Page 526 of 3502
ATC-148
REFRIGERANT LINES
CHECKING PROCEDURE
To prevent inaccurate or false readings, make sure there is no refrigerant vapor, shop chemicals, or cigarette
smoke in the vicinity of the vehicle. Perform the leak test in calm area (low air/wind movement) so that the
leaking refrigerant is not dispersed.
1. Stop the engine.
2. Connect a suitable A/C manifold gauge set (SST) to the A/C service valves.
3. Check if the A/C refrigerant pressure is at least 345 kPa (3.45 bar, 3.52 kg/cm
2 , 50 psi) above 16°C
(61°F). If less than specification, recover/evacuate and recharge the system with the specified amount of
refrigerant.
NOTE:
At temperatures below 16°C (61°F), leaks may not be detected since the system may not reach 345 kPa
(3.45 bar, 3.52 kg/cm
2 , 50 psi).
4. Perform the leak test from the high-pressure side (compressor discharge a to evaporator inlet g) to the
low-pressure side [evaporator drain hose h to shaft seal l (QR engine) or m (VQ engine)]. Refer to AT C -
133, "Components" . Perform a leak check for the following areas carefully. Clean the component to be
checked and move the leak detected probe completely around the connection/component.
Compressor
Check the fitting of high- and low-pressure flexible hoses, relief valve and shaft seal.
Condenser
Check the fitting of high-pressure flexible hose and pipe, refrigerant pressure sensor.
Liquid tank
Check the fitting of refrigerant connection.
Service valves
Check all around the service valves. Ensure service valve caps are secured on the service valves (to pre-
vent leaks).
NOTE:
After removing A/C manifold gauge set from service valves, wipe any residue from valves to prevent any
false readings by leak detector.
Cooling unit (Evaporator)
With engine OFF, turn blower fan on “High” for at least 15 seconds to dissipate any refrigerant trace in the
cooling unit. Wait a minimum of 10 minutes accumulation time (refer to the manufacturer’s recommended
procedure for actual wait time) before inserting the leak detector probe into the drain hose.
Keep the probe inserted for at least 10 seconds. Use caution not to contaminate the probe tip with water
or dirt that may be in the drain hose.
5. If a leak detector detects a leak, verify at least once by blowing compressed air into area of suspected
leak, then repeat check as outlined above.
6. Do not stop when one leak is found. Continue to check for additional leaks at all system components.
If no leaks are found, perform steps 7 - 10.
7. Start the engine.
8. Set the A/C control as follows;
a. A/C switch: ON
b. Mode door position: VENT (Ventilation)
c. Intake door position: Recirculation
d. Temperature setting: Max. cold
e. Fan speed: High
9. Run engine at 1,500 rpm for at least 2 minutes.
Page 651 of 3502
BCM (BODY CONTROL MODULE)
BCS-9
C
D
E
F
G
H
I
J
L
MA
B
BCS
MAJOR COMPONENTS AND CONTROL SYSTEM
System Input Output
Remote control entry system
Remote keyless entry receiver
Key switch
Front door switch (driver side)
Front door switch (passenger side)
Rear door switch RH
Rear door switch LH
Front door lock assembly
(driver side) (door lock actuator)
Front door lock assembly
(passenger side) (door lock actuator)
Rear door lock actuator RH
Rear door lock actuator LH
Trunk lid opener actuator
Turn signal lamp (RH, LH)
Combination meter
(turn signal indicator, warning chime)
Intelligent Key system
Intelligent Key unit
Front door switch (driver side)
Front door switch (passenger side)
Rear door switch RH
Rear door switch LH
Front door lock assembly
(driver side) (door lock actuator)
Front door lock assembly
(passenger side) (door lock actuator)
Rear door lock actuator RH
Rear door lock actuator LH
Trunk lid opener actuator
Turn signal lamp (RH, LH)
Combination meter
(turn signal indicator, warning chime)
Power door lock system
Power window main switch
(door lock and unlock switch)
Front door lock assembly (driver side)
(door unlock sensor)
Key switch
Front door switch (driver side)
Front door switch (passenger side)
Rear door switch RH
Rear door switch LH
Front door lock assembly
(driver side) (door lock actuator)
Front door lock assembly
(passenger side) (door lock actuator)
Rear door lock actuator RH
Rear door lock actuator LH
Trunk lid openerTrunk lid and fuel lid opener switch
(Trunk lid opener switch)Trunk lid lock assembly
(trunk lid opener actuator)
Power supply (IGN) to power window,
sunroofIgnition power supply Power window and sunroof system
Power supply (BAT) to power window,
sunroof and power seatBattery power supply Power window, sunroof system and power seat
Headlamp Combination switch
IPDM E/R
Combination meter
(HIGH beam indicator)
Exterior lamp battery saver control
Ignition switch
