wiring NISSAN TIIDA 2007 Service Repair Manual

ACC-2Revision: June 2006
PRECAUTIONS
2007 Versa
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS00U76
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NIN G:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.

AT-1
AUTOMATIC TRANSAXLE
C TRANSMISSION/TRANSAXLE
CONTENTS
D
E
F
G
H
I
J
K
L
M
SECTION AT
A
B
AT
Revision: June 20062007 Versa INDEX FOR DTC ........................................................ 5
Alphabetical Index .................................................... 5
DTC No. Index ......................................................... 6
PRECAUTIONS .......................................................... 7
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 7
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect .......................................... 7
Precautions for On Board Diagnostic (OBD) System
of A/T and Engine .................................................... 8
Precautions .............................................................. 8
Service Notice or Precautions .................................. 9
PREPARATION ..........................................................11
Special Service Tools ..............................................11
Commercial Service Tools ...................................... 14
A/T FLUID ................................................................. 16
Checking A/T Fluid ................................................. 16
Changing A/T Fluid ................................................ 17
A/T Fluid Cooler Cleaning ...................................... 17
A/T CONTROL SYSTEM .......................................... 20
Cross-Sectional View ............................................. 20
Shift Mechanism ..................................................... 21
TCM Function ......................................................... 30
CAN Communication .............................................. 31
Input/Output Signal of TCM .................................... 31
Line Pressure Control ............................................ 32
Shift Control ........................................................... 33
Lock-up Control ...................................................... 34
Engine Brake Control (Overrun Clutch Control) ..... 35
Control Valve .......................................................... 37
Centrifugal Cancel Mechanism .............................. 38
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 39
Introduction ............................................................ 39
OBD-II Function for A/T System ............................. 39
One or Two Trip Detection Logic of OBD-II ............ 39
OBD-II Diagnostic Trouble Code (DTC) ................. 39
Malfunction Indicator Lamp (MIL) ........................... 42
TROUBLE DIAGNOSIS ............................................ 43
DTC Inspection Priority Chart ................................ 43Fail-safe .................................................................. 43
How to Perform Trouble Diagnoses for Quick and
Accurate Repair ...................................................... 45
A/T Electrical Parts Location .................................. 50
Circuit Diagram ....................................................... 52
Inspections Before Trouble Diagnosis .................... 53
Road Test ............................................................... 58
Check Before Engine is Started .............................. 58
Check at Idle ........................................................... 59
Cruise Test — Part 1 .............................................. 61
Cruise Test — Part 2 .............................................. 64
Cruise Test — Part 3 .............................................. 65
Vehicle Speed at Which Gear Shifting Occurs ....... 67
Vehicle Speed at Which Lock-up Occurs/Releases ... 67
Symptom Chart ....................................................... 68
TCM Terminals and Reference Value ..................... 78
CONSULT-II Function (A/T) .................................... 80
Diagnostic Procedure Without CONSULT-II ........... 90
DTC U1000 CAN COMMUNICATION LINE .............. 94
Description .............................................................. 94
On Board Diagnosis Logic ...................................... 94
Possible Cause ....................................................... 94
DTC Confirmation Procedure ................................. 94
Wiring Diagram — AT — CAN ................................ 95
Diagnostic Procedure ............................................. 96
DTC P0705 PARK/NEUTRAL POSITION (PNP)
SWITCH .................................................................... 97
Description .............................................................. 97
CONSULT-II Reference Value ................................ 97
On Board Diagnosis Logic ...................................... 97
Possible Cause ....................................................... 97
DTC Confirmation Procedure ................................. 97
Wiring Diagram — AT — PNP/SW ......................... 98
Diagnostic Procedure ............................................. 99
Component Inspection ..........................................101
DTC P0710 A/T FLUID TEMPERATURE SENSOR
CIRCUIT ..................................................................102
Description ............................................................102
CONSULT-II Reference Value ..............................102
On Board Diagnosis Logic ....................................102

