fault Peugeot 307 SW 2003 User Guide

14-04-2003
THE ALARM This provides two types of protec- tion: Ðexterior protection: it sounds if
a door, the boot or the bonnet is opened.
Ð interior protection: it sounds if
the volume inside the passengercompartment changes (breakingof a window or a movement insi-de the vehicle).
Setting the alarm  Switch off the ignition and get out of the vehicle.
 Set the alarm within five minutesof getting out of the vehicle, bylocking or deadlocking using theremote control (button Aindica-
tor light flashes once persecond).
Note: if you wish to lock your vehicle
without setting the alarm, use thedoor lock. When the alarm is triggered, thesiren sounds and the direction indi-cator lights flash for thirty seconds. After triggering, the alarm remains set.
Warning:
if the alarm has been
triggered ten times in succession, on the eleventh time it becomesinactive. Note: if button Aindicator light
flashes rapidly, the alarm has been triggered while you were away fromyour vehicle.
Disarming Unlock the vehicle with the remote control key (button Aindicator light
goes out). Note: if the alarm has been triggered
while you were away from your vehicle, the rapid flashing of the indi-cator light will stop when you switchon the ignition.
To set the alarm with exterior protection only If, while you are away from the vehicle, you wish to leave a windowpartially open or a pet inside thevehicle, you should choose exterior
protection only.  Switch off the ignition,
 In the next ten seconds, press button Auntil the indicator light is
on continuously,
 Get out of the vehicle,
Set the alarm by locking or dead-locking using the remote control(button Aindicator light flashes
once a second).
Note: when the alarm is set but the
remote control does not operate:  Unlock the doors with the key
and open the door. The alarm istriggered.
 Switch on the ignition in the next
ten seconds. The alarm is disar-med.
Incorrect operation When the ignition is switched on, if button Alights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have the system checked. Automatic activation* The alarm is activated automatically two minutes after the last closure ofa door or the boot. In order to avoid accidental triggering of the alarm when a door or the bootis opened, it is essential to first pressthe unlocking button on the remotecontrol.
* According to destination.
YOUR 307 SW IN DETAIL
106

14-04-2003
TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver's door lock.
To open, pull handle Aand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened.
"Tailgate open" warning When the engine is running, an audible signal and a diagram dis-played briefly on the multi-functiondisplay warn you that the tailgate isnot properly closed. In addition, if the vehicle is being dri- ven, the courtesy lights flash. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. PANORAMIC ROOF
Your vehicle is fitted with a tinted glass panoramic roof whichincreases the light and visibility in thepassenger compartment. Its electricconcealing shutter improves tempe-rature conditions.
To open:
press part Aof the switch.
To close: press part Bof the switch.
Manually: press the switch without
going past the point of resistance; the shutter stops as soon as the switch is released. Automatically: press the switch
beyond the point of resistance; one press fully opens or closes the shut-
ter. Press the switch again to stop
the shutter.
YOUR 307 SW IN DETAIL
108

14-04-2003
TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver's door lock.
To open, pull handle Aand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened.
"Tailgate open" warning When the engine is running, an audible signal and a diagram dis-played briefly on the multi-functiondisplay warn you that the tailgate isnot properly closed. In addition, if the vehicle is being dri- ven, the courtesy lights flash. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. PANORAMIC ROOF
Your vehicle is fitted with a tinted glass panoramic roof whichincreases the light and visibility in thepassenger compartment. Its electricconcealing shutter improves tempe-rature conditions.
To open:
press part Aof the switch.
To close: press part Bof the switch.
Manually: press the switch without
going past the point of resistance; the shutter stops as soon as the switch is released. Automatically: press the switch
beyond the point of resistance; one press fully opens or closes the shut-
ter. Press the switch again to stop
the shutter.
YOUR 307 SW IN DETAIL
108

