CVT-44
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
6. While holding down the foot brake, gradually press down the
accelerator pedal.
7. Quickly read off the stall speed, and then quickly remove your
foot from the accelerator pedal.
CAUTION:
Do not hold down the accelerator pedal for more than 5 sec-
onds during this test.
8. Move the selector lever to the “N” position.
9. Cool down the CVT fluid.
CAUTION:
Run the engine at idle for at least 1 minute.
10. Repeat steps 6 through 9 with selector lever in “R” position.
Judgement Stall Test
O: Stall speed within standard value position.
H: Stall speed is higher than standard value.
L: Stall speed is lower than standard value.
Stall speed: 2,600 - 3,150 rpm
SAT5 1 4G
SAT7 7 1B
Selector lever position
Expected problem location
“D” “R”
Stall rotation HO

Forward clutch
OH

Reverse brake
LL

Engine and torque converter one-way clutch
HH

Line pressure low

Primary pulley

Secondary pulley

Steel belt

TROUBLE DIAGNOSIS
CVT-45
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
LINE PRESSURE TEST
Line Pressure Test Port
Line Pressure Test Procedure
1. Inspect the amount of engine oil and replenish if necessary.
2. Drive the car for about 10 minutes to warm it up so that the CVT fluid reaches in the range of 50 to 80°C
(122 to 176°F), then inspect the amount of CVT fluid and replenish if necessary.
NOTE:
The CVT fluid temperature rises in the range of 50 - 80°C (122 - 176°F) during 10 minutes of driving.
3. After warming up CVT, remove the oil pressure detection plug and install the oil pressure gauge [special
service tool: - (OTC3492)].
CAUTION:
When using the oil pressure gauge, be sure to use the O-ring attached to the oil pressure detec-
tion plug.
4. Securely engage the parking brake so that the tires do not turn.
5. Start the engine, and then measure the line pressure at both idle
and the stall speed.
CAUTION:

Keep the brake pedal pressed all the way down during
measurement.

When measuring the line pressure at the stall speed,
refer to CVT-43, "
STALL TEST" .
6. After the measurements are complete, install the oil pressure
detection plug and tighten to the specified torque below.
CAUTION:

Do not reuse O-ring.

Apply CVT fluid to O-ring.
SCIA6184E
SAT5 1 3G
: 7.5 N·m (0.77 kg-m, 66 in-lb)SAT4 9 3G

CVT-46
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
Line Pressure
*: Reference values
Judgement of Line Pressure Test
Road TestUCS005YC
DESCRIPTION

The purpose of the test is to determine overall performance of
CVT and analyze causes of problems.

The road test consists of the following three parts:
1. “Check Before Engine Is Started” CVT-49
.
2. “Check at Idle” CVT-49
.
3. “Cruise Test” CVT-50
.
Engine speed Line pressure kPa (kg/cm
2 , psi)
“R”, “D” and “L” positions
At idle 650 (6.63, 94.3)
At stall 4,250 (43.35, 616.3)*
Judgement Possible cause
Idle speedLow for all positions
(“P”, “R”, “N”, “D”, “L”)Possible causes include malfunctions in the pressure supply system and low oil pump output.
For example

Oil pump wear

Pressure regulator valve or plug sticking or spring fatigue

Oil strainer
oil pump
pressure regulator valve passage oil leak

Engine idle speed too low
Only low for a specific
positionPossible causes include an oil pressure leak in a passage or device related to the position after
the pressure is distributed by the manual valve.
HighPossible causes include a sensor malfunction or malfunction in the line pressure adjustment
function.
For example

Accelerator pedal position signal malfunction

CVT fluid temperature sensor malfunction

Pressure control solenoid A (line pressure solenoid) malfunction (sticking in OFF state, filter
clog, cut line)

Pressure regulator valve or plug sticking
Stall speedLine pressure does
not rise higher than
the line pressure for
idle.Possible causes include a sensor malfunction or malfunction in the pressure adjustment func-
tion.
For example

