NISSAN PICK-UP 2005 Repair Manual
Manufacturer: NISSAN, Model Year: 2005, Model line: PICK-UP, Model: NISSAN PICK-UP 2005Pages: 88, PDF Size: 1.77 MB
Page 1 of 88
GENERAL INFORMATIONGI
MAINTENANCEMA
ENGINE LUBRICATION &
COOLING SYSTEMSLC
ENGINE CONTROL SYSTEMEC
ACCELERATOR CONTROL, FUEL &
EXHAUST SYSTEMSFE
MANUAL TRANSAXLEMT
TRANSFERTF
FRONT AXLE & FRONT SUSPENSIONFA
REAR AXLE & REAR SUSPENSIONRA
BRAKE SYSTEMBR
STEERING SYSTEMST
RESTRAINT SYSTEMRS
BODY & TRIMBT
HEATER & AIR CONDITIONERHA
ELECTRICAL SYSTEMEL
ALPHABETICAL INDEXIDX
PICKUP
MODEL D22 SERIES
FOREWORD
This supplement contains informa-
tion concerning necessary service
procedures and relevant data for the
model D22 series.
All information, illustrations and spe-
ci®cations contained in this supple-
ment are based on the latest product
information available at the time of
publication. If your NISSAN model
differs from the speci®cations contain-
ed in this supplement, consult your
NISSAN distributor for information.
The right is reserved to make chan-
ges in speci®cations and methods at
any time without notice.
Edition:October 2005
Printing:October 2005 (01)
PublicationNo.:SM5E00-1D22E0E
ReferenceNo.:7711347678
NISSAN EUROPE S.A.S.
2005NISSANEUROPES.A.S.PrintedintheNetherlands
Not to be reproduced in whole or in part without the prior written permission of Nissan Europe S.A.S., Paris, France.
QUICK REFERENCE INDEX
RESTRAINT SYSTEMRS
ENGINE MECHANICALEM
CLUTCHCL
PROPELLER SHAFT &
DIFFERENTIAL CARRIERPD
Page 2 of 88
FOREWORD
This manual contains maintenance and repair procedures for NISSAN
PICKUP, model D22 series.
In order to assure your safety and the efficient functioning of the vehicle,
this manual should be read thoroughly. It is especially important that the
PRECAUTIONS in the GI section be completely understood before starting
any repair task.
All information in this manual is based on the latest product information
at the time of publication. The right is reserved to make changes in speci-
®cations and methods at any time without notice.
IMPORTANT SAFETY NOTICE
The proper performance of service is essential for both the safety of the
technician and the efficient functioning of the vehicle.
The service methods in this Service Manual are described in such a man-
ner that the service may be performed safely and accurately.
Service varies with the procedures used, the skills of the technician and the
tools and parts available. Accordingly, anyone using service procedures,
tools or parts which are not speci®cally recommended by NISSAN must
®rst completely satisfy himself that neither his safety nor the vehicle's
safety will be jeopardized by the service method selected.
NISSAN EUROPE S.A.S.
Service Engineering Section
Paris, France
Page 3 of 88
ELECTRICALSYSTEMSECTION
EL
MODIFICATION NOTICE:
I Wiring diagrams have been changed.
I Harness layouts have been changed.
CONTENTS
POWER SUPPLY ROUTING ...........................................2
Schematic ....................................................................2
Wiring Diagram Ð POWER Ð....................................3
WARNING LAMPS ........................................................10
Schematic/With Tachometer for Europe and
Australia .....................................................................10
Wiring Diagram Ð WARN Ð/With Tachometer
for Europe and Australia ............................................ 11
Schematic/Without Tachometer for Europe ...............16 Wiring Diagram Ð WARN Ð/Diesel Engine
without Tachometer....................................................17
HORN ........................................................................\
.....22
Wiring Diagram Ð HORN Ð.....................................22
HARNESS LAYOUT ......................................................24
Main Harness.............................................................24
Engine Harness .........................................................31
Engine Room Harness ..............................................32
GI
MA
EM
LC
EC
FE
CL
MT
AT
TF
PD
FA
RA
BR
ST
RS
BT
HA
IDX
EL-1
Page 4 of 88
Schematic
GEL185B
POWER SUPPLY ROUTING
EL-2
Page 5 of 88
Wiring Diagram Ð POWER Ð
BATTERY POWER SUPPLY Ð IGNITION SWITCH IN ANY POSITION
GEL186B
POWER SUPPLY ROUTING
EL-3
GI
MA
EM
LC
EC
FE
CL
MT
AT
TF
PD
FA
RA
BR
ST
RS
BT
HA
IDX
Page 6 of 88
GEL187B
POWER SUPPLY ROUTING
Wiring Diagram Ð POWER Ð (Cont'd)EL-4
Page 7 of 88
GEL188B
POWER SUPPLY ROUTING
Wiring Diagram Ð POWER Ð (Cont'd)EL-5
GI
MA
EM
LC
EC
FE
CL
MT
AT
TF
PD
FA
RA
BR
ST
RS
BT
HA
IDX
Page 8 of 88
ACCESSORY POWER SUPPLY Ð IGNITION SW. IN ªACCº OR ªONº
GEL189B
POWER SUPPLY ROUTING
Wiring Diagram Ð POWER Ð (Cont'd)EL-6
Page 9 of 88
IGNITION POWER SUPPLY Ð IGNITION SW. IN ªONº AND/OR ªSTARTº
GEL190B
POWER SUPPLY ROUTING
Wiring Diagram Ð POWER Ð (Cont'd)EL-7
GI
MA
EM
LC
EC
FE
CL
MT
AT
TF
PD
FA
RA
BR
ST
RS
BT
HA
IDX
Page 10 of 88
GEL191B
POWER SUPPLY ROUTING
Wiring Diagram Ð POWER Ð (Cont'd)EL-8
