TRUNK LID OPENER SWITCHDLK-123
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
YES >> GO TO 3
NO >> Repair harness or connector.
3.CHECK TRUNK LID OPENER SWITCH GROUND CIRCUIT
Check continuity between trunk lid opener switch connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4.CHECK TRUNK LID OPENER SWITCH
Refer to DLK-123, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 5
NO >> Replace trunk lid opener switch.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461856
1.CHECK TRUNK LID OPENER SWITCH
1. Turn ignition switch OFF.
2. Disconnect trunk lid opener switch connector.
3. Check continuity between trunk lid opener switch connector.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace trunk lid opener switch.
Trunk lid opener switch Terminal GroundContinuity
M75 2 Yes
Te r m i n a l Condition Continuity
Trunk lid opener switch
12 ON (press and hold) Yes
OFF (release) No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 892 of 4801
DLK-124
< DTC/CIRCUIT DIAGNOSIS >
TRUNK LID OPENER CANCEL SWITCH
TRUNK LID OPENER CANCEL SWITCH
DescriptionINFOID:0000000009461857
Cancels trunk lid open operation.
Component Function CheckINFOID:0000000009461858
1.CHECK FUNCTION
With CONSULT
Check trunk lid opener cancel switch TR CA NCEL SW in Data Monitor mode with CONSULT.
Is the inspection result normal?
YES >> Trunk lid opener cancel switch is OK.
NO >> Refer to DLK-124, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461859
Regarding Wiring Diagram information, refer to DLK-77, "Wiring Diagram".
1.CHECK TRUNK LID OPENER CANCEL SIGNAL
Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> GO TO 2
2.CHECK TRUNK LID OPENER CANCEL SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM connector and trunk lid opener cancel switch connector.
3. Check continuity between BCM connector and ground.
Monitor item Condition
TR CANCEL SW Trunk lid opener cancel switch is turned to “ON”: ON
Trunk lid opener cancel switch is turned to “OFF”: OFF
Te r m i n a l s Condition of trunk lid opener cancel switch Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M17 33 Ground ON 0
OFF
JPMIA0012GB
BCM connector Terminal Trunk lid opener cancel
switch connector Terminal Continuity
M17 33 M74 1 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 893 of 4801
TRUNK LID OPENER CANCEL SWITCHDLK-125
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair harness or connector.
3.CHECK TRUNK LID OPENER CANCEL SWITCH GROUND CIRCUIT
Check continuity between trunk lid opener switch connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4.CHECK TRUNK LID OPENER CANCEL SWITCH
Refer to DLK-125, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 5
NO >> Replace trunk lid opener cancel switch.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461860
1.CHECK TRUNK LID OPENER CANCEL SWITCH
1. Disconnect trunk lid opener cancel switch connector.
2. Check continuity between trunk lid opener cancel switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace trunk lid opener cancel switch.
BCM connector Terminal GroundContinuity
M17 33 No
Trunk lid opener cancel switch Te r m i n a l
Ground Continuity
M74 2 Yes
Te r m i n a l Condition Continuity
Trunk lid opener cancel
switch
12 ON Yes
OFF (cancel) No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 894 of 4801
DLK-126
< DTC/CIRCUIT DIAGNOSIS >
TRUNK LAMP SWITCH
TRUNK LAMP SWITCH
DescriptionINFOID:0000000009461861
Detects trunk open/close condition.
Component Function CheckINFOID:0000000009461862
1.CHECK FUNCTION
With CONSULT
Check TRNK/HAT MNTR in Data Monitor mode with CONSULT.
Is the inspection result normal?
YES >> Trunk lamp switch is OK.
NO >> Refer to DLK-126, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461863
Regarding Wiring Diagram information, refer to DLK-51, "Wiring Diagram".
1.CHECK TRUNK LAMP SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
2.CHECK TRUNK LAMP SWITCH CIRCUIT
1. Disconnect BCM and trunk lamp switch and trunk release solenoid connectors.
2. Check continuity between BCM connector and trunk la mp switch and trunk release solenoid connector.
3. Check continuity between BCM connector and ground.
Monitor item Condition
TRNK/HAT MNTR OPEN : ON
CLOSE : OFF
Te r m i n a l s Trunk
condition Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M19 97 Ground OPEN 0
CLOSE
JPMIA0011GB
BCM connector Terminal Trunk lamp switch and
trunk release solenoid connector Terminal Continuity
M19 97 B28 1 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 895 of 4801
TRUNK LAMP SWITCHDLK-127
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between BCM and trunk lamp switch and trunk release solenoid.
3.CHECK TRUNK LAMP SWITCH GROUND CIRCUIT
Check continuity between trunk lid lock assembly connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace trunk lamp switch and trunk release solenoid ground circuit.
