Page 171 of 320
Fireextinguisher
Takingoutreextinguisher
Incarswithafireextinguisher,theextinguisherisfittedtothefrontofthedriver’sseat.
1.HoldfireextinguisherwithonehandandpressthePRESSbuttononthefasteningstrapwiththeotherhand(arrow).
2.Removefireextinguisherfrommounting.
Insertingreextinguisher
1.Placefireextinguisherinthemounting.
2.EngagefasteningstraplugAinthetensionjackandclosetensionjack(arrow).
Note
Payattentiontothefinalcontroldateonthefireextinguisher.Ifthefireextinguisherisusedafteritsexpirationdatehaselapsed,itmaynotoperateproperly.
Followtheoperatinginstructionsonthefireextinguisher.
Thefunctionalabilityofthefireextinguishershouldbecheckedbyaspecialistworkshopevery1-2years.
Afteruse,havethefireextinguisherrefilled.
Controls,Instruments169
Page 172 of 320
Frontluggagecompartment
TrunkEntrapment
Yourvehicleisequippedwithaninternalfront/reartrunkreleasemechanism.
ApersontrappedintheluggagecompartmentcanreleasethelidfromtheinsideusingunlockinghandleA.ThehandleAisfluorescentandglowsinthedark.
Rearluggagecompartment
Warningmessage
Awarningmessageintheon-boardcomputerlightsupwhenunlockinghandleAisoperated.
Stopthevehicleimmediatelywhenthewarningmessagelightsup.
Checktheluggagecompartment.
Closethelid.
Frontluggagecompartmentlid
Functionwithvehiclestationary
IftheluggagecompartmentlidisunlockedwithunlockinghandleA,thelidcanbeopenedfromtheinsideimmediately.
Functionwithvehicleinmotion
IftheluggagecompartmentlidisunlockedwithunlockinghandleAwhenaspeedof2mph(3km/h)isexceeded,thewarningmessageintheon-boardcomputerlightsup.Atthesametime,thelidisunlockedandthelatchstrikerpopsintothecatch-hookposition.Thelidlockisfullyreleasedassoonasthecarslowstolessthan2mph(3km/h),andthetrappedpersoncanopenthelidimmediately.
Danger!
Riskofaccident.Ifthewarningmessageintheon-boardcomputerlightsupwhenthevehicleisinmotion,thelidmayimpactinfrontofthewindshieldandcantearoff.Youcanlosecontrolofthevehicle,andseriouspersonalinjuryordeathmayresult.
Stopthevehicleimmediatelywhenthewarningmessagelightsup.
Checktheluggagecompartment.
Closethelid.
170Controls,Instruments
Page 173 of 320
Rearluggagecompartmentlid
IftherearluggagecompartmentlidisunlockedwithunlockinghandleA,thelidopensimmediately.
Stopthevehicleimmediatelywhenthewarningmessagelightsup.
Checktheluggagecompartment.
Closethelid.
Note
Thefrontlidcannotbeopenedfromtheinsideifthebatteryisdisconnectedorempty.
Safetyreasonsthereforerequirethatyouunscrewthelatchstrikerofthefrontlidlockifyouplantoputthevehicleoutofoperationforanextendedperiod.
PleaseconsultyourauthorizedPorschedealer.Theywilladviseyouaboutthenecessarymeas-ures.
Note
Whenloadingtheluggagecompartment,makesurethatitemsofluggageorotherobjectscannotbecomecaughtonhandleA.Thiscouldcausetheluggagecompartmenttoopenunintentionally.
Controls,Instruments171
Page 174 of 320
A-OpeningfrontluggagecompartmentlidB-Openingrearluggagecompartmentlid
Luggagecompartmentlids
Unlocking
Operatetheappropriatepull-buttonnexttothedriver’sseat.Theluggagecompartmentisilluminatedwhentherespectivelidisopen.
Pleaseobservethechapter”LOADSWITCH-OFFAFTER2HOURSOR7DAYS”onpage265.