Accelerator pedal position signal malfunction

TCM malfunction

Pressure control solenoid A (line pressure solenoid) malfunction (shorting, sticking in ON
state)

Pressure regulator valve or plug sticking
The pressure rises,
but does not enter the
standard position.Possible causes include malfunctions in the pressure supply system and malfunction in the
pressure adjustment function.
For example

Accelerator pedal position signal malfunction

Pressure control solenoid A (line pressure solenoid) malfunction (sticking, filter clog)

Pressure regulator valve or plug sticking
Only low for a specific
positionPossible causes include an oil pressure leak in a passage or device related to the position after
the pressure is distributed by the manual valve.
SAT7 8 6A

TROUBLE DIAGNOSIS
CVT-47
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa

Before road test, familiarize yourself with all test procedures and
items to check.

Perform tests on all items until specified symptom is found.
Troubleshoot items which check out No Good after road test.
CONSULT-II OPERATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which performs CAN communication.

Using CONSULT-II, perform a cruise test and record the result.

Print the result and ensure that shifts and lock-ups take place as per Shift Schedule.
1. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
2. Touch “MAIN SIGNALS” to set recording condition.
3. See “Numerical Display”, “Barchart Display” or “Line Graph Dis-
play”.
4. Touch “START”.
5. When performing cruise test. Refer to CVT-50, "
Cruise Test" .
6. After finishing cruise test part, touch “RECORD”.
SAT4 9 6G
BCIA0031E
SCIA5493E
SCIA4584E

CVT-48
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
7. Touch “STORE”.
8. Touch “BACK”.
9. Touch “DISPLAY”.
10. Touch “PRINT”.
11. Check the monitor data printed out.
SCIA4492E
SCIA4493E
SCIA4492E
SCIA4494E

TROUBLE DIAGNOSIS
CVT-49
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
Check before Engine Is StartedUCS005YD
1. CHECK O/D OFF INDICATOR LAMP
1. Park vehicle on flat surface.
2. Move selector lever to “P” position.
3. Turn ignition switch OFF. Wait at least 5 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does O/D OFF indicator lamp come on for about 2 seconds?
YES >> 1. Turn ignition switch OFF.
2. Perform self-diagnosis and note NG items.
Refer to CVT-60, "
SELF-DIAGNOSTIC RESULT MODE" .
3. Go to CVT-49, "
Check at Idle" .
NO >> Stop “Road Test”. Go to CVT-180, "
O/D OFF Indicator Lamp Does Not Come On" .
Check at IdleUCS005YE
1. CHECK STARTING THE ENGINE
1. Park vehicle on flat surface.
2. Move selector lever to “P” or “N” position.
3. Turn ignition switch OFF.
4. Turn ignition switch START.
Is engine started?
YES >> GO TO 2.
NO >> Stop “Road Test”. Mark the box on the CVT-37, "
DIAGNOSTIC WORKSHEET" . Go to CVT-181,
"Engine Cannot Be Started in “P” and “N” Position" .
2. CHECK STARTING THE ENGINE
1. Turn ignition switch ON.
2. Move selector lever to “D”, “L” or “R” position.
3. Turn ignition switch START.
Is engine started?
YES >> Stop “Road Test”. Mark the box on the CVT-37, "DIAGNOSTIC WORKSHEET" . Go to CVT-181,
"Engine Cannot Be Started in “P” and “N” Position" .
NO >> GO TO 3.
3. CHECK “P” POSITION FUNCTION
1. Move selector lever to “P” position.
2. Turn ignition switch OFF.
3. Release parking brake.
4. Push vehicle forward or backward.
5. Apply parking brake.
Does vehicle move when it is pushed forward or backward?
YES >> Mark the box CVT-182, "In “P” Position, Vehicle Moves Forward or Backward When Pushed" on
the CVT-37, "
DIAGNOSTIC WORKSHEET" . Continue “Road Test”.
NO >> GO TO 4.