Combination switchIPDM E/R
Auto light system
Optical sensor
Combination switch
Ignition switch (ACC, ON)IPDM E/R
Parking, license plate and tail lamps Combination switch
IPDM E/R
Combination meter (Tail lamp indicator)
Front fog lamp Combination switch
IPDM E/R
Combination meter
(Front fog lamp indicator)
Page 660 of 3502
BL-2 Check Door Lock Actuator Output Signal ............... 39
Check Door Lock Actuator Circuit .......................... 40
(DRIVER SIDE AND REAR LH) .......................... 40
(PASSENGER SIDE AND REAR RH) ................. 41
Check Door Unlock Sensor .................................... 42
FUEL FILLER LID OPENER ..................................... 44
Component Part and Harness Connector Location ... 44
Wiring Diagram –F/LID– ......................................... 45
REMOTE KEYLESS ENTRY SYSTEM ..................... 46
Component Parts and Harness Connector Location ... 46
System Description ................................................. 46
INPUTS ............................................................... 46
OPERATED PROCEDURE ................................. 47
CAN Communication System Description .............. 48
CAN Communication Unit ....................................... 48
Schematic ............................................................... 49
Wiring Diagram — KEYLES— ................................ 50
FIG. 1 ................................................................... 50
FIG. 2 ................................................................... 51
FIG. 3 ................................................................... 52
Terminals and Reference Value for BCM ................ 53
Terminals and Reference Value for IPDM E/R ........ 54
CONSULT-II Function (BCM) .................................. 54
CONSULT-II START PROCEDURE .................... 54
CONSULT-II APPLICATION ITEMS .................... 54
Work Flow ............................................................... 56
Trouble Diagnosis Symptom Chart ......................... 56
Check Key Fob Battery and Function ..................... 57
Check ACC Switch ................................................. 58
Check Door Switch ................................................. 59
CHECK DOOR SWITCH (EXCEPT TRUNK
ROOM LAMP SWITCH) ...................................... 59
CHECK TRUNK ROOM LAMP SWITCH ............ 61
Check Key Switch ................................................... 63
Check Hazard Function .......................................... 64
Check Map Lamp and Ignition Keyhole Illumination
Function .................................................................. 64
ID Code Entry Procedure ....................................... 64
KEY FOB ID SET UP WITH CONSULT-II ........... 64
KEY FOB ID SET UP WITHOUT CONSULT-II .... 66
Key Fob Battery Replacement ................................ 67
INTELLIGENT KEY SYSTEM ................................... 68
Component Parts and Harness Connector Location ... 68
System Description ................................................. 70
DOOR LOCK/UNLOCK, TRUNK OPEN FUNC-
TION .................................................................... 70
REMOTE KEYLESS ENTRY FUNCTIONS ......... 71
ENGINE START FUNCTION ............................... 72
WARNING AND ALARM FUNCTION .................. 73
CHANGE SETTINGS FUNCTION ....................... 76
INTELLIGENT KEY REGISTRATION .................. 76
STEERING LOCK UNIT REGISTRATION .......... 77
CAN Communication System Description .............. 77
CAN Communication Unit ....................................... 77
Schematic ............................................................... 78
Wiring Diagram — I/KEY— .................................... 80
Terminals and Reference Value for Intelligent Key
Unit ......................................................................... 88
Terminals and Reference Value for Steering Lock Unit .......................................................................... 90
Terminals and Reference Value for BCM ................ 90
Diagnosis Procedure ............................................... 91
WORK FLOW ...................................................... 91
ENGINE START FUNCTION DIAGNOSTIC
PROCEDURE ...................................................... 92
CONSULT-II Functions (INTELLIGENT KEY) ......... 93
CONSULT-II Inspection Procedure ......................... 93
BASIC OPERATION ............................................ 93
CONSULT-II Application Items ................................ 93
SELF-DIAGNOSTIC RESULTS ........................... 93
DATA MONITOR .................................................. 93
WORK SUPPORT ............................................... 94
