PORSCHE CAYNNE 2011 2.G Information Manual

Child seats.
With their unique design, Porsche
child seats comply with the
latest safet y standards. Available
from Porsche Tequipment, they
have been specially tested and
approved for use in Porsche
vehicles, offering comfort and safet y for all passengers up to
12 years of age. All fabrics are
breathable, kind to the skin and
easy to clean. The covers can
be removed and are washable.
For added safet y, the Porsche
Baby and Porsche Junior Seat
ISOFIX come with their own five-point harness with central
adjustment of the seat-belt length.
All of the Cayenne models have
standard ISOFIX mounting
points on the outer rear seats.
These are available as an
option for the front passenger
seat. If a
child seat is mounted
The best seats in the house.
For everyone.
Rear bench in conjunction with comfor t seats
on the front passenger seat,
the corresponding airbag can
be quickly deactivated using a
key- operated switch. All Porsche
child seats can be easily installed
via the ISOFIX slot-in connectors.
Alternatively, they can be secured
using the three-point seat belts.
bag. It also features a folding
armrest. The process is quite
simple: unlock and fold down.
The rear seat backrest can be
adjusted by up to 6 degrees:
3 degrees forward of
the starting
position and 3 degrees back.
When it comes to being user-
friendly, the Cayenne models get
right to the point – quick and
e as y.
Rear seats.
The rear bench of fers generous
space for up to three adult
passengers and is st yled to match
the front comfort or sports seats.
For added practicalit y, the bench
features fore/af t adjustment of
160 mm and a 40/20/40 split-
folding facilit y. The flexible centre
section folds down to create a
load-through facilit y for longer
items such as the optional ski
Comfort and transport | Comfort · 85
84 · Comfort and transport | Comfor t

system, a storage compartment in
the centre console and a handy
drawer beneath both the driver’s
and front passenger’s seat.
Interior lighting.
The interior lighting concept
with delayed- of f function is
well thought-out to provide the
required level of light whenever you need it. The generous stand-
ard equipment includes dimmable
door handle illumination, foot well
illumination front and rear, ignition
lock illumination, a front light
console with reading lights as well
as reading lights at the rear. This
is complemented by door entry
lights, front and rear, and red
door safet y lights. In addition,
all Cayenne models come with
luggage compartment illumination
and a tailgate courtesy-light
function.
Porsche Rear Seat
Entertainment.
Available as a factory-fit ted option
from Porsche Exclusive, the
Porsche Rear Seat Entertainment
package includes t wo display
consoles, each with an integrated
media player and USB port, and
t wo wireless infrared headphones.
Storage compartments.
Ef ficiency also means having the
important things at your fingertips
when you need them. Which is
why the Cayenne models of fer
a wide range of storage options.
These include door storage com-
partments with bot tle holders,
storage pockets on the front seat
backrests, a glove compartment
cooled by the air- conditioning
The perfect place to be.
Not just for the driver.
The display consoles are trimmed
in matching interior leather with
decorative seams and are located
on the front seat backrests. Each
one contains a high -resolution
7-inch W VGA TFT colour display.
For greater convenience, they
are swivel-mounted and feature
touchscreen operation. Boasting
built-in anti-shock protection, the
system is compatible with CDs
and DVDs and can even receive
T V broadcasts – in conjunction
with the optional T V tuner. It is also possible to connect t wo
separate and individually select-
able AV sources, such as a games
console or digital camera.
Designed to the highest standards
of safet y and ergonomics,
Porsche Rear Seat Entertainment
blends harmoniously within the
passenger compartment.
Optional for all Cayenne
models.
Door storage compartment with bot tle holder Porsche Rear Seat Entertainment
Cupholders in centre console
86 · Comfort and transport | Comfor tComfort and transport | Comfort · 87

Porsche Communication
Management (PCM) with
navigation module.
PCM is the central control system
for all information and commu-
nication functions. It is powerful
and versatile, yet easy to use.
Key features include a 7-inch high-
resolution touchscreen display.
As before, you can also operate
PCM using the rotary push -but ton
control. The menu layout is ex-
tremely clear, with no more than
five entries per page enabling
fast and accurate operation. A
help function is displayed at the
bot tom of the screen for further
guidance in specific situations.
Radio functions comprise
42 presets, an FM t win -tuner
with RDS frequency diversit y, which continuously searches the
airwaves for the best possible
signal from the selected radio
station, and dynamic autostore.
The CD/ DVD drive plays CDs
and audio DVDs and is MP3-
compatible. Audio playback of
video DVDs is also supported.

