DRUM BRAKE : Inspection
INFOID:0000000005394848
INSPECTION
Lining Thickness Inspection
Check lining thickness.
Drum Inner Diameter Inspection
Check inner diameter of brake drum.
Measurement area: lining contact surface (center)
Wheel Cylinder Leakage Inspection
• Check wheel cylinder for brake fluid leakage.
• Check for wear, damage, and looseness. If any non-standard con- dition is found, replace it.
Other Inspections
Check the following:
• Inside of the drum for excessive wear, damage, and cracks.
• Lining for excessive wear, damage, and peeling.
• Shoe sliding surface for excessive wear and damage.
• Return spring for sagging.
• Check back plate for damage, cracks, and deforma tion. Replace back plate as necessary.
Replace applicable part as necessary.
AXLE AND SUSPENSION PARTS
Standard thickness (A) : Refer to BR-42,
"Rear Drum Brake"
Repair limit thickness (A) : Refer toBR-42,
"Rear Drum Brake"
SBR021A
Standard inner diameter : Refer toBR-42, "Rear
Drum Brake"
Repair limit inner diameter : Refer toBR-42, "Rear
Drum Brake"
SBR022A
WFIA0528E
Revision: January 20102010 Versa

CHASSIS AND BODY MAINTENANCEMA-47
< SERVICE INFORMATION >
C
DE
F
G H
I
J
K
M A
B
MA
N
O P
AXLE AND SUSPENSION PARTS : Axle and Suspension PartsINFOID:0000000005394849
Check front and rear axle and suspension parts for excessive play,
cracks, wear or other damage.
• Shake each wheel to check for excessive play.
• Check wheel bearings for smooth operation.
• Check axle and suspension nuts and bolts for looseness.
• Check strut (shock absorber) for oil leakage or other damage.
• Check suspension ball joint for grease leakage and ball joint dust
cover for cracks or other damage.
DRIVE SHAFT
DRIVE SHAFT : Drive ShaftINFOID:0000000005394850
Check boot and drive shaft for cracks, wear, damage and grease
leakage.
LOCKS, HINGES AND HOOD LATCH
SMA525A
SFA392B
SDIA1190J
Revision: January 20102010 Versa

MA-48
< SERVICE INFORMATION >
CHASSIS AND BODY MAINTENANCE
LOCKS, HINGES AND HOOD LATCH : Lubr icating Locks, Hinges and Hood Latch
INFOID:0000000005394851
SEAT BELT, BUCKLES, RETRAC TORS, ANCHORS AND ADJUSTERS
SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS : Checking
Seat Belts, Buckles, Retractors, Anchors and Adjusters
INFOID:0000000005394852
Check the seat belt buckles, webbing, retractors, anc hors and adjusters. Replace any seat belt assembly as
necessary. Refer to SB-8, "
Seat Belt Inspection" .
• Check the seat belt anchors for loose bolts, damage, or excessive wear.
• Check the seat belt webbing for any damage, cuts, fraying, or excessive wear.
• Check the retractor for smooth operation.
• Check the function of the buckles by inserting the seat belt tongue and checking for proper engagement of
the buckle and press the button on the buckle to c heck for proper release of the seat belt tongue.
CAUTION:
• After any collision, inspect all seat belt assemblies, including retractors and other attached compo- nents, such as the guide rail set. NISSAN recommends replacing all seat belt assemblies in use dur-
ing a collision, unless they are not damaged an d are inspected to confirm they are operating
properly after a minor collision.
Also inspect all seat belt assemblies that are not in use during a collision, and replace any compo-
nents if damaged or not operating properly. The seat belt pre-tensioner should be replaced even if
the seat belts are not in use during a frontal collision where the driver and passenger air bags have
been deployed.
ALPIA0002ZZ
Revision: January 20102010 Versa

