C1116 STOP LAMP SWITCH
C1116 STOP LAMP SWITCH
DescriptionINFOID:0000000003766763
The stop lamp switch transmits the stop lamp switch signal (ON/OFF) to the ABS actuator and electric unit
(control unit).
DTC LogicINFOID:0000000003766764
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1116” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-30, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766765
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Disconnect stop lamp switch connector.
4. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to BRC-30, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace stop lamp switch.
3.CHECK STOP LAMP SWITCH CIRCUIT
Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003766766
1.CHECK STOP LAMP SWITCH
DTC Display item Malfunction detected condition Possible cause
C1116 STOP LAMP SW When stop lamp switch circuit is open. Harness or connector
 Stop lamp switch
 ABS actuator and electric unit
(control unit)
ABS actuator and electric unit (control unit)
— Condition Voltage
Connector Terminal
E34 20 GroundBrake pedal is depressed Battery voltage
Brake pedal is released Approx. 0 V

C1116 STOP LAMP SWITCH
BRC-31
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
1. Turn the ignition switch OFF.
2. Disconnect stop lamp switch connector.
3. Check the continuity between stop lamp switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch. Refer to BR-17, "
Exploded View".
Stop lamp switch
Condition Continuity
Te r m i n a l
1 − 2Release stop lamp switch
(When brake pedal is depressed.)Existed
Push stop lamp switch
(When brake pedal is released.)Not existed

BRC-32
< COMPONENT DIAGNOSIS >[ABS]
C1120, C1122, C1124, C1126 IN ABS SOL
C1120, C1122, C1124, C1126 IN ABS SOL
DescriptionINFOID:0000000003766768
The solenoid valve increases, holds or decreases the fluid pressure of each brake caliper according to the sig-
nals transmitted by the ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000003766769
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1120”, “C1122”, “C1124” or “C1126” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-32, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766770
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SOLENOID AND ACTUATOR RELAY POWER SUPPLY CIRCUIT
Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK SOLENOID AND ACTUATOR RELAY GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1120 FR LH IN ABS SOLWhen the control unit detects a malfunction in the front
LH inlet solenoid circuit.
ABS actuator and electric unit
(control unit) C1122 FR RH IN ABS SOLWhen the control unit detects a malfunction in the front
RH inlet solenoid circuit.
C1124 RR LH IN ABS SOLWhen the control unit detects a malfunction in the rear LH
inlet solenoid circuit.
C1126 RR RH IN ABS SOLWhen the control unit detects a malfunction in the rear
RH inlet solenoid circuit.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 3 Ground Battery voltage

C1120, C1122, C1124, C1126 IN ABS SOL
BRC-33
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003766771
1.CHECK ACTIVE TEST
1. Select each test menu item on “ACTIVE TEST”.
2. On the display, touch “Up”, “Keep” and “Down”, and check that the system operates as shown in the table
below.
*: On for 1 to 2 seconds after the touch, and then Off.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is
an operation for checking.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-32, "
Diagnosis Procedure".
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E341
Ground Existed
4
Test item Display itemDisplay (Note)
Up Keep Down
FR RH SOLFR RH IN SOL Off On On
FR RH OUT SOL Off Off On*
FR LH SOLFR LH IN SOL Off On On
FR LH OUT SOL Off Off On*
RR RH SOLRR RH IN SOL Off On On
RR RH OUT SOL Off Off On*
RR LH SOLRR LH IN SOL Off On On
RR LH OUT SOL Off Off On*

BRC-34
< COMPONENT DIAGNOSIS >[ABS]
C1121, C1123, C1125, C1127 OUT ABS SOL
C1121, C1123, C1125, C1127 OUT ABS SOL
DescriptionINFOID:0000000003767295
The solenoid valve increases, holds or decreases the fluid pressure of each brake caliper according to the sig-
nals transmitted by the ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000003766774
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1121”, “C1123”, “C1125” or “C1127” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-34, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003767296
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SOLENOID AND ACTUATOR RELAY POWER SUPPLY CIRCUIT
Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK SOLENOID AND ACTUATOR RELAY GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1121 FR LH OUT ABS SOLWhen the control unit detects a malfunction in the front
LH outlet solenoid circuit.
ABS actuator and electric unit
(control unit) C1123 FR RH OUT ABS SOLWhen the control unit detects a malfunction in the front
RH outlet solenoid circuit.
C1125 RR LH OUT ABS SOLWhen the control unit detects a malfunction in the rear LH
outlet solenoid circuit.
C1127 RR RH OUT ABS SOLWhen the control unit detects a malfunction in the rear
RH outlet solenoid circuit.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 3 Ground Battery voltage

