display Peugeot 307 SW Dag 2002.5 Workshop Manual

22-07-2002
Maintenance position This position enables the wiper blades to be removed.
In the minute following switching off of the ignition, any action on the stalkpositions the wipers in the centre ofthe windscreen so that they may becleaned or replaced.
To park the wipers after this has been done, switch on the ignitionand operate the stalk.
YOUR 307 SW IN DETAIL
112
Do not cover the rain sen- sor located on the wind-screen behind the interior
mirror.
When using an automatic carwash, switch off the ignition orcheck that the wiper stalk is not in
the automatic position. In winter, itis advisable to wait for the wind-screen to completely clear of icebefore operating the automaticwipe. Rear windscreen wiper
Turn ring Ato the first notch
for intermittent wiping.
Rear windscreen wash Turn ring Apast the first
notch; the windscreen wash then the windscreen wiperoperate for a fixed period. Automatic windscreen wipers In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the intensi-ty of the rainfall.
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wiping active" appears on the mul-
tifunction display. Disarming Disarming of the function is accom- panied by an audible signal. In the event of malfunction , the dri-
ver is informed by an audible signal and the message "Auto wind-
screen wiper faulty" on the multi-
function display. In the AUTOposition, the wind-
screen wiper will operate in intermit- tent mode.
Contact a PEUGEOT dealer to have the system checked.

22-07-2002
YOUR 307 SW IN DETAIL113
TRIP COMPUTER
Each time the button on the end of the wash/wipe stalk
is pressed, the follo-
wing sequence of data is displayed:
Monochrome screen CT
Ð the "vehicle" index with:
¥ range, current consumption and the distance still to be driven,
Ð index "1"(route "1") with:
¥ the distance driven and the ave- rage speed calculated over route "1" ,
Ð index "2"(route "2") with the same
features.
It also permits access to the Excess
Speed Warning function.
Zero re-set When the required route is dis- played, press the button for morethan two seconds.
Monochrome screen B
- the remaining range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
In addition, it allows access to the war-
ning log information and to the function
Excess speed warning .
Zero reset Press the stalk for more than two seconds.
Colour screen DT
Ð the "Current information" with:
¥ the range,
¥ the current consumption,
¥ the distance still to be driven.
Ð "Route 1" with:
¥ the distance travelled,
¥ the average coonsumption,
¥ the average speed,
Ð "Route 2" with the same features.
It also permits access to the Excess
Speed Warning function.
Zero re-setWhen the required route is dis- played, press the button for morethan two seconds.

YOUR 307 SW IN DETAIL
114
Distance remaining to be tra- velled This is the distance remaining to the destination. It can either be calcula-ted by the navigation if guidance is
activated, or entered by the user,minus the distance covered since thedistance was entered. Note:if digits are missing, dashes
are displayed in their place.
Average speed This is the average speed calculated since the computer was last set tozero (with the ignition on). The warnings log This summarises the active warning messages by displaying them on themultifunction screen. The excess speed warning function* This monitors the maximum speed required. In the event that the pro-grammed speed is exceeded, themessage "Speed too high" appears
on the multifunction screen, accom-panied by an audible signal. Programming Accelerate to the desired speed. Keep pressing the control to store in
memory.
Range This shows the distance that can still be covered with the fuel remaining inthe tank. Note:
this figure may increase if
there is a change in the style of dri- ving or the road surface, producing asignificant drop in the currentconsumption. If horizontal segments are displayed for long periods instead of digits,
contact a PEUGEOT dealer. Current consumption This is the average fuel consumption during the last few seconds. This function is displayed only when the vehicle is travelling at a speedgreater than 30 km/h.
Average consumption This is the average fuel consumption since the computer was last set tozero. Distance travelled This indicates the distance travelled since the computer was last set tozero.
* During the year. Activation Keep pressing the control until the display indiciates
"Excess speed
ON" .
Switching off Keep pressing the control until the display indiciates "Excess speed
OFF" .
The routes The routes "1"and "2"are indepen-
dent but have identical application.Route "1"for example allows you to
make daily calculations and route "2" monthly calculations.
22-07-2002

22-07-2002
YOUR 307 SW IN DETAIL113
TRIP COMPUTER
Each time the button on the end of the wash/wipe stalk
is pressed, the follo-
wing sequence of data is displayed:
Monochrome screen CT
Ð the "vehicle" index with:
¥ range, current consumption and the distance still to be driven,
Ð index "1"(route "1") with:
¥ the distance driven and the ave- rage speed calculated over route "1" ,
Ð index "2"(route "2") with the same
features.
It also permits access to the Excess
Speed Warning function.
Zero re-set When the required route is dis- played, press the button for morethan two seconds.
Monochrome screen B
- the remaining range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
In addition, it allows access to the war-
ning log information and to the function
Excess speed warning .
Zero reset Press the stalk for more than two seconds.
Colour screen DT
Ð the "Current information" with:
¥ the range,
¥ the current consumption,
¥ the distance still to be driven.
Ð "Route 1" with:
¥ the distance travelled,
¥ the average coonsumption,
¥ the average speed,
Ð "Route 2" with the same features.
It also permits access to the Excess
Speed Warning function.
Zero re-setWhen the required route is dis- played, press the button for morethan two seconds.