AT-2Revision: June 20062007 Versa Possible Cause .....................................................102
DTC Confirmation Procedure ...............................102
Wiring Diagram — AT — FTS ...............................103
Diagnostic Procedure ...........................................104
Component Inspection ..........................................106
DTC P0720 VEHICLE SPEED SENSOR·A/T (REV-
OLUTION SENSOR) ...............................................107
Description ............................................................107
CONSULT-II Reference Value ..............................107
On Board Diagnosis Logic ....................................107
Possible Cause .....................................................107
DTC Confirmation Procedure ...............................107
Wiring Diagram — AT — VSSA/T .........................109
Diagnostic Procedure ...........................................110
DTC P0725 ENGINE SPEED SIGNAL ...................113
Description ............................................................113
CONSULT-II Reference Value ..............................113
On Board Diagnosis Logic ....................................113
Possible Cause .....................................................113
DTC Confirmation Procedure ...............................113
Wiring Diagram — AT — ENGSS .........................114
Diagnostic Procedure ...........................................115
DTC P0731 A/T 1ST GEAR FUNCTION .................117
Description ............................................................117
On Board Diagnosis Logic ....................................117
Possible Cause .....................................................117
DTC Confirmation Procedure ...............................118
Diagnostic Procedure ...........................................119
DTC P0732 A/T 2ND GEAR FUNCTION ................121
Description ............................................................121
On Board Diagnosis Logic ....................................121
Possible Cause .....................................................121
DTC Confirmation Procedure ...............................122
Diagnostic Procedure ...........................................123
DTC P0733 A/T 3RD GEAR FUNCTION ................124
Description ............................................................124
On Board Diagnosis Logic ....................................124
Possible Cause .....................................................124
DTC Confirmation Procedure ...............................125
Diagnostic Procedure ...........................................126
DTC P0734 A/T 4TH GEAR FUNCTION ................128
Description ............................................................128
CONSULT-II Reference Value ..............................128
On Board Diagnosis Logic ....................................128
Possible Cause .....................................................128
DTC Confirmation Procedure ...............................129
Diagnostic Procedure ...........................................130
DTC P0740 TORQUE CONVERTER CLUTCH
SOLENOID VALVE .................................................134
Description ............................................................134
CONSULT-II Reference Value ..............................134
On Board Diagnosis Logic ....................................134
Possible Cause .....................................................134
DTC Confirmation Procedure ...............................134
Wiring Diagram — AT — TCV ..............................135
Diagnostic Procedure ...........................................136
Component Inspection ..........................................138
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP) .139
Description ............................................................139CONSULT-II Reference Value ............................... 139
On Board Diagnosis Logic .................................... 139
Possible Cause ..................................................... 139
DTC Confirmation Procedure ................................ 140
Diagnostic Procedure ............................................ 141
DTC P0745 LINE PRESSURE SOLENOID VALVE . 145
Description ............................................................ 145
CONSULT-II Reference Value ............................... 145
On Board Diagnosis Logic .................................... 145
Possible Cause ..................................................... 145
DTC Confirmation Procedure ................................ 145
Wiring Diagram — AT — LPSV ............................ 146
Diagnostic Procedure ............................................ 147
Component Inspection .......................................... 150
DTC P0750 SHIFT SOLENOID VALVE A ............... 151
Description ............................................................ 151
CONSULT-II Reference Value ............................... 151
On Board Diagnosis Logic .................................... 151
Possible Cause ..................................................... 151
DTC Confirmation Procedure ................................ 151
Wiring Diagram — AT — SSV/A ........................... 152
Diagnostic Procedure ............................................ 153
Component Inspection .......................................... 155
DTC P0755 SHIFT SOLENOID VALVE B ............... 156
Description ............................................................ 156
CONSULT-II Reference Value ............................... 156
On Board Diagnosis Logic .................................... 156
Possible Cause ..................................................... 156
DTC Confirmation Procedure ................................ 156
Wiring Diagram — AT — SSV/B ........................... 157
Diagnostic Procedure ............................................ 158
Component Inspection .......................................... 160
DTC P1760 OVERRUN CLUTCH SOLENOID
VALVE ...................................................................... 161
Description ............................................................ 161
CONSULT-II Reference Value ............................... 161
On Board Diagnosis Logic .................................... 161
Possible Cause ..................................................... 161
DTC Confirmation Procedure ................................ 161
Wiring Diagram — AT — OVRCSV ...................... 162
Diagnostic Procedure ............................................ 163
Component Inspection .......................................... 165
DTC VEHICLE SPEED SENSOR MTR ................... 166
Description ............................................................ 166
CONSULT-II Reference Value ............................... 166
On Board Diagnosis Logic .................................... 166
Possible Cause ..................................................... 166
DTC Confirmation Procedure ................................ 166
Wiring Diagram — AT — VSSMTR ....................... 167
Diagnostic Procedure ............................................ 168
DTC BATT/FLUID TEMP SEN (A/T FLUID TEMP
SENSOR CIRCUIT AND TCM POWER SOURCE) . 170
Description ............................................................ 170
CONSULT-II Reference Value ............................... 170
On Board Diagnosis Logic .................................... 170
Possible Cause ..................................................... 170
DTC Confirmation Procedure ................................ 170
Wiring Diagram — AT — BA/FTS ......................... 171

