weight NISSAN NOTE 2016 Service Repair Manual

AV-182
< BASIC INSPECTION >[NAVIGATION]
INSPECTION AND ADJUSTMENT
Is the difference corrected?
YES >> On the CONSULT screen, touch “OK” button to complete writing to the around view monitor con-
trol unit.
NO >> GO TO 5.
5.PERFORM “CALIBRATING CAMERA IMAGE”
Preparation of target line
1. Hang a string with a weight as shown in the figure. Put the points FM0, RM0 (mark) on the ground at the
center of the vehicle front end and rear end with white packing tape or a pen.
2. Route the vinyl string under the vehicle, and then pull and fix it on the point approximately 1.0 m (39.9 in)
to the front and rear of the vehicle thr ough the points FM0 and RM0 using packing tape.
Target line preparation procedure 1
3. Put the points FM and RM (mark) 75 cm (29. 5 in) from the points FM0 and RM0 individually.
4. Route the vinyl string through the points FM and RM us ing a triangle scale, and then fix it at approximately
1.5 m (59 in) on both sides with packing tape.
5. Put the points FL, FR, RL, and RR (mark) to both right and left [vehicle width / 2 + 30 cm (11.8 in)] from the points FM and RM.
Target line preparation procedure 2
AWNIA3140ZZ
1. Thread 2. Weight3. Point FM0 (mark)
4. Point RM0 (mark) 5. Packing tape (to fix the vinyl string) 6. Vinyl string
JSNIA0921ZZ
1. Point FM 2. Point RM3. Triangle scale
4. Point FL (mark) 5. Point FR (mark) 6. Point RL (mark)
Revision: August 2015 2016 Versa Note

cardiagn.com

BRM-8
< PRECAUTION >
PRECAUTIONS IN REPAIRING HIGH STRENGTH STEEL
PRECAUTIONS IN REPAIRING HIGH STRENGTH STEEL
High Strength Steel (HSS)INFOID:0000000012430793
High strength steel is used for body panels in order to reduce vehicle weight.
Accordingly, precautions in repairing automotive bodies made of high strength steel are described below:
SP130 is the most commonly used HSS.
Read the following precautions when repairing HSS:
1. Additional points to consider
• The repair of reinforcements (such as side members) by heat-
ing is not recommended since it may weaken the component.
When heating is unavoidable, do not heat HSS parts above
550° C (1,022° F).
Verify heating temperature with a thermometer.
(Crayon-type and other similar type thermometer are appropri-
ate.)
• When straightening body panels, use caution in pulling any HSS panel. Because HSS is very strong, pulling may cause
deformation in adjacent portions of the body. In this case,
increase the number of measuring points, and carefully pull
the HSS panel.
• When cutting HSS panels, avoid gas (torch) cutting if possible. Instead, use a saw to avoid weakening surrounding areas due
to heat. If gas (torch) cutting is unavoidable, allow a minimum
margin of 50 mm (1.97in).
Tensile strength Nissan/Infiniti designation Major applicable parts
373 N/mm
2
(38kg/mm2,54klb/sq in) SP130• Front side member assembly
• Hoodledge assembly
• Upper dash
• Front pillar rein
forcement assembly
• Rear side member assembly
• Other reinforcements
PIIA0115E
PIIA0116E
PIIA0117E
Revision: August 2015 2016 Versa Note

cardiagn.com

COMPONENT PARTSBRC-9
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Switches the fluid pressure line to increase or hold according to signals from control unit.
ABS OUT Valve
Switches the fluid pressure line to increase, hold or decrease according to signals from control unit.
Cut Valve 1, Cut Valve 2
Shuts off the ordinary brake line from master cylinder, when VDC function and TCS function are activated.
Suction Valve 1, Suction Valve 2
Supplies the brake fluid from master cylinder to the pump, when VDC function and TCS function are activated.
Return Check Valve
Returns the brake fluid from brake caliper and wheel cyli nder to master cylinder by bypassing orifice of each
valve when brake is released.
Reservoir
Temporarily reserves the brake fluid drained from brake caliper, so that pressure efficiently decreases when
decreasing pressure of brake caliper and wheel cylinder.
Yaw rate/side/decel G sensor
Calculates the following information that affects the v ehicle, and transmits a signal to ABS actuator and elec-
tric unit (control unit) via communication lines:
• Vehicle rotation angular velocity (yaw rate signal)
• Vehicle lateral acceleration (side G signal) and longitudinal acceleration (decel G signal)
Pressure Sensor
Detects the brake fluid pressure and transmits signal to ABS actuator and electric unit (control unit).
Wheel Sensor and Sensor RotorINFOID:0000000012430829
NOTE:
• Wheel sensor of front wheel is installed on steering knuckle.
• Sensor rotor of front wheel is integrated in wheel hub assembly.
• Wheel sensor of rear wheel is installed on back plate of rear brake.
• Sensor rotor of rear wheel is installed on rear brake drum.
• Never measure resistance and voltage value using a tester because sensor is active sensor.
• Downsize and weight reduction is aimed. IC for detection portion
and magnet for sensor rotor are adopted.
• Power supply is supplied to detection portion so that magnetic field
line is read. Magnetic field that is detected is converted to current
signal.
• When sensor rotor rotates, magnetic field changes. Magnetic field
change is converted to current signals (rectangular wave) and is
transmitted to ABS actuator and electric unit (control unit). Change
of magnetic field is pr oportional to wheel speed.
Stop Lamp SwitchINFOID:0000000012430830
Detects the operation status of brake pedal and transmits converted electric signal to ABS actuator and elec-
tric unit (control unit).
Steering Angle SensorINFOID:0000000012430831
Detects the following information and transmits steering angle signal to ABS actuator and electric unit (control
unit) via CAN communication:
• Steering wheel rotation amount
• Steering wheel rotation angular velocity
• Steering wheel rotation direction
JPFIC0131GB
Revision: August 2015 2016 Versa Note

