• Discard any sensor which has been dropped from a he
ight of more than 0.5 m (19.7 in) onto a hard
surface such as a concrete floor; use a new one.
• Before installing new sensor, clean exhaust syst em threads using Oxygen Sensor Thread Cleaner
[commercial service tool (J-43897-18 or J-43897-12)] an d approved Anti-seize Lubricant (commercial
service tool).
Do you have CONSULT?
YES >> GO TO 13.
NO >> GO TO 14.
13.CONFIRM A/F ADJUSTMENT DATA
With CONSULT
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” in “DATA MONI TOR” mode of “ENGINE” using CONSULT.
3. Make sure that “0.000” is displayed on CONSULT screen.
Is
“0.000” displayed?
YES >> INSPECTION END
NO >> GO TO 14.
14.CLEAR THE MIXTURE RATIO SELF-LEARNING VALUE
Clear the mixture ratio self-learning value. Refer to EC-181, "Work Procedure"
.
Do you have CONSULT?
YES >> GO TO 15.
NO >> INSPECTION END
15.CONFIRM A/F ADJUSTMENT DATA
With CONSULT
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” in “DATA MONI TOR” mode of “ENGINE” using CONSULT.
3. Make sure that “0.000” is displayed on CONSULT screen.
>> INSPECTION END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-472
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
P2100, P2103 THROTTLE CONTROL MOTOR RELAY
DTC LogicINFOID:0000000009462403
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, co nfirm that battery voltage is more than 8 V.
Witch DTC is detected?
P2100 >> GO TO 2.
P2103 >> GO TO 3.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P2100
1. Turn ignition switch ON and wait at least 2 seconds.
2. Start engine and let it idle for 5 seconds.
3. Check DTC.
Is DTC detected?
YES >> Proceed to EC-472, "Diagnosis Procedure".
NO >> INSPECTION END
3.PERFORM DTC CONFIRMATION PROCEDURE FOR DTC P2103
1. Turn ignition switch ON and wait at least 1 second.
2. Check DTC.
Is DTC detected?
YES >> Proceed to EC-472, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462404
1.CHECK THROTTLE CONTROL MOTOR RELAY POWER SUPPLY
1. Turn ignition switch OFF.
2. Check the voltage between ECM harness connector and ground.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P2100 ETC MOT PWR-B1
(Throttle actuator ″A ″ control
motor circuit/open) ECM detects a voltage of power source for
throttle control motor is excessively low. • Harness or connectors
(Throttle control moto r relay circuit is
open)
• Throttle control motor relay
P2103 ETC MOT PWR
(Throttle actuator ″A ″ control
motor circuit high) ECM detect the throttle control motor relay is
stuck ON. • Harness or connectors
(Throttle control moto r relay circuit is
shorted)
• Throttle control motor relay
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P2100, P2103 THROTTLE CONTROL MOTOR RELAY
EC-473
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*1: Except for California
*2: For California
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK THROTTLE CONTROL MOTO R RELAY POWER SUPPLY CIRCUIT
1. Disconnect ECM harness connector.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between ECM harness connector and IPDM E/R harness connector.
*1: Except for California
*2: For California
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK THROTTLE CONTROL MOTOR RELAY INPUT SIGNAL
Check the voltage between ECM harness connector and ground as per the following conditions.
*1: Except for California
*2: For California
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 4.
4.CHECK THROTTLE CONTROL MOTO R RELAY INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ECM harness connector and IPDM E/R harness connector.
+ −
Voltag e
ECM
Connector Terminal Connector Terminal
F14
*1
F91*22 E10*1
E31*2128 Battery voltage
+
−
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal
F14
*1
F91*22F8357Existed
ECM ConditionVo l ta g e
(Approx.)
+
−
Connector Terminal Connector Terminal
F14
*1
F91*221 E10*1
E31*2128Ignition switch: OFF 0 V
Ignition switch: ON Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-474
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2100, P2103 THROTTLE
CONTROL MOTOR RELAY
*1: Except for California
*2: For California
5. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace error-detected parts.
+ −
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal
F14
*1
F91*221 F84 65 Existed
