POWER SUPPLY ROUTING CIRCUITPG-19
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
Wiring Diagram —Ignition Power Supply —INFOID:0000000009460437
ABMWA2175GB
Revision: November 20132014 Altima NAM

PG-20
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY ROUTING CIRCUIT
ABMWA2176GB
Revision: November 20132014 Altima NAM

PG
POWER SUPPLY ROUTING CIRCUITPG-21
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMWA2177GB
Revision: November 20132014 Altima NAM

PG-22
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY ROUTING CIRCUIT
ABMIA5127GB
Revision: November 20132014 Altima NAM

PG
POWER SUPPLY ROUTING CIRCUITPG-23
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMIA5128GB
Revision: November 20132014 Altima NAM

PG-24
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY ROUTING CIRCUIT
ABMIA5129GB
Revision: November 20132014 Altima NAM

PG
POWER SUPPLY ROUTING CIRCUITPG-25
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMIA5130GB
Revision: November 20132014 Altima NAM

PG-26
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY ROUTING CIRCUIT
ABMIA5131GB
Revision: November 20132014 Altima NAM

PG
POWER SUPPLY ROUTING CIRCUITPG-27
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMIA5132GB
Revision: November 20132014 Altima NAM

PG-28
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY ROUTING CIRCUIT
Fuse
INFOID:0000000009460438
• If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
• Use fuse of specified rating. Never use fuse of more than specified
rating.
• Do not partially install fuse; always insert it into fuse holder prop- erly.
• Remove fuse for “ELECTRICAL PARTS (BAT)” if vehicle is not
used for a long period of time.
Fusible LinkINFOID:0000000009460439
A melted fusible link can be detected either by visual inspection or by
feeling with finger tip. If its condition is questionable, use circuit
tester or test lamp.
CAUTION:
• If fusible link should melt, it is possible that critical circuit
(power supply or large current carrying circuit) is shorted. In
such a case, carefully check and eliminate cause of malfunc-
tion.
• Never wrap outside of fusible link with vinyl tape. Important: Never let fusible link touch an y other wiring harness, vinyl or
rubber parts.
CEL083
1 : Fusible link
ALMIA0015GB
Revision: November 20132014 Altima NAM
