NISSAN NOTE 2016 Service Repair Manual

AV-196
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUIT
U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUIT
DTC LogicINFOID:0000000012433054
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012433055
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CHECK LH SIDE CAMERA POWER SUPPLY AND GROUND CIRCUIT CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect around view monitor control unit and LH side camera connectors.
3. Check continuity between around view monitor control unit connector B54 and LH side camera connector D4.
4. Check continuity between around view m onitor control unit connector B54 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connectors.
2.CHECK LH SIDE CAMERA POWER SUPPLY VOLTAGE
1. Connect around view monitor control unit and LH side camera connectors.
2. Turn ignition switch ON.
3. Check voltage between around view monitor control unit connector B54 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace around view monitor control unit. Refer to AV-249, "
Removal and Installation".
3.CHECK LH SIDE CAMERA IMAGE SIGNAL A ND IMAGE SIGNAL GROUND CIRCUIT CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect around view monitor control unit and LH side camera connectors.
CONSULT Display DTC Detection Condition Possible Cause
Left side display output signal
diagnosis (Harness disconnec-
tion)
[ U 111 D ] Left side camera image signal circuit open or
short.
Check left side camera image signal circuit.
Around view monitor control unit
LH side camera
Continuity
Connector TerminalsConnector Terminals
B54 30
D4 2
Ye s
29 1
Around view monitor control unit
GroundContinuity
Connector Terminal
B54 30 No
Around view monitor control unit
GroundCondition Vol tag e
(Approx.)
Connector Terminal
B54 30—CAMERA switch is ON or
selector lever in R (re-
verse).
6.0 V
Revision: August 2015
2016 Versa Note

cardiagn.com

AV
U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUITAV-197
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
3. Check continuity between around view monitor cont rol unit connector B54 and LH side camera connector
D4.
4. Check continuity between around view monitor control unit connector B54 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connectors.
4.CHECK LH SIDE CA MERA IMAGE SIGNAL
1. Connect around view monitor control unit and LH side camera connectors.
2. Turn ignition switch ON.
3. Check signal between the terminals of around view monitor control unit connector B54.
Is the inspection result normal?
YES >> Replace around view monitor control unit. Refer to AV-249, "Removal and Installation".
NO >> Replace LH side camera. Refer to AV-252, "
Removal and Installation".
Around view monitor control unit LH side camera
Continuity
Connector TerminalsConnector Terminals
B54 32
D4 8
Ye s
31 7
Around view monitor control unit
GroundContinuity
Connector Terminal
B54 32 No
Around view monitor control unit connector B54
ConditionReference value
(+) (− )
Terminal Terminal
32 31CAMERA switch is ON or se-
lector lever in R (reverse).
JSNIA0834GB
Revision: August 2015
2016 Versa Note

cardiagn.com

AV-198
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
U1200 AV CONTROL UNIT
U1200 AV CONTROL UNIT
DTC LogicINFOID:0000000012433056
DTC DETECTION LOGIC
CONSULT Display
DTC Detection Condition Possible Cause
Cont Unit
[U1200] Abnormalities are detected in Navigation control
unit. Replace AV control unit if malfunction occurs
constantly.
Refer to AV-241, "
Removal and Installation".
Revision: August 2015
2016 Versa Note

cardiagn.com

AV
U1217 AV CONTROL UNITAV-199
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
U1217 AV CONTROL UNIT
DTC LogicINFOID:0000000012433057
DTC DETECTION LOGIC
CONSULT Display DTC Detection Condition Possible Cause
BLUETOOTH MODULE
[U1217] Connection failure to the internal Bluetooth
® sub
unit is detected. Replace AV control unit if malfunction occurs
constantly.
Refer to AV- 2 4 1 , "
Removal and Installation".
Revision: August 2015
2016 Versa Note

cardiagn.com

AV-200
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
U1229 AV CONTROL UNIT
U1229 AV CONTROL UNIT
DTC LogicINFOID:0000000012433058
DTC DETECTION LOGIC
CONSULT Display
DTC Detection Condition Possible Cause
iPod CERTIFICATION
[U1229] iPod authentication chip error. Replace AV control unit if malfunction occurs
constantly.
Refer to AV-241, "
Removal and Installation".
Revision: August 2015
2016 Versa Note

