2-38 Windshield Washer
At the end of the lever on right side of the steering
wheel, is a wiper symbol.
To spray washer fluid on the windshield, push the button
on the end of the lever. The wipers will run for several
cycles and then either stop or return to the preset speed.
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
The LOW WASHER
FLUID light, located on the
instrument panel will come
on when your vehicle is low
on washer fluid.
If you see this light while driving, your vehicle's washer
fluid is low. You should refill the windshield washer
fluid reservoir as soon as possible so that you'll have
washer fluid when you need it.

2-65
The main components of your instrument panel are listed below:
A. Side Window Defogger Vents
B. Instrument Panel Vents
C. Turn Signal/Multifunction Lever
D. Instrument Panel Cluster
E. Windshield Wipers/Washer Fluid Lever
F. Cruise Control (CRUISE) Button
G. Hazard Warning Button
H. Instrument Panel Fuse Block
I. Instrument Panel Brightness Thumbwheel
J. Fog Lamp Switch (If Equipped)
K. Trunk Lid Release Button
L. Storage BinM. Trip Odometer
N. Tilt Wheel Lever (located on the steering
wheel column)
O. Audio Steering Wheel Controls (If Equipped)
P. Horn
Q. Cruise Control Buttons
R. Ignition Switch
S. Heated Seat Switches, (If Equipped)
T. Accessory Power Outlets
U. Comfort Controls
V. Audio System
W. Glove Box

2-83 Low Washer Fluid Light
This light appears when
your vehicle is low on
windshield washer fluid.
This light will come on when your ignition is turned on
to check the bulb. It will go out after a few seconds. If
the light does not come on when you start your vehicle,
the bulb may need to be replaced. See your dealer to
have it fixed right away.
If this light appears while you're driving, your vehicle is
low on washer fluid. Be sure to refill the tank as soon as
possible so that you'll have washer fluid available when
you need it.
Fuel Gage
United States Canada
Your fuel gage tells you about how much fuel you have
left when the ignition is on.
When the indicator nears empty, you still have a little
fuel left, but you should get more soon.

4-19
Driving in Rain and on Wet RoadsRain and wet roads can mean driving trouble. On a wet
road, you can't stop, accelerate or turn as well because
your tire
-to-road traction isn't as good as on dry roads.
And, if your tires don't have much tread left, you'll get
even less traction. It's always wise to go slower and be
cautious if rain starts to fall while you are driving. The
surface may get wet suddenly when your reflexes are
tuned for driving on dry pavement.
The heavier the rain, the harder it is to see. Even if your
windshield wiper blades are in good shape, a heavy rain
can make it harder to see road signs and traffic signals,
pavement markings, the edge of the road and even
people walking.
It's wise to keep your windshield wiping equipment in
good shape and keep your windshield washer tank filled
with washer fluid. Replace your windshield wiper
inserts when they show signs of streaking or missing
areas on the windshield, or when strips of rubber start to
separate from the inserts.

4-24
Once you are moving on the freeway, make certain you
allow a reasonable following distance. Expect to move
slightly slower at night.
When you want to leave the freeway, move to the proper
lane well in advance. If you miss your exit, do not,
under any circumstances, stop and back up. Drive on to
the next exit.
The exit ramp can be curved, sometimes quite sharply.
The exit speed is usually posted.
Reduce your speed according to your speedometer, not
to your sense of motion. After driving for any distance
at higher speeds, you may tend to think you are going
slower than you actually are.
Before Leaving on a Long Trip
Make sure you're ready. Try to be well rested. If you
must start when you're not fresh
-- such as after a day's
work
-- don't plan to make too many miles that first part
of the journey. Wear comfortable clothing and shoes you
can easily drive in.Is your vehicle ready for a long trip? If you keep it
serviced and maintained, it's ready to go. If it needs
service, have it done before starting out. Of course,
you'll find experienced and able service experts in
Oldsmobile dealerships all across North America.
They'll be ready and willing to help if you need it.
Here are some things you can check before a trip:

Windshield Washer Fluid: Is the reservoir full?
Are all windows clean inside and outside?

Wiper Blades: Are they in good shape?

Fuel, Engine Oil, Other Fluids: Have you checked
all levels?

Lamps: Are they all working? Are the lenses clean?

Tires: They are vitally important to a safe,
trouble
-free trip. Is the tread good enough for
long
-distance driving? Are the tires all inflated to the
recommended pressure?

Weather Forecasts: What's the weather outlook
along your route? Should you delay your trip a short
time to avoid a major storm system?

Maps: Do you have up
-to-date maps?

