NISSAN X-TRAIL 2003 Service Repair Manual

SERVICE DATA AND SPECIFICATIONS (SDS)
EC-873
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Camshaft Position Sensor (PHASE)EBS0115H
Refer to EC-653, "Component Inspection" .
Throttle Control MotorEBS0115I
InjectorEBS0115J
Fuel PumpEBS0115K
Resistance [at 25°C (77°F)] Approximately 1 - 15Ω
Resistance [at 10 - 60°C (50 - 140°F)] 13.5 - 17.5Ω
Resistance [at 25°C (77°F)] Approximately 0.2 - 5.0Ω

EC-874
[YD (WITH EURO-OBD)]
INDEX FOR DTC

[YD (WITH EURO-OBD)]INDEX FOR DTCPFP:00024
Alphabetical IndexEBS0116O
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-44, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-944, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
Items
(CONSULT-II screen terms) DTC*
1 *2
(CONSULT-II, GST )TripMI lighting
up Reference page
APP SEN 1/CIRCUIT P0122 1 —EC-987
APP SEN 1/CIRCUIT P0123 1 —EC-987
APP SEN 2/CIRCUIT P0222 1 —EC-1025
APP SEN 2/CIRCUIT P0223 1 —EC-1025
APP SENSOR P2135 1 —EC-1149
BARO SEN/CIRC P2228 3×EC-1167
BARO SEN/CIRC P2229 3×EC-1167
BATTERY VOLTAGE P0563 1 —EC-1087
CAN COMM CIRCUIT U1000 1 —EC-944
CKP SEN/CIRCUIT P0335 3×EC-1044
CKP SENSOR P0336 3×EC-1050
CMP SEN/CIRCUIT P0340 3×EC-1056
CMP SENSOR P0341 3×EC-1062
CMP/CKP RELATION P0016 3×EC-947
CYL1 INJECTOR P0201 3×EC-1005
CYL2 INJECTOR P0202 3×EC-1005
CYL3 INJECTOR P0203 3×EC-1005
CYL4 INJECTOR P0204 3×EC-1005
ECM P0605 3×EC-1089
ECM P0606 3×EC-1091
ECM RELAY P0686 1 —E C - 111 0
ECT SEN/CIRCUIT P0117 3×EC-981
ECT SEN/CIRCUIT P0118 3×EC-981
EGR SYSTEM P0401 3×EC-1073
EGR VALVE P0404 3×EC-1080
ENG OVER TEMP P0217 1×EC-1011
FRP RELIEF VALVE P1272 3×EC-1127
FRP SEN/CIRC P0192 3×EC-997
FRP SEN/CIRC P0193 3×EC-997
FUEL LEAK P0093 3×EC-959
FUEL PUMP P0089 3×EC-956
FUEL PUMP P1273 3×EC-1134
FUEL PUMP P1274 1×EC-1139
FUEL PUMP P1275 1×EC-1144
FUEL PUMP/CIRC P0628 3×EC-1093
FUEL PUMP/CIRC P0629 3×EC-1093

INDEX FOR DTC
EC-875
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

*1: 1st trip DTC No. and 2nd trip DTC No. are the same as DTC No.
*2: This number is prescribed by ISO 15031-6.FUEL TEMP SEN/CIRC P0182 3×EC-993
FUEL TEMP SEN/CIRC P0183 3×EC-993
GLOW RELAY P0380 3×EC-1069
HIGH FUEL PRESS P0088 3×EC-954
IAT SEN/CIRCUIT P0112 3×EC-976
IAT SEN/CIRCUIT P0113 3×EC-976
INJ ADJ RES/CIRC1 P1260 3×E C - 111 5
INJ ADJ RES/CIRC1 P1261 3×E C - 111 5
INJ ADJ RES/CIRC2 P1262 3×E C - 111 5
INJ ADJ RES/CIRC2 P1263 3×E C - 111 5
INJ ADJ RES/CIRC3 P1264 3×E C - 111 5
INJ ADJ RES/CIRC3 P1265 3×E C - 111 5
INJ ADJ RES/CIRC4 P1266 3×E C - 111 5
INJ ADJ RES/CIRC4 P1267 3×E C - 111 5
INJ PWR/CIRC P2146 3×EC-1155
INJ PWR/CIRC P2149 3×EC-1155
INJECTOR P0200 3×EC-1003
INJECTOR/CIRC P2147 3×EC-1160
INJECTOR/CIRC P2148 3×EC-1160
INJECTOR 1 P1268 1 —EC-1121
INJECTOR 2 P1269 1 —EC-1121
INJECTOR 3 P1270 1 —EC-1121
INJECTOR 4 P1271 1 —EC-1121
MAF SEN/CIRCUIT P0102 3×EC-970
MAF SEN/CIRCUIT P0103 3×EC-970
MAF SENSOR P0101 3×EC-963
NATS MALFUNCTION P1610 - P1617 1 —EC-896
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000—— —
SENSOR PWR/CIRC1 P0642 3×EC-1098
SENSOR PWR/CIRC1 P0643 3×EC-1098
SENSOR PWR/CIRC2 P0652 3×EC-1104
SENSOR PWR/CIRC2 P0653 3×EC-1104
TC BOOST SEN/CIRC P0237 3×EC-1038
TC BOOST SEN/CIRC P0238 3×EC-1038
TC BOOST SOL/CIRC P0045 3×EC-949
TC SYSTEM P0234 1 —EC-1031
TCS/CIRC P1212 1 —E C - 111 4
TCS C/U FUNCTN P1211 1 —E C - 111 3
Items
(CONSULT-II screen terms) DTC*1 *2
(CONSULT-II, GST )TripMI lighting
up Reference page

