OPEL VIVARO C 2020.25 Manual user

In brief9Mirror adjustment
Interior mirror
To adjust the mirror, move the mirror
housing in the desired direction.
Manual anti-dazzle interior mirror
3 41.
Automatic anti-dazzle interior mirror 3 41.
Exterior mirrors
Select the relevant exterior mirror by
pushing the mirror button C to the
left or right.
Adjust the respective mirror with the
four-way control.
Convex mirrors 3 39.
Electric adjustment 3 39.
Folding mirrors 3 40.
Heated mirrors 3 40.
Steering wheel adjustment
Unlock lever, adjust steering wheel,
then engage lever and ensure it is fully locked. Do not adjust steering
wheel unless vehicle is stationary and steering wheel lock has been
released.
Seat position 3 48.
Ignition positions 3 153.

10In briefInstrument panel overview

In brief111Power windows .....................42
2 Exterior mirrors .....................39
3 Side air vents ...................... 149
4 Selective ride control ..........172
5 Turn lights ........................... 134
Headlight flash ....................132
High beam ........................... 131
Exit lighting .......................... 137
6 Head-up display controls ....121
7 Steering wheel controls ........94
8 Steering wheel paddles ........94
9 Instruments ......................... 105
Driver Information Centre .... 116
10 Button for Driver
Information Centre ..............116
Windscreen wiper and
washer .................................. 95
Rear wiper and washer .........97
11 Head-up display ..................121
12 Air vents .............................. 149
13 Control elements for Info
Display ................................ 12014Info Display ......................... 120
15 Climate control system ........ 141
16 Storage compartment ...........79
17 Storage compartment ...........79
18 AUX input
19 Power outlet .......................... 98
20 Airbag deactivation ...............65
21 USB port ............................... 98
22 Seat heating .......................... 52
23 Electronic Stability Control
and Traction Control ...........171
Tyre deflation detection
system ................................. 238
Stop-start system ................157
Heated windscreen ...............45
Electric child locks ................. 29
Central locking system ..........25
24 Hazard warning flashers .....133
25 Manual transmission ...........168
Automatic transmission .......165
26 Power button ....................... 154
27 Automatic locking ..................2928Ignition switch .....................153
29 Control elements for
Infotainment system
30 Steering wheel adjustment ...94
31 Fuse box ............................. 231
32 Horn ...................................... 95
33 Cruise control ...................... 174
Speed limiter ....................... 177
Adaptive cruise control .......180
34 Bonnet release lever ...........214
35 Anti-theft alarm system .........37
Lane departure warning ......200
Side blind spot alert ............194
Parking assist ...................... 192
Parking heater ....................147
Headlight range adjustment 132
High beam assist ................131

12In brief

In brief13Exterior lightingAUTO:automatic light control
switches automatically
between daytime running
light and headlightF:sidelightsD:headlight
Automatic light control 3 131.
Front fog lights 3 134.
Rear fog light 3 134.
Headlight flash and high beam
High beam 3 131.
High beam assist 3 131.
Headlight flash 3 132.
Turn lightsup:right turn lightsdown:left turn lights
Turn lights 3 134.

14In briefHazard warning flashers
Operated by pressing ç.
Hazard warning flashers 3 133.
Horn
Press d.
Washer and wiper systems
Windscreen wiper2:fast1:slowINT:interval wiping0:offAUTO:automatic wiping with rain
sensor
For a single wipe when the
windscreen wiper is off, press the
lever down.
Windscreen wiper 3 95.

In brief15Windscreen washer
Windscreen washer system 3 95.
Washer fluid 3 216.
Wiper blade replacement 3 219.
Rear window wiper0:offS:rear window wiperR:rear window washerRear window washer
Set to R.
Washer fluid is sprayed on the rear
window and the wiper wipes a few
times.
Rear window wiper and washer
3 97.

16In briefClimate control
Heated rear window
The heating is operated by pressing
è .
Heated rear window 3 44.
Heated windscreen 3 45.
Heated exterior mirrors
Depending on the version, heating is
operated by pressing è or m .
Heating works with the engine
running and is switched off
automatically after a short time.
Heated exterior mirrors 3 40.
Demisting and defrosting the
windows
Heating and ventilation system, air
conditioning system
● Set fan speed ý to highest level.
● Set temperature controller ñ to
warmest level.
● Switch on cooling A/C, if
required.
● Switch on heated rear window è.
● Open side air vents as required and direct them towards the doorwindows.

In brief17Note
If the settings for demisting and
defrosting are selected, an
Autostop may be inhibited.
If the settings for demisting and
defrosting are selected while the
engine is in an Autostop, the engine
will restart automatically.
Stop-start system 3 157.
Heating and ventilation system
3 139.
Air conditioning system 3 141.Electronic climate control system
● Press h. The LED in the button
illuminates to indicate activation.
● Air conditioning and automatic mode are automatically switched
on. The LED in the button A/C
illuminates, AUTO is shown in the
display.
● Temperature and air distribution are set automatically and the fan
runs at high speed.
● Switch on heated rear window è.
● Switch on heated windscreen
9 .
● To return to previous mode, press h again.
Note
If h is pressed while the engine is
running, an Autostop will be inhibited
until h is pressed again.
If h is pressed while the engine is
in an Autostop, the engine will restart automatically.
Electronic climate control system 3 143.

18In briefTransmission
Manual transmission
To engage reverse on 5-speed
transmission, depress the clutch
pedal and move the selector lever to
the right and rear.
To engage reverse on 6-speed
transmission, depress the clutch
pedal, pull the ring under the selector
lever and move the selector lever
quite to the left and front.
Manual transmission 3 168.
Automatic transmissionType A
Turn the gear selector.
P:park position, front wheels are
locked, engage only when the
vehicle is stationary and the
parking brake is appliedR:reverse gear, engage only when
the vehicle is stationaryN:neutralD:automatic modeM:manual mode
