brake fluid Peugeot 306 Break 2002 Owner's Manual

MAINTENANCE OF YOUR 30619
SPECIAL FEATURES
Some of your vehicleÕs vital components have specific servicing schedules. The airbags and the pretensioning seat belts must be replaced every 10 years. The brake fluid must be replaced every 36/40,000 miles (60,000 km) or every 2 years.
The pollen filter must be checked during each regular service at the PEUGEOT dealer. NB:
the coolant does not need to be renewed.
Arduous conditions of use If the vehicle is used under certain particularly arduous conditions: ¥Continuous door-to-door use.
¥ Town use (e.g. taxi).
¥ Repeated short journeys, with the engine cold in low temperatures,
Or in long stays under the following conditions: ¥ Hot countries with temperatures often above 30 ¡C.
¥ Cold countries with temperatures often below minus 15 ¡C.
¥ Countries with a dusty atmosphere.
¥ Countries whose lubricants or fuels do not conform to our recommendations.
It is necessary to follow an ÒArduous conditionsÓ service schedule which includes special operations and shorter service intervals: ¥ Every 12,000 miles (20 000 km) or every year for petrol vehicles.
¥ Every 9,000 miles (15 000 km) or every year for Direct Injection Diesel engine vehicles.
¥ Every 6,000 miles (10 000 km) or every year for Indirect Injection Diesel engine vehicles.

MAINTENANCE OF YOUR 30619
SPECIAL FEATURES
Some of your vehicleÕs vital components have specific servicing schedules. The airbags and the pretensioning seat belts must be replaced every 10 years. The brake fluid must be replaced every 36/40,000 miles (60,000 km) or every 2 years.
The pollen filter must be checked during each regular service at the PEUGEOT dealer. NB:
the coolant does not need to be renewed.
Arduous conditions of use If the vehicle is used under certain particularly arduous conditions: ¥Continuous door-to-door use.
¥ Town use (e.g. taxi).
¥ Repeated short journeys, with the engine cold in low temperatures,
Or in long stays under the following conditions: ¥ Hot countries with temperatures often above 30 ¡C.
¥ Cold countries with temperatures often below minus 15 ¡C.
¥ Countries with a dusty atmosphere.
¥ Countries whose lubricants or fuels do not conform to our recommendations.
It is necessary to follow an ÒArduous conditionsÓ service schedule which includes special operations and shorter service intervals: ¥ Every 12,000 miles (20 000 km) or every year for petrol vehicles.
¥ Every 9,000 miles (15 000 km) or every year for Direct Injection Diesel engine vehicles.
¥ Every 6,000 miles (10 000 km) or every year for Indirect Injection Diesel engine vehicles.

20TYPES OF SERVICE
Each vehicle has its own servicing cycle, defined by the manufacturer in accordance with each vehicleÕs specific technical features.
This cycle consists of alternating 2 types of service A and C, intermediate visits, and a few additional operations depending on your vehicle ; these correspond to key stages in the life of your 306. Services of type B are designed for less recent vehicles.
Your dealer will indicate the type and content of the next service when the first service is carried out, and at each subsequent service.
Intermediate visit
* Whichever comes first Automatic gearbox oil level every 40,000 miles (60,000km) Brake fluid
replacement every 2 years or every 40,000 miles (60,000km)
These operations are carried out with synthetic based oil; Fuel Economy oil or
MAINTENANCE OF YOUR 306
THE MAINTENANCE CYCLE FOR YOUR PETROL 306
Service every 20,000 miles (30 000 km) or 2 years
MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000) 80,000 (120 000)
1st service at
6,000 miles (10 000 km)* or 6 months
The validity of the
Warranty depends on this service.
100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000) 180,000 (270 000)
+ timing belt replacement + timing belt replacement
AA
A
CC
AACC