EC-876
[YD (WITH EURO-OBD)]
INDEX FOR DTC

DTC No. IndexEBS0116P
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-44, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-944, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
DTC*
1 *2
(CONSULT-II, GST)Items
(CONSULT-II screen item) TripMI lighting
upReference page
U1000 CAN COMM CIRCUIT 1 —EC-944
P0000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.—— —
P0016 CMP/CKP RELATION 3×EC-947
P0045 TC BOOST SOL/CIRC 3×EC-949
P0088 HIGH FUEL PRESS 3×EC-954
P0089 FUEL PUMP 3×EC-956
P0093 FUEL LEAK 3×EC-959
P0101 MAF SENSOR 3×EC-963
P0102 MAF SEN/CIRCUIT 3×EC-970
P0103 MAF SEN/CIRCUIT 3×EC-970
P0112 IAT SEN/CIRCUIT 3×EC-976
P0113 IAT SEN/CIRCUIT 3×EC-976
P0117 ECT SEN/CIRCUIT 3×EC-981
P0118 ECT SEN/CIRCUIT 3×EC-981
P0122 APP SEN 1/CIRCUIT 1 —EC-987
P0123 APP SEN 1/CIRCUIT 1 —EC-987
P0182 FUEL TEMP SEN/CIRC 3×EC-993
P0183 FUEL TEMP SEN/CIRC 3×EC-993
P0192 FRP SEN/CIRC 3×EC-997
P0193 FRP SEN/CIRC 3×EC-997
P0200 INJECTOR 3×EC-1003
P0201 CYL1 INJECTOR 3×EC-1005
P0202 CYL2 INJECTOR 3×EC-1005
P0203 CYL3 INJECTOR 3×EC-1005
P0204 CYL4 INJECTOR 3×EC-1005
P0217 ENG OVER TEMP 1×EC-1011
P0222 APP SEN 2/CIRCUIT 1 —EC-1025
P0223 APP SEN 2/CIRCUIT 1 —EC-1025
P0234 TC SYSTEM 1 —EC-1031
P0237 TC BOOST SEN/CIRC 3×EC-1038
P0238 TC BOOST SEN/CIRC 3×EC-1038
P0335 CKP SEN/CIRCUIT 3×EC-1044
P0336 CKP SENSOR 3×EC-1050
P0340 CMP SEN/CIRCUIT 3×EC-1056
P0341 CMP SENSOR 3×EC-1062
P0380 GLOW RELAY 3×EC-1069

INDEX FOR DTC
EC-877
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

*1: 1st trip DTC No. and 2nd trip DTC No. are the same as DTC No.
*2: This number is prescribed by ISO 15031-6.P0401 EGR SYSTEM 3×EC-1073
P0404 EGR VALVE 3×EC-1080
P0563 BATTERY VOLTAGE 1 —EC-1087
P0605 ECM 3×EC-1089
P0606 ECM 3×EC-1091
P0628 FUEL PUMP/CIRC 3×EC-1093
P0629 FUEL PUMP/CIRC 3×EC-1093
P0642 SENSOR PWR/CIRC1 3×EC-1098
P0643 SENSOR PWR/CIRC1 3×EC-1098
P0652 SENSOR PWR/CIRC2 3×EC-1104
P0653 SENSOR PWR/CIRC2 3×EC-1104
P0686 ECM RELAY 1 —E C - 111 0
P1211 TCS C/U FUNCTN 1 —E C - 111 3
P1212 TCS/CIRC 1 —E C - 111 4
P1260 INJ ADJ RES/CIRC1 3×E C - 111 5
P1261 INJ ADJ RES/CIRC1 3×E C - 111 5
P1262 INJ ADJ RES/CIRC2 3×E C - 111 5
P1263 INJ ADJ RES/CIRC2 3×E C - 111 5
P1264 INJ ADJ RES/CIRC3 3×E C - 111 5
P1265 INJ ADJ RES/CIRC3 3×E C - 111 5
P1266 INJ ADJ RES/CIRC4 3×E C - 111 5
P1267 INJ ADJ RES/CIRC4 3×E C - 111 5
P1268 INJECTOR 1 1 —EC-1121
P1269 INJECTOR 2 1 —EC-1121
P1270 INJECTOR 3 1 —EC-1121
P1271 INJECTOR 4 1 —EC-1121
P1272 FRP RELIEF VALVE 3×EC-1127
P1273 FUEL PUMP 3×EC-1134
P1274 FUEL PUMP 1×EC-1139
P1275 FUEL PUMP 1×EC-1144
P1610 - P1617 NATS MALFUNTION 1 —EC-896
P2135 APP SENSOR 1 —EC-1149
P2146 INJ PWR/CIRC 3×EC-1155
P2147 INJECTOR/CIRC 3×EC-1160
P2148 INJECTOR/CIRC 3×EC-1160
P2149 INJ PWR/CIRC 3×EC-1155
P2228 BARO SEN/CIRC 3×EC-1167
P2229 BARO SEN/CIRC 3×EC-1167
DTC*1 *2
(CONSULT-II, GST)Items
(CONSULT-II screen item) TripMI lighting
upReference page

