NISSAN TEANA 2014 Service Manual

DAS-188
< DTC/CIRCUIT DIAGNOSIS >[BSW]
C1A39 STEERING ANGLE SENSOR
C1A39 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009464833
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition ON.
2. Perform “All DTC Reading” with CONSULT.
3. Check if the "C1A39" is detected as the current malfunction in "Self Diagnostic Result" of "AVM".
Is
“C1A39” detected as the current malfunction?
YES >> Refer to DAS-188, "Diagnosis Procedure".
NO >> Refer to GI-43, "Intermittent Incident"
.
Diagnosis ProcedureINFOID:0000000009464834
1.CHECK STRG SENSOR SEL F-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-45, "DTC Index"
.
NO >> GO TO 2.
2.CHECK ALL UNIT SELF-DIANOSIS RESULTS
Check if any DTC is detected exc ept for ITS control unit about ABS in "ALL DTC READING" with CONSULT.
Is any DTC detected except for ITS?
YES >> Replace steering angle sensor. Refer to BRC-132, "Removal and Installation".
NO >> Replace ITS control unit. Refer to DAS-68, "Removal and Installation"
.
DTC Trouble diagnosis name DTC detecting condition Possible causes
C1A39 STRG SEN CIR ITS control unit receives the message that
means "Steering angle sensor is failed" from
steering angle sensor. • Steering angle sensor
• ITS control unit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
U0122 VDC P-RUN DIAGDAS-189
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U0122 VDC P-RUN DIAG
DTC LogicINFOID:0000000009464835
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition ON.
2. Perform “All DTC Reading” with CONSULT.
3. Check if the “U0122” is detected as the current malfunction in self-diagnosis results of “AVM”.
Is
“U0122” detected as the current malfunction?
YES >> Refer to DAS-189, "Diagnosis Procedure".
NO >> Refer to GI-43, "Intermittent Incident"
.
Diagnosis ProcedureINFOID:0000000009464836
1.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and re pair or replace the malfunctioning parts.
NO >> GO TO 2.
2.CHECK ITS CONTROL UNIT SE LF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and re pair or replace the malfunctioning parts.
NO >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Instal-
lation".
DTC Trouble diagnosis name DTC detecting condition Possible causes
U0122 VDC P-RUN DIAG ITS control unit receives the incorrect signal
about P-RUN from VDC via V-CAN communi-
cation ABS actuator and electric unit (control
unit)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-190
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U0416 VDC CHECKSUM DIAG
U0416 VDC CHECKSUM DIAG
DTC LogicINFOID:0000000009464837
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition ON.
2. Perform “All DTC Reading” with CONSULT.
3. Check if the “U0416” is detected as the current malfunction in self-diagnosis results of “AVM”.
Is
“U0416” detected as the current malfunction?
YES >> Refer to DAS-190, "Diagnosis Procedure".
NO >> Refer to GI-43, "Intermittent Incident"
.
Diagnosis ProcedureINFOID:0000000009464838
1.CHECK VDC UNIT SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and re pair or replace the malfunctioning parts.
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and re pair or replace the malfunctioning parts.
NO >> Replace the ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Instal-
lation".
DTC Trouble diagnosis name DTC detecting condition Possible causes
U0416 VDC CHECKSUM
DIAG ITS control unit receives the incorrect signal
about P-RUN from VDC via V-CAN communi-
cation ABS actuator and electric unit (control
unit)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
U0428 STEERING ANGLE SENSORDAS-191
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U0428 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009464839
Diagnosis ProcedureINFOID:0000000009464840
1.ADJUST THE NEUTRAL POSITION OF THE STEERING ANGLE SENSOR
When U1232 is detected, adjust the neutral position of the steering angle sensor.
>> Perform adjustment of the neutral position of the steering angle sensor. Refer to BRC-33, "CON-
SULT Function (ABS)".
DTCDisplay contents of
CONSULT DTC detection condition Possible malfunction factor
U0428 ST ANGLE SENSOR
CALIBRATION [U0428] The neutral position adjustment of the steering angle sen-
sor is incomplete. Adjust neutral position of the steering
angle sensor.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-192
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464841
CAN COMMUNICATION
CAN (Controller Area Network) is a serial communication
line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control units , and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H, CAN-L) allowing a hi gh rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads the required data only.
CAN communication signal chart. Refer to LAN-32, "CAN COMMUNICATION SYSTEM : CAN Communica-
tion Signal Chart".
ITS COMMUNICATION
• ITS communication is a multiplex communication system . This enables the system to transmit and receive
large quantities of data at high speed by connecting control units with 2 communication lines.
• ITS communication lines adopt twisted-pair line st yle (two lines twisted) for noise immunity.
DTC LogicINFOID:0000000009464842
DTC DETECTION LOGIC
NOTE:
If “U1000” is detected, first di agnose the CAN communication system.
Diagnosis ProcedureINFOID:0000000009464843
1.PERFORM THE SELF-DIAGNOSIS
1. Turn the ignition switch ON.
2. Turn the MAIN switch of ITS system ON, and then wait for 30 seconds or more.
3. Perform “All DTC Reading” with CONSULT.
4. Check if the “U1000” is detected as the current malfunction in “Self Diagnostic Result” of “AVM”.
Is
“U1000” detected as the current malfunction?
YES >> Refer to DAS-192, "Description".
NO >> Refer to GI-43, "Intermittent Incident"
.