YOUR 307 SW IN DETAIL
114
Distance remaining to be tra- velled This is the distance remaining to the destination. It can either be calcula-ted by the navigation if guidance is
activated, or entered by the user,minus the distance covered since thedistance was entered. Note:if digits are missing, dashes
are displayed in their place.
Average speed This is the average speed calculated since the computer was last set tozero (with the ignition on). The warnings log This summarises the active warning messages by displaying them on themultifunction screen. The excess speed warning function* This monitors the maximum speed required. In the event that the pro-grammed speed is exceeded, themessage "Speed too high" appears
on the multifunction screen, accom-panied by an audible signal. Programming Accelerate to the desired speed. Keep pressing the control to store in
memory.
Range This shows the distance that can still be covered with the fuel remaining inthe tank. Note:
this figure may increase if
there is a change in the style of dri- ving or the road surface, producing asignificant drop in the currentconsumption. If horizontal segments are displayed for long periods instead of digits,
contact a PEUGEOT dealer. Current consumption This is the average fuel consumption during the last few seconds. This function is displayed only when the vehicle is travelling at a speedgreater than 30 km/h.
Average consumption This is the average fuel consumption since the computer was last set tozero. Distance travelled This indicates the distance travelled since the computer was last set tozero.
* During the year. Activation Keep pressing the control until the display indiciates
"Excess speed
ON" .
Switching off Keep pressing the control until the display indiciates "Excess speed
OFF" .
The routes The routes "1"and "2"are indepen-
dent but have identical application.Route "1"for example allows you to
make daily calculations and route "2" monthly calculations.
22-07-2002

22-07-2002
YOUR 307 SW IN DETAIL115
Trip computer function This function allows inputting of the distance to the destination (whenguidance is not activated; otherwisethe information is given by the navi-gation) and also changing of the
units (¡C or ¡F, km and litres or milesand gallons). Diagnostics This function tells you the warnings, the quantity of emergency fuel andthe GPS cover present at the timeconsulted. Note: these alerts have previously
been displayed in the form of mes- sages and/or warning lights on thecontrol unit. There are 6 categories of diagnostics:
- engine diagnostics (warnings lin- ked to the engine and gearbox etc....),
- brake diagnostics,
- suspension diagnostics (warnings linked to the suspension, ESP etc....),
- wheel diagnostics (warnings linked to tyres),
- doors and windows diagnostics,
- passenger compartment diagnos- tics. Distance to destination When guidance is not activated, this enables an approximate value to beentered to make all the trip computercalculations possible.
Specific features of the mono- chrome screen CT and thecolour screen DT General menu Press the
"MENU"button to access
the general menu.Select the icon "Trip computer"
using the knob, then validate to
access the "Trip computer" menu.
The ''trip computer'' menu offers various choices:
- Trip computer configuration,
- Diagnostics.
"Trip computer" context menu The context menu associated with the "Trip Computer" application
appears as a superimposed display
when the Trip Computer is the appli-cation currently being used in the
main screen window. Briefly press the continuous applica-
tion "Trip computer" button to selectone of the following functions:
- warnings log,
- Distance to destination.

22-07-2002
S: sport programme.


: snow programme.
P ark: to immobilise the vehicle or start the engine ,
with the handbrake on or off.
R everse: to reverse (select this function with the
vehicle stationary, engine at idle). N eutral: to start the engine and to park, with the hand-
brake on. Note: if function Nis engaged inadvertently while dri-
ving, allow the engine to return to idle before engaging function Dto accelerate.
D rive : for driving in automatic mode.
M anual: for driving in manual mode.
YOUR 307 SW IN DETAIL 127
Moving Off
With the engine running, to move off from position P:
it is essential to press the
brake pedal to exit position P,
select function R, D or M, then
gradually release the pressureon the brake pedal; the vehicle
moves off immediately.
You can also move off from position N:
release the handbrake, with yourfoot on the brake,
select function R, D or M, then
gradually release the pressureon the brake pedal; the vehicle
moves off immediately.
WARNING When the engine is at idle, brakes not applied, if function R, D or Mis
selected the vehicle moves evenwithout the accelerator being pres-sed.For this reason, do not leave
children unsupervised inside thevehicle, with the engine running. When maintenance operations need to be carried out with the engine run-ning, apply the handbrake and selectposition P.
"PORSCHE TIPTRONIC SYSTEM" AUTOMATIC GEARBOX The four speed automatic gearbox offers a choice between the comfort of inte-
gral automatic operation , enhanced by a sport and a snow programme, or the
pleasure of manual gear changing.
Gear selection gate Move the lever in the gate to select a function. Once the function is selected, the corresponding indicator light appears on
the instrument panel display.

