NISSAN TEANA 2014 Service Manual

DAS-228
< SYSTEM DESCRIPTION >[MOD]
SYSTEM
SYSTEM
System DescriptionINFOID:0000000009464890
SYSTEM DIAGRAM
ITS CONTROL UNIT INPUT/OUTPUT SIGNAL ITEM
Input Signal Item
Output Signal Item
AWOIA0038GB
Transmit unit Signal name Description
ECM CAN communication Engine speed signal Receives engine status
BCM CAN communication Door open status signal Receives door open status
Light status signal Receives light status
Turn signal Receives turn signal status
Washer level
switch Hard wire Washer fluid level status
ABS actuator
and electric unit
(control unit) CAN communication Wheel speed signal Receives wheel speed
TCM CAN communication Shift selector position signal Receives shift selector position
Combination
meter CAN communication Moving Object Detection ON/
OFF signal Receives the ON/OFF status for Moving Object Detection
function
Rear view cam-
era NTSC Video signal Receives the Rear View Camera image from camera for
Moving Object Detection function in ITS controller
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
SYSTEM
DAS-229
< SYSTEM DESCRIPTION >[MOD]
C
D E
F
G H
I
J
K L
M B
N P
AFUNCTION DESCRIPTION
• The Moving Object Detection (MOD) system can help alert the driver of approaching vehicles or rear objects when the driver is
backing out of a parking space.
• The MOD system comprises of the rear view camera as the main detection system, which is located on the trunk as illustrated.
• The MOD system operates at speeds below 8 km/h (5 MPH)
whenever the vehicle is in R (reverse).
• The MOD system uses the rear view camera to detect approach- ing moving objects from either side.
• The MOD system can detect moving objects on either side as close as rear obstacles of up to approximately 3 m (10 feet).
MOVING OBJECT DETECTION SY STEM OPERATION DESCRIPTION
• ITS control unit enables Moving Object Detection system.
• Combination meter turns Moving Object Detection ON indicator lamp ON/OFF according to the signals from ITS control unit via CAN communication.
• ITS control unit starts the control as follows, based on a vehicle detection signal.
Operation Condition of Moving Object Detection System
ITS control unit performs the control w hen the following conditions are satisfied:
• Moving Object Detection ON indicator: ON
• When the vehicle is moving in R (reverse) at 8 km/h (5 MPH) or less.
NOTE:
• When the Moving Object Detection system setti ng on the Vehicle Information Display is ON.
Reception unit Signal name Description
Combination
meter CAN communication Buzzer Request
Transmits a buzzer request signal when a moving object
is detected.
Display CAN communication Visual signal request Transmits a visual signal request from the ITS controller
to display Rear View while the shift selector is in R (re-
verse).
ALOIA0162ZZ
ALOIA0163ZZ
ALOIA0164ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-230
< SYSTEM DESCRIPTION >[MOD]
SYSTEM
• Moving Object Detection braking will not operate or
will stop operating and only a warning chime will sound
under the following conditions:
- When driving with a tire that is not within normal tire conditions (pressure, wear, chain, spare, etc.)
- When the vehicle is equipped with non-original brake parts or suspension parts.
• Do not use the MOD system when towing a trailer.
• Excessive noise such as the audio system will inte rfere with the chime sound, and it may not be heard.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
OPERATIONDAS-231
< SYSTEM DESCRIPTION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
OPERATION
System Display and WarningINFOID:0000000009464891
INDICATOR AND WARNING LAMP
The MOD system can be turned ON or OFF for the current ignition cycle using the warning system switch.
When toggled between ON and OFF, the indicator will appear on the right side of the rear view camera screen.
DISPLAY AND WARNING OPERATION
No. Name Description
1 MOD indicator (blue)
• Turns ON while MOD system is ON
• Under the following conditions, the MOD indicator (blue) will blink.
- When the VDC system (except TCS function) or ABS operates.
- When the VDC system is turned off.
MOD warning lamp (orange) • Turns ON when MOD system is malfunctioning
• Blinks under the following conditions:
- When the component temperature reaches high level.
- When rear view camera blockage is detected.
Vehicle condition/Driver's operation
Moving Ob- ject Detec- tion ON
indicator Vehicle speed
(Approx.)
