YOUR 406 AT A GLANCE
14FUEL FILLER FLAP
To open: firmly pull the handle
on the floor to the outside of the driver's seat.
To close: from outside the
vehicle, push back the flap and
check that it is secured correctly. Filling with fuel Switch off the engine.
A filler cap hook is provided.
A label on the inside of the flap shows which fuels are permitted and which are not. The capacity of the tank is approximately 15.4 gallons (70 litres).
Low fuel level warning lightFrom the time this light comes on, the range remaining is approximately 30 miles (50 km) .
11 3
OPENING THE BONNET Inside the vehicle: Pull the
handle. Outside the vehicle: Lift
the catch and open the bonnet.
11 3

∀∀
MAINTENANCE OF YOUR 40623
∀All driving conditions.o Arduous conditions.
A AND C SERVICES AND THE INTERMEDIATE VISIT
- Oil filter∀∀- Fuel filter (Petrol only)∀- Fuel filter element (Diesel only)∀- Air filter element∀- Spark plugs (Petrol only)HPI∀
- Operation of lights and indicators∀∀∀- Condition of glass, headlamp & light lenses and mirrors∀∀- Horn∀∀- Windscreen washer jets∀∀- Condition of wiper blades∀∀- Condition and tension of the ancillary drive belts∀∀- Handbrake∀∀- Condition of hydraulic circuits (hoses and covers)∀∀- Condition of rubber boots and gaiters∀∀∀- Brake pads∀∀
o- Play in hubs, link rods, ball joints, flexible mountings∀- Shock absorbers∀- Rear drum brake lining wear∀- Condition and pressure of tyres (including spare wheel)∀∀∀- Emission control check (Petrol only)∀∀∀- Smoke opacity (Diesel only)∀∀- Pollen filter (according to specification)∀∀o- Visual check of the whole vehicle∀∀
DRAIN and
REFILL
REPLACE
CHECK
ROAD TEST SERVICE
Level
Operation Description of Operation First Service
A C Intermediate
- Engine oil∀∀- Bleed fuel filter (Diesel only)∀∀∀
- Engine oil (check + top-up)∀∀- Gearbox level (check + top-up)∀∀- Battery level (check + top-up) if cap is removable∀∀- Front/rear screen wash level (check + top-up)∀∀∀∀- Coolant level (check + top-up)∀∀∀∀- Brake fluid level (check + top-up)∀∀∀- Power steering fluid level (check + top-up, according to specification)∀∀∀

Lighting rheostat
With the lights on, press the button to vary the intensity of the lighting of theinstruments and controls. When thelighting reaches the minimum (ormaximum) setting, release the but-ton then press it again to increase (orreduce) the brightness. As soon as the lighting is of the required brightness, release the button.
Trip recorder zero reset With the ignition on, press the button. Instrument panel display After switching on the ignition, three functions are shown in succession:
- engine oil level indicator,
- service indicator,
- total distance recorder. Engine oil level
When the ignition is switched on, the engine oil level indicator is displayed for approximately five seconds, then the service indicator is displayed for five seconds.
Maximum Use the dipstick to confirm the level on the indicator; a surplus of oil can cause damage to the engine.
Contact a PEUGEOT dealer as soon as possible. Minimum
Check the level with the dipstick and top it up. The figure shown is only correct if the vehicle has been on stable, level ground, withthe engine stopped, for 10 minutes. No oil It is essential to top up the oil to the correct level, otherwise the engine will be damaged.
YOUR 406 IN DETAIL
134

AUTOMATIC SWITCHING ON OF THE LIGHTS Side lights and dipped beam head- lamps switch on automatically if the
light is poor, or during continuousoperation of the windscreen wipers.
They switch off as soon as the lightbecomes bright enough or the wind-screen wipers stop. This function is active when the vehi-
cle is supplied to the customer.
To disarm or activate the function: Start with the key in the acces- sories position (1st notch),
 Press the end of the stalk formore than two seconds.
Note: In foggy weather, the bright-
ness sensor can detect sufficientlight. Because of this, the lights do
not come on automatically. Do not cover the brightness sen-
sor connected to the rain sensor,located in the windscreen behind
the mirror. It is used for automaticswitching on of the lights. Operating check
Triggering of the sensor
Triggering of this function is accom- panied by an audible signal and themessage
"Automatic lighting of
the headlamps activated" on the
multi–function display. Note: Always operate the lighting
controls manually where this is pos- sible. Disarming Disarming of the function is accom- panied by an audible signal. When driving, if this function is
switched off when the headlampswould switch on in automatic mode,the lights remain on. It is however possible to disarm this
function and switch off the lights by:
- manually switching off the lights using the lights stalk,
- switching off the engine.
YOUR 406 IN DETAIL 125
If the brightness sensor does not
function correctly, the system acti-
vates the function (the lights come
on). The driver is alerted by theflashing of the 'dipped beam' warn-ing light on the instrument panel.
Contact a PEUGEOT dealer to have the system checked. Follow me Home When there is a low level of bright- ness or at night, if you leave yourvehicle, the side lights and thedipped beam lights may remain onfor approximately one minute.
To do this: place the lights stalk in the AUTO
position,
 place the key in the accessories position (first notch on key),
 press the end of the lights stalk formore than two seconds,
 place the lights stalk in the 0position,
 flash the headlamps,
 get out of the car and lock it.