4.CHECK BCM OUTPUT SIGNAL
1. Insure trunk remains closed during this step.
2. Connect BCM connector.
3. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5.CHECK TRUNK LAMP SWITCH
Refer to DLK-127, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 6
NO >> Replace trunk lamp switch and trunk release solenoid.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461864
1.CHECK TRUNK LAMP SWITCH
1. Turn ignition switch OFF.
2. Disconnect trunk lamp switch and trunk release solenoid connector.
3. Check trunk lamp switch.
BCM connector Terminal GroundContinuity
M19 97 No
Trunk lamp switch and trunk release solenoid connector Te r m i n a l
GroundContinuity
B28 2 Yes
Te r m i n a l s Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M19 97 Ground
JPMIA0011GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 896 of 4801
DLK-128
< DTC/CIRCUIT DIAGNOSIS >
TRUNK LAMP SWITCH
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace trunk lamp switch and trunk release solenoid.
Te r m i n a l
Trunk condition Continuity
Trunk lamp switch and trunk release
solenoid
12 OPEN Yes
CLOSE No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 897 of 4801
DOOR REQUEST SWITCHDLK-129
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR REQUEST SWITCH
DescriptionINFOID:0000000009461865
Transmits door lock/unlock operation to BCM.
Component Function CheckINFOID:0000000009461866
1.CHECK FUNCTION
With CONSULT
Check door request switch REQ SW-DR, REQ SW-AS in Data Monitor mode.
Is the inspection result normal?
YES >> Door request switch is OK.
NO >> Refer to DLK-129, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461867
Regarding Wiring Diagram information, refer to DLK-61, "Wiring Diagram".
1.CHECK DOOR REQUEST SWITCH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
Monitor item Condition
REQ SW-DR
REQ SW-AS Door request switch is pressed : ON
Door request switch is released : OFF
Te r m i n a l s Door request
switch Condition Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M18 Door request switch
(driver side) 71
Ground Pressed 0
Released
Door request switch (passenger side) 72 Pressed 0
Released
JMKIA0059GB
JMKIA0059GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 898 of 4801
DLK-130
< DTC/CIRCUIT DIAGNOSIS >
DOOR REQUEST SWITCH
2.CHECK DOOR REQUEST SWITCH CIRCUIT
1. Disconnect BCM and front outside handle connector.
2. Check continuity between BCM connector and front outside handle connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between BCM and front outside handle.
3.CHECK DOOR REQUEST SWITCH GROUND CIRCUIT
Check continuity between front outside handle connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace front outside handle ground circuit.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5.CHECK DOOR REQUEST SWITCH
Refer to DLK-131, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 6
BCM connector Terminal Front outside
handle connector Terminal Continuity
M18 71 D6 (driver side)
3Yes
72 D106 (passenger side)
BCM connector Terminal GroundContinuity
M18 71
No
72
Front outside
handle
connector Te r m i n a l
GroundContinuity
D6 (driver side) 4Yes
D106 (passenger
side)
Te r m i n a l s Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M18 71
Ground
72
JMKIA0059GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 899 of 4801
DOOR REQUEST SWITCHDLK-131
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Replace malfunctioning front outside handle.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461868
1.CHECK DOOR REQUEST SWITCH
Check front outside handle (request switch).
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunction front outside handle.
Te r m i n a l Door request switch
condition Continuity
Front outside handle (request switch)
34 Pressed Yes
Released No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 900 of 4801
DLK-132
< DTC/CIRCUIT DIAGNOSIS >
TRUNK OPENER REQUEST SWITCH
TRUNK OPENER REQUEST SWITCH
DescriptionINFOID:0000000009461869
Performs trunk lid open request when it is pressed.
Component Function CheckINFOID:0000000009461870
1.CHECK FUNCTION
With CONSULT
Check trunk opener request switch REQ SW -BD/TR in Data Monitor mode.
Is the inspection result normal?
YES >> Trunk opener request switch is OK.
NO >> Refer to DLK-132, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461871
Regarding Wiring Diagram information, refer to DLK-61, "Wiring Diagram".
1.CHECK TRUNK OPENER REQUEST SWITCH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 6
NO >> GO TO 2
2.CHECK TRUNK OPENER REQUEST SWITCH CIRCUIT
1. Disconnect BCM and trunk opener request switch connector.
2. Check continuity between BCM connector and trunk opener request switch connector.
3. Check continuity between BCM connector and ground.
Monitor item Condition
REQ SW -BD/TR Trunk opener request switch is pressed : ON
Trunk opener request switch is released : OFF
Te r m i n a l s Trunk lid opener request
switch condition Voltage (V)
(Approx.)
(+)
(–)
BCM connector Terminal
M19 83 Ground Pressed 0
Released
JPMIA0016GB
BCM connector Terminal Trunk opener request switch
connector Terminal Continuity
M19 83 B33 1 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