[km/h (MPH)] Status of vehi-
cle detection
within detec- tion area Indication on the
Moving Object Detection indicator Buzzer
OFF — — OFF OFF
Blue Less than ap-
prox.
8 km/h ( 5 MPH) Ve h i c l e i s
detected ON ON
Approx.
8 km/h ( 5
MPH) or more Vehicle is ab-
sent ON OFF
Ve h i c l e i s detected ON OFF
Vehicle is not detected ON OFF
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-232
< SYSTEM DESCRIPTION >[MOD]
HANDLING PRECAUTION
HANDLING PRECAUTION
Precautions for Moving Objects DetectionINFOID:0000000009464892
REAR VIEW CAMERA HANDLING
• The rear view camera which is located on the back
of the trunk performs the Moving Object Detection sys-
tem.
• Always keep the rear view camera lens clean.
• Do not attach a sticker (including transparent material ), install an accessory or paint work over the camera
lens.
• Do not strike or scratch the lens causing physical damage to the camera or the surrounding area.
MOVING OBJECT DETECTION
• The Moving Object Detection system is not a repl acement for proper driving procedure and is not designed
to prevent contact with vehicles or objects. When backing up, always look in the direction driver will move to
ensure it is safe to proceed. Never rely solely on the Moving Object Detection system.
• Using the Moving Object Detection system under some road or weather conditions could lead to improper
system operation. Always rely on driver's own steering and braking operation to avoid accidents.
• The Moving Object Detection system may not provide a warning for vehicles that pass through the detection
zone quickly.
• Do not use the Moving Object Detection system when towing a trailer.
• Excessive noise (e.g., audio system volume, open v ehicle window) will interfere with the chime sound, and it
may not be heard.
• The rear view camera may not be able to detect and activate Moving Object Detection when certain objects are present such as:
- Pedestrians, bicycles, animals.
- A vehicle passing at a speed greater than approximately 15 MPH (24km/h).
• Severe weather or road spray conditions may reduce the ability of the radar to detect other vehicles.
• Do not use the MOD system under the following condi tions because the system may not function properly:
- When driving with a tire that is not within normal tire condition (example: tire wear, low pressure, spare tire, chain, non-standard wheels).
- When the vehicle is equipped with non-original brake parts or suspension parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
DIAGNOSIS SYSTEM (ITS CONTROL UNIT)DAS-233
< SYSTEM DESCRIPTION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
DIAGNOSIS SYSTEM (ITS CONTROL UNIT)
CONSULT Function (AVM)INFOID:0000000009951658
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and no-start condition.
APPLICATION ITEMS
CONSULT performs the following functions via CAN communication using ITS control unit.
SELF DIAGNOSTIC RESULT
Refer to DAS-239, "DTC Index".
DATA MONITOR
Diagnosis mode Description
Self Diagnostic Result Displays the name of a malfunctioning system stored in the ITS control unit
Data Monitor Displays ITS control unit input/output data in real time
Work support Displays causes of automatic system cancellation occurred during system control
Active Test Enables an operational check of a load by transmitting a driving signal from the ITS control unit to
the load
ECU identification Displays ITS control unit part number
Configuration The vehicle specification can be written when replacing the ITS control unit
Monitored item [Unit] Description
ST ANGLE SENSOR SIGNAL
[On/Off] Indicates [On/Off] status as judged from ITS control unit (Angle sensor transmits angle signal
through CAN communication)
REVERSE SIGNAL
[On/Off] Indicates [On/Off] status as judged from ITS control unit (TCM transmits reverse signal
through CAN communication)
VEHICLE SPEED SIGNAL
[On/Off] Indicates vehicle speed calculated from ITS control unit through CAN communication [ABS ac-
tuator and electric unit (control unit) transmits vehicle speed signal (wheel speed) through
CAN communication]
CAMERA SWITCH SIGNAL
[On/Off] Indicates [On/Off] status of camera switch signal as judged from ITS control unit
CAMERA OFF SIGNAL
[On/Off] Indicates [On/Off] status of camera OFF signal as judged from ITS control unit
ST ANGLE SENSOR TYPE
[Absolute/Not] Indicates whether steering angle sensor type is absolute or not (ON means “controlling”)
STEERING GEAR RATIO TYPE
[Type 0/1] Indicates the type of the steering gear ratio (type 1 or 2)
STEERING POSITION
[LHD/RHD] Indicates the steering
position (LHD or RHD)
REAR CAMERA IMAGE SIGNAL
[OK/Not] Indicates the status of the rear camera image as read from ITS control unit through dedicated
ITS communication lines
WASH SW
[ON/OFF] Indicates the state of the wash switch indicator output
R-CAMERA COMM STATUS
[OK/Not] Indicates the status of the rear camera communication status as read from ITS control unit
through dedicated ITS communication lines
R-CAMERA COMM LINE
[OK/Not] Indicates the condition of the rear camera communication line whether transmitting properly
through dedicated ITS communication lines
PUMP COMM STATUS
[OK/NG] Indicates the state of the communication signal from pump control unit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-234
< SYSTEM DESCRIPTION >[MOD]
DIAGNOSIS SYSTEM (ITS CONTROL UNIT)
WORK SUPPORT
ACTIVE TEST
CAUTION:
• Never perform “Active Test” while driving the vehicle.