EC-878
[YD (WITH EURO-OBD)]
PRECAUTIONS

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS0116Q
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
On Board Diagnostic (OBD) System of EngineEBS011T4
The ECM has an on board diagnostic system. It will light up the malfunction indicator (MI) to warn the driver of
a malfunction causing emission deterioration.
CAUTION:

Be sure to turn the ignition switch OFF and disconnect the battery ground cable before any repair
or inspection work. The open/short circuit of related switches, sensors, solenoid valves, etc. will
cause the MI to light up.

Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MI to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)

Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-70, "
HAR-
NESS CONNECTOR" .

Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MI to light up due to the short circuit.

Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MI to light up due to the malfunction of the fuel system, etc.

Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM
before returning the vehicle to the customer.
PrecautionsEBS0116R

Always use a 12 volt battery as power source.

Do not attempt to disconnect battery cables while engine is
running.

Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect battery
ground cable. Failure to do so may damage the ECM
because battery voltage is applied to ECM even if ignition
switch is turned off.

Before removing parts, turn ignition switch OFF and then
disconnect battery ground cable.
SEF289H

PRECAUTIONS
EC-879
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


Do not disassemble ECM.

When connecting ECM harness connector, fasten it
securely with levers as far as they will go as shown in the
figure.

When connecting or disconnecting pin connectors into or
from ECM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on ECM
pin terminal, when connecting pin connectors.

Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge)
voltage to develop in coil and condenser, thus resulting in
damage to IC's.

Keep engine control system harness at least 10cm (4 in)
away from adjacent harness, to prevent engine control sys-
tem malfunctions due to receiving external noise, degraded
operation of IC's, etc.

Keep engine control system parts and harness dry.

Before replacing ECM, perform ECM Terminals and Refer-
ence Value inspection and make sure ECM functions prop-
erly. Refer to EC-919, "
ECM Terminals And Reference
Val ue" .

Handle mass air flow sensor carefully to avoid damage.

Do not disassemble mass air flow sensor.

Do not clean mass air flow sensor with any type of deter-
gent.

Even a slight leak in the air intake system can cause seri-
ous incidents.

Do not shock or jar the camshaft position sensor, crank-
shaft position sensor.
MBIB0625E
PBIB1512E
SEF291H
MEF040D

EC-880
[YD (WITH EURO-OBD)]
PRECAUTIONS


After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.

When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.

Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.

Do not disassemble fuel pump.
If NG, take proper action.

Do not disassemble fuel injector.
If NG, replace fuel injector.

Do not depress accelerator pedal when staring.

Immediately after staring, do not rev up engine unnecessar-
ily.

Do not rev up engine just prior to shutdown.

When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standingwave
radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
SAT652J
SEF348N
SEF709Y
SEF708Y

PRECAUTIONS
EC-881
[YD (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Wiring Diagrams and Trouble DiagnosisEBS0116S
When you read Wiring diagrams, refer to the following:

GI-14, "How to Read Wiring Diagrams".

PG-2, "POWER SUPPLY ROUTING" for power distribution circuit
When you perform trouble diagnosis, refer to the following:

GI-10, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES".

GI-23, "How to Perform Efficient Diagnosis for an Electrical Incident".

EC-882
[YD (WITH EURO-OBD)]
PREPARATION

PREPARATIONPFP:00002
Special Service ToolsEBS011T9
Commercial Service ToolsEBS011TA
Tool number
Tool nameDescription
EG17650301
Radiator cap tester
adapterAdapting radiator cap tester to radiator cap and
radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV109E0010
Break-out boxMeasuring the ECM signals with a circuit tester
KV109E0080
Y-cable adapterMeasuring the ECM signals with a circuit tester
S-NT564
S-NT825
S-NT826
Tool name Description
Socket wrench Removing and installing engine coolant
temperature sensor
S-NT705