CVT-50
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
4. CHECK “N” POSITION FUNCTION
1. Start engine.
2. Move selector lever to “N” position.
3. Release parking brake.
Does vehicle move forward or backward?
YES >> Mark the box CVT-182, "In “N” Position, Vehicle Moves" on the CVT-37, "DIAGNOSTIC WORK-
SHEET" . Continue “Road Test”.
NO >> GO TO 5.
5. CHECK SHIFT SHOCK
1. Apply foot brake.
2. Move selector lever to “R” position.
Is there large shock when changing from
“N” to “R” position?
YES >> Mark the box CVT-183, "Large Shock “N” → “R” Position" on the CVT-37, "DIAGNOSTIC WORK-
SHEET" . Continue “Road Test”.
NO >> GO TO 6.
6. CHECK “R” POSITION FUNCTION
Release foot brake for several seconds.
Does vehicle creep backward when foot brake is released?
YES >> GO TO 7.
NO >> Mark the box CVT-184, "
Vehicle Does Not Creep Backward in “R” Position" on the CVT-37,
"DIAGNOSTIC WORKSHEET" . Continue “Road Test”.
7. CHECK “D”, “L” POSITIONS FUNCTION
Move selector lever to “D” and “L” positions and check if vehicle creeps forward.
Does vehicle creep forward in all positions?
YES >> Go to CVT-50, "Cruise Test" .
NO >> Stop “Road Test”. Mark the box on the CVT-37, "
DIAGNOSTIC WORKSHEET" . Go to CVT-185,
"Vehicle Does Not Creep Forward in “D” or “L” Position" .
Cruise TestUCS005YF
1. CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 1
1. Drive vehicle for approximately 10 minutes to warm engine oil and CVT fluid up to operating temperature.
2. Park vehicle on flat surface.
3. Move selector lever to “P” position.
4. Start engine.
5. Move selector lever to “L” position.
6. Accelerate vehicle to 2/8-way throttle depressing accelerator
pedal constantly.
Read vehicle speed and engine speed. Refer to CVT-53,
"Vehicle Speed When Shifting Gears" .
OK or NG
OK >> GO TO 2.
NG >> Mark the box of CVT-186, "
Vehicle Speed Does Not
Change in “L” Position" on the CVT-37, "DIAGNOSTIC
WORKSHEET" . Continue “Road Test”. CVT fluid operating temperature: 50 - 80°C (122 - 176°F)
SCIA6644E

TROUBLE DIAGNOSIS
CVT-51
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
2. CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 2
1. Park vehicle on flat surface.
2. Move selector lever to “D” position.
3. Push overdrive control switch. (O/D OFF indicator lamp is on.)
4. Accelerate vehicle to 2/8-way throttle depressing accelerator
pedal constantly.
Read vehicle speed and engine speed. Refer to CVT-53,
"Vehicle Speed When Shifting Gears" .
OK or NG
OK >> GO TO 3.
NG >> Mark the box of CVT-187, "
Vehicle Speed Does Not
Change in overdrive-off mode" on the CVT-37, "DIAG-
NOSTIC WORKSHEET" . Continue “Road Test”.
3. CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 3
1. Park vehicle on flat surface.
2. Move selector lever to “D” position.
3. Push overdrive control switch. (O/D OFF indicator lamp is off.)
4. Accelerate vehicle to 2/8-way throttle depressing accelerator
pedal constantly.
Read vehicle speed and engine speed. Refer to CVT-53,
"Vehicle Speed When Shifting Gears" .
OK or NG
OK >> GO TO 4.
NG >> Mark the box of CVT-188, "
Vehicle Speed Does Not
Change in “D” Position" on the CVT-37, "DIAGNOSTIC
WORKSHEET" . Continue “Road Test”.
4. CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 4
1. Park vehicle on flat surface.
2. Move selector lever to “L” position.
3. Accelerate vehicle to full depression depressing accelerator
pedal constantly.
Read vehicle speed and engine speed. Refer to CVT-53,
"Vehicle Speed When Shifting Gears" .
OK or NG
OK >> GO TO 5.
NG >> Mark the box of CVT-186, "
Vehicle Speed Does Not
Change in “L” Position" on the CVT-37, "DIAGNOSTIC
WORKSHEET" . Continue “Road Test”.
SCIA6644E
SCIA6644E
SCIA4366E