• The “Active Test” cannot be performed when th e following systems warning indicators are illumi-
nated:
- Lane Departure Warning indicator
- Blind Spot Warning indicator
• Place the shift selector to P (park) position, and then perform the test.
BSW ON INDICATOR
ILL
[On/Off] Indicates [On/Off] status of the illumination signal
ITS SW 1
[On/Off] Indicates the state of the warning system switch as seen by the ITS control unit
ITS SW 1 IND
[On/Off] Indicates the state of the warning system switch indicator output
TURN SIGNAL
[Left/N/Right] Indicates [Left/N/Right] status of the turn signal output
ITS SW 2
[ON/OFF/No setting] Indicates the state of the warning system secondary switch as seen by the ITS control unit
ITS SW 2 IND
[ON/OFF/No setting] Indicates the state of the warning system secondary switch indicator output
Monitored item
[Unit] Description
Work support items Description
PREDICTIVE COURSE LINE
DISPLAY Setting whether predictive guide line displays or not
INITIALIZE CAMERA IMAGE
CALIBRATION Start the initialization process of the rear camera
STEERING ANGLE SENSOR
ADJUSTMENT Execute register neutral point of steering angle sensor
CALIBRATING CAMERA IM-
AGE (REAR CAMERA) Displays the various values of the rear camera during the calibration process
REAR WIDE-VIEW FIXED
GUIDE LINE CORRECTION Adjustment the position of fixed guide line on rear wide view
REAR CAMERA ITS Displays and sets camera image calibration values
CAUSE OF LDW CANCEL Displays the information about reason of LDW cancellation
CAUSE OF BSW CANCEL Displays the information about reason of BSW cancellation
Te s t i t e m D e s c r i p t i o n
WASH ACTIVE ON
Activates the washer to clean the lens of rear camera
OFF
LED LH INDICATOR ON
Flashes the left side LED light for ITS system
OFF
LED RH INDICATOR ON
Flashes the right side LED light for ITS system
OFF
AIR ACTIVE ON
Activates the air pump to clean the lens of rear camera
OFF
AIR & WASH ACTIVE ON
Activates the air pump and washer to clean the lens of rear camera
OFF
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
DIAGNOSIS SYSTEM (ITS CONTROL UNIT)DAS-235
< SYSTEM DESCRIPTION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
ECU IDENTIFICATION
ITS control unit part number is displayed.
CONFIGURATION
The specifications of the vehicle can be writ ten and read in the ITS control unit when replaced.
