Page 3 of 128
4YOUR 307 AT A GLANCE
THE KEYS The keys allow you to switch on the ignition and to independentlyoperate the locks on the front doors,the fuel filler cap and the glove box,as well as operate the passenger airbag disarming switch. Central locking
From the driver's door, the keys allow you to lock, deadlock* orunlock the doors and the bootand to fold back the exterior mir-rors*. If one of the doors or the boot is open, it is impossible to operatethe central locking; a bleep indi-cates locking by remote control. The remote control performs the same functions at a distance.
* According to specificationThe remote control key Locking ➜
Press button Ato lock the
vehicle. This is confirmed by fixed lighting of the direction indi-cators for approximately twoseconds. Note: in addition to deadloc-
king, a long press on button A
automatically closes the win- dows* and the sunroof*.
Vehicles fitted withdeadlocking*
Deadlocking* renders the internal and external doorlocking controls inoperative.
➜ Press button Ato deadlock
the vehicle.
This is confirmed by fixed lighting of the direction indicators forapproximately two seconds.
A second press on button Ain
the five seconds following dead- locking, changes deadlocking tonormal locking. This is confirmed by fixed lighting of the direction indicators forapproximately two seconds,accompanied by a brief sound ofthe horn.
Unlocking Press button Bto unlock the
vehicle. This is confirmed by rapid flashing of thedirection indicators. Note : If the vehicle is
locked and unlocking
is then activated inadvertently,the vehicle will re-lock automati-cally unless a door is openedwithin 30 seconds of unlocking.
STARTING
STOP position:
The ignition is off.
1st notch, Accessories position:
The ignition is off but the acces-sories can be used. 2nd notch, Running position: The ignition is on. Starting position:
Operates the starter.
65
Page 7 of 128
AIRBAGS The air bags have been designed to maximise the safety of the occu-pants in the event of serious colli-
sions. They work in conjunctionwith the force limiting seat belts. Front air bags These are folded in the centre of the steering wheel for the driverand in the fascia for the front
passenger. They are deployed
simultaneously, except in caseswhere the passenger air bag isdisarmed. Precautions regarding the passenger air bag ➜disarm the air bag if you ins- tall a rear-facing child seat,
➜ arm the air bag for an adult
passenger. Disarming the passenger air bag* ➜
with the ignition off, insert the key into slot 1and turn the
passenger air bag switch tothe "OFF" position.
As soon as you remove the childseat, turn the air bag switch to the''ON'' position, to activate the air
bag again.Operating check
With the ignition switched on (2nd notch of the igni-tion), illumination of thiswarning light, accompa-
nied by an audible signal and themessage ''Passenger air bag
disarmed'' on the multi-function
display, indicates that thepassenger air bag is disarmed(switch in the "OFF"position).
The warning light remains onthroughout the disarming process. Side air bags* and curtain air bags** The side air bags are incorpora- ted into the seat backs of thefront seats, on the door side. The curtain air bags are incorpo- rated into the door pillars and thetop of the passenger compart-ment.
They are deployed unilaterally, on whichever side the collisionoccurs.
* According to country.
** According to specifi- cation.
8YOUR 307 AT A GLANCE
9192
Page 9 of 128
10OPENING THE BONNET Inside the vehicle: Push the
handle on the left-hand side, under the fascia. Outside the vehicle: Lift the catch, raise thebonnet and secure thestrut to keep the bonnetopen.
FILLING WITH FUEL This operation must be carried out with
the engine switched off.
➜ Open the fuel filler flap.
➜ Insert the key then turn it to the left.
➜ Remove the cap and hook it onto the clip on the inside of the flap.
A label on the inside of the flap shows which type of fuel to use.
When you fill your tank, do not continue after the third cut-off of the pump. This could cause your vehicle to malfunction. The capacity of the tank is approximately 13 gallons (60 litres). ➜ After filling the tank, lock the cap and close the flap.
Low fuel level warning light From the time this light comes on, the range remaining is approximately 30 miles(50 km).