cardiagn.com

SYSTEMBRC-27
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Major signal transmission between each unit via communication lines is shown in the following table.
VDC/TCS/ABS : EBD FunctionINFOID:0000000012430840
SYSTEM DIAGRAM
• By preventing rear wheel slip increase through rear wheel brake force (brake fluid pressure) control that is
electronically controlled when slight skip on front and rear wheels are detected during braking, stability dur-
ing braking is improved.
• EBD function is expanded and developed from conventional ABS function and corrects rear wheel brake force to appropriate level by electronic control according to load weight (number of passengers).
Component Signal description
Combination meter Receives the following signals from ABS actuator and electric unit (control unit) via CAN com-
munication:
• VDC warning lamp signal
• ABS warning lamp signal
AWFIA0808GB
JPFIC0142GB
Revision: August 2015
2016 Versa Note

cardiagn.com

DLK-140
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
HOOD
REMOVAL AND INSTALLATION
HOOD
Exploded ViewINFOID:0000000012430085
HOOD ASSEMBLY
HOOD ASSEMBLY : Removal and InstallationINFOID:0000000012430086
CAUTION:
• Use two people when removing or installing hood assembly due to its heavy weight.
• Use protective tape or shop cloths to protect surrounding components from damage during removal
and installation of hood assembly.
REMOVAL
1. Support hood assembly using a suitable tool.
WARNING:
Bodily injury may occur if hood assembly is not supported properly when removing hood assem-
bly.
2. Remove hood hinge nuts and hood assembly.
3. Remove clips and hood insulator (if necessary).
INSTALLATION
1. Hood 2. Bumper rubber (hood side) 3. Hood insulator
4. Hood rod clamp 5. Bumper rubber (body side) 6. Hood rod grommet
7. Hood hinge (LH) 8. Hood support rod 9. Hood hinge (RH)
A. Hood insulator clip
AWKIA2564ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-142
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
HOOD
CLEARANCE ADJUSTMENT
1. Loosen hood hinge nuts and bolts.
2. Loosen hood lock assembly bolts.
3. Adjust the hood lock assembly so the clearance m
easurements are within the specifications provided.
4. Tighten hood hinge nuts and bolts to specified torque.
5. Tighten hood lock assembly bolts to specified torque.
HEIGHT ADJUSTMENT
1. Loosen hood lock assembly bolts.
2. Adjust the surface height of hood assembly to front upper grille, front fender and front combination lamp to
the specified values by rotating hood bumper rubber.
3. Temporarily tighten hood lock assembly bolts.
4. Adjust (A) as shown to the following value with hood’s own weight by dropping it from approximately 200 mm (7.87 in) height or by pressing hood lightly [approximately 29 N (3.0 kg, 6.5 lb)].
5. After adjustment, tighten hood lock assembly bolts to specified torque.
HOOD HINGE
HOOD HINGE : Removal and InstallationINFOID:0000000012430088
REMOVAL
1. Remove hood assembly. Refer to DLK-140, "HOOD ASSEMBLY : Removal and Installation".
2. Remove front fender. Refer to DLK-147, "
Removal and Installation".
3. Remove cowl top side cover. Refer to EXT-36, "
Exploded View".
4. Remove hood hinge bolts and hood hinge.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Before installing the hood hinge, apply anticorrosive agent onto the surface of the vehicle.
C – CH Clearance 3.5
± 1.0 (0.14 ± 0.04) 1.5 (0.06) 1.5 (0.06)
J Surface height 0.0 ± 1.5 (0.0 ± 0.06) 1.5 (0.06) 1.5 (0.06)
Section Item Measurement
StandardParallelism Equality
1. Hood striker 2. Secondary latch3. Primary latch
A. 20.0 mm (0.79 in)
ALKIA3162ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