AT-3
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa Diagnostic Procedure ........................................... 172
Component Inspection ......................................... 175
DTC TURBINE REVOLUTION SENSOR ............... 176
Description ........................................................... 176
CONSULT-II Reference Value .............................. 176
On Board Diagnosis Logic ................................... 176
Possible Cause .................................................... 176
DTC Confirmation Procedure ............................... 176
Wiring Diagram — AT — PT/SEN ........................ 177
Diagnostic Procedure ........................................... 178
CONTROL UNIT (RAM), CONTROL UNIT (ROM) . 182
Description ........................................................... 182
On Board Diagnosis Logic ................................... 182
Possible Cause .................................................... 182
DTC Confirmation Procedure ............................... 182
Diagnostic Procedure ........................................... 182
MAIN POWER SUPPLY AND GROUND CIRCUIT . 183
Wiring Diagram — AT — MAIN ............................ 183
Diagnostic Procedure ........................................... 184
PNP, OD SWITCH AND CLOSED THROTTLE,
WIDE OPEN THROTTLE POSITION SIGNAL CIR-
CUIT ........................................................................ 186
CONSULT-II Reference Value .............................. 186
TCM Terminals and Reference Value ................... 186
Diagnostic Procedure ........................................... 187
Component Inspection ......................................... 191
SHIFT POSITION INDICATOR CIRCUIT ............... 192
Description ........................................................... 192
CONSULT-II Reference Value .............................. 192
Diagnostic Procedure ........................................... 192
TROUBLE DIAGNOSIS FOR SYMPTOMS ............ 193
Wiring Diagram — AT — NONDTC ...................... 193
OD OFF Indicator Lamp Does Not Come On ...... 198
Engine Cannot Be Started in “P” and “N” Position . 200
In “P” Position, Vehicle Moves Forward or Backward
When Pushed ....................................................... 201
In “N” Position, Vehicle Moves ............................. 201
Large Shock “N” → “R” Position ........................... 202
Vehicle Does Not Creep Backward in “R” Position . 203
Vehicle Does Not Creep Forward in “D”, “2” or “1”
Position ................................................................ 205
Vehicle Cannot Be Started from D
1 ...................... 206
A/T Does Not Shift: D
1 → D2 or Does Not Kickdown:
D
4 → D2 ............................................................... 208
A/T Does Not Shift: D
2 → D3 ............................... 210
A/T Does Not Shift: D
3 → D4 ............................... 212
A/T Does Not Perform Lock-up ............................ 214
A/T Does Not Hold Lock-up Condition ................. 215
Lock-up Is Not Released ...................................... 216
Engine Speed Does Not Return to Idle (Light Brak-
ing D
4 → D3 ) ....................................................... 217
A/T Does Not Shift: D
4 → D3 , When OD OFF .... 218
A/T Does Not Shift: D
3 → 22 , When Selector Lever
“D” → “2” Position ................................................ 219
A/T Does Not Shift: 2
2 → 11 , When Selector Lever
“2” → “1” Position ................................................. 221
Vehicle Does Not Decelerate by Engine Brake .... 223
TCM Self-diagnosis Does Not Activate ................ 227TRANSMISSION CONTROL MODULE ..................228
Removal and Installation ......................................228
SHIFT CONTROL SYSTEM ....................................229
Control Device Removal and Installation ..............229
Control Device Disassembly and Assembly .........232
Selector Lever Knob Removal and Installation .....233
Adjustment of A/T Position ...................................233
Checking of A/T Position ......................................234
A/T SHIFT LOCK SYSTEM ....................................235
Description ............................................................235
Shift Lock System Parts Location .........................235
Wiring Diagram — AT — SHIFT ...........................236
Diagnostic Procedure ...........................................237
KEY INTERLOCK CABLE ......................................239
Removal and Installation ......................................239
ON-VEHICLE SERVICE ..........................................242
Control Valve Assembly and Accumulators ..........242
Park/Neutral Position (PNP) Switch .....................246
Revolution Sensor ................................................247
Turbine Revolution Sensor (Power Train Revolution
Sensor) .................................................................248
Differential Side Oil Seal .......................................250
AIR BREATHER HOSE ..........................................252
Removal and Installation ......................................252
TRANSAXLE ASSEMBLY ......................................253
Removal and Installation ......................................253
OVERHAUL ............................................................257
Components .........................................................257
Oil Channel ...........................................................265
Locations of Adjusting Shims, Needle Bearings and
Thrust Washers ....................................................266
Locations of Snap Rings .......................................267
DISASSEMBLY .......................................................268
Disassembly .........................................................268
REPAIR FOR COMPONENT PARTS .....................285
Manual Shaft ........................................................285
Oil Pump ...............................................................289
Control Valve Assembly ........................................293
Control Valve Upper Body ....................................302
Control Valve Lower Body ....................................306
Reverse Clutch .....................................................309
High Clutch ...........................................................314
Forward and Overrun Clutches ............................320
Low & Reverse Brake ...........................................327
Rear Internal Gear and Forward Clutch Hub ........332
Output Shaft, Output Gear, Idler Gear, Reduction
Pinion Gear and Bearing Retainer ........................336
Band Servo Piston Assembly ...............................343
Final Drive ............................................................349
ASSEMBLY .............................................................354
Assembly (1) .........................................................354
Adjustment (1) ......................................................355
Assembly (2) .........................................................361
Adjustment (2) ......................................................366
Assembly (3) .........................................................369
SERVICE DATA AND SPECIFICATIONS (SDS) ....378
General Specifications ..........................................378
Vehicle Speed at Which Gear Shifting Occurs .....378
Vehicle Speed at When Lock-up Occurs/Releases .378

