Peugeot 508 2014 Owner's Manual - RHD (UK, Australia)

329
06
Press  to display the audio settings menu.
The settings available are:
- Ambience,
- Bass,
- Treble,
- Loudness,
- Distribution: Personalised or Driver,
- Left / right balance,
- Fader (front / rear balance),
- Auto. volume.
AUDIO SETTINGS
SCREEN C
The distribution (or spatialisation using the Arkamys© system), is © system), is ©
an audio process which allows the sound quality to be improved according to the setting chosen, corresponding to the position of the listeners in the vehicle.
Select and confi rm " Other settings… " to display the next setting in the list.
The Ambience, Treble and Bass audio settings are different and independent for each sound source.
On-board Audio: Arkamys © Sound Staging. © Sound Staging. ©
With Sound Staging, the driver and passengers are immersed in an "audio scene" recreating the natural atmosphere of an auditorium: truly a part of the scene and its surroundings.
This new sensation is made possible by software in the audio system which processes the digital signals from the media players (radio, CD, MP3…) without changing the audio settings. This processing takes account of the characteristics of the passenger compartment to produce optimum results.
The Arkamys© software installed in your audio system processes © software installed in your audio system processes ©
the digital signal from the media players (radio, CD, MP3, ...) and recreates a natural musical scene, with harmonious placement of instruments and voices in the space in front of passengers, level with the windscreen.

330
07
SCREEN C
Multimedia
Media parameters
Choice of playback mode
Choice of track listing
Telephone
Call
Dial
Directory
Calls list
Voice mail box
Directory management
Consult an entry
Delete an entry
Delete all entries
Telephone management
Telephone status
Hang up
Normal
Random
Random all
Repeat
By folders
By artists
By genres
By playlists
Radio parameters
SCREEN MENU MAP

MAIN FUNCTION
Option A1
Option A2
OPTION A
OPTION B
1
2
2
1
2
2
2
2
1
2
2
2
1
2
1
3
3
3
3
3
3
3
3
1
1
2
2
1

331
07SCREEN MENU MAP
Personalisation-
configuration
Choice of language
Display confi guration
Bluetooth connection
Connections management
Choice of units
Date and time adjustment
Display parameters
Brightness
1
1
2
2
2
2
1
1 Search for a device

332
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
There is a difference in sound quality between the different audio sources (radio, CD...).
For optimum sound quality, the audio settings (Volume, Bass, Treble, Ambience, Loudness) can be adapted to the different sound sources, which may result in audible differences when changing source (radio, CD...).
Check that the audio settings (Volume, Bass, Treble, Ambience, Loudness) are adapted to the sources listened to. It is advisable to set the AUDIO functions (Bass, Treble, Front-Rear Fader, Left-Right Balance) to the middle position, select the musical ambience "None" and set the loudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
When changing the settings for treble and bass, the ambience setting is deselected.
When changing the ambience setting, treble and bass are reset to zero.
Choosing an ambience imposes settings for treble and bass. Modifying one without the other is not possible. Modify the treble and bass settings or the ambience setting to obtain the desired sound quality.
When changing the balance setting, distribution is deselected.
Choosing a distribution setting imposes a balance setting. Modifying one\
without the other is not possible. Modify the balance setting or the distribution setting to obtain the desired sound quality.
The following tables contain answers to the most frequently asked questi\
ons.

333
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The quality of reception of the radio station listened to gradually deteriorates or the stored stations do not function (no sound, 87.5 MHz is displayed...).
The vehicle is too far from the transmitter used by the station listened\
to or there is no transmitter in the geographical area through which the\
vehicle is travelling.
Activate the RDS function to enable the system to check whether there is a more powerful transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks...) blo\
ck reception, including in RDS mode. This phenomenon is normal and does not indicate a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going through a car wash or into an underground car park). Have the aerial checked by a PEUGEOT dealer.
Sound cut-outs of 1 to 2 seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency permitting better reception of the station. Deactivate the RDS function if the phenomenon is too frequent and always on the same route.
The traffi c announcement (TA) is displayed. I do not receive any traffi c information.
The radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c information.
The stored stations are not found (no sound, 87.5 MHz is displayed...).
An incorrect waveband is selected. Press the BAND button to return to the waveband on which the stations are stored.

334
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
The CD is ejected automatically or is not played by the player.
The CD is inserted upside down, is unplayable, does not contain any audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.
- Check that the CD is inserted in the player the right way up.
- Check the condition of the CD: the CD cannot be played if it is too damaged.
- Check the content in the case of a recorded CD: consult the advice in the "Audio" section.
- The audio equipment's CD player does not play DVDs.
- Due to their quality level, certain writeable CDs will not be played by the audio system.
The CD player sound is poor. The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable conditions.
The audio settings (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selecting an ambience.
The Bluetooth connection is cut. The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.
The message "USB device error" is displayed on the screen.
The USB memory stick is not recognised.
The memory stick may be corrupt.
Reformat the memory stick (FAT 32).

