ECM controls the engine by various functions.
ENGINE CONTROL SYSTEM : Fail SafeINFOID:0000000009462092
NON DTC RELATED ITEM
DTC RELATED ITEM
Description
When a DTC is detected, ECM executes a mode (in the
Fail-safe mode) applicable to the DTC. The fail-safe
mode has the preset traveling control mode (accelera tor angle variation and engine output limit) and device fix
mode.
Function Reference
Multiport fuel injection system EC-43, "MULTIPORT FUEL INJECTION SYSTEM : System De-
scription (with automatic air conditioner)"
Electric ignition system
EC-48, "ELECTRIC IGNITION SYSTEM : System Description"
Intake valve timing control EC-49, "INTAKE VALVE TIMING CONTROL : System Description"
Exhaust valve timing control EC-52, "EXHAUST VALVE TIMING
CONTROL : System Descrip-tion"
Intake manifold runner control EC-53, "INTAKE MANIFOLD RUNNER CONTROL : System De-scription"
Intake manifold tuning system
EC-54, "INTAKE MANIFOLD TUNI
NG SYSTEM : System Descrip-tion"
Engine protection control EC-55, "ENGINE PROTECTION CONTROL AT LOW ENGINE OIL PRESSURE : System Description"
Fuel filler cap warning systemEC-56, "FUEL FILLER CAP WARNING SYSTEM : System De-scription"
Air conditioning cut control
EC-56, "AIR CONDITIONING CUT CONTROL : System Descrip-tion (with automatic air conditioner)"
Cooling fan controlEC-59, "COOLING FAN CONTROL :
System Description (with au-tomatic air conditioner)"
Evaporative emission system EC-62, "EVAPORATIVE EMISSION
SYSTEM : System Descrip-tion"
Automatic speed control device (ASCD) EC-63, "AUTOMATIC SPEED CONTROL DEVICE (ASCD) : Sys-tem Description"
CAN communication
EC-64, "CAN COMMUNICATION : System Description"
Detected
items Engine operating condition
in fail-safe mode Remarks Reference page
Malfunction
indicator
lamp circuit Engine speed will not rise
more than 2,500 rpm due
to the fuel cut When there is an open circuit on MIL circuit, the ECM cannot warn the
driver by lighting up MIL when there is malfunction on engine control
system.
Therefore, when electrical controlled throttle and part of ECM related
diagnoses are continuously detected as NG for 5 trips, ECM warns the
driver that engine control system malfunctions and MIL circuit is open
by means of operating fail safe function.
The fail safe function also operates when above diagnoses except MIL
circuit are detected and demands the driver to repair the malfunction. EC-517, "Compo-
nent Function
Check"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-82
< SYSTEM DESCRIPTION >[QR25DE]
DIAGNOSIS SYSTEM (ECM)
ALT DUTY SIG On/Off• The control condition of the power gener-
ation voltage variable control (deter-
mined by ECM according to the input
signals) is indicated.
- On: Power generation voltage variable control is active.
- Off: Power generation voltage variable control is inactive.
I/P PULLY SPD rpm • Indicates the engine speed computed
from the input speed sensor signal.
VEHICLE SPEED km/h or mph • The vehicle speed computed from the
vehicle speed signal sent from TCM is
displayed.
IDL A/V LEARN YET/CMPLT • Displays the condition of Idle Air Volume
Learning
- YET: Idle air volume learning has not been performed yet.
- CMPLT: Idle air volume learning has al-
ready been performed successfully.
TRVL AFTER MIL km or mile • Distance traveled while MIL is activated.
ENG OIL TEMP °C or °F • The engine oil temperature (determined
by the signal voltage of the engine oil
temperature sensor) is displayed.
A/F S1 HTR(B1) % • Air fuel ratio (A/F) sensor 1 heater control
value computed by ECM according to the
input signals.
• The current flow to the heater becomes
larger as the value increases.
VHCL SPEED SE km/h or mph • The vehicle speed computed from the
vehicle speed signal sent from combina-
tion meter is displayed.
SET VHCL SPD km/h or mph • The preset vehicle speed is displayed.
MAIN SW On/Off • Indicates [ON/OFF] condition from MAIN
switch signal.
CANCEL SW On/Off • Indicates [ON/OFF] condition from CAN-
CEL switch signal.