An optional integrated six- disc
CD/ DVD autochanger is available
for PCM. A navigation module with high-
speed hard drive is included
with PCM. The map display of fers
a conventional 2D layout as well
as a perspective view. In some
regions, even topography with
superimposed satellite map and
buildings can be displayed in 3D.
In split-screen mode, you can view
the current map section together
with a list of icons for the next
manoeuvre.
The CDR-31 can also be com-
bined with the optional BOSE
®
Surround Sound System (p. 92)
or Burmester
® High-End Surround
Sound System (p. 94) for the
ultimate in audio performance.
Other options available in
conjunction with the CDR-31
include an integrated six- disc
CD autochanger.
With an optional mobile phone
preparation (p. 90), you can
connect a Bluetooth
® Hands- Free
Profile (HFP) - compatible mobile
phone.
CDR-31 audio system.
A Porsche engine provides an
impressive sound experience
in its own right. The Cayenne
models offer the perfect accom-
paniment inside the cockpit.
The CDR-31 audio system has a
7-inch colour touchscreen display
which enables you to navigate
and select the main menus and
functions with ease and efficiency.
The integrated CD radio, featuring
an FM twin-tuner with RDS,
30 memor y presets, dynamic
autostore and speed-sensitive
volume control, includes a sound
system with 10 loudspeakers
and a total audio output of
10 0 w a t t s .
Standard on the Cayenne,
Cayenne Diesel, Cayenne S
and Cayenne S Hybrid.
The key to success in management:
focused performance with slices of delight.
The system also indicates the
respective speed limit for the
roads covered in the database
via PCM or the TFT display in
the instrument cluster.
Standard on the Cayenne Turbo.
Optional for all other Cayenne
models.
Porsche Communication Management (PCM) with navigation module
Comfort and transport | Comfort · 89
88 · Comfort and transport | Comfor t

via the CDR-31 or PCM head
unit. Connection to the mobile
phone net work is via the handset
antenna.Optional for all Cayenne
models.
Telephone module.
This optional quad-band GSM
telephone module combines ease
of use with optimised sound
qualit y. Simply insert your mobile
phone SIM card in the slot in
PCM to make calls via the hands-
free facilit y or optional Bluetooth
®
handset. For even greater conveni-
ence, you can use a Bluetooth®
SIM Access Profile (SAP) -
compa tible handset. Once
The sof t ware complies with the
statutory requirements for auto -
matic logbooks as specified by
the German revenue authorities.Optional for all Cayenne
models.
Mobile phone preparation.
With this optional preparation,
you can establish a Bluetooth
®
connection with a mobile phone
that only supports the Hands- Free
Profile (HFP) and use the CDR-31
audio system or PCM as a hands-
free system. As a Bluetooth
®-
based solution, you can connect
your handset without even taking
it out of your pocket. The basic
phone functions are accessible
Voice control.
Do you wish to get to the point –
or your required destination –
more quickly? All you have to
do is say so. The optional voice
control system with whole-word
recognition is at your command
– without the tedious task of
voice learning. Audio prompts
make voice inputs even simpler.
You can also browse through
lists by voice command.
Optional for all Cayenne
models.
Electronic logbook.
This optional addition to PCM
enables you to automatically
record on every journey the
mileage, route distance, date and
time as well as starting location
and destination. Data can be
downloaded from PCM via
Bluetooth
® or a USB port and
processed on a PC using soft-
ware included with the package. connected, the GSM antenna on
the mobile phone is disabled to
prolong bat tery life and the ex-
ternal
vehicle antenna is utilised
instead.
Depending on the phone
model, you can access contact
details on the mobile phone SIM
card and internal memory and
perform all operations via PCM,
voice control
or the multifunction
steering
wheel, which means
your phone can remain in your
pocket.
In addition, the telephone
module enables you to establish
a Bluetooth
® connection to a
mobile phone that only supports
the Hands- Free Profile (HFP). In
this case, the GSM connection
to the mobile phone net work is
via the handset antenna. PCM
acts as a hands-free system.
A cordless handset with keypad
and display is also available
as an option. This is stowed in
the centre console. However,
the handset cannot be used to
establish a Bluetooth® connection
using the Hands- Free Profile
(HFP).
Optional for all Cayenne
models.
Universal audio interface.
On vehicles with the CDR-31
audio system, this optional
package located in the front
centre console provides an AUX-
In port, e.g. for a compatible
MP3 player. On vehicles equipped
with PCM, the package includes
an AUX- In port and a USB port
which can be used to connect
an iPod
®. The iPod® as well as
other compatible MP3 players
or memory sticks connected
via USB can be operated using
PCM. For more information,
please consult your Porsche
Centre.
Optional for all Cayenne
models.
TV tuner.
The optional T V tuner receives
unencrypted analogue and digital
television signals. For your safet y,
these can only be viewed via
the PCM display when the vehicle
is stationary. In conjunction
with the Porsche Rear Seat
Enter tainment package, T V
broadcasts can be received on
the rear screens while the car
is in motion.Optional for all Cayenne
models.
Universal audio inter face
Electronic logbook
90 · Comfort and transport | Comfor t Comfort and transport | Comfor t · 91