335
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION
A telephone connects automatically, disconnecting another telephone.
Automatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.
The Apple ® player is ® player is ®
not recognised when connecting to the USB port.
The Apple ® player is of a generation that is not compatible with the USB. ® player is of a generation that is not compatible with the USB. ® Connect the Apple ® player to the AUX Jack socket ® player to the AUX Jack socket ®
using a suitable cable (not supplied).
The hard disk or device is not recognised when connecting to the USB port.
Some hard disks and devices need a power supply greater than is provided by the audio system. Connect the device to the 230 V socket, the 12 V socket or an external power supply.
Caution : ensure that the device does not transmit a voltage greater than 5 V (risk of destruction of the system).
When streaming, the sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le to improve streaming.
In "Random all" play, not all of the tracks are played.
In "Random all" play, the system can only take into account up to 999 tracks.
With the engine off, the audio system switches off after a few minutes of use.
When the engine is switched off, the audio system operating time depends on the battery charge.
The switch-off is normal: the audio system switches to economy mode and switches off to prevent discharging the vehicle's battery.
Start the vehicle's engine to increase the battery charge.
The message "the audio system is overheated" appears on the display.
In order to protect the installation if the surrounding temperature is t\
oo high, the audio system switches to an automatic thermal protection mode \
leading to a reduction of the volume or stopping of the playing of the C\
D.
Switch the audio system off for a few minutes to allow the system to cool.

336

.
337
Alphabetical index
Accessories ..................................................215Accessory socket, 12 volt ...............................77Additive, AdBlue ............................230, 232-234Adjusting headlamps ....................................14 4Adjusting head restraints ..........................6 7, 7 0Adjusting seat belt height .............................173Adjusting the steering wheel ..........................76Airbags ............................................................32Airbags, curtain .....................................17 7, 178Airbags, front.........................................175 , 178Airbags, lateral ......................................17 7, 178Air conditioning .........................................20, 89Air conditioning, automatic .......................87, 90Air conditioning, digital ...................................98Air conditioning, manual ...........................87, 88Air conditioning, quad-zone ...............93, 96, 98Air filter ..........................................................Air filter ..........................................................Air filter228Air flow ............................................................20Air vents ..........................................................86Alarm ...............................................................53Anti-theft .......................................................102Armrest ............................................................77Armrest, rear ...................................................Armrest, rear ...................................................Armrest, rear78Assistance call ......................................166, 250Audible warning ............................................166Audio streaming (Bluetooth) ........294, 320, 322Audio system (radio) .....................................307Automatic illumination of headlamps .....1 3 7, 1 41Automatic operation of hazard warning lamps ............................................165Automatic rain sensitive windscreen wipers .................................................147, 149Auxiliary socket .............................................319
Capacity, fuel tank ..........................................64CD .................................................................314CD MP3 .................................................315, 316Central locking ................................................47Changing a bulb ....................192, 197, 198, 20 0Changing a fuse ............................................201Changing a wheel .................................185, 18 6Changing a wiper blade ........................150, 20 9Changing the date .....................................41, 42Changing the remote control battery ........5 0 , 51Changing the time .....................................41, 42Checking levels .....................................225-227Checking the engine oil level ..........................37Checking tyre pressures (using the kit) ..............................................179Checks ..................................221-224, 228, 229Children .........................................157, 161, 162Child seats ...........................153, 15 4, 15 6, 159Child seats, conventional ......................15 6, 157Closing the boot ..............................................57Closing the doors ............................................47Connectors, audio ...........................79, 317, 319Container, AdBlue ................................233, 234Coolant level ...........................................33, 227Coolant temperature indicator ........................Coolant temperature indicator ........................Coolant temperature indicator33
Date (setting) .............................................41, 42Daytime running lamps .........139, 192, 19 4, 19 6Deactivating ESP ..........................................171Deactivating the passenger airbag ...............175Deadlocking ....................................................48Defrosting ........................................................98Diesel ..............................................................25Diesel additive level ......................................227Diesel engine pre-heat warning lamp ............25Dimensions ...................................................246Dipped beam ..................................136, 192-19 4Dipstick ....................................................3 7, 2 2 5Directional lighting ................................145, 146Direction indicators .......140, 165, 192, 19 6 -198Driving positions (memorising) .......................69Dynamic emergency braking ........................103Dynamic stability control (DSC) ..............3 0, 171
Backup switching off .....................................Backup switching off .....................................Backup switching off102Battery ..................................................205, 228Battery, charging ...........................................205
Eco-driving .....................................................20Eco-driving (advice) ........................................20Economical driving ........................................20Economy mode .............................................208Electronic engine immobiliser.................52, 102Electronic stability control (ESC) ..................169Emergency boot release .................................60Emergency call .....................................166, 250Emergency warning lamps .....................83, 165Energy economy mode .................................208
A
C
D
B
E
Courtesy lamps .............................................151Cruise control ........................................1 2 7, 1 3 0Cup holder .......................................................Cup holder .......................................................Cup holder77
Battery, remote control .............................50-52Blind ................................................................61Blue HDi ........................................................230Bluetooth (hands-free) ..........................2 7 7, 3 2 1Bluetooth (telephone) ....................................277Boot ...........................................................57- 5 9Boot (opening) .................................................46Brake discs ....................................................229Brake lamps ..........................................197, 198Brake pads ....................................................229Brakes ...........................................................229