RESUME/ACC SW On/Off • Indicates [ON/OFF] condition from RE-
SUME/ACCELERATE switch signal.
SET SW On/Off • Indicates [ON/OFF] condition from SET/
COAST switch signal.
BRAKE SW1 On/Off • Indicates [ON/OFF] condition from brake
pedal position switch signal.
BRAKE SW2 On/Off • Indicates [ON/OFF] condition of stop
lamp switch signal.
VHCL SPD CUT Non/Cut • Indicates the vehicle cruise condition.
- Non: Vehicle speed is maintained at the
ASCD set speed.
- Cut: Vehicle speed decreased to exces- sively low compared with the ASCD set
speed, and ASCD operation is cut off.
Monitored item Unit
Monitor Item
Selection
Description Remarks
ECU
IN-
PUT
SIG-
NALS MAIN
SIG-
NAL S
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-90
< ECU DIAGNOSIS INFORMATION >[QR25DE]
ECM
VIAS S/V-1• Engine: After warming up
• Selector lever: P or N
• Air conditioner switch: OFF
•No load When revving engine up to 5,000 rpm
quickly Off
→ On → Off
AIR COND RLY • Engine: After warming up, idle the
engine Air conditioner switch: OFF Off
Air conditioner switch: ON
(Compressor operates) On
FUEL PUMP RLY • For 1 second after turning ignition switch: ON
• Engine running or cranking On
• Except above Off
VENT CONT/V • Ignition switch: ON Off
THRTL RELAY • Ignition switch: ON On
COOLING FAN • Engine: After warming up, idle the
engine
• Air conditioner switch: OFF Engine coolant temperature is 97
°C
(207 °F) or less Off
Engine coolant temperature between
98 °C (208 °F) and 99 °C (210 °F) or more Low
Engine coolant temperature between
100 °C (212 °F) or more Hi
• Engine: After warming up, idle the engine
• Air conditioner switch: ON
• Refrigerant pressure is less than 1,280 kPa (12.80 bar, 13.05 kg/
cm
2, 185.6 psi) Engine coolant temperature is 97
°C
(207 °F) or less Off
Engine coolant temperature between
98 °C (208 °F) and 99 °C (210 °F) or more Mid
Engine coolant temperature between
100 °C (212 °F) or more Hi
HO2S2 HTR (B1) • Engine speed: Below 3,600 rpm after the following conditions are met.
- Engine: After warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load On
• Engine speed: Above 3,600 rpm Off
ALT DUTY SIG • Power generation voltage variable control: Operating On
• Power generation voltage variable control: Not operating Off
I/P PULLY SPD • Vehicle speed: More than 20 km/h (12 MPH) Almost the same speed as
the tachometer indication
VEHICLE SPEED • Turn drive wheels and compare CONSULT value with the speedometer indi-
cation. Almost the same speed as
the speedometer indication
IDL A/V LEARN • Engine: running Idle air volume learning has not been per-
formed yet. YET
Idle air volume learning has already been
performed successfully. CMPLT
TRVL AFTER MIL • Ignition switch: ON Vehicle has traveled after MIL has turned
ON. 0 - 65,535 km
(0 - 40,723 miles)
ENG OIL TEMP • Engine: After warming up More than 70 °C (158 °F)
A/F S1 HTR(B1) • Engine: After warming up, idle the engine
(More than 140 seconds after starting engine.) 4 - 100%
VHCL SPEED SE • Turn drive wheels and compare CONSULT value with the speedometer indi-
cation. Almost the same speed as
the speedometer indication
SET VHCL SPD • Engine: Running ASCD: Operating The preset vehicle speed is
displayed
MAIN SW • Ignition switch: ON MAIN switch: Pressed On
MAIN switch: Released Off
Monitor Item Condition Values/Status
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-606
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
COOLING FANHI/MID/
LOW/OFF • The control condition of the cool-
ing fan (determined by ECM ac-
cording to the input signals) is
indicated.
HI: High speed operation
MID: Middle speed operation
LOW: Low speed operation
OFF: Stop
HO2S2 HTR (B1)
On/Off Indicates [On/Off] condition of heat-
ed oxygen sensor 2 heater deter-
mined by ECM according to the
input signals.