21
MAINTENANCE OF YOUR 306Intermediate visit
Brake fluid
replacement every 2 years or every 36,000 (60 000km).
These operations are carried out with synthetic based oil; Fuel Economy oil or
synthetic oil can also be used.
THE MAINTENANCE CYCLE FOR YOUR 306 DIESEL TURBO HDI
Service every 12,000 miles (20 000 km) or 2 years
MILES (KM) 12,000 (20 000) 24,000 (40 000) 36,000 (60 000) 48,000 (80 000)
1st Service at 6,000 miles
(10 000 km)* or 6 months*
The validity of the Warranty depends on this service.
60,000 (100 000) 72,000 (120 000) 84,000 (140 000) 96,000 (160 000) 108,000 (180 000)
+ timing belt replacement
AAA
AAA
C
CC
* Whichever comes first

MAINTENANCE OF YOUR 306
22
Intermediate visit
Brake fluid
replacement every 2 years or every 40,000 (60 000km).
These operations are carried out with synthetic based oil; Fuel Economy oil or
synthetic oil can also be used.
THE MAINTENANCE CYCLE FOR YOUR 306 DIESEL (INDIRECT INJECTION)
MILES (KM) 10,000 (15 000) 20,000 (30 000) 30,000 (45 000) 40,000 (60 000) 50,000 (75 000)
1st Service at 6,000 miles (10 000 km)* or 6 months*
The validity of the Warranty depends on this service.
60,000 (90 000) 70,000 (105 000) 80,000 (120 000) 90,000 (135 000) 100,000 (150 000) 110,000 (165 000)
+ timing belt replacement
AAAA
AAAAA
C
C
* Whichever comes first

MAINTENANCE OF YOUR 30623
PEUGEOT SERVICING LEVELS A AND C
First Level
Operations Description of operations
serviceACIntermediate visit
DRAIN AND REFILL- Engine oil.- Bleed fuel filter (diesel).- Oil filter.- Fuel filter (Petrol).REPLACEMENT- Fuel filter element (Diesel).- Air filter element.- Spark plugs (Petrol).- Engine oil (check + top up).- Manual gearbox oil (check + top up).- Battery (check + top up) if cap is removable.LEVEL- Front/rear windscreen wash (check + top up).- Coolant (check + top up).- Brake fluid (check + top up).- Power steering fluid (check + top up according to specification).- Operation of lights and indicators.- Condition of glass, headlamp and light lenses and mirrors.- Horn.- Windscreen washer jets.- Condition of wiper blades.- Condition and tension of ancillary drive belts.- Handbrake.- Condition of hydraulic circuits (hoses and covers), check for leaks.CHECK- Condition of rubber boots and gaiters.- Brake pad wear. - Play in hubs, rods, ball joints, flexible mountings.- Shock absorbers for leaks.- Rear drum brake lining wear.- Condition and pressure of tyres (including spare wheel).- Emission control check according to current legislation (Petrol).- Smoke opacity (Diesel).- Pollen filter check (according to specification). - Visual check of the whole vehicle by a PEUGEOT dealer.
: All driving conditions : Arduous conditions

25
MAINTENANCE OF YOUR 306
Recommendations for approved lubricants
The oils which appear in the tableopposite are suitable for most purposes. The diagram opposite states the optimum range of viscosity depen-ding on the temperatures at which theoils are to be used. It is also possible to use synthetic oils of Ôsuperior qualityÕ. In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJquality (for petrol engines), or CD/CF(for diesel engines) may be used byfollowing the ÔArduous ConditionsÕmaintenance schedule which speci-fies shorter intervals. Do not hesitate to ask for advice from
a PEUGEOT dealer to maintaindriving pleasure and to minimise themaintenance cost of your vehicle. For countries outside Europe, please
contact a local PEUGEOT dealer.
0W203040
50
20W
15W
10W
5W
ESSENTIAL ESSENTIAL
Manual gearbox ESSO GEAR OIL BVTOTAL TRANSMISSION BV75W 80 PR 9736.41 75W 80
Automatic ESSENTIAL
gearbox AL4 ATF 4HP20-AL4 PR 9736.22
Automatic ESSO ATF D TOTAL FLUIDE AT42
gearbox PR 9730.944 HP-14
Power steering ESSO ATF D TOTAL FLUIDE AT42 PR 9730.94
Brake fluid PEUGEOT DOT4 Coolant PROCOR TM108 / GLYSANTIN G33 or REVKOGEL 2000
ESSENTIAL Protection to minus 35 ¡C
Other approved products