Theluggagecompartmentlidcanalsobeunlockedwiththeradioremotecontrol.
Pleaseobservethechapter”KEYWITHRADIOREMOTECONTROL”onpage23.
Note
Ifthevehiclebatteryisdischarged,thefrontluggagecompartmentlidcanbeopenedonlybyconnectinganexternalelectricalpowersource.
Pleaseobservethechapter”EMERGENCYUNLOCKINGOFTHEFRONTLUGGAGECOMPARTMENTLID”onpage266.
Pleaseobservethedescriptioninsidethefuseboxlid.
Warningmessage
Awarningmessageintheon-boardcomputercomesonifthelidsarenotcompletelyclosed.
Fullyclosethelid.Openingfrontluggagecompartmentlid
Caution!
Riskofdamagetoluggagecompartmentlidorwindshieldwipers.
Makesurethatthewindshieldwipersarenotfoldedoutforwardswhenopeningtheluggagecompartmentlid.
Raiselidslightlyandunlatchthesafetycatchwiththelever(arrow).
172Controls,Instruments
Page 175 of 320
Closingfrontandrearluggage
compartmentlid
Lowerthelidandcloseit.
Pushthelidclosedwiththepalmofyourhandintheareaofthelock.Checkthatthelidhascorrectlyengagedinthelock.
Warning!
Riskoflossofcontroloranaccident,resultinginseriouspersonalinjuryordeath.
Shouldyounoticeatanytimewhiledrivingthatoneofthelidsisnotsecuredproperly,pleasestopimmediatelyinasuitableplaceandcloseit.Thefrontlidmayflyupimpairingvision.
Controls,Instruments173
Page 176 of 320
FrontLuggageCompartment
Accesscovers
(onvehicleswithDVDnavigationorCDchanger)
Opening
GraspaccesscoverAorBatthehandleandopen.
ThedriveforDVDnavigationandtheCDchangercanbefoundbehindtheaccesscoverB.
Caution!
Riskofdamage.
Donotstoreanyheavy,damporheat-sensitiveobjectsbehindtheaccesscovers.
Toolbox
Opening
Unlockturn-locksC.
Opentoolboxandplaceitontheflooroftheluggagecompartment.
174Controls,Instruments
Page 177 of 320
E-AdapterforsecuritywheelboltsF-TirellingcompressorG-TowinghookH-ToolkitI-Leverforconvertibletopemergencyoperation(underthetoolkit)J-Tiresealant
Closing
Inserttoolboxintotheguidepegsintheluggagecompartmentfloor.
Closetoolboxandlocktheturn-locksC.
Controls,Instruments175
Page 178 of 320
A-ToppingupengineoilB-Checkcoolantlevel,topupifnecessary
RearLuggageCompartment
Therefillingpointsforengineoilandcoolantarelocatedbehindtheserviceflapintherearluggagecompartment.
Openingtheserviceap
Opentheflapbypullingthehandhold.
Pleaseobservethechapter”ENGINEOILLEVEL”onpage213.
Pleaseobservethechapter”COOLANTLEVEL”onpage210.
176Controls,Instruments
Page 179 of 320
PorscheCommunication
Management(PCM)
GeneralinformationtothePorsche
CommunicationManagement(PCM)
RefertotheseparateoperatinginstructionsbeforeputtingthePCMintooperation.
Pleaseobservethechapter”LOADSWITCH-OFFAFTER2HOURSOR7DAYS”onpage265.
Warning!
Thereisdangerofaccidentifyousetoroperatetheon-boardcomputer,radio,navigationsystem,telephoneorotherequipmentwhendriving.Thiscoulddistractyoufromtrafcandcauseyoutolosecontrolofthevehicleresultinginseriouspersonalinjuryordeath.
Operatethecomponentswhiledrivingonlyifthetrafficsituationallowsyoutodosafely.
Carryoutanycomplicatedoperatingorsettingproceduresonlywiththevehiclestationary.