ACTIVE TEST ...................................................... 95
Trouble Diagnosis Symptom Chart ......................... 96
ALL FUNCTIONS OF THE INTELLIGENT KEY
ARE NOT OPERATING ....................................... 96
REMOTE KEYLESS ENTRY FUNCTION MAL-
FUNCTION .......................................................... 96
DOOR LOCK FUNCTION MALFUNCTION ......... 97
TRUNK OPEN FUNCTION MALFUNCTION ....... 97
HAZARD REMINDER FUNCTION MALFUNC-
TION .................................................................... 98
ENGINE START FUNCTION MALFUNCTION .... 98
WARNING CHIME FUNCTION MALFUNCTION ... 99
Check CAN Communication System ....................100
Check Intelligent Key Unit Power Supply and
Ground Circuit .......................................................100
Check Key Switch (Intelligent Key Unit Input) .......101
Check Key Switch (BCM Input) .............................102
Check Ignition knob Switch ...................................103
Check Door Switch ...............................................105
CHECK DOOR SWITCH (EXCEPT TRUNK
ROOM LAMP SWITCH) .....................................105
CHECK TRUNK ROOM LAMP SWITCH ...........107
Check Door Request Switch .................................109
Check Intelligent Key Warning Buzzer .................. 111
Check Outside Key Antenna .................................112
Check Inside Key Antenna ....................................114
Check Steering Lock Unit ......................................115
Check Headlamp Function ....................................117
Removal and Installation of Intelligent Key Unit ....117
REMOVAL ..........................................................117
INSTALLATION ..................................................117
Intelligent Key Battery Replacement .....................117
DISASSEMBLY AND ASSEMBLY OF INTELLI-
GENT KEY .........................................................117
INTELLIGENT KEY BATTERY INSPECTION ...118
DOOR ......................................................................119
Fitting Adjustment .................................................119
FRONT DOOR ...................................................119
REAR DOOR .....................................................119
STRIKER ADJUSTMENT ..................................120
Removal and Installation of Front Door ................120
REMOVAL ..........................................................120
INSTALLATION ..................................................120
Removal and Installation of Rear Door .................120
REMOVAL ..........................................................121
Page 676 of 3502
BL-18
RADIATOR CORE SUPPORT
RADIATOR CORE SUPPORTPFP:62500
Removal and InstallationBIS000VT
REMOVAL
1. Remove front bumper. Refer to EI-14, "FRONT BUMPER" .
2. Remove head lamp (LH/RH). Refer to LT- 3 6 , "
Removal and Installation" (Xenon type), LT- 6 2 , "Removal
and Installation" (Conventional type)
3. Remove air duct clips, and then remove air duct.
4. Remove crash zone sensor. Refer to SRS-44, "
CRASH ZONE SENSOR" .
5. Remove hood lock assembly, and then hood lock cable. Refer to BL-16, "
Removal and Installation of
Hood Lock Control" .
6. Remove ambient sensor. Refer to ATC-109, "
AMBIENT SENSOR" .
7. Remove hydraulic piping clips and tabs. Refer to PS-39, "
HYDRAULIC LINE" .
8. Remove radiator core support lower harness clips and mounting bolts, and then remove radiator core sup-
port lower. Remove mounting bolts with power tool.
9. Disconnect horn connectors and remove harness clips.
10. Remove each harness clip and nuts of radiator core support. Remove nuts with power tool.
11. Remove condenser mounting bracket bolts.
1. Radiator core support side (RH) 2. Air guide (RH) 3. Bolt
4. Nut 5. Radiator core support lower 6. Nut
7. Radiator core support center 8. Bolt 9. Horn (High)
10. Horn (Low) 11. Clip 12. Air guide (LH)
13. Radiator core support side (LH) 14. Radiator core support upper 15. Nut
16. Bolt 17. Bolt
PIIB0266E
Page 680 of 3502
BL-22
POWER DOOR LOCK SYSTEM
System DescriptionBIS000VW
Power is supplied at all times
through 50A fusible link (letter M , located in the fuse and fusible link box)
to BCM terminal 55.
through 15A fuse [No. 17, located in the fuse block (J/B)]
to BCM terminal 42.
to key switch terminal 1 (without intelligent key system)
through 15A fuse [No. 18, located in the fuse block (J/B)]
to key switch terminal 3 (with intelligent key system)
When key switch is ON (key is inserted in ignition key cylinder), power is supplied
through key switch terminal 4 (without intelligent key system) or 8 (with intelligent key system)
to BCM terminal 37.