PRECAUTIONS
AT-7
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
UCS006XG
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WA RN ING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions Necessary for Steering Wheel Rotation After Battery DisconnectUCS006XH
NOTE:

This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).

Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK″ position.

Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.

A/T CONTROL SYSTEM
AT-31
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
CAN CommunicationUCS005M D
SYSTEM DESCRIPTION
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only. For details, refer to LAN-47,
"CAN System Specification Chart" .
Input/Output Signal of TCMUCS005M E
*1: Spare for vehicle speed sensor·A/T (revolution sensor)
*2: Spare for accelerator pedal position signal
*3: If these input and output signals are different, the TCM triggers the fail-safe function.
*4: Used as a condition for starting self-diagnostics; if self-diagnosis are not started, it is judged that there is some kind of error.
*5: Input by CAN communications.
*6: Output by CAN communications.Control itemLine
pressure
controlVehicle
speed
controlShift
controlLock-up
controlEngine
brake
controlFail-safe
functionSelf-diag-
nostics
function
InputAccelerator pedal position signal
(*5)XXXXX(*3) XX
Vehicle speed sensor·A/T
(Revolution sensor)XXXXX(*3) XX
Vehicle speed sensor·MTR (*1) X (*1) X (*1) X (*1) X X
Closed throttle position signal
(*5)(*2) X(*2) XXX(*4) X
Wide open throttle position signal
(*5)(*2) X (*2) X (*4) X
Turbine revolution sensor (Power
train revolution sensor)XX X XX
Engine speed signal X X X X
PNP switch X X X X X (*3) X (*4) X
Stop lamp switch signal
(*5)XX (*4) X
A/T fluid temperature sensors
(*5)XXXX XX
Overdrive control switch signal
(*5)XXXX (*4) X
TCM power supply voltage signal X X X X
Out-
putShift solenoid valve A/B X (*3) X X
Line pressure solenoid X (*3) X X
Torque converter clutch solenoid
valveX(*3) XX
Overrun clutch solenoid valve X X (*3) X X
OD OFF indicator lamp
(*6)XX