Specially custom-engineered
for the Cayenne models, the
system features a total of
14 loudspeakers (including active
subwoofer and centre-fill speaker)
that combine with a 585-wat t
9-channel amplifier to produce
a powerful sound experience.
In combination with Porsche
Communication Management
(PCM), the BOSE
® Surround
Sound System enables playback
of audio DVDs, making full use
of the impressive sound spectrum
of 5.1 digital recordings. Of
course, you can still play other
audio sources such as CDs and MP3s. In stereo or, at the push
of a but ton, in one of the virtual
surround modes generated by
BOSE® Centerpoint® 2 technology.
The BOSE®- patented AudioPilot®
noise compensation technology
uses a microphone in the cockpit
to monitor ambient sound. The
system is then able to provide
real-time adjustment of all audio
output – for a more consistent
aural experience. Standard on the Cayenne Turbo.
Optional for all other Cayenne
models.
compatible with both Porsche
Communication Management
(PCM) and the CDR-31 audio
system.
BOSE® Surround Sound System.
Providing a compelling 360 -
degree soundstage, the BOSE
®
Surround Sound System is
Where does a 360-degree sound experience get you?
Back to the point.
Porsche Communication Management (PCM) with CD/ DVD autochanger BOSE® loudspeaker
Comfort and transport | Comfor t · 93
92 · Comfort and transport | Comfor t

option for all Cayenne models
with CDR-31 and PCM.
The technologies behind the
system meet the same exacting
standards as those in the com-
pany’s high - end home audio
products. State-of-the-art and
featured like this in a Porsche for the first time. The extravagance
is uncompromising, the crafts-
manship excellent, the sound
phenomenal. The system owes
its eminence to countless
details, and one overriding goal:
perfection in sound.
In figures: 16 - channel amplifier
with a total output of more than
1,000 wat ts, 16 loudspeakers
(including active subwoofer with
300 -wat t Class D amplifier), a
total diaphragm area of more than
2,400 cm
2, and a frequency range
of 30 Hz to 20 kHz. Crossover technology has been
carried over virtually unmodified
from the company’s high - end
home audio systems. Analogue
and digital filters have been
optimally defined for their new
location and finely tuned af ter
extensive in-car audio testing.
The t weeters are ribbon -based
air motion transformers (AMT)
of fering unmistakably fine, clear
and undistorted high -frequency
sound reproduction with excellent
level stabilit y.
qualities. Once you’ve heard it
for yourself, you’ll know we are
not exaggerating. Based in
Berlin, Burmester® is one of the
most respected premium audio
manufacturers worldwide. The
Burmester
® High - End Surround
Sound System is available as an
Burmester® High-End
Surround Sound System.
The Cayenne models are
marked by exceptional versatilit y.
With the optional High-End
Surround Sound System from
Burmester
® it could even be
said that they of fer concert-hall
This is one standing ovation you’ll have to give sitting down.
Furthermore, the elegant, purist
design with galvanised surrounds
and Burmester
® logos on select-
ed loudspeakers makes it clear
that the appeal of the Burmester
®
High - End Surround Sound System
is as much about the visual as it is
the audio.
Optional for all Cayenne
models.
Burmester® loudspeaker
94 · Comfort and transport | Comfor t Comfort and transport | Comfor t · 95
Optimised sound distribution in the Cayenne (schematic representation)

