fault Peugeot 307 SW 2003 Owner's Guide

14-04-2003
AIR BAGS The air bags have been designed to maximise the safety of the occupantsin the event of serious collisions.They work in conjunction with theforce-limiting seat belts. The electronic detectors register and analyse any abrupt deceleration ofthe vehicle: if the triggering thresholdis reached, the air bags inflate ins-tantly and protect the occupants ofthe vehicle. Immediately after the impact, the air bags deflate rapidly so that they donot hinder the visibility of the occu-pants nor their exit if necessary fromthe vehicle. The air bags are not deployed in the case of collisions which are notserious, for which the seat belt is suf-ficient to ensure maximum protec-
tion. The seriousness of a collisiondepends on the nature of the obs-tacle and the speed of the vehicle atthe moment of the collision. Air bags only operate when the ignition is switched on. Note:the gas escaping from the air
bags can be a minor irritant. FRONT AIR BAGS These are folded in the centre of the steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,except in cases where the passen-ger air bag is disarmed. Front air bag fault
If this warning light comes on, accompanied by anaudible signal and the mes-sage "Air bag fault" on the
multifunction display,
contact a PEUGEOT dealer to havethe system checked. Disarming the passenger air bag*
To ensure the safety of your child, it is essential to disarm the pas-senger air bag when you install arear-facing child seat on the frontpassenger seat.
With the ignition switched off, insert the key into the passengerair bag disarming switch 1, turn it
to the "OFF" position, then remo-
ve the key keeping the slot in thisposition.
The air bag warning light on the instrument panel is lit throughout thedisarming process.
* According to destination.
YOUR 307 SW IN DETAIL 133

14-04-2003
In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is remo- ved, turn the air bag slot to the "ON"
position to re-activate the air bag andthus ensure the safety of your pas-senger in the event of an impact. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
With the ignition on (2ndnotch), illumination of thiswarning light accompaniedby an audible signal and themessage "Passenger air
bag disarmed" on the multifunction
display, indicates that the passengerair bag is disarmed (switch in the"OFF" position). SIDE AIR BAGS* AND
CURTAIN AIR BAGS* The side air bags are incorporated into the front seat backs on the doorside. The curtain air bags are incorporated into the door pillars and the upperpart of the passenger compartment. They are deployed independently of each other depending on which sidethe collision occurs. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comes on,accompanied by an audiblesignal and the message "Air bag fault" on the multi-
function display, contact a
PEUGEOT dealer to have thesystem checked.
* According to destination.
YOUR 307 SW IN DETAIL
134
If the two "Air bag fault" and "Passenger air bagdisarmed" warning lights
come on permanently, donot install a rearwardfacing child seat andconsult a PEUGEOT
dealer.

14-04-2003
In the "OFF" position, the passenger
air bag will not be triggered in the event of an impact. As soon as the child seat is remo- ved, turn the air bag slot to the "ON"
position to re-activate the air bag andthus ensure the safety of your pas-senger in the event of an impact. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
With the ignition on (2ndnotch), illumination of thiswarning light accompaniedby an audible signal and themessage "Passenger air
bag disarmed" on the multifunction
display, indicates that the passengerair bag is disarmed (switch in the"OFF" position). SIDE AIR BAGS* AND
CURTAIN AIR BAGS* The side air bags are incorporated into the front seat backs on the doorside. The curtain air bags are incorporated into the door pillars and the upperpart of the passenger compartment. They are deployed independently of each other depending on which sidethe collision occurs. Operating check This is confirmed by an indicator light, accompanied by an audiblesignal and a message on the multi-
function display.
If this indicator light comes on,accompanied by an audiblesignal and the message "Air bag fault" on the multi-
function display, contact a
PEUGEOT dealer to have thesystem checked.
* According to destination.
YOUR 307 SW IN DETAIL
134
If the two "Air bag fault" and "Passenger air bagdisarmed" warning lights
come on permanently, donot install a rearwardfacing child seat andconsult a PEUGEOT
dealer.