Ground is supplied
to BCM terminal 52
through body grounds M71 and M72.
to power window main switch (door lock and unlock switch) terminal 17
through body grounds M71 and M72.
to front door lock assembly (driver side) (door unlock sensor) terminal 5
through body grounds M71 and M72.
LOCK OPERATION
When the door is locked with power window main switch (door lock and unlock switch)
Ground is supplied
to BCM terminal 60
through power window main switch (door lock and unlock switch) terminal 18
through power window main switch (door lock and unlock switch) terminal 17
through body grounds M71 and M72.
When the driver side door locked with hand or key cylinder
Ground is intercepted
to BCM terminal 7.
When you meet either the above-mentioned
Power is supplied
through BCM terminal 50
to each door lock actuators terminal 3
Ground is supplied
to each door lock actuators terminal 2
through BCM terminal 51.
Each door lock actuator locks the door lock.
UNLOCK OPERATION
When the door is unlocked with power window main switch (door lock and unlock switch)
Ground is supplied
to BCM terminal 61
through power window main switch (door lock and unlock switch) terminal 6
through power window main switch (door lock and unlock switch) terminal 17
through body grounds M71 and M72.
When the driver side door unlocked with hand or key cylinder
Ground is supplied
to BCM terminal 7
through front door lock assembly (driver side) (door unlock sensor) terminal 4
through front door lock assembly (driver side) (door unlock sensor) terminal 5
Page 687 of 3502
POWER DOOR LOCK SYSTEM
BL-29
C
D
E
F
G
H
J
K
L
MA
B
BL
Terminals and Reference Value for BCMBIS000W1
*1: with intelligent key*2: without intelligent key
Work FlowBIS000W2
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to BL-22, "
System Description" .
3. According to the trouble diagnosis chart by symptom, repair or replace the cause of the malfunction.
Refer to BL-31, "
Trouble Diagnosis Chart by Symptom" .
4. Does power door lock system operate normally?
YES: GO TO 5.
NO: GO TO 3.
5. INSPECTION END
Te r m i -
nalWire
colorItemSignal
Input/
OutputConditionVoltage (V)
(Approx.)
7 LG/R Door unlock sensor signal InputDriver side door
lock knobON (Lock) 5
OFF (Unlock) 0
12 R/LFront door switch
(Passenger side) signalInputFront door
(Passenger side)ON (Open) 0
OFF (Close) Battery voltage
13 R/B Rear door switch RH signal Input Rear door RHON (Open) 0
OFF (Close) Battery voltage
37B/R
*1
BR*2Key switch signal Input KeyInserted Battery voltage
Removed 0
39 L CAN-HInput/
Output——
40 P CAN-LInput/
Output——
42 Y/R Power source (Fuse) Input — Battery voltage
50 VDoor lock actuator
LOCK output signalOutputDoor lock and unlock switch
(Free → Lock)0 → Battery voltage → 0
51 G/YDoor lock actuator
UNLOCK output signalOutputDoor lock and unlock switch
(Free → Unlock)0 → Battery voltage → 0
52 B Ground — — 0
55 W/B Power source (Fusible link) Input — Battery voltage
60 GRDoor lock and unlock switch
LOCK signalInputDoor lock and
unlock switchLock 0
Other than above Battery voltage
61 GR/RDoor lock and unlock switch
UNLOCK signalInputDoor lock and
unlock switchUnlock 0
Other than above Battery voltage
62 SBFront door switch
(Driver side) signalInputFront door
(Driver side)ON (Open) 0
OFF (Close) Battery voltage
63 R/W Rear door switch LH signal Input Rear door LHON (Open) 0
OFF (Close) Battery voltage
Page 688 of 3502
BL-30
POWER DOOR LOCK SYSTEM
CONSULT-II Function (BCM)BIS000W3
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II START PROCEDURE
Refer to GI-34, "CONSULT-II Start Procedure" .
CONSULT-II APPLICATION ITEMS
Data Monitor
*: With Intelligent Key system
Active Test
BCM diagnosis
partInspection item, Self-diagnosis
modeContent
Door lockDATA MONITOR Displays BCM input data on real-time basis.