C1121, C1123, C1125, C1127 OUT ABS SOL
BRC-35
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003767297
1.CHECK ACTIVE TEST
1. Select each test menu item on “ACTIVE TEST”.
2. On the display, touch “Up”, “Keep” and “Down”, and check that the system operates as shown in the table
below.
*: On for 1 to 2 seconds after the touch, and then Off.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is
an operation for checking.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-34, "
Diagnosis Procedure".
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E341
Ground Existed
4
Test item Display itemDisplay (Note)
Up Keep Down
FR RH SOLFR RH IN SOL Off On On
FR RH OUT SOL Off Off On*
FR LH SOLFR LH IN SOL Off On On
FR LH OUT SOL Off Off On*
RR RH SOLRR RH IN SOL Off On On
RR RH OUT SOL Off Off On*
RR LH SOLRR LH IN SOL Off On On
RR LH OUT SOL Off Off On*

BRC-36
< COMPONENT DIAGNOSIS >[ABS]
C1140 ACTUATOR RELAY SYSTEM
C1140 ACTUATOR RELAY SYSTEM
DescriptionINFOID:0000000003766753
Activates or deactivates each solenoid valve according to the signals transmitted by the ABS actuator and
electric unit (control unit).
DTC LogicINFOID:0000000003766754
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1140” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-36, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766755
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SOLENOID AND ACTUATOR RELAY POWER SUPPLY CIRCUIT
Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK SOLENOID AND ACTUATOR RELAY GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1140 ACTUATOR RLYDuring the actuator relay operating with OFF, when the
actuator relay turns ON, or when the control line for the
relay is shorted to the ground. Harness or connector
 ABS actuator and electric unit
(control unit) During the actuator relay operating with ON, when the
actuator relay turns ON, or when the control line for the
relay is open.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 3 Ground Battery voltage
ABS actuator and electric unit (control unit)
— Continuity
Connector Terminal
E341
Ground Existed
4

C1140 ACTUATOR RELAY SYSTEM
BRC-37
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003767291
1.CHECK ACTIVE TEST
1. On “ACTIVE TEST”, select “ABS MOTOR”.
2. Touch “On” and “Off” on screen. Make sure motor relay and actuator relay operates as shown in table
below.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is
an operation for checking.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-36, "
Diagnosis Procedure".
Test item Display itemDisplay
On Off
ABS MOTORMOTOR RELAY On Off
ACTUATOR RLY (Note) On On

BRC-38
< COMPONENT DIAGNOSIS >[ABS]
U1000, U1002 CAN COMM CIRCUIT
U1000, U1002 CAN COMM CIRCUIT
DescriptionINFOID:0000000003766819
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000003766820
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“U1000” or “U1002” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-38, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766821
1.PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“U1000” or “U1002” detected?
YES >> Proceed to diagnosis procedure. Refer to LAN-14, "Trouble Diagnosis Flow Chart".
NO >> INSPECTION END
DTC Display item Malfunction detected condition Possible cause
U1000 CAN COMM CIRCUITWhen ABS actuator and electric unit (control unit) is not
transmitting or receiving CAN communication signal for 2
seconds or more. CAN communication line
 ABS actuator and electric unit
(control unit)
U1002 SYSTEM COMM (CAN)When ABS actuator and electric unit (control unit) is not
transmitting or receiving CAN communication signal for 2
seconds or less.

POWER SUPPLY AND GROUND CIRCUIT
BRC-39
< COMPONENT DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
POWER SUPPLY AND GROUND CIRCUIT
DescriptionINFOID:0000000003766827
Supplies power to ABS actuator and electric unit (control unit).
Diagnosis ProcedureINFOID:0000000003766828
1.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) IGNITION POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
4. Turn the ignition switch ON.
CAUTION:
Never start the engine.
5. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform the trouble diagnosis for power supply circuit.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY
1. Turn the ignition switch OFF.
2. Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform the trouble diagnosis for power supply circuit.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair or replace damaged parts.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 18 Ground Approx. 0 V
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 18 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E34 3 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E341
Ground Existed
4