14-04-2003
AUTOMATIC SWITCHING ON OF LIGHTS The side lights and dipped beam headlamps switch on automatically if
the light is poor, or during operation
of the windscreen wipers. They swit-
ch off when the light becomes brightenough or the windscreen wipersstop. Note:In foggy weather or in snow,
the brightness sensor can detect suf-
ficient light. As a consequence, the
lights will not come on automatically. This function is active when the vehicle is delivered.
To disarm or activate the function:  Turn the key to the accessories position (1st notch),
 Press the end of the lights stalkfor more than four seconds.
The brightness sensor, connected
to the rain sensor, is located in thecentre of the windscreen, behind
the interior mirror. It is used forautomatic switching on of thelights. Operating check ActivationActivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting
active" on the multi-function display.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is disarmed tem-
porarily when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by anaudible signal, accompanied by themessage "Automatic switching on
of lights faulty" on the multi-func-
tion display.
Contact a PEUGEOT dealer to have the system checked.
* During the year.
YOUR 307 SW IN DETAIL 111
Direction indicators (flashers) Left: downwards.
Right: upwards.
In good or rainy weather, both day and night, thefront fog lamps and therear fog lamp are dazz-
ling and are prohibited. Do not forget to switch them off when they are no longer needed.

14-04-2003
AUTOMATIC SWITCHING ON OF LIGHTS The side lights and dipped beam headlamps switch on automatically if
the light is poor, or during operation
of the windscreen wipers. They swit-
ch off when the light becomes brightenough or the windscreen wipersstop. Note:In foggy weather or in snow,
the brightness sensor can detect suf-
ficient light. As a consequence, the
lights will not come on automatically. This function is active when the vehicle is delivered.
To disarm or activate the function:  Turn the key to the accessories position (1st notch),
 Press the end of the lights stalkfor more than four seconds.
The brightness sensor, connected
to the rain sensor, is located in thecentre of the windscreen, behind
the interior mirror. It is used forautomatic switching on of thelights. Operating check ActivationActivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting
active" on the multi-function display.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is disarmed tem-
porarily when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by anaudible signal, accompanied by themessage "Automatic switching on
of lights faulty" on the multi-func-
tion display.
Contact a PEUGEOT dealer to have the system checked.
* During the year.
YOUR 307 SW IN DETAIL 111
Direction indicators (flashers) Left: downwards.
Right: upwards.
In good or rainy weather, both day and night, thefront fog lamps and therear fog lamp are dazz-
ling and are prohibited. Do not forget to switch them off when they are no longer needed.

14-04-2003
YOUR 307 SW IN DETAIL113
Do not cover the rain sen- sor located on the wind-screen behind the interior
mirror.
When using an automatic carwash, switch off the ignition orcheck that the wiper stalk is not in
the automatic position. In winter, itis advisable to wait for the wind-screen to completely clear of icebefore operating the automaticwipe. Rear windscreen wiper
Turn ring Ato the first notch
for intermittent wiping.
Rear windscreen wash Turn ring Apast the first
notch; the windscreen wash then the windscreen wiperoperate for a fixed period. Automatic windscreen wipers In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the inten-
sity of the rainfall .
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wiping active" appears on the mul-
tifunction display. Disarming Disarming of the function is accom- panied by an audible signal. In the event of malfunction , the dri-
ver is informed by an audible signal and the message "Auto wind-
screen wiper faulty" on the multi-
function display. In the AUTOposition, the wind-
screen wiper will operate in intermit- tent mode.
Contact a PEUGEOT dealer to have the system checked.

14-04-2003
Unlocking Pull on the handle and press the but- ton to release the handbrake. Illumination of this warninglight and of the STOPwar-
ning light, accompanied byan audible signal (while thevehicle is being driven) and
the message "handbrake on" on
the multi-function display, indicatesthat the handbrake is still on or hasnot been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal, accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), keeping within the limit of localspeed restrictions.
Contact a PEUGEOT dealer as soon as possible. HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion.
ANTI-LOCK BRAKING SYSTEM
(ABS) AND THE ELECTRONICBRAKE FORCE DISTRIBUTION(EBFD)
The ABS, in conjunction with the electronic brake force distribution,increases the stability and manoe-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
When this warning lightcomes on, accompanied bya buzzer and the message"ABS fault" , it indicates
that there is a malfunction of
the ABS, which can cause a loss ofcontrol of the vehicle when braking.
When this warning lightcomes on, connected to the
STOPand ABS warning
lights, accompanied by abuzzer and the message
"Braking fault" , it indicates that
there is a malfunction of the electro-nic brake force distribution, whichcan cause a loss of control of thevehicle when braking.