ACTIVE TEST Sends drive signals to door lock actuator to perform operation check.
Monitor item Content
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEY ON SW Indicates [ON/OFF] condition of key switch.
CDL LOCK SW Indicates [ON/OFF] condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of unlock signal from door lock and unlock switch.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch driver side.
DOOR SW-AS Indicates [ON/OFF] condition of front door switch passenger side.
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
BACK DOOR SW This is displayed even when it is not equipped.
LOCK STATUS Indicates [ON/OFF] condition of driver side door lock knob
SHOCK SENSOR Indicates [ON/OFF] condition of shock sensor
VEHICLE SPEED Indicates [km/h] condition of vehicle speed
KEYLESS LOCK Indicates [ON/OFF] condition of lock signal from keyfob.
KEYLESS UNLOCK Indicates [ON/OFF] condition of unlock signal from keyfob.
I-KEY LOCK* Indicates [ON/OFF] condition of lock signal from door request switch.
I-KEY UNLOCK* Indicates [ON/OFF] condition of unlock signal from door request switch.
Test item Content
DOOR LOCKThis test is able to check all door lock actuators lock or unlock operation.
These actuators lock or unlock when “LOCK” or “UNLOCK” on CONSULT-II screen is touched.
Page 689 of 3502
POWER DOOR LOCK SYSTEM
BL-31
C
D
E
F
G
H
J
K
L
MA
B
BL
Trouble Diagnosis Chart by SymptomBIS000W4
Always check the “Work Flow” before troubleshooting. Refer to BL-29, "Work Flow" .
Symptom Diagnoses service procedureReference
page
All door lock actuator does not operate1. Check BCM power supply and ground cir-
cuit BL-32
2. Check door lock and unlock switchBL-37
3. Check door unlock sensorBL-42
4. Check door lock actuator output signalBL-39
5. Replace BCMBCS-16
Key reminder door system does not operate properly.1. Check key switchBL-352. Check door switchBL-33
3. Replace BCMBCS-16
Power door lock does not operate with door lock and unlock switch.1. Check door lock and unlock switchBL-372. Replace BCMBCS-16
Power door lock does not operate with driver side door lock knob or
door key cylinder operation.
(Power door lock operate properly with door lock and unlock switch.)1. Check door unlock sensorBL-42
2. Replace BCMBCS-16
Specific door lock actuator does not operate. Check door lock actuator circuitBL-40
Page 700 of 3502
BL-42
POWER DOOR LOCK SYSTEM
Check Door Unlock SensorBIS000WB
1. CHECK DOOR UNLOCK SENSOR SIGNAL
With CONSULT-II
Check lock status (“LOCK STATUS”) in DATA MONITOR mode with CONSULT-II.
When driver side door lock knob is turned to LOCK:
When driver side door lock knob is turned to UNLOCK
Without CONSULT-II
Driver side door lock knob operate, check voltage between BCM connector and ground
OK or NG
OK >> Door unlock sensor is OK.
NG >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and front door lock assembly (driver side) connector.
3. Check continuity between BCM connector M3 terminal 7 and
front door lock assembly (driver side) connector D24 terminal 4.
4. Check continuity between BCM connector M3 terminal 8 and
ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness between BCM and front door
lock assembly (driver side). LOCK STATUS : OFF
LOCK STATUS : ON
PIIB0533E
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (-)
M3 7 (LG/R) GroundDoor lock
knob: LOCK 5
: UNLOCK 0
PIIB8747E
7 (LG/R) – 4 (LG/R) : Continuity should exist.
7 (LG/R) – Ground : Continuity should not exist.
PIIB8748E
Page 701 of 3502
POWER DOOR LOCK SYSTEM
BL-43
C
D
E
F
G
H
J
K
L
MA
B
BL
3. CHECK DOOR UNLOCK SENSOR GROUND CIRCUIT
Check continuity between front door lock assembly (driver side) con-
nector D24 terminal 5 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between BCM connector M3 terminal 7 and
ground.
OK or NG
OK >> Check condition of harness and connector.
NG >> Replace BCM.5 (B) – Ground : Continuity should exist.
PIIB2332E
7 (LG/R) – Ground : Approx. 5V
PIIB8747E
