95
YOUR 306 IN DETAIL
A warning light which remains per- manently lit indicates that the unit con-
cerned is not operating correctly. Donot ignore this warning: contact a
PEUGEOT dealer as soon as possible.
Coolant temperature gauge
- needle in zone A, the temperature
is correct.
- needle in zone B, the temperature
is too high.
The STOP warning light comes on.
You must stop.
Contact a PEUGEOT dealer.
* According to specification.
Handbrake, low brake fluid level and electronicbrake force distributionwarning light
Indicates either:
Ð that the handbrake is on or has not been released correctly,
Ð an excessive drop in the brake fluid level (if the light remains lit even with the handbrake released),
Ð a malfunction of the braking system, if lit at the same time as the ABSwarning light.
Stop immediately.
Contact a PEUGEOT dealer.
STOP warning light
(Together with the oil pressure warning light).
You must stop.
Contact a PEUGEOT dealer. Oil pressure warning light
Together with the STOP warning light.
You must stop. Indicates either:
- oil pressure is too low,
- a lack of oil in the lubricating circuit.
Top up the oil level if necessary.
Contact a PEUGEOT dealer.
Battery charge warning light Indicates either: - faulty operation of the
battery charging circuit,
- loose battery or starter terminals,
- a broken or loose alternator drive belt
- an alternator fault,
Contact a PEUGEOT dealer. Low coolant level warning light*
You must stop.
Wait until the engine cools
before topping up.The cooling circuit is pressurised.When opening to top up, turn the cap to the first notch to let the pressuredrop.
Contact a PEUGEOT dealer.
Engine autodiagnostic warning light* This comes on each time the ignition is switched on. If itcomes on when driving, this
indicates faulty operation of the injec-tion, ignition or emission controlsystem. There is a risk of damage to the cat- alytic converter if your vehicle is fitted with one.
Contact a PEUGEOT dealer.
Low fuel warning light Indicates that there are approximately 1.3 gallons(6 litres) of fuel remainingin the fuel tank.
(The capacity of the tank is approxi-mately 60 litres).
A
B
INSTRUMENTS AND CONTROLS

MAINTENANCE OF YOUR 30631
Power steering reservoir
Open the reservoir, with the engine cold, at outside temperature, the levelshould always be above the MINImark, close to the MAXI mark.
Windscreen and headlamp wash reservoir* For best quality cleaning and for your
safety, we recommend that you useproducts approved by PEUGEOT(capacity 4,4 litres or 6 litres withheadlight wash). Battery
At the start of winter, have your battery checked by a PEUGEOT
dealer. Air filter Regular replacement of the filter element is essential. If you drive invery dusty conditions, change it twiceas often. Brake pads Brake pad wear depends on the style of driving, in particular for vehicleswhich are used in town or for shortjourneys or which are driven in a
sporty manner, it may be necessaryto check the thickness of the padseven between services. Manual gearbox This does not need an oil change. Check the level according to the
manufacturerÕs service schedule. Autoadaptive automatic gearbox This does not need an oil change: have the level checked by a
PEUGEOT dealer according to the
manufacturerÕs service schedule.
Only use products appro-
ved by Automobiles
PEUGEOT.
To ensure best perfor-
mance from components as impor- tant as the power steering and thebraking system, PEUGEOT selectsand offers quite specific products.
Fuel supply cut-off* In a serious collision, a system pre- vents fuel from reaching the engine.
To re-establish the fuel supply, press the switch on the angle of the front
left-hand suspension assembly, underthe bonnet.
* According to specification.