14-04-2003
Unlocking Pull on the handle and press the but- ton to release the handbrake. Illumination of this warninglight and of the STOPwar-
ning light, accompanied byan audible signal (while thevehicle is being driven) and
the message "handbrake on" on
the multi-function display, indicatesthat the handbrake is still on or hasnot been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal, accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), keeping within the limit of localspeed restrictions.
Contact a PEUGEOT dealer as soon as possible. HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion.
ANTI-LOCK BRAKING SYSTEM
(ABS) AND THE ELECTRONICBRAKE FORCE DISTRIBUTION(EBFD)
The ABS, in conjunction with the electronic brake force distribution,increases the stability and manoe-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
When this warning lightcomes on, accompanied bya buzzer and the message"ABS fault" , it indicates
that there is a malfunction of
the ABS, which can cause a loss ofcontrol of the vehicle when braking.
When this warning lightcomes on, connected to the
STOPand ABS warning
lights, accompanied by abuzzer and the message
"Braking fault" , it indicates that
there is a malfunction of the electro-nic brake force distribution, whichcan cause a loss of control of thevehicle when braking.

14-04-2003
Unlocking Pull on the handle and press the but- ton to release the handbrake. Illumination of this warninglight and of the STOPwar-
ning light, accompanied byan audible signal (while thevehicle is being driven) and
the message "handbrake on" on
the multi-function display, indicatesthat the handbrake is still on or hasnot been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal, accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 60 mph (100 km/h), keeping within the limit of localspeed restrictions.
Contact a PEUGEOT dealer as soon as possible. HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion.
ANTI-LOCK BRAKING SYSTEM
(ABS) AND THE ELECTRONICBRAKE FORCE DISTRIBUTION(EBFD)
The ABS, in conjunction with the electronic brake force distribution,increases the stability and manoe-vrability of your vehicle, particularlyon poor or slippery road surfaces. Note: when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
When this warning lightcomes on, accompanied bya buzzer and the message"ABS fault" , it indicates
that there is a malfunction of
the ABS, which can cause a loss ofcontrol of the vehicle when braking.
When this warning lightcomes on, connected to the
STOPand ABS warning
lights, accompanied by abuzzer and the message
"Braking fault" , it indicates that
there is a malfunction of the electro-nic brake force distribution, whichcan cause a loss of control of thevehicle when braking.

14-04-2003
REAR PARKING ASSISTANCE This system consists of four proximi- ty sensors, located in the rear bum-
per, and a special speaker. This detects any obstacle (person, vehicle, tree, gate, etc.) behind thevehicle. Nevertheless, it cannotdetect obstacles located just below
the bumper. An object, such as a stake, a road- works cone or any other similarobject may be detected at the begin-ning of the manoeuvre, but may nolonger be detected when the vehiclecomes close to it. Note:this function will be disarmed
automatically when the vehicle is towing a trailer or when a bicycle car-rier is fitted (vehicle fitted with towingattachment or bicycle carrier recom-mended by PEUGEOT).
In bad or wintry weather, ensure that the sensors are not covered with
mud, frost or snow. Activation The system is activated as soon as reverse gear is engaged; an audiblebleep shows that it is active. The proximity information is given by an audible signal, which becomesmore rapid as the vehicle approachesthe obstacle. When the distance between the rear of the vehicle and the obstacle is lessthan approximately twenty-five centi-metres, the audible signal becomescontinuous.Deactivation
Change to neutral, the system is again inactive.
YOUR 307 SW IN DETAIL
132
Detection zone
If there is an operating fault, the audible signalwill be a short bleep follo-wed by a long bleep when
changing to reverse gear.