FRONT DOORDLK-149
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
FRONT DOOR
Exploded ViewINFOID:0000000012430095
DOOR ASSEMBLY
DOOR ASSEMBLY : Removal and InstallationINFOID:0000000012430096
CAUTION:
• Use two people when removing or inst alling front door due to its heavy weight
• When removing and installing front door assembl y, support the door using a suitable tool.
• Do not use air tools or electric tools for servicing.
• Before servicing, turn ignition sw itch off, disconnect both battery terminals and wait at least three
minutes.
REMOVAL
1. Disconnect the battery positive and negative terminal s and wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove dash side finisher. Refer to INT-24, "
DASH SIDE FINISHER : Removal and Installation".
3. Disconnect the harness connectors from the front door.
4. Remove door check link bolt (body side).
5. Remove door hinge nuts (door side) and front door assembly.
INSTALLATION
1. Inside seal 2. Door sash front tape 3. Grommet (driver side only)
4. Door upper hinge 5. Door lower hinge6. Door check link
7. Front door panel 8. Lower grommet9. Upper grommet
10. Door striker 11. Body panel plug12. Door sash rear tape
AWKIA2492ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-152
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
FRONT DOOR
2. Adjust door striker so that it becomes parallel with front door lock
insertion direction.
3. Tighten door striker bolts to specification. Refer to DLK-149, "
Exploded View".
DOOR HINGE
DOOR HINGE : Removal and InstallationINFOID:0000000012430100
REMOVAL
CAUTION:
• Use two people when removing or installing front door due to its heavy weight
• When removing and installing front door assembly, support the door using a suitable tool.
• Use shops cloths to protect surrounding components from damage during removal and installation of front door assembly.
1. Remove front fender. Refer to DLK-147, "
Removal and Installation".
2. Remove front door assembly. Refer to DLK-149, "
DOOR ASSEMBLY : Removal and Installation".
3. Remove front door hinge bolts (body side) and front door hinge.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Apply anticorrosive agent to the hinge mating surface.
• After installation, perform the front door adjustment procedure. Refer to DLK-150, "
DOOR ASSEM-
BLY : Adjustment".
• Check door hinge rota ting point for poor lubrication. If neces-
sary, apply a suitable multi-purpose grease.
DOOR CHECK LINK
DOOR CHECK LINK : Re moval and InstallationINFOID:0000000012430101
REMOVAL
1. Remove front door speaker. Refer to AV-54, "Removal and Installation" (BASE AUDIO), AV-114,
"Removal and Installation" (DISPLAY AUDIO) or AV-243, "Removal and Installation" ( N AV I G AT I O N ) .
2. Remove door check link bolt (body side).
3. Remove door check link bolts (door side) and remove.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• After installation, check rear door open/close, lock/ unlock operation.
PIIB2804J
JMKIA8072ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-154
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
REAR DOOR
REAR DOOR
Exploded ViewINFOID:0000000012430102
DOOR ASSEMBLY
DOOR ASSEMBLY : Removal and InstallationINFOID:0000000012430103
CAUTION:
• Use two people when removing or instal
ling rear door due to its heavy weight.
• When removing and installing rear door assem bly, support door using a suitable tool.
REMOVAL
1. Remove rear door harness grommet (1) from body side outer
(2), then pull out rear door harness.
1. Door sash rear tape 2. Inside seal3. Door sash front tape
4. Door upper hinge 5. Door lower hinge 6. Door check link
7. Rear door panel 8. Door striker 9. Grommet
10. Body panel plug
AWKIA2570ZZ
JMKIA8083ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR DOORDLK-157
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
2. Loosen door hinge nuts (door side).
3. Adjust the surface height of rear door according to the specifications provided.
4. Temporarily tighten door hinge nuts (door side).
5. Loosen door hinge nuts and bolts (body side).
6. Raise rear door at rear end to adjust clearance of rear door according to the specifications provided.
7. After adjustment tighten bolts and nuts to the specified torque. CAUTION:
• Apply touch-up paint (body color) to the head of hinge bolts and nuts.
• Check door hinge rotating point for poor lubricat ion. If necessary, apply a suitable multi-purpose
grease.
8. Install center pillar lower finisher. Refer to INT-25, "
CENTER PILLAR LOWER FINISHER : Removal and
Installation".
DOOR STRIKER
DOOR STRIKER : Removal and InstallationINFOID:0000000012430105
REMOVAL
Remove bolts and rear door striker.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse door striker bolts.
• Tighten door striker bolts to specification. Refer to DLK-154, "
Exploded View".
• After installation, check front do or open/close operation. If necessary, adjust the door striker. Refer
to DLK-157, "
DOOR STRIKER : Adjustment".
DOOR STRIKER : AdjustmentINFOID:0000000012430106
DOOR STRIKER ADJUSTMENT
1. Loosen door striker bolts.
2. Adjust door striker so that it becomes parallel with rear door lock
insertion direction.
3. Tighten door striker bolts to specification. Refer to DLK-154, "
Exploded View".
DOOR HINGE
DOOR HINGE : Removal and InstallationINFOID:0000000012430107
REMOVAL
CAUTION:
• Use two people when removing or inst alling front door due to its heavy weight
• When removing and installing front door assembl y, support the door using a suitable tool.
• Use shops cloths to protect surro unding components from damage during removal and installation
of front door assembly.
1. Remove rear door assembly. Refer to DLK-154, "
DOOR ASSEMBLY : Removal and Installation".
2. Remove center pillar lower finisher. Refer to INT-25, "
CENTER PILLAR LOWER FINISHER : Removal
and Installation".
PIIB2804J
Revision: August 2015 2016 Versa Note

cardiagn.com