92
YOUR 306 IN DETAIL
1Low coolant level*.
2 Headlamp main beam.
3 Pre-heat (Diesel).
4 Headlamp dipped beam.
5 Water in fuel filter warning light* (Diesel).
6 Speedometer.
7 Left indicator.
8 Low oil pressure warning light.
9 Handbrake low brake fluid level andelectronic brake force distribution.
10 Battery charge. 11
Right indicator.
12 Rev counter.
13 Front fog lamps*.
1 4 Rear fog lamp.
15 ABS: anti-lock braking system*.
16 Fuel gauge.
17 Low fuel level.
18 STOP warning.
19 Seat belt not fastened warning light*.
20 Disarming of passenger airbag**. 21
Side airbags warning light*.
22 Front* and side** airbag warninglight and disarming passengerairbag*.
23 Autodiagnostics*.
24 Trip recorder and service indicator.
25 Trip recorder zero reset and clocksetting.
26 Coolant temperature gauge.
* According to specification or country.
** According to model.
56 78 910 11 12 13 14 15
4 321
26 25 24 23 22 21 20 19 18 17 16
INSTRUMENT PANEL

93
YOUR 306 IN DETAIL
13 14
1Low coolant level.
2 Headlamp main beam.
3 Headlamp dipped beam.
4 Speedometer.
5 Left indicator.
6 Low oil pressure warning light.
7 Handbrake low brake fluid level and electronic brake force distribution.
8 Battery charge.
9 Right indicator.
10 Rev counter.
11 Front fog lamps. 12
Brake pad wear warning light*.
13 Rear fog lamp.
14 ABS: anti-lock braking system*.
15 Fuel gauge.
16 Low fuel level.
17 Oil level and temperature gauge.
18 STOP warning.
19 Seat belt not fastened warninglight*.
20 Disarming of passenger airbag**.
21 Side airbags warning light*. 22
Front* and side** airbag warninglight and disarming passengerairbag*.
23 Autodiagnostics*.
24 Trip recorder and service indicator.
25 Trip recorder zero reset and clocksetting.
26 Coolant temperature gauge.
* According to specification or country.
** According to model.
12 3 4 56789 1 0 11 1 2
26 25 24 23 22 21 20 19 18 17 16 15
13 14
INSTRUMENT PANEL

94
YOUR 306 IN DETAIL
1Low coolant level*.
2 Headlampt main beam.
3 Pre-heat (Diesel).
4 Headlamp dipped beam.
5 Water in fuel filter warning light* (Diesel).
6 Speedometer.
7 Left indicator.
8 Low oil pressure warning light.
9 Gear indicator (automatic gearbox).
10 Handbrake low brake fluid level andelectronic brake force distribution. 11
Battery charge.
12 Right indicator.
13 Rev counter.
14 Front fog lamps*.
15 Rear fog lamp.
16 ABS: anti-lock braking system*.
17 Fuel gauge.
18 Low fuel level.
19 Oil level.
20 STOP warning.
21 Seat belt not fastened warninglight*. 22
Disarming of passenger airbag**.
23 Side airbags warning light**.
24 Front* and side** airbag warninglight and disarming passengerairbag*.
25 Autodiagnostics*.
26 Trip recorder and service indicator.
27 Trip recorder zero reset and clocksetting.
28 Coolant temperature gauge.
* According to specification or country.
** According to model.
56 78910 11 12 13 14 15 16
4 321
28 27 26 25 24 23 22 21 20 19 18 17
INSTRUMENT PANEL
