-
sonable protection against harmful inter-
ference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruc-
tions, may cause harmful interference to
radio communications. However, there is
no guarantee that interference will not oc-
cur in a particular installation. If this equip-
ment does cause harmful interference toradio or television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
— Reorient or relocate the receiving an-
tenna
— Increase the separation between the
equipment and the receiver
— Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
— Consult the dealer or an experienced
radio/TV technician for help.
Maintenance and do-it-yourself
8-25
06.7.5/Z50-D/V5.0