22-07-2002
Automatic operation Automatic changing of the four
gears: select function Din the gate.
The gearbox always selects the most suitable gear according to the follo-wing parameters:
- the style of driving,
- the road profile,
- the vehicle load. The gearbox is then operating in auto-adaptive mode, without anyaction on your part.
WARNING Never select function Nwhen the
vehicle is moving. Never select functions Por Runless
the vehicle is stationary.Never change between functions to optimise braking on a slippery surface. Notes For immediate maximum accelera-
tion without touching the gear lever,press the accelerator pedal down as
far as it will go (kickdown). The gear-box will automatically change downor maintain the gear selected untilmaximum engine speed is reached. When the brake is applied, the gear- box will automatically change down
in order to provide efficient enginebraking. If you take your foot off the accelera-
tor suddenly, the gearbox will notchange to a higher gear for reasons
of safety.
Sport and snow programmes In addition to the auto-adaptive pro- gramme, there are two special pro-grammes. The programme is displayed on the instrument panel screen. Sport programme Press button Sonce the vehicle
has been started and function D
selected.
The gearbox automatically favours sporty driving and more dynamicacceleration. Snow programme This programme improves starting
and drive when traction is poor. Press button

once the vehicle
has been started and function D
selected.
The gearbox adapts to driving on slippery roads. Note: you can return to the auto-
adaptive programme at any time. Press button Sor

again to
switch off the programme you are in. Manual operation Manual changing of the
four gears:
select function Mon the gate,
push the lever to the +sign to
change to a higher gear,
pull the lever to the -sign to
change to a lower gear.
You can change from position D (dri-
ving in automatic mode) to position M (driving in manual mode) at any
time. Note It is only possible to change from one gear to another if the vehicle speedand engine speed permit. If they donot, the vehicle will operate tempora-rily in automatic mode. When the vehicle is stationary or
moving very slowly, the gearboxautomatically selects gear M1.
Programmes S(sport) and

(snow)
do not operate in manual mode.
YOUR 307 SW IN DETAIL
128

22-07-2002
Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"handbrake on" on the
multi-function display, indi-
cates that the handbrake is still on orhas not been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 100 km/h, keeping within the limit of local speed restric-tions.
Contact a PEUGEOT dealer as soon as possible. Illumination of this warninglight, accompanied by anaudible signal and the mes-sage
"Braking fault" on the
multi-function display, indi-
cates a malfunction of the electronicbrake force distribution, which cancause a loss of control of the vehiclewhen braking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake. ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases thestability and manoeuvrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note:
when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion. Normal operation of the ABS maymake itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.

22-07-2002
Unlocking Pull on the handle and press the but- ton to release the handbrake.Illumination of this light,accompanied by an audiblesignal and the message"handbrake on" on the
multi-function display, indi-
cates that the handbrake is still on orhas not been properly released.
Operating abnormality Any operating abnormality is indica- ted by an audible signal accompa-nied by the message "Automatic
gearbox faulty" on the multi-func-
tion display and flashing of the Sportand Snow warning lights on the ins-trument panel. In this situation the gearbox operates in downgrade mode (locked in 3rd
gear). You may feel a substantialknock when changing from Pto R
and from Nto R(this will not cause
any damage to the gearbox). Do not exceed 100 km/h, keeping within the limit of local speed restric-tions.
Contact a PEUGEOT dealer as soon as possible. Illumination of this warninglight, accompanied by anaudible signal and the mes-sage
"Braking fault" on the
multi-function display, indi-
cates a malfunction of the electronicbrake force distribution, which cancause a loss of control of the vehiclewhen braking.
Stop immediately.
Contact a PEUGEOT dealer.
HANDBRAKE Locking Pull the handbrake to immobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull the handbrake. ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases thestability and manoeuvrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note:
when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
YOUR 307 SW IN DETAIL 129
If the battery is flat and the lever is in position P, it
will be impossible tochange to another posi-tion. Normal operation of the ABS maymake itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