CHASSIS AND BODY MAINTENANCEMA-49
< SERVICE INFORMATION >
C
DE
F
G H
I
J
K
M A
B
MA
N
O P
• If any component of the seat belt assembly is susp ected of being damaged or not operating prop-
erly, do not repair the component. Replace the components as an assembly.
• If the seat belt webbing is cut, frayed, or damaged then replace the seat belt assembly.
• Never lubricate the seat belt buckle or tongue.
• When replacing any seat belt assembly alw ays use a Genuine NISSAN seat belt assembly.
Revision: January 20102010 Versa

MT-1
TRANSMISSION/TRANSAXLE
DE
F
G H
I
J
K L
M
SECTION MT
A
B
MT
N
O P
CONTENTS
MANUAL TRANSAXLE
RS5F91R
SERVICE INFORMATION .. ..........................
3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ............................... ......
3
Precaution for Procedure without Cowl Top Cover ......4
Service Notice or Precaution .....................................4
PREPARATION ...................................................5
Special Service Tools ........................................ ......5
Commercial Service Tools .......................................7
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING .............................
8
NVH Troubleshooting Chart ................................ ......8
DESCRIPTION ....................................................9
System Diagram .................................................. ......9
System Description ...................................................9
M/T OIL ...............................................................11
Draining ...................................................................11
Refilling ...................................................................11
Inspection ................................................................11
SIDE OIL SEAL ..................................................12
Removal and Installation .........................................12
POSITION SWITCH ........................................ ....13
Checking ............................................................. ....13
CONTROL LINKAGE .........................................14
Exploded View .................................................... ....14
Removal and Installation .........................................14
Inspection ............................................................ ....15
AIR BREATHER HOSE ......................................16
Exploded View .................................................... ....16
Removal and Installation ..................................... ....16
TRANSAXLE ASSEMBLY ................................17
Exploded View .........................................................17
Removal and Installation .........................................17
Disassembly and Assembly .....................................18
INPUT SHAFT AND GEAR ...............................36
Disassembly and Assembly .....................................36
MAINSHAFT AND GEAR .................................37
Disassembly and Assembly .....................................37
FINAL DRIVE ....................................................41
Disassembly and Assembly .....................................41
SHIFT CONTROL ..............................................42
Inspection ................................................................42
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
43
General Specification ..............................................43
RS6F94R
SERVICE INFORMATION .. .........................
44
PRECAUTIONS .................................................44
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ....
44
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ...................................
44
Precaution for Procedure without Cowl Top Cover ....45
Precaution ...............................................................45
PREPARATION .................................................46
Special Service Tool ................................................46
Commercial Service Tool ........................................48
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ...........................
51
NVH Troubleshooting Chart ....................................51
Revision: January 20102010 Versa

MT-2
DESCRIPTION ...................................................52
Cross-Sectional View .......................................... ...52
M/T OIL ..............................................................54
Changing M/T Oil ................................................. ...54
Checking M/T Oil ....................................................54
VEHICLE SPEED SENSOR ..............................55
Removal and Installation ..................................... ...55
SIDE OIL SEAL .................................................56
Removal and Installation ..................................... ...56
POSITION SWITCH ...........................................57
Checking .............................................................. ...57
CONTROL LINKAGE ........................................58
Component of Control Device and Cable ............ ...58
Removal and Installation ........................................58
AIR BREATHER HOSE .....................................60
Removal and Installation ..................................... ...60
TRANSAXLE ASSEMBLY ................................61
Component .......................................................... ...61
Removal and Installation .........................................61
Disassembly and Assembly ................................. ...62
INPUT SHAFT AND GEARS .............................80
Disassembly and Assembly ................................. ...80
MAINSHAFT AND GEARS ...............................85
Disassembly and Assembly ................................. ...85
REVERSE IDLER SHAFT AND GEARS ...........90
Disassembly and Assembly ................................. ...90
FINAL DRIVE .....................................................92
Disassembly and Assembly ....................................92
SHIFT CONTROL ..............................................94
Inspection ............................................................. ...94
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
95
General Specification ........................................... ...95
Revision: January 20102010 Versa