338Alphabetical index
Filling with fuel ..........................................64, 66Fitting a wheel ...............................................188Fitting roof bars .............................................214Fittings, boot .............................................80, 81Flashing indicators ................................140, 16 5Foglamps ......................................................192Foglamps, rear ..............................................Foglamps, rear ..............................................Foglamps, rear13 8Folding the rear seats .....................................72Front foglamps ..............................138, 192, 195Front seats ................................................67- 6 9Fuel............................................................20, 66Fuel consumption ............................................20Fuel filler cap ...................................................64Fuel filler flap ...................................................64Fuel gauge ......................................................64Fuel tank..........................................................64Fusebox, dashboard .....................................201Fuses .............................................................201
Gear lever .......................................................Gear lever .......................................................Gear lever20Gear lever, automatic gearbox .....................113Gear lever, electronic gear control gearbox ....Gear lever, electronic gear control gearbox ....Gear lever, electronic gear control gearbox117Gear lever, manual gearbox .........................111Gear shift indicator .......................................Gear shift indicator .......................................Gear shift indicator112G . P. S . ............................................................262Guidance ..............................................260, 268Guide-me-home ............................................141
Halogen headlamps ..............................192, 193Hands-free kit .......................................2 7 7, 3 2 1Hazard warning lamps ............................83, 165Headlamp adjustment ...................................14 4Headlamps, directional .........................145, 192Headlamp wash ............................................148Headlamp wash reservoir .............................Headlamp wash reservoir .............................Headlamp wash reservoir227Head restraints, front ................................6 7, 7 0Head restraints, rear .......................................Head restraints, rear .......................................Head restraints, rear72Head-up display ............................125, 128, 13 0Heated seats .............................................6 7, 7 0Heating .........................................20, 88, 96, 99Height and reach adjustment, steering wheel ..............................................76High load retaining net ....................................84Hill start assist ...............................................124
Gearbox, automatic ..............................113 , 2 2 9Gearbox, electronic gear control ...117, 121, 2 29Gearbox, manual ...................111, 112, 121, 2 29
Identification plates .......................................247Indicator lamps, status ..............................25, 29Indicators, direction ......................................165Inflating accessories (using the kit) ..............179Inflating tyres ..................................................20Inputs for audio system .................................319
Labels, identification .....................................247Lamps, warning and indicator .......................warning and indicator .......................warning and indicator23, 27, 28Level, brake fluid ...........................................226Level, headlamp wash ..........................148, 2 27Level, power steering fluid ............................226
Jack .......................................................185, 18 6JACK socket ..................................................319JBL (audio system) ...................................7, 2 51
Instrument panel .............................................22Instrument panels ...........................................23Instrument panel screen .........................2 3 , 112Intelligent Traction Control ............................170Interior fittings .................................................77Interior mood lighting ....................................152ISOFIX ..........................................................161ISOFIX child seats ................................160 -162ISOFIX mountings.........................................160
Keeping children safe .....................153, 154, 157, 161, 162, 175Key ..........................................43 - 45, 47, 50, 52Key, electronic .....................................4 3 - 4 7, 5 0Keyless Entry and Starting .........44, 45, 52, 101Key with remote control ................................102
FH
G
IL
J
K
Engine compartment ............................221-224Engine compartment fusebox .......................201Engine, Diesel .........66, 219, 222-224, 238, 242Engine oil ......................................................225Engine oil level indicator .........................Engine oil level indicator .........................Engine oil level indicator3 7, 2 2 5Engine, petrol .........................66, 221, 235, 236Engines ................................................235, 238Environment ..............................................2 0 , 51ESC/ASR .......................................................169