CVT-52
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
5. CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 5
1. Park vehicle on flat surface.
2. Move selector lever to “D” position.
3. Push overdrive control switch. (O/D OFF indicator lamp is on.)
4. Accelerate vehicle to full depressing depressing accelerator
pedal constantly.
Read vehicle speed and engine speed. Refer to CVT-53,
"Vehicle Speed When Shifting Gears" .
OK or NG
OK >> GO TO 6.
NG >> Mark the box of CVT-187, "
Vehicle Speed Does Not
Change in overdrive-off mode" on the CVT-37, "DIAG-
NOSTIC WORKSHEET" . Continue “Road Test”.
6. CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 6
1. Park vehicle on flat surface.
2. Move selector lever to “D” position.
3. Push overdrive control switch. (O/D OFF indicator lamp is off.)
4. Accelerate vehicle to full depression depressing accelerator
pedal constantly.
Read vehicle speed and engine speed. Refer to CVT-53,
"Vehicle Speed When Shifting Gears" .
OK or NG
OK >> GO TO 7.
NG >> Mark the box of CVT-188, "
Vehicle Speed Does Not
Change in “D” Position" on the CVT-37, "DIAGNOSTIC
WORKSHEET" . Continue “Road Test”.
7. CHECK ENGINE BRAKE FUNCTION — PART 1
1. Release accelerator pedal.
2. Check engine brake. (O/D OFF indicator lamp is off.)
Does engine braking effectively reduce speed in
“D” position?
YES >> GO TO 8.
NO >> Mark the box of CVT-189, "
Vehicle Does Not Decelerate by Engine Brake" on the CVT-37,
"DIAGNOSTIC WORKSHEET" . Continue “Road Test”.
8. CHECK ENGINE BRAKE FUNCTION — PART 2
1. Push overdrive control switch. (O/D OFF indicator lamp is on.)
2. Check engine brake.
Does engine braking effectively reduce speed in
“D” position?
YES >> GO TO 9.
NO >> Mark the box of CVT-189, "
Vehicle Does Not Decelerate by Engine Brake" on the CVT-37,
"DIAGNOSTIC WORKSHEET" . Continue “Road Test”.
SCIA4366E
SCIA4366E

TROUBLE DIAGNOSIS
CVT-53
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
9. CHECK ENGINE BRAKE FUNCTION — PART 3
1. Move selector lever to “L” position.
2. Check engine brake.
Does engine braking effectively reduce speed in
“L” position?
YES >> 1. Stop the vehicle.
2. Perform self-diagnosis. Refer to CVT-60, "
SELF-DIAGNOSTIC RESULT MODE" .
NO >> Mark the box of CVT-189, "
Vehicle Does Not Decelerate by Engine Brake" on the CVT-37,
"DIAGNOSTIC WORKSHEET" . Then continue trouble diagnosis.
Vehicle Speed When Shifting GearsUCS005YG
Numerical value data are reference values.
CAUTION:
Lock-up clutch is engaged when vehicle speed is approximately 18 km/h (11 MPH) to 90 km/h (56 MPH).Engine type Throttle position Shift patternEngine speed (rpm)
At 40 km/h (25 MPH) At 60 km/h (37 MPH)
MR18DE8/8“D” position
Overdrive-off mode
“L” position3,600 - 4,400 4,400 - 5,200
2/8“D” position 1,400 - 2,400 1,500 - 2,500
Overdrive-off mode 2,200 - 3,000 2,800 - 3,600
“L” position 3,200 - 4,000 3,900 - 4,700