4-28
Include an ice scraper, a small brush or broom, a supply
of windshield washer fluid, a rag, some winter outer
clothing, a small shovel, a flashlight, a red cloth and a
couple of reflective warning triangles. And, if you will
be driving under severe conditions, include a small bag
of sand, a piece of old carpet or a couple of burlap bags
to help provide traction. Be sure you properly secure
these items in your vehicle.
Driving on Snow or Ice
Most of the time, those places where your tires meet the
road probably have good traction.
However, if there is snow or ice between your tires and
the road, you can have a very slippery situation. You'll
have a lot less traction or ªgripº and will need to be
very careful.

6-
6-1
Section 6 Service and Appearance Care
Here you will find information about the care of your vehicle. This section begins with service and fuel information,
and then it shows how to check important fluid and lubricant levels. There is also technical information about your
vehicle, and a part devoted to its appearance care.
6
-2 Service
6
-3 Fuel
6
-5 Fuels in Foreign Countries
6
-6 Filling Your Tank
6
-8 Filling a Portable Fuel Container
6
-8 Checking Things Under the Hood
6
-11 Engine Oil
6
-16 Engine Air Cleaner/Filter
6
-19 Passenger Compartment Air Filter
6
-20 Automatic Transaxle Fluid
6
-24 Engine Coolant
6
-27 Cooling System Pressure Cap
6
-28 Power Steering Fluid
6
-29 Windshield Washer Fluid
6
-30 Brakes
6
-33 Battery
6
-34 Bulb Replacement6
-42 Windshield Wiper Blade Replacement
6
-43 Tires
6
-51 Appearance Care
6
-51 Cleaning the Inside of Your Vehicle
6
-53 Care of Safety Belts
6
-55 Cleaning the Outside of Your Vehicle
6
-56 Cleaning Aluminum or Chrome-Plated
Wheels (If Equipped)
6
-57 Finish Damage
6
-58 GM Vehicle Care/Appearance Materials
6
-59 Vehicle Identification Number (VIN)
6
-59 Service Parts Identification Label
6
-60 Electrical System
6
-67 Replacement Bulbs
6
-67 Capacities and Specifications
6
-68 Normal Maintenance Replacement Parts

6-8
Filling a Portable Fuel Container
CAUTION:
Never fill a portable fuel container while it is in
your vehicle. Static electricity discharge from the
container can ignite the gasoline vapor. You can
be badly burned and your vehicle damaged if this
occurs. To help avoid injury to you and others:

Dispense gasoline only into
approved containers.

Do not fill a container while it is inside a
vehicle, in a vehicle's trunk, pickup bed or
on any surface other than the ground.

Bring the fill nozzle in contact with the
inside of the fill opening before operating
the nozzle. Contact should be maintained
until the filling is complete.

Don't smoke while pumping gasoline.
Checking Things Under the Hood
CAUTION:
An electric fan under the hood can start up and
injure you even when the engine is not running.
Keep hands, clothing and tools away from any
underhood electric fan.
CAUTION:
Things that burn can get on hot engine parts and
start a fire. These include liquids like gasoline,
oil, coolant, brake fluid, windshield washer and
other fluids, and plastic or rubber. You or others
could be burned. Be careful not to drop or spill
things that will burn onto a hot engine.

6-10 Engine Compartment Overview
When you open the hood of the 3.5L V6 engine, you'll see the following:
A. Windshield Washer
Fluid Reservoir
B. Auxiliary Fuse Box
C. Battery
D. Remote Positive (+)TerminalE. Main Underhood Fuse Box
F. Engine Coolant Surge Tank
G. Power Steering Fluid Reservoir
H. Engine Oil Fill Cap
I. Engine Oil DipstickJ. Automatic Transaxle
Fluid Dipstick
K. Brake Fluid Reservoir
L. Engine Air Cleaner/Filter

6-29 What to Use
To determine what kind of fluid to use, see
ªRecommended Fluids and Lubricantsº in the Index.
Always use the proper fluid. Failure to use the proper
fluid can cause leaks and damage hoses and seals.
Windshield Washer Fluid
What to Use
When you need windshield washer fluid, be sure to read
the manufacturer's instructions before use. If you will be
operating your vehicle in an area where the temperature
may fall below freezing, use a fluid that has sufficient
protection against freezing. See ªEngine Compartment
Overviewº in the Index for reservoir location.
Adding Washer Fluid
United States Canada
If the windshield washer fluid level in your vehicle is
low, the LOW WASHER FLUID warning light, or the
light with the washer fluid symbol, located on the
instrument panel, will come on. You will need to add
fluid soon.
The windshield washer fluid reservoir is located in the
engine compartment on the passenger's side of the
vehicle, near the diagonal cross brace.
Open the cap with the washer symbol on it. Add washer
fluid until the tank is full.