Te s t i t e mOper-
ation Description
Blind Spot Warning ON indicator lamp
(Yellow)
BSW ON INDICATOR Off
Stops transmitting the Blind Spot Warning ON indicator
signal below to end the test Off
On Transmits the Blind Spot Warning ON indicator signal to
the warning lamp on the door ON
Washer Off
Stops transmitting activate signal to washer below to
end the test Off
On Transmits activate signal to washer ON
Air pump Off
Stops transmitting activate signal to air pump below to
end the test Off
On Transmits activate signal to air pump ON
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-236
< ECU DIAGNOSIS INFORMATION >[MOD]
ITS CONTROL UNIT
ECU DIAGNOSIS INFORMATION
ITS CONTROL UNIT
Reference ValueINFOID:0000000009951659
VALUES ON THE DIAGNOSIS TOOL
Monitor item Condition Value/Status
ST ANGLE SENSOR
SIGNAL Ignition switch ON Steering angle signal is received On
Steering angle signal is not received Off
REVERSE SIGNAL Ignition switch ON Shift selector in R (reverse) On
Shift selector is not in R (reverse) Off
VEHICLE SPEED
SIGNAL While driving Vehicle speed signal is received On
Vehicle speed signal is not received Off
CAMERA SWITCH
SIGNAL Ignition switch ON Camera switch is pressed On
Camera switch is not pressed Off
CAMERA OFF SIG-
NAL Ignition switch ON Purpose switch is pressed On
Purpose switch is not pressed Off
ST ANGLE SENSOR
TYPE Ignition switch ON Steering angle sensor type is displayed Absolute
Steering angle sensor type is not received Not
STEERING GEAR
RATIO TYPE Ignition switch ON Pattern 1 type of steering gear ratio displayed Pattern 1
Pattern 2 type of steering gear ratio displayed Pattern 2
STEERING POSI-
TION Ignition switch ON It recognizes steering position is left LHD
It recognizes steering position is right RHD
R-CAMERA COMM
STATUS Ignition switch ON Rear camera serial status is OK OK
Rear camera serial status is not OK NG
R-CAMERA COMM
LINE Ignition switch ON Rear camera serial communication signal is received OK
Rear camera serial communication signal is not received NG
ILL Ignition switch ON Illumination is ON On
Illumination is OFF Off
ITS SW 1 Ignition switch ON ITS switch is pressed On
ITS switch is not pressed Off
ITS SW 1 IND Ignition switch ON Indicator of ITS switch 1 is lighting On
Indicator of ITS switch 1 is not lighting Off
TURN SIGNAL Ignition switch ON Turn signal left is received Left
Turn signal neutral is received N
Turn signal right is received Right
REAR CAMERA IM-
AGE SIGNAL Ignition switch ON Camera image signal is received On
Camera image signal is not received Off
ITS SW 2 Ignition switch ON For this vehicle, the displaying is fixed No setting
ITS SW 2 IND Ignition switch ON For this vehicle, the displaying is fixed No setting
WASH SW Ignition switch ON Wash switch signal is pressed On
Wash switch signal is not pressed Off
PUMP COMM STA-
TUS Ignition switch ON Pump communication signal is received On
Pump communication signal is not received Off
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
ITS CONTROL UNITDAS-237
< ECU DIAGNOSIS INFORMATION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
TERMINAL LAYOUT
PHYSICAL VALUES
ALOIA0156ZZ
Te r m i n a l N o . (Wire color) Description
Condition Va l u e
(Approx.)
+ − Signal name Input/
Output
1
(BR) Ground Washer level switch Input Ignition
switch ON When washer fluid is low
(switch closed) 0 V
When washer fluid is not
low (switch open) 12 V
2
(G) Ground Washer signal pump to
camera Input Ignition switch ON 5 V
3
(W) Ground
Washer signal camera
to pump Output Ignition switch ON 5 V
7
(P) Ground CAN -L — — — —
17
(G) Ground SOW LED signal R Output
While
driving LDW/BSW detected 12 V
LDW/BSW is not detected 0 V
20
(G) Ground Battery supply Input — — 12 V
22
(P) Ground Serial ground Output — — 0 V
27
(L) Ground CAN -H — — — —
28
(R) Ground Reverse Input
Ignition
switch ON Shift selector in R (re-
verse) 12 V
Shift selector not in R (re-
verse) 0 V
32
(P) Ground Cancel SW output Input Ignition
switch ON Cancel switch pressed 0 V
Cancel switch not pressed 12 V
33
(BG) Ground LED input Output Ignition
switch ON Warning system is ON 12 V
Warning system is OFF 0 V
37
(W) Ground SOW LED signal L Output While
driving LDW/BSW detected 12 V
LDW/BSW is not detected 0 V
39
(BG) Ground Ignition power supply Input Ignition switch ON Battery Voltage
40
(B) Ground Ground — — — 0 V
50, 53 Ground Shield — — — 0 V
51
(R) Ground RR CAM GND Output
Ignition
switch ON —0 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