cardiagn.com

AV
U122F AV CONTROL UNITAV-201
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
U122F AV CONTROL UNIT
DTC LogicINFOID:0000000012433059
DTC DETECTION LOGIC
CONSULT Display DTC Detection Condition Possible Cause
Digital broadcasting connection
error
[U122F] Communication error with digital audio broadcast
module internal to AV control unit. Replace AV control unit if malfunction occurs
constantly.
Refer to AV- 2 4 1 , "
Removal and Installation".
Revision: August 2015
2016 Versa Note

cardiagn.com

AV-202
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
U1232 STEERING ANGLE SENSOR
U1232 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000012433060
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012433061
1.ADJUST THE NEUTRAL POSITION OF THE STEERING ANGLE SENSOR
When U1232 is detected, adjust the neutral position of the steering angle sensor.
>> Perform adjustment of the neutral position of the steering angle sensor. Refer to AV-146, "
CON-
SULT Function".
CONSULT DisplayDTC Detection Condition Possible Cause
ST ANG SEN CALIB
[U1232] The neutral position adjustment of the steering
angle sensor is incomplete. Adjust neutral position of the steering angle sen-
sor.
Revision: August 2015
2016 Versa Note

cardiagn.com

AV
U1244 GPS ANTENNAAV-203
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
U1244 GPS ANTENNA
DTC LogicINFOID:0000000012433062
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012433063
Regarding Wiring Diagram information, refer to AV-155, "Wiring Diagram".
1.GPS ANTENNA INSPECTION
Visually inspect the GPS antenna and antenna feeder. Refer to AV-253, "
Removal and Installation".
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning components.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Disconnect AV control unit connector M108.
2. Turn ignition switch ON.
3. Check voltage between AV control unit connector M108 and ground.
Is inspection result normal?
YES >> Replace GPS antenna. Refer to AV-253, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-241, "
Removal and Installation".
CONSULT DisplayDTC Detection Condition Possible Cause
GPS ANTENNA CONN
[U1244] Open or short to ground is detected in GPS an-
tenna connection. • GPS antenna disconnection.
• Open or short to ground in GPS antenna signal
circuit.
AV c o n t r o l u n i t Ground
Voltag e
Connector Terminal
M108 55—5.0 V
Revision: August 2015 2016 Versa Note

cardiagn.com

AV-204
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
U1258 SATELLITE RADIO ANTENNA
U1258 SATELLITE RADIO ANTENNA
DTC LogicINFOID:0000000012433064
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012433065
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.SATELLITE ANTENNA INSPECTION
Visually inspect the satellite antenna and antenna feeder. Refer to AV-256, "
Feeder Layout".
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning components.
2.CHECK AV CONTROL UNIT VOLTAGE
1. Turn ignition switch ON.
2. Check voltage between AV control unit connector M111 and ground.
Is inspection result normal?
YES >> Replace satellite radio antenna AV-254, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-241, "
Removal and Installation".
CONSULT DisplayDTC Detection Condition Possible Cause
XM ANTENNA CONN
[U1258] Open or short to ground is detected in satellite
antenna connection. • Satellite antenna disconnection.
• Open or short to ground in satellite antenna
signal circuit.
AV control unit GroundVoltage
Connector Terminal
M 111 5 7—5 . 0 V
Revision: August 2015 2016 Versa Note

cardiagn.com

AV
U1263 USBAV-205
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
U1263 USB
DTC LogicINFOID:0000000012433066
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM SELF DIAGNOSTIC RESULT
1. If there is a device connected to the USB interface, disconnect it.
2. Turn ignition switch ON and wait for 2 seconds or more.
3. Perform Self Diagnostic Result for MULTI AV.
Is DTC U1263 displayed?
YES >> Refer to AV-205, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012433067
1.CHECK USB INTERFACE HARNESS
Visually inspect USB interface harness. Refer to AV-245, "
Removal and Installation".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace USB interface harness. Refer to AV-245, "
Removal and Installation".
2.CHECK USB INTERFACE HARNESS
Check USB interface harness. Refer to AV-226, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace AV control unit. Refer to AV-241, "Removal and Installation".
NO >> Replace USB interface harness. Refer to AV-245, "
Removal and Installation".
CONSULT Display DTC Detection Condition Possible Cause
USB OVERCURRENT
[U1263] Overcurrent in USB harness is detected. • Device connected to USB interface.
• Harness between the AV control unit and USB
interface.
Revision: August 2015 2016 Versa Note