7171
YOUR 307 AT A GLANCE
Page 18 of 128
MILES (KM)40,000 (60 000)80,000 (120 000) 120,000 (180 000)
THE SERVICE LEVELS Each vehicle has its own servicing cycle, based upon the engine type.
This cycle consists of alternating 2 types of service, A and C, intermediate visits and a few additional operations specific to your vehicle; these correspond to key stages in the life of your 307. At your first and each subsequent service, your dealer will advise you of the type and content of the next service due.
PEUGEOT SERVICING
22
1st service at 6 000 miles
(10 000 km) or 6 months*.
This is necessary in order to benefit from the warranty.
Replacement of automatic gearbox oil every 40,000 miles (60 000 km). Replacement of brake fluidevery 2 years or 40,000 miles (60 000km).
These fixed operations are carried out with synthetically based oil. Synthetic oil or Fuel economy oil may also be used.
Arduous conditions of use (see corresponding section)
- Replacement of air filterevery 24,000 miles (40 000km).
- Replacement of timing beltevery 48,000 miles (80 000km).
* Whichever comes first.
+ replacement of timing belt
Intermediate visit included in the fixed interval services.
MAINTENANCE CYCLE FOR YOUR 307 PETROL ENGINE
Service every 2 years or 20,000 miles (30 000 km) maximum
Page 35 of 128
GENERAL FUNCTIONSOn/off With the ignition key in the accessories or ignition position, press button Mto switch the set on or off.
The set can operate for 30 minutes without the vehicle ignition being switched on.
Anti-theft systemThe audio system is coded in such a way that it can operate only on your vehicle. It would not function if fitted to another vehicle. The anti-theft system is automatic and requires no action on your part. ADJUSTING THE VOLUME Press button Oto increase the volume or button Nto decrease it.
Continuous pressure on buttons Oand Nallows a gradual adjustment of the volume.
AUDIO SETTINGS Press button Gseveral times in succession to access the bass (BASS), treble (TREB), loudness (LOUD),
fader ( FAD), balance (BAL)and automatic volume correction.
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing button G
after configuration of the automatic volume correction. Note : bass and treble settings are specific to each source. It is possible to set them differently for radio,
cassette (RB3), CD (RD3) and CD changer.
YOUR 307 IN DETAIL
40
Page 64 of 128
VOTRE 307 DANS LE DƒTAIL63
Never leave a child or an animal in a vehicle whichis exposed to the sun withthe windows closed.
Never leave the keys within reach
of children inside the car. Strap children into their seats even on short journeys. Observe the precautions regar- ding the passenger air bag. Observe the fitting and fastening recommendations, indicated in
the child seat instructions, strictly.From 3 to 10 years (33 to 80 lbs or 15 to 36 kg)
"Recaro Start": is fitted in the rear with the three-point seat belt. The height, depth and length of the seat must be adjusted in line with the age and size of your child. "Klippan Optima" : is fitted in the rear with a three-point seat belt. Above 6 years (approximately 45 lbs or 22 kg), use the booster on its own.
Remember, even for short journeys, to fasten the three-point seat belts or the child seat straps, keeping the slack in relation to the child's body to a minimum.
To prevent the doors from opening accidentally, use the "child-proof" lock. Also, do not open the rear windows more than a third.
* According to current legislation.
4
5
Page 66 of 128
THE KEYS The keys allow you to switch on the ignition and to independently opera-te the locks on the front doors, thefuel filler cap, the glove box and thepassenger air bag disarming switch. Central locking
From the driver's door, the keys allow you to lock, deadlock* or unlock thedoors and tailgate, as well as fold backthe exterior mirrors*. If one of the doors or boot is open, the central locking does not work; ableep indicates this when locking byremote control. The remote control performs the same functions at a distance.The remote control LockingPress button
Ato lock the vehicle.
This is confirmed by fixed lighting of the direction indicators for approxi-mately two seconds. Note : a long press on button A, in
addition to locking, automatically closes the windows* and the sun-roof*.
