glove box Peugeot Expert VU 2016 Owner's Manual

108
Expert_en_Chap03_ergonomie-et-confort_ed01-2016
Lowering the seat cushion
F Remove the non-slip net.
F to r eposition the seat cushion, press firmly
at the top of the seat with one hand to
lower the seat cushion until it engages in
the seating position.
Non-slip net
Fitting the net
F Place the first fixing in the upper cut-out 1 ,
located on the folded cushion. th en turn it
a quarter turn clockwise to secure it.
F

P
lace the second fixing in the lower cut-
out
2, located on the seat support.
t
h
en
turn it a quarter turn clockwise to secure it. F

E
ngage the first hook on the ring 3
, located
in the open glove box.
F
E
ngage the second hook on the ring 4
,
located on the floor.
Removing the net
F Remove the hooks from the rings 4 and 3 .
F R emove the lower 2 then upper fixing 1 , by
turning them a quarter turn anti-clockwise
to release them.
Ease of use and comfort

120
Expert_en_Chap03_ergonomie-et-confort_ed01-2016
Front door pockets
Liquids carried in an open vessel (a cup
or mug) could be spilt, presenting a risk
of damage on contact with the controls
in the dashboard and centre console.
t
a k e c a r e .
Glove box
It houses the passenger front airbag
deactivation switch and can hold a water bottle,
the vehicle's handbook pack...
Storage compartment
It can hold a water bottle, the vehicle's
handbook pack...
F
t
o o
pen the storage compartment, press
the left hand end of the control and guide
the lid to its open position notch.
If it is so equipped, it is illuminated when the lid
is opened.
With air conditioning, it gives access
to the ventilation nozzle, delivering the
same air-conditioned air as the vents
in the passenger compartment.
While driving , keep the glove boxes
closed. ot herwise there is a risk of
injury in the event of an accident or
sudden braking.
Ease of use and comfort

171
Expert_en_Chap05_securite_ed01-2016
Front airbagsDeployment
the airbags are deployed, except the
passenger front airbag if it is deactivated, in
the event of a serious front impact to all or part
of the front impact zone A, in the longitudinal
centreline of the vehicle on a horizontal plane
and directed from the front to the rear of the
vehicle.
th

e front airbag inflates between the thorax
and head of the front occupant of the vehicle
and the steering wheel, driver's side, and the
dashboard, passenger side to cushion their
for ward movement.
System which protects the driver and
passenger(s) in the event of a serious front
impact in order to limit the risk of injury to the
head and thorax.
th

e driver's airbag is fitted in the centre of the
steering wheel; the front passenger airbag is
fitted in the dashboard above the glove box. When driving
, keep the glove box
closed.
o
t
herwise there is a risk of
injury in the event of an accident or
sudden braking.
5
Safety