The ESP system offers increased safety duringnormal driving, but shouldnot incite the driver to take
risks or to drive at high speed.
The operation of the system isassured to the extent to which the recommendations of the manu-facturer regarding the wheels(tyres and wheel rims), the brakingcomponents, the electronic compo-nents and the assembly and repairprocedures within the PEUGEOTnetwork are respected.
After an accident or impact, havethe system checked by a
PEUGEOT dealer.
DRIVING YOUR 406
152
TRACTION CONTROL (ASR) AND
DYNAMIC STABILITY CONTROL(ESP) These systems are linked and com-
plement the ABS system.
The ASR system optimises drive to prevent the wheels skidding, by act-ing on the brakes of the drive wheelsand on the engine. It also allows thedirectional stability of the vehicle tobe improved on acceleration. If thereis a variation between the trajectoryfollowed by the vehicle and that
required by the driver, the ESP sys-tem automatically acts on the engineand the brake of one or morewheels,in order to put the vehicle back oncourse.
Operation of the ASR and
ESP systems
When one of these two sys-tems is operating, this lightflashes. Handbrake Applying When parking, pull the handbrake toimmobilise your vehicle.
Warning:
when parking on a slope,
direct your wheels towards the pave- ment and pull on the handbrake. Releasing Pull the handle and press the buttonto release the handbrake.
Disarming the ESP / ASR systems In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),it could prove useful to disarm theASR system to make the wheelsspin and regain grip.
Press the switch "ESP OFF", sit-
uated to the left of the steering wheel.
The switch lights up and the indicatorlights come on , accompanied by the
message '' ASR/ESP de-activated''
on the multi–function display: the
ESP and ASR systems no longer
affect the operation of the engine orthe brakes. They engage again: automatically when the ignition is
switched off,
 manually by pressing the switchagain.
Operating check When a system malfunctionoccurs, the switch lightflashes and the indicatorlight comes on.
Contact a PEUGEOT dealer tocheck the system.

BATTERY
To charge the battery using a battery charger:
- Disconnect the battery,
- Follow the instructions for use given by the battery charger manufacturer,
- Reconnect starting with the negative (–) terminal,
- Check that the terminals and connectors are clean. If they are covered with sul-phate (white or greenish deposit), disconnect them and clean them.
To start the vehicle from another battery:
- Connect the red cable to the positive (+) terminals of the two batteries,
- Connect one end of the green or black cable to the negative (-) terminal of the slave battery,
- Connect the other end of the green or black cable to an earth point on the bro- ken down vehicle, as far as possible from the battery,
Operate the starter, let the engine run.
Wait for the engine to return to idle, then disconnect the cables.
- Never disconnect a terminal when the engine is running. - Never charge a battery without first disconnecting the terminals.
- Close the sunroof before disconnecting the battery. If it does not ope-rate normally following re-connection of the battery, you must re-ini- tialise it by turning the control to the maximum tilt position and pres-sing it for an extended period.
- After every reconnection of the battery, switch on the ignition and wait 1 minute before starting to allow the electronic systems to be initialised. Ifslight difficulties are experienced after this, please contact a PEUGEOT
dealer.
It is advisable to disconnect the battery if the vehicle is not to be used
for a period of more than one month.Economy mode
With the engine switched off and the ignition key in the "running" or"accessories" position for about half
an hour, certain electrical equipment(displays, instrument panel, warninglights, courtesy lights, electric win-
dows, wipers etc.) will switch offautomatically to avoid draining the
battery. Once the electrical equipment goes into economy mode, it is necessaryto start the engine to enable theequipment to work again.
MAINTENANCE OF YOUR 406
48

TOWING A TRAILER,
CARAVAN, BOAT ETC.
Only use original PEUGEOT tow bars that have been tested andapproved from the design stage ofyour vehicle. The tow bar must be fitted by a
PEUGEOT dealer.
Your vehicle is basically designed for transporting people and luggage but it
may also be used for towing a trailer. Driving with a trailer subjects the towing vehicle to more significantstress and its driver must be particu-larly careful. Air density decreases with altitude, thus reducing engine performance.The maximum towing load mustbe reduced by 10% for every 1000 metres of altitude. Driving advice Distribution of loads: Distribute
the load in the trailer so that the heaviest items are as close as possi-ble to the axle and the nose weightapproaches the maximum permittedwithout exceeding it. Cooling:
Towing a trailer on a slope
increases the temperature of thecoolant. As the fan is electrically controlled, its cooling capacity is not dependenton the engine speed.
On the contrary, use a high gear to lower the engine speed, and reduceyour speed. The maximum towing speed on a long slope depends on the gradientand the outside temperature. For vehicles fitted with a direct injec- tion petrol engine, after towing or dri-ving at high speed for a long periodof time, the fan may operate forapproximately 6 minutes. In all cases, pay attention to the coolant temperature. If the warning light comes on, stop
the vehicle and switch off the engineas soon as possible. Tyres:
Check the tyre pressures of
the towing vehicle and the trailer,observing the recommended pres-sures. Brakes: Towing increases the brak-
ing distance. Lights: Check the electrical sig-
nalling on the trailer.Side wind: Take into acount the
increased sensitivity to side wind.
MAINTENANCE OF YOUR 406 51