TROUBLE DIAGNOSIS
AT-45
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
How to Perform Trouble Diagnoses for Quick and Accurate RepairUCS005M N
INTRODUCTION
The TCM receives a signal from the vehicle speed sensor, accelera-
tor pedal position sensor or PNP switch and provides shift control or
lock-up control via A/T solenoid valves.
The TCM also communicates with the ECM by means of a sig-
nalsent from sensing elements used with the OBD-related parts of
theA/T system for malfunction-diagnostic purposes. The TCM is
capa-ble of diagnosing malfunctioning parts while the ECM can store
mal-functions in its memory.
Input and output signals must always be correct and stable in the
operation of the A/T system. The A/T system must be in good oper-
ating condition and be free of valve seizure, solenoid valve malfunc-
tion, etc.
It is much more difficult to diagnose a malfunction that occurs intermittently rather than continuously. Most
intermittent malfunctions are caused by poor electric connections or improper wiring. In this case, careful
checking of suspected circuits may help prevent the replacement of good parts.
A visual check only, may not find the cause of the malfunctions. A
road test with CONSULT-II or a circuit tester connected should be
performed. Follow the AT-46, "
WORK FLOW" .
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a driveability complaint. The cus-
tomer can supply good information about such malfunctions, espe-
cially intermittent ones. Find out what symptoms are present and
under what conditions they occur. A “DIAGNOSTIC WORKSHEET”
like the example (AT- 4 7 , "
DIAGNOSTIC WORKSHEET" ) should be
used.
Start your diagnosis by looking for “conventional” malfunctions first.
This will help troubleshoot driveability malfunctions on an electroni-
cally controlled engine vehicle.
Also check related Service bulletins for information.
SAT6 3 1IA
SAT6 3 2I
SEF 2 34 G

AT-94
DTC U1000 CAN COMMUNICATION LINE
Revision: June 20062007 Versa
DTC U1000 CAN COMMUNICATION LINEPFP:31940
DescriptionUCS005N8
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent malfunction detection ability.
Many electronic control units are equipped onto a vehicle, and each control unit shares information and links
with other control units during operation (not independent). In CAN communication, control units are con-
nected with 2 communication lines (CAN H line, CAN L line) allowing a high rate of information transmission
with less wiring. Each control unit transmits/receives data but selectively reads required data only.
On Board Diagnosis LogicUCS005N9

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “U1000 CAN COMM CIRCUIT” with CONSULT-II or 12th judgement flicker with-
out CONSULT-II is detected when TCM cannot communicate to other control units.
Possible CauseUCS005NA
Harness or connector
(CAN communication line is open or shorted.)
DTC Confirmation ProcedureUCS005NB
CAUTION:
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Touch “START”.
4. Wait at least 6 seconds or start engine and wait for at least 6
seconds.
5. If DTC is detected, go to AT-96, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II”.
WITHOUT CONSULT-II
1. Turn ignition switch ON.
2. Wait at least 6 seconds or start engine and wait at least 6 seconds.
3. Perform self-diagnosis. Refer to AT-90, "
Diagnostic Procedure Without CONSULT-II" .
4. If DTC is detected, go to AT-96, "
Diagnostic Procedure" .
BCIA0031E

DTC U1000 CAN COMMUNICATION LINE
AT-95
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
Wiring Diagram — AT — CANUCS005N C
BCWA0648E

AT-98
DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH
Revision: June 20062007 Versa
Wiring Diagram — AT — PNP/SWUCS005NJ
BCWA0649E
