NISSAN NOTE 2016 Service Repair Manual

PWC-50
< SYMPTOM DIAGNOSIS >
REAR RH SIDE POWER WINDOW DOES NOT OPERATE
REAR RH SIDE POWER WINDOW DOES NOT OPERATE
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW
SWITCH RH ARE OPERATED
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW
SWITCH RH ARE OPERATED : Diagnosis Procedure
INFOID:0000000012431843
1.CHECK REAR POWER WINDOW SWITCH RH
Check rear power window switch RH.
Refer to PWC-32, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK REAR POWER WINDOW MOTOR RH
Check rear power window motor RH.
Refer to PWC-37, "
REAR RH : Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
WHEN REAR POWER WINDOW SWITCH RH IS OPERATED
WHEN REAR POWER WINDOW SWITCH RH IS OPERATED : Diagnosis Procedure
INFOID:0000000012431844
1.CHECK REAR POWER WINDOW SWITCH RH POWER SUPPLY AND GROUND CIRCUIT
Check rear power window switch RH power supply and ground circuit.
Refer to PWC-28, "
REAR POWER WINDOW SWIT CH : Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK REAR POWER WINDOW SWITCH RH
Check rear power window switch RH.
Refer to PWC-32, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
WHEN POWER WINDOW MAIN SWITCH IS OPERATED
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR RH SIDE POWER WINDOW DOES NOT OPERATE
PWC-51
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure
INFOID:0000000012431845
1.CHECK REAR POWER WINDOW SWITCH RH
Check rear power window switch RH.
Refer to PWC-32, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
Revision: August 2015 2016 Versa Note

cardiagn.com

PWC-52
< SYMPTOM DIAGNOSIS >
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATE NORMAL-LY (DRIVER SIDE)
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATE NOR-
MALLY (DRIVER SIDE)
Diagnosis ProcedureINFOID:0000000012431846
1.REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
Replace main power window and door lock/unlock switch.
>> Refer to PWC-55, "
Removal and Installation".
Revision: August 2015 2016 Versa Note

cardiagn.com

POWER WINDOW RETAINED POWER OPERATION DOES NOT OPERATE
PROPERLY
PWC-53
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW RETAINED POWE R OPERATION DOES NOT OPER-
ATE PROPERLY
Diagnosis ProcedureINFOID:0000000012431847
1. CHECK FRONT DOOR SWITCH
Check front door switch.
Refer to PWC-40, "
WITH INTELLIGENT KEY SYST EM : Component Inspection" (with Intelligent Key system)
or PWC-42, "
WITHOUT INTELLIGENT KEY SYSTEM : Component Inspection" (without Intelligent Key sys-
tem).
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

PWC-54
< SYMPTOM DIAGNOSIS >
POWER WINDOW LOCK SWITCH DOES NOT FUNCTION
POWER WINDOW LOCK SWITCH DOES NOT FUNCTION
Diagnosis ProcedureINFOID:0000000012431848
1.REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
Replace main power window and door lock/unlock switch.
>> Refer to PWC-55, "
Removal and Installation".
Revision: August 2015 2016 Versa Note

cardiagn.com

MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCHPWC-55
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
REMOVAL AND INSTALLATION
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
Removal and InstallationINFOID:0000000012829245
REMOVAL
1. Remove main power window and door lock/unlock switch finisher door handle pull escutcheon.
2. Remove screw (A) from main power window and door lock/
unlock switch finisher.
3. Remove main power window and door lock/unlock switch fin- isher (1) using a suitable tool (B).
: Pawl
4. Disconnect the harness connectors from the ma in power window and door lock/unlock switch.
5. Release pawls and remove main power window and door lock/ unlock switch (1) from main power window and door lock/unlock
switch finisher assembly (2) using a suitable tool.
: Pawl
CAUTION:
Do not bend back the pawls on th e switch finisher too far or
damage may occur.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
When the main power window and door lock/unlock switch is removed or replaced, it is necessary to perform
the initialization procedure. Refer to PWC-23, "
Work Flow".
AWKIA2536ZZ
AWKIA2506ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PWC-56
< REMOVAL AND INSTALLATION >
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Removal and InstallationINFOID:0000000012829246
REMOVAL
1. Remove power window and door lock/unlock switch (RH) finisher door handle pull escutcheon.
2. Remove screw (B) from power window and door lock/unlock
switch (RH) finisher.
3. Remove power window and door lock/unlock switch (RH) fin- isher (1) using a suitable tool (A).
: Pawl
4. Disconnect the harness connector from the pow er window and door lock/unlock switch (RH).
5. Release pawls and remove power window and door lock/unlock switch (1) from power window and door lock/unlock switch (RH)
finisher (2) using a suitable tool.
: Pawl
CAUTION:
Do not bend back the pawls on the switch finisher too far or
damage may occur.
INSTALLATION
Installation is in the reverse order of removal.
AWKIA2505ZZ
AWKIA2507ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR POWER WINDOW SWITCHPWC-57
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
REAR POWER WINDOW SWITCH
Removal and InstallationINFOID:0000000012829247
REMOVAL
1. Remove rear power window switch door handle pull escutcheon.
2. Remove screw (A) from rear power window switch finisher.
3. Remove rear power window switch finisher (1) using a suitable tool (B).
: Pawl
4. Disconnect the harness connector from the rear power window switch.
5. Release pawls and remove rear power window switch (1) from rear power window switch finisher (2) using a suitable tool.
CAUTION:
Do not bend back the pawls on th e switch finisher too far or
damage may occur.
INSTALLATION
Installation is in the reverse order of removal.
AWKIA2510ZZ
AWKIA2511ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