DTC Trouble diagnosis name DTC detecting condition Possible causes
U1000 CAN COMM CIRCUIT If ITS control unit is not transmitting or receiving
CAN communication signal or ITS communica-
tion signal for 2 seconds or more • CAN communication system
• ITS communication system
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
U1010 CONTROL UNIT (CAN)DAS-193
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000009464844
CAN controller controls the communication of CA N communication signal and ITS communication signal, and
the error detection.
DTC LogicINFOID:0000000009464845
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000009464846
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn the MAIN switch of ITS system ON.
2. Perform “All DTC Reading” with CONSULT.
3. Check if the “U1010” is detected as the current malfunction in “Self Diagnostic Result” of “AVM”.
Is
“U1010” detected as the current malfunction?
YES >> Replace the ITS control unit. Refer to DAS-68, "Removal and Installation".
NO >> Inspection End.
DTC Trouble diagnosis name DTC detecting condition Possible causes
U1010 CONTROL UNIT (CAN) If ITS control unit detects malfunction by CAN
controller initial diagnosis ITS control unit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-194
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U111A REAR CAMERA IMAGE SIGNAL CIRCUIT
U111A REAR CAMERA IMAGE SIGNAL CIRCUIT
DTC LogicINFOID:0000000009464847
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000009464848
Regarding Wiring Diagram information, refer to
DAS-166, "Wiring Diagram".
1.CHECK CONTINUITY REAR CAMERA POWER SUPPLY AND GROUND CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the ITS control unit connector and rear camera connector.
3. Check for continuity between ITS control unit harness connector and rear camera harness connector.
4. Check for continuity between ITS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the harness or connector.
2.CHECK VOLTAGE REAR CAMERA POWER SUPPLY
1. Connect the ITS control unit connector and rear camera connector.
2. Turn the ignition switch ON.
3. Check voltage between ITS control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace ITS control unit. Refer to DAS-68, "Removal and Installation"
.
DTCTrouble diagnosis
name DTC detecting condition Possible causes
U111A REAR CAMERA IM- AGE SIGNAL Rear camera image signal circuit is open or
shorted Check rear camera image signal circuit
between rear camera and around view
monitor control unit.
ITS control unit Rear Camera Continuity
Connector Terminal Connector Terminal
M59 51
B357
Ye s
52 8
ITS control unit GroundContinuity
Connector Terminal
M59 52 No
Te r m i n a l
ConditionVo l ta g e
(Approx.)
(+)
(–)
ITS control unit
Connector Terminal
M59 52 Ground "CAMERA"
switch is ON or
shift selector is
in R (Reverse) 6.2 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
U111A REAR CAMERA IMAGE SIGNAL CIRCUITDAS-195
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
3.CHECK CONTINUITY REAR CA MERA IMAGE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the ITS control unit c onnector and rear camera connector.
3. Check for continuity between ITS control unit harness connector and rear camera harness connector.
4. Check for continuity between ITS control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK REAR CAMERA IMAGE SIGNAL
1. Connect the ITS control unit connector and rear camera connector.
2. Turn the ignition switch ON.
3. Using an oscilloscope, check voltage between ITS control unit harness connector terminals.
Is inspection result normal?
YES >> Replace ITS control unit. Refer to DAS-68, "Removal and Installation".
NO >> Replace rear view camera. Refer to DAS-219, "Removal and Installation"
.
ITS control unit Rear View Camera
Continuity
Connector Terminal Connector Terminal
M59 50
B351
Ye s
66 5
ITS control unit GroundContinuity
Connector Terminal
M59 50
No
66
Te r m i n a l
ConditionVo l ta g e
(Approx.)
(+) (–)
ITS control unit
Connector Terminal Connector Terminal
M5966M5950 "CAMERA"
switch is ON or
shift selector is
in R (Reverse)
ALOIA0179ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS-196
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U1232 STEERING ANGLE SENSOR
U1232 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009464849
Diagnosis ProcedureINFOID:0000000009464850
1.REGISTER THE NEUTRAL POSITION
OF THE STEERING ANGLE SENSOR
1. Turn the ignition switch ON.
2. Perform registration of the neutral positi on of the steering angle sensor. Refer to DAS-158, "CONSULT
Function (AVM)".
3. Check “Self Diagnostic Result” of “AVM” with CONSULT. Refer to DAS-158, "CONSULT Function (AVM)"
.
Is
“ST ANGLE SEN CALIB” detected?
YES >> GO TO 2.
NO >> Inspection End.
2.CHECK STEERING ANGLE SENSOR
Check steering angle sensor.
Is the inspection result normal?
YES >> Replace ITS control unit. Refer to DAS-68, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
DTC Display contents of
CONSULT DTC detection condition Possible malfunction factor
U1232 ST ANGLE SEN CALIB The neutral position registration of the steering angle sen-
sor cannot finish. • Steering angle sensor
•ITS control unit
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DAS
U1305 CAMERA IMAGE CALIBDAS-197
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U1305 CAMERA IMAGE CALIB
DTC LogicINFOID:0000000009464851
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000009464852
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1305” is current in “Self Diagnostic Result” of “AVM”.
Is
“U1305” detected?
YES >> Perform ITS configurati on using CONSULT. Refer to DAS-158, "CONSULT Function (AVM)". If
problem persists, repair or replace the malfunctioning part.
NO >> Refer to GI-43, "Intermittent Incident"
.
DTC Trouble diagnosis name DTC detecting condition Possible causes
U1305 CAMERA CONFIG ITS control unit configuration is incomplete Perform ITS configuration with CONSULT
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