ThereceptionconditionsfortheradiomoduleintegratedinthePCMchangecontinuouslyasyoudrive.Interferencefrombuildings,terrainandtheweatherisunavoidable.FMstereoreception
isparticularlysusceptibletovaryingreceptionconditions.
ElectronicaccessoriesshouldonlyberetrofittedbyyourauthorizedPorschedealer.
AccessorieswhichhavenotbeentestedandapprovedbyPorschemayimpairradiofunctionandreception.
Navigation
Whenputintooperationforthefirsttime,adistanceofapprox.31miles(50km)mustbedriveninorderforthenavigationsystemtocompletetheprocessoffinecalibration.Thesameapplieswhenthetiresarechanged(e.g.summer/snowtires)ornewtiresfitted.Fulllocationaccuracyisnotyetachievedduringthefine-calibrationprocess.
Ifthevehiclehasbeentransported(e.g.ferry,cartrain),thesystemmaytakeafewminutestodeterminethecurrentlocationafterithasbeenswitchedon.
Serioustireslip(e.g.spinningwheelsonsnow)mayresultintemporarilyinaccuratenavigation.
Whenthebatteryhasbeendisconnected,itmaytakeupto15minutesbeforethenavigationsystembecomesoperationalagain.
Controls,Instruments177
Page 180 of 320
CarAudioOperation/Tips
Generalinformation
Forradiooperationseeyourradiomanualwhichisincludedwithyouron-boardlitera-ture.
Pleaseobservethechapter”LOADSWITCH-OFFAFTER2HOURSOR7DAYS”onpage265.
FMreception
Avehicleisnotanidealplacetolistentoaradio.Becausethevehiclemoves,receptionconditionsareconstantlychanging.Buildings,terrain,signaldistanceandnoisefromothervehiclesareallworkingagainstgoodreception.SomeconditionsaffectingFMmayappeartobeproblemswhentheyarenot.
Thefollowingcharacteristicsarecompletelynormalforagivenreceptionarea,andtheydonotindicateanyproblemwiththeradioitself.
Note
ElectronicaccessoriesshouldonlybeinstalledbyyourauthorizedPorschedealer.EquipmentwhichhasnotbeentestedandapprovedbyPorschemayimpairradiofunctionandreception.
Fadinganddrifting
FMrangeislimitedtoabout25miles(40km),exceptforsomehighpowerstations.
Ifavehicleismovingawayfromthedesiredstation’stransmitter,thesignalwilltendtofadeand/ordrift.ThisconditionismoreprevalentwithFMthanAM,andisoftenaccompaniedbydistortion.Fadinganddriftingcanbeminimizedtoacertaindegreebycarefulattentiontofinetuningorselectionofastrongersignal.
Staticanduttering
Whentheline-of-sightlinkbetweenatransmitterandvehicleisblockedbylargebuildingsormoun-tains,theradiosoundmaybeaccompaniedwithstaticorflutteringbecauseofthecharacteristicofFM.Inasimilareffect,aflutteringnoiseissome-timesheardwhendrivingalongatree-linedroad.
Thisstaticandflutteringcanbereducedbyadjust-ingthetonecontrolforgreaterbassresponseuntilthedisturbancehaspassed.
Multipath
BecauseofthereflectingcharacteristicsofFM,directandreflectedsignalsmayreachtheantennaatthesametime(multipath)andcanceleachotherout.Asavehiclemovesthroughtheseelectronicdeadspots,thelistenermayhearamomentaryflutterorlossofreception.
Stationswapping
WhentwoFMstationsareclosetoeachother,andanelectronicdeadspot,suchasstaticormultipatharea,interruptstheoriginalsignal,sometimesthestrongersecondsignalwillbeselectedautomaticallyuntiltheoriginalonereturns.Thisswappingcanalsooccurasyoudriveawayfromtheselectedstationandapproachanotherstationofastrongersignal.
178Controls,Instruments
