NISSAN TEANA 2003  Service Manual REAR DISC BRAKE
BR-33
C
D
E
G
H
I
J
K
L
MA
B
BR

REAR DISC BRAKEPFP:44000
On-Board InspectionBFS000C2
PAD WEAR INSPECTION
Check pad thickness from the inspection hole on cylinder body.
Use a scale f

Page 852 of 3502

NISSAN TEANA 2003  Service Manual BR-34
REAR DISC BRAKE

WARNING:
Clean dust on caliper and brake pads with a vacuum dust collector to minimize the hazard of air borne
particles or other materials.
CAUTION:
While removing cylinder b

Page 853 of 3502

NISSAN TEANA 2003  Service Manual REAR DISC BRAKE
BR-35
C
D
E
G
H
I
J
K
L
MA
B
BR

Removal and Installation of Brake Caliper AssemblyBFS000C5
REMOVAL
1. Remove tyres from vehicle.
2. Secure disc rotor using wheel nut to wheel hub.
CA

Page 854 of 3502

NISSAN TEANA 2003  Service Manual BR-36
REAR DISC BRAKE

Disassembly and Assembly of Brake Caliper AssemblyBFS000C6
NOTE:
Do not remove torque member, pads, shims, shim covers, and pad retainers when disassembling and assem-
bling cy

Page 855 of 3502

NISSAN TEANA 2003  Service Manual REAR DISC BRAKE
BR-37
C
D
E
G
H
I
J
K
L
MA
B
BR

INSPECTION AFTER DISASSEMBLY
Cylinder Body
CAUTION:
Use new brake fluid to clean. Do not use mineral oils such as gasoline or kerosene.
Check inside

Page 856 of 3502

NISSAN TEANA 2003  Service Manual BR-38
REAR DISC BRAKE

4. Fix piston boot with retaining ring.
CAUTION:
Make sure boot is firmly in cylinder body groove on.
Do not reuse retainer ring.
5. Apply PBC (Poly Butyl Cuprysil) grease or

Page 857 of 3502

NISSAN TEANA 2003  Service Manual REAR DISC BRAKE
BR-39
C
D
E
G
H
I
J
K
L
MA
B
BR

DISC ROTOR INSPECTION
Visual Inspection
Check surfaces of disc rotor for uneven wear, cracks, and serious damage. If a malfunction is detected,
replac

Page 858 of 3502

NISSAN TEANA 2003  Service Manual BR-40
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsBFS000C7
Unit: mm (in)
Brake PedalBFS000C8
Unit: mm (in)
Brake BoosterBFS000C9
Vacuum

Page 859 of 3502

NISSAN TEANA 2003  Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
BR-41
C
D
E
G
H
I
J
K
L
MA
B
BR

Rear Disc BrakeBFS000CC
Unit: mm (in)
Brake padStandard thickness  8.5 (0.335)
Repair limit thickness 2.0 (0.079)
Disc rotorStan

Page 860 of 3502

NISSAN TEANA 2003  Service Manual BR-42
SERVICE DATA AND SPECIFICATIONS (SDS)