Vehicles fitted with deadlocking*
Warning: deadlocking* renders the
interior and exterior door locking controls inoperative. Pressing button Adeadlocks the
vehicle. This is confirmed by fixed lighting of the direction indicators forapproximately two seconds. Note: a long press on button Aper-
mits automatic closing of the win- dows* and the sunroof*, in additionto deadlocking.
A second press on button A within
five seconds of deadlocking changes
this to normal locking. This is confir-med by fixed lighting of the directionindicators for two seconds, followedby a brief sound from the horn.
YOUR 307 IN DETAIL 65
Unlocking Press button
Bto unlock the vehicle
This is confirmed by rapid flashing of the direction indicators. Note: if the vehicle is locked and
unlocking is activated inadvertently, unless the doors are opened within30 seconds, the vehicle will lock
automatically. Note: do not repeatedly press the
buttons of your remote control out of
range of your vehicle. You risk cau-sing it not to work and the remotecontrol would have to be reprogram-med. Locating your car
To locate your car, if you have loc- ked it, in a car park: press button A(the courtesy
lights come on and the direction indicators flash for a fewseconds).
* According to specification.
Page 67 of 128
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle. Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition.Changing the battery of the remote control The information
"battery flat"is given
by an audible signal accompanied by the message ''Remote control batte-
ry low'' on the multifunction display.
To replace the battery, remove the boltthen unclip the casing using a coin atthe ring (CR2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control. Programming the remote control Switch off the ignition.
Switch the ignition on again.
Immediately press button A.
Switch off the ignition and remo- ve the remote control key from
the ignition lock. The remotecontrol is now working again.
YOUR 307 IN DETAIL
66
Electronic engine immobiliser This locks the engine control system as soon as the ignition has been
switched off and therefore preventsstarting of the vehicle by anyone who
does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode is recognised and starting ispossible. If the system does not function correctly
, the central locking button
indicator light, situated in the centreof the instrument panel, flashesrapidly when the ignition is switchedon (2nd notch on the ignition key),accompanied by an audible signaland the message "Anti-theft device
faulty" on the multifunction display.
WARNING: your vehicle is no longer
protected in this event. Contact a
PEUGEOT dealer as soon as pos-sible.
* According to specification.
Page 68 of 128
Make a careful note of the number on each key. The key number is coded on the label attached to the key. If the key is lost, your PEUGEOT dealer can rapidly supply you with new keys. The high-frequency remote control is a high-performance system.Do not operate it while it is in your pocket as there is a possibility that it may unlock your vehicle without your
knowledge.The remote control cannot operate if the key is in the ignition, even if the ignition is switched off, except for reprogram- ming. Do not operate the deadlock if there is someone inside the vehicle.As a safety measure (when there are children on board), remove the ignition key when leaving the vehicle, even for a short time.
Do not handle the buttons of your remote control when out of range of your vehicle. You run the risk of stopping it from working. It would then be necessary to reprogramme the remote control. When buying a second-hand car:
- Ensure that you are given the confidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones that can start your vehicle.
Do not make any modifications to the electronic engine immobiliser system.
YOUR 307 IN DETAIL 67
Page 69 of 128
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle. Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition.Changing the battery of the remote control The information
"battery flat"is given
by an audible signal accompanied by the message ''Remote control batte-
ry low'' on the multifunction display.
To replace the battery, remove the boltthen unclip the casing using a coin atthe ring (CR2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control. Programming the remote control Switch off the ignition.
Switch the ignition on again.
Immediately press button A.
Switch off the ignition and remo- ve the remote control key from
the ignition lock. The remotecontrol is now working again.
YOUR 307 IN DETAIL
66
Electronic engine immobiliser This locks the engine control system as soon as the ignition has been
switched off and therefore preventsstarting of the vehicle by anyone who
does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode is recognised and starting ispossible. If the system does not function correctly
, the central locking button
indicator light, situated in the centreof the instrument panel, flashesrapidly when the ignition is switchedon (2nd notch on the ignition key),accompanied by an audible signaland the message "Anti-theft device
faulty" on the multifunction display.
WARNING: your vehicle is no longer
protected in this event. Contact a
PEUGEOT dealer as soon as pos-sible.
* According to specification.
