On-line handbook
Select one of the following means of access to view your
handbook on-line...
Referring to the handbook on-line also gives you access to the latest information available, easily identified by the bookmark,
associated with this symbol:If the "My
Peuge
Ot" f
unction is not available on the Peuge
Ot
p
ublic website for your country, you can find your handbook at the
following address:
http://public.servicebox.peugeot.com/ddb/
the language,
the vehicle, its body style,
the print edition of your handbook appropriate for the date of registration of
your vehicle.
Select:
th
is personal space offers advice and other useful information for
the care and maintenance of your vehicle.
Find your handbook on the Peuge
Ot w
ebsite, under
"My Peuge
Ot". S
can this code for direct access to your handbook.
Page 3 of 389
Welcome
We draw your attention to the following points:
- th e fitting of electrical equipment or accessories not listed by
P
e
uge
Ot
may cause faults and failures with the electrical
system of your vehicle. Contact a P
e
uge
Ot
dealer or a
qualified workshop for information on the range of recommended
accessories.
-
A
ny modification or adaptation not intended or authorised by
Automobiles P
e
uge
Ot
or carried out without meeting the
technical requirements defined by the manufacturer would lead
to the suspension of the new vehicle warranty.
Thank you for choosing a 4008, a symbol of
confidence, passion and inspiration
this handbook has been designed to help to make the most of
your 4008 in all circumstances and in complete safety.
ta
ke the time to read through it so as to familiarise yourself with
your
vehicle.
th
e descriptions and illustrations are given as indications only.
Automobiles P
e
uge
Ot
reserves the right to modify the technical
characteristics, equipment and accessories without having to update
this edition of the handbook.
th
is handbook covers all of the variations in equipment available
across the whole 4008 range.
Your vehicle will be fitted with only some of the equipment described
in this document, depending on its trim level, version and the
specification for the country in which it was sold. For any work on your vehicle, use a qualified workshop that has the
technical information, competence and equipment required, which a
Pe
ugeOt d ealer is able to provide.
th
is document forms an integral part of your vehicle. Remember to
pass it on to the new owner in the event of the sale of the vehicle.
Key
Warning:
this symbol is for warnings that you must
observe for your own safety, the safety of
others, and to avoid the risk of damage to
your vehicle.
Information:
this symbol draws your attention to
additional information for the best use of
your vehicle.
Protection of the environment:
this symbol accompanies advice related to
the protection of the environment.