HO2S2 HTR (B2)
ALT DUTY SIG On/Off The control condition of the power
generation voltage variable control
(determined by ECM according to
the input signals) is indicated.
• On: Power generation voltage variable control is active.
• Off: Power generation voltage
variable control is inactive.
I/P PULLY SPD rpm Indicates the engine speed comput-
ed from the input speed sensor sig-
nal.
VEHICLE SPEED km/h or
mph The vehicle speed computed from
the vehicle speed signal sent from
TCM is displayed.
IDL A/V LEARN YET/
CMPLT Displays the condition of idle air vol-
ume learning
• Yet: Idle Air Volume Learning has not been performed yet.
• Cmplt: Idle Air Volume Learning
has already been performed suc-
cessfully.
TRVL AFTER MIL km or
mile Distance traveled while MIL is acti-
vated.
ENG OIL TEMP °C or °F The engine oil temperature (deter-
mined by the signal voltage of the
engine oil temperature sensor) is
displayed.
VHCL SPEED SE km/h or
mph The vehicle speed computed from
the vehicle speed signal sent from
combination meter is displayed.
SET VHCL SPD km/h or
mph • The preset vehicle speed is dis-
played.
MAIN SW On/Off Indicates [On/Off] condition from
MAIN switch signal.
CANCEL SW On/Off Indicates [On/Off] condition from
CANCEL switch signal.
RESUME/ACC SW On/Off Indicates [On/Off] condition from
RESUME/ACCELERATE switch sig-
nal.
SET SW On/Off Indicates [On/Off] condition from
SET/COAST switch signal.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-616
< ECU DIAGNOSIS INFORMATION >[VQ35DE]
ECM
HO2S2 HTR (B2)Engine speed: Below 3,600 rpm after the following conditions are met.
• Engine: After warming up
• Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at idle for 1 minute under no load On
Engine speed: Above 3,600 rpm Off
ALT DUTY SIG Power generation voltage variable control: Operating On
Power generation voltage variable control: Not operating Off
I/P PULLY SPD Vehicle speed: More than 20 km/h (12 MPH) Almost the same speed as
the tachometer indication
VEHICLE SPEED Turn drive wheels and compare CONSULT value with the speedometer indica-
tion. Almost the same speed as
the speedometer indication
IDL A/V LEARN Engine: Running Idle air volume learning has not been per-
formed yet. YET
Idle air volume learning has already been
performed successfully. CMPLT
TRVL AFTER MIL Ignition switch: ON Vehicle has traveled after MIL has illumi-
nated. 0 - 65,535 km
(0 - 40,723 miles)
ENG OIL TEMP Engine: After warming up More than 70 °C (158 °F)
VHCL SPEED SE Turn drive wheels and compare CONSULT value with the speedometer indica-
tion. Almost the same speed as
the speedometer indication
SET VHCL SPD Engine: Running ASCD: Operating The preset vehicle speed is
displayed
MAIN SW Ignition switch: ON MAIN switch: Pressed On
MAIN switch: Released Off
CANCEL SW Ignition switch: ON CANCEL switch: Pressed On
CANCEL switch: Released Off
RESUME/ACC SW Ignition switch: ON RESUME/ACCELERATE switch:
Pressed On
RESUME/ACCELERATE switch: Re-
leased Off
SET SW Ignition switch: ON SET/COAST switch: Pressed On
SET/COAST switch: Released Off
BRAKE SW1
(Brake pedal posi-
tion switch) Ignition switch: ON Brake pedal: Fully released On
Brake pedal: Slightly depressed Off
BRAKE SW2
(Stop lamp switch) Ignition switch: ON Brake pedal: Fully released Off
Brake pedal: Slightly depressed On
VHCL SPD CUT Ignition switch: ON Non
LO SPEED CUT Ignition switch: ON Non
AT OD MONITOR Ignition switch: ON Off
AT OD CANCEL Ignition switch: ON Off
CRUISE LAMP Ignition switch: ON MAIN switch: Pressed at the 1st time
→
at the 2nd time On
→ Off
SET LAMP • MAIN switch: ON
• When vehicle speed is between 40 km/h (25 MPH) and 144 km/h
(89 MPH) ASCD: Operating On
ASCD: Not operating Off
ALT DUTY Engine: Idle 0 - 80%
Monitor Item Condition Values/Status
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

LAN
SYSTEMLAN-33
< SYSTEM DESCRIPTION > [CAN]
C
D E
F
G H
I
J
K L
B
A
O P
N
Engine status signal T R R R R
Fuel consumption monitor signal T R R
Fuel filler cap warning display signal T R
Malfunctioning indicator lamp signal TR
RT
Oil pressure warning lamp signal T R
Power generation command value
signal TR