14-04-2003
CHANGING A BULB Front lights Note:on the right-hand side, remove the style cover, fixed
with two plastic screws, to access the bulbs. Handle the bulbs with a dry cloth.
1 - Dipped beam headlamps (H7-55W).
2 - Main beam headlamps (H1-55W).
3 - Front fog lamps (H1-55 W). Turn the protective cover corresponding to the faulty bulb a quarter of a turn and remove it.
 Disconnect the connector.
 Press the end of the securing clip to free it. Changethe bulb. When fitting the new bulb, ensure that the direction notches are positioned correctly and the securing clip
is fixed properly.
 Reconnect the connector.
 Refit the protective cover, positioning it with the arrowupwards, then turn it a quarter of a turn to the right. The headlamps are fitted with polycarbonate glass with aprotective coating.
Do not clean them with a dry or
abrasive cloth, nor with a detergent or solvent product. Use a sponge and soapy water.
4 - Side lights W 5 W.  Pull the socket rearwards, remove the bulb and chan- ge it.
5 - Direction indicators (PY 21 W amber).  Turn the bulb holder a quarter of a turn and remove it.
 Change the bulb.
Note: In certain climatic conditions (low temperature,
humidity), condensation inside the headlamp glass is
normal ; it disappears a few minutes after the lights are
switched on.
PRACTICAL INFORMATION 145

14-04-2003
PRACTICAL INFORMATION147
Third brake light: 4 W 5 W bulbs.  Remove the tailgate upper trim carefully by unclipping it on eitherside, perpendicular to its direc-tion of engagement.
 Insert a screwdriver into the twoouter holes Bto press on the two
tabs C.
 Push the light unit outwards whilemaintaining the pressure on thetabs.
 Pull the light unit outwards whiletilting it.
 Change the faulty bulb.
 When refitting, ensure that thelight unit tabs are engaged cor-rectly and that the tailgate uppertrim has been put back in place
correctly.
Press the tab Aand remove the
bulb holder.
 Change the faulty bulb.
Note: if necessary use the wheelbra-
ce to remove the bolts. When refitting, take care to position
the bulb holder and the bulb correctly. Number plate lights (W 5 W)  Insert a small screwdriver in one of the external holes of the lens.
 Push the lens outwards to unclipit.
 Remove the lens.
 Change the faulty bulb.
Rear lights
1 - Brake lights (P 21 W).
2 - Side lights (R 5 W).
3 - Direction indicators (P 21 W).
4 - Reversing lights (P 21 W), left
side.
Fog lamp (P 21 W), right side.
These 5 bulbs are changed by remo- ving the light:  Remove the respective boot side trim to access the light.
 Remove the mounting nut for thelight inside the boot.
 Remove the mounting nut for thelight outside the boot.
 Remove the light.
 Unclip the harness.

CHANGING A FUSE The fuse boxes are located under the fascia (left-hand side) and in theengine compartment. The spare fuses and special pliers A
are fixed to the inside of the lid of the instrument panel fuse box. Removing and changing a fuse Before changing a fuse you must establish the cause of the fault and
have it corrected. The fuse numbersare indicated on the fuse box.  Use the special pliers A.
Always change a faulty fuse for one of the same rating. Instrument panel fuses
Unscrew the bolt a quarter of a turn with a coin, then pull thehandle to open the cover andaccess the fuses.
PRACTICAL INFORMATION
148
Fuse no. Rating Functions
1 10 A Rear fog lamp.
2 15 A Rear screen wiper.
4 15 A Front electric windows.
5 15 A Left brake light including trailer.
7 30 A Rear courtesy light, front courtesy light, map readers - 12V front socket - Glove box lighting -
Sunroof shutter.
Correct
Pliers AIncorrect
14-04-2003

CHANGING A FUSE The fuse boxes are located under the fascia (left-hand side) and in theengine compartment. The spare fuses and special pliers A
are fixed to the inside of the lid of the instrument panel fuse box. Removing and changing a fuse Before changing a fuse you must establish the cause of the fault and
have it corrected. The fuse numbersare indicated on the fuse box.  Use the special pliers A.
Always change a faulty fuse for one of the same rating. Instrument panel fuses
Unscrew the bolt a quarter of a turn with a coin, then pull thehandle to open the cover andaccess the fuses.
PRACTICAL INFORMATION
148
Fuse no. Rating Functions
1 10 A Rear fog lamp.
2 15 A Rear screen wiper.
4 15 A Front electric windows.
5 15 A Left brake light including trailer.
7 30 A Rear courtesy light, front courtesy light, map readers - 12V front socket - Glove box lighting -
Sunroof shutter.
Correct
Pliers AIncorrect