PRECAUTIONSMT-3
< SERVICE INFORMATION > [RS5F91R]
D
E
F
G H
I
J
K L
M A
B
MT
N
O P
SERVICE INFORMATION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005777024
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SRS section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wheel Rotation After Battery Disconnect
INFOID:0000000005716034
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecti ng both battery cables with the ignition knob in the
″ LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS , an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
Revision: January 20102010 Versa

MT-4
< SERVICE INFORMATION >[RS5F91R]
PRECAUTIONS
5. When the repair work is completed, return the ignition switch to the
″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of a ll control units using CONSULT-III.
Precaution for Procedure without Cowl Top CoverINFOID:0000000005716035
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Service Notice or PrecautionINFOID:0000000005716036
•Use recommended brake fluid when adding flui d to the clutch reservoir tank. Refer to MA-14.
• Never reuse fluid drained from clutch system.
• Be careful not to splash brake fluid on painted areas.
• Use new brake fluid to clean or wash all part s of master cylinder and operating cylinder.
• Never use mineral oils such as gasoline or kerosene. It will ruin the rubber parts of the hydraulic sys-
tem.
• If transaxle assembly is removed from the vehicle , always replace CSC (Concentric slave cylinder).
Return CSC to original position to remove transaxle assembly. Dust on clutch disc sliding parts may
damage CSC seal and may cause clutch fluid leakage.
• Do not disassemble clutch master cylinder and CSC.
WARNING:
After cleaning clutch disc, clean it with a dust collector. Do not use compressed air.
PIIB3706J
Revision: January 20102010 Versa

PREPARATIONMT-5
< SERVICE INFORMATION > [RS5F91R]
D
E
F
G H
I
J
K L
M A
B
MT
N
O P
PREPARATION
Special Service ToolsINFOID:0000000005397161
The actual shapes of tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
—
( J-46534 )
Trim tool set For removing trim
KV32500QAA
(—)
(Renault SST: B.vi 1666)
Drift set Installing differential side oil seal
1. ( – )
(Stamping number: B.vi 1666-A)
Drift
a: 54.3 mm (2.138 in) dia
b: 45 mm (1.77 in) dia
c: 26.6 mm (1.047 in) dia
2. ( – )
(Stamping number: B.vi 1666-B)
Drift
a: 54 mm (2.13 in) dia
b: 48.6 mm (1.913 in) dia
c: 26.6 mm (1.047 in) dia
KV32300QAC
(—)
Puller Removing 5th main gear
KV32300QAD
(—)
Puller Removing 5th main gear
ST35300000
(—)
Drift • Removing and installing input shaft rear
bearing
• Removing and installing mainshaft rear bearing
a: 45 mm (1.77 in) dia.
b: 59 mm (2.23 in) dia.
AWJIA0483ZZ
JPDIC0730ZZ
SCIA1781J
SCIA1782J
ZZA0969D
Revision: January 20102010 Versa

MT-6
< SERVICE INFORMATION >[RS5F91R]
PREPARATION
K V 111 0 11 S 0
(—)
Va l v e s e a t r e m o v e rRemoving mainshaft front bearing
ST33400001
(J-26082)
Drift Installing mainshaft front bearing
a: 60 mm (2.36 in) dia.
a: 47 mm (1.85 in) dia.
KV40100900
(—)
Drift Installing input shaft front bearing
a: 52 mm (2.05 in) dia.
a: 39.5 mm (1.55 in) dia.
KV32300QAE
(—)
Drift Installing differential side bearing outer race
a: 65 mm (2.56 in) dia.
a: 63 mm (2.48 in) dia.
ST33052000
(—)
Drift Removing differential side bearing
a: 22 mm (0.87 in) dia.
a: 28 mm (1.10 in) dia.
KV40104920
(—)
Drift Installing differential side bearing
a: 21.7 mm (0.85 in) dia.
a: 44.7 mm (1.76 in) dia.
Tool number
(Kent-Moore No.)
Tool name
Description
ZZA0872D
ZZA0814D
NT084
SCIA1783J
ZZA0969D
ZZA0969D
Revision: January 20102010 Versa