Target throttle position signal T R
Wide open throttle position signal T R
EPS operation signal R T
Hydraulic pump electric power steer-
ing warning lamp signal TR
Detention switch signal T R R
Front wiper stop position signal T R
High beam status signal R T
Hood switch signal T R
Interlock/PNP switch signal RT
TR R
Low beam status signal R T
Oil pressure switch signal RT
TR R
Push-button ignition switch status
signal TR
Rear window defogger control signal R T
Sleep ready signal T R
Starter relay status signal T R
Steering lock unit status signal T R
Steering lock relay signal RT
TR
Current gear position signal T R R
CVT position indicator signal T R R
Input shaft revolution signal R T R R
Manual mode indicator signal T R R
N range signal T R
Output shaft revolution signal R T R R
O/D OFF indicator signal
*1TR R
P range signal T R R
Shift position signal T R R
Brake fluid level signal T R
Distance to empty signal T R
Fuel filler cap warning reset signal R T
Fuel level low warning signal T R
Fuel level sensor signal R T Signal name
ECM
EPS
IPDM-E TCM
M&A
STRG AV
AV M
HVAC ABS
BCM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

MWI-8
< SYSTEM DESCRIPTION >
COMPONENT PARTS
Unit Description
Combination meter Controls the following with the signals received from each unit via CAN communication and the signals
from switches and sensors:
• Speedometer
• Tachometer
• Engine coolant temperature gauge
• Fuel gauge
• Warning lamps
• Indicator lamps
• Meter illumination control
• Meter effect function
• Information display
Meter control switch Transmits the following signals to the combination meter:
• Trip reset switch signal
• Illumination control switch signal (+)
• Illumination control switch signal ( −)
ECM Transmits the following signals to the combination meter via CAN communication:
• Engine speed signal
• Engine coolant temperature signal
• Engine oil pressure warning signal
• Fuel consumption monitor signal
ABS actuator and electric unit
(control unit) Transmits the vehicle speed signal to the combination meter via CAN communication.
Power steering control module Transmits the EPS signal to the combination meter via CAN communication.
BCM Transmits the following signals to the combination meter via CAN communication:
• Tire pressure information
• Position light request signal
• Low tire pressure warning lamp signal
• Door switch signal
• Trunk lamp switch signal
TCM Receives the O/D OFF switch signal from the combination meter via CAN communication.
Transmits the O/D OFF indicator request signal to the combination meter via CAN communication.
CVT shift selector switch
(overdrive co ntrol switch)
(with QR25DE) Transmits the O/D OFF switch signal to the combination meter
Fuel level sensor unit Transmits the fuel level sensor signal to the combination meter.
Seat belt buckle switch LH
(RH similar) Transmits the seat belt buckle switch LH signal to the combination meter.
Air bag diagnosis sensor unit Transmits the following signals to the combination meter:
• Seat belt buckle switch RH signal
• Air bag warning indicator
Engine oil pressure sensor Transmits the engine oil pressure sensor signal to the ECM.
Ambient sensor Transmits the ambient sensor signal to the IPDM E/R.
A/C auto amp. • Receives the ambient sensor signal from the IPDM E/R (with auto A/C).
• Transmits the ambient sensor signal to the combination meter via CAN communication.
Parking brake switch Transmits the parking brake switch signal to the combination meter.
Washer fluid level switch Transmits the washer fluid level switch signal to the combination meter.
Steering switch Transmits the following signals to the information display:
• Display signal
• Menu up signal
• Menu down signal
• Enter signal
• Back signal
IPDM E/R • Receives the ambient sensor signal from the ambient sensor.
• Transmits the ambient sensor signal to the combination meter (without auto A/C).
• Transmits the ambient sensor signal to the A/C auto amp (with auto A/C).
Brake fluid level switch Transmits the brake fluid level switch signal to the combination meter.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