for the rear cabin area, with sep-
arate temperature controls for lef t
and right. The rear climate control
set tings can also be adjusted
from the front seats.Optional for the Cayenne,
Cayenne Diesel, Cayenne S
and Cayenne Turbo.
Water-repellent side windows.
The front side windows on the
Cayenne models have a water-
repellent finish that automatically
disperses moisture and dirt.
The result: optimum visibilit y,
even in poor weather conditions.
(Note: surface finish may require
occasional renewal.)
Privacy glass.
Available as an option, dark-tinted
glass provides privacy for the
rear seat and luggage area.Optional for all Cayenne
models.
Heated windscreen.
For added comfort and practi-
calit y, the heated windscreen
ensures optimum visibilit y on
cold days.Optional for all Cayenne
models.
Heat and noise-insulating glass.
All Cayenne models are equipped
as standard with heat-insulating
tinted glass featuring a grey top
tint on the windscreen. As an
optional alternative, heat and
noise-insulating laminated glass
of fers additional protection
against infrared radiation. Enjoy
peace and quiet, and an even
more pleasant climate, in the
passenger compartment.
The heat and noise-insulating
glass option also includes privacy
glass at the rear.Optional for all Cayenne
models.
sensor. Other features include
an active carbon filter,
which
excludes dust, pollen and external
odours.
Four-zone climate control.
Four-zone climate control pro -
vides independent air conditioning
Climate control.
All Cayenne models are equipped
with climate control as standard.
This system provides independent
control of the temperature and air
flow volume for driver and front
passenger as well as an auto -
matic air recirculation function
with an air qualit y and
humidity
As a child, you went out whatever the weather.
Nothing has changed.
Cayenne S Hybrid with privacy glass
Four-zone climate control for rear seat area
Comfort and transport | Comfort
· 97
96 · Comfort and transport | Comfor t

Porsche Entry & Drive.
With Porsche Entry & Drive, you
can avoid the inconvenience of
using a conventional key.
To enter the car, simply touch the
door handle and the system auto -
matically checks the encrypted
access code on the key in your
pocket. If the code is accepted,
the doors are unlocked and
you can step inside. To start or
stop the engine, simply push
the ignition but ton.When you leave the car, all you
have to do is press a but ton on
the outside of the door handle.
Porsche Entry & Drive then locks
the car, arms the immobiliser
and locks the steering column.
Optional for all Cayenne
models.
Anti-theft protection.
The Cayenne models are all
equipped as standard with an
engine immobiliser and anti-thef t
alarm featuring ultrasonic interior
surveillance.
The alarm circuit includes all four
doors, engine lid, tailgate, rear
screen, interior, ignition and trailer
(if fitted).
Rain sensor.
The front wiper system has t wo
fixed speeds and an automatic
rain sensor function.
Washer fluid is delivered via t wo
heated jets, ensuring uniform
coverage of the entire windscreen
area.
The rear wiper system is designed
for maximum visibilit y in all
conditions.
Sunscreen.
To protect the interior against
direct sunlight, an electrically
operated sunscreen for the rear
side windows is available as an
option. It can also be controlled
from the driver’s seat.
Optional for all Cayenne
models.
Inconspicuous. Unobtrusive. Indispensable.
The immobiliser system works
by automatically communicating
with the vehicle key. If the key
is approved, the engine can be
started as normal.
When the key is removed from the
ignition, the steering column is
automatically locked to provide
additional securit y.
Preparation for Porsche Vehicle
Tracking System (PVTS).
This preparation enables future
installation of the Porsche Vehicle
Tracking System (PV TS) obtain-
able from Porsche Tequipment.
PV TS can be used to locate a
stolen vehicle in 25 EU countries
as well as Norway, Switzerland
and Russia – irrespective of where
you live. The vehicle is not tracked con-
tinually, only when the alarm is
triggered. In the event of vehicle
thef t or manipulation, or if the
loss of the vehicle is reported by
the owner, a silent alarm is auto -
matically triggered. The package
includes a special wiring loom,
higher capacit y bat tery (depend-
ing on vehicle specification) and
tilt sensor for the alarm system.
Optional for all Cayenne
models.Rain sensor
Sunscreen
Comfort and transport | Comfort · 99
98 · Comfort and transport | Comfor t Porsche Vehicle Tracking System (PV TS) uses GPS technology in the event of an alarm

Panoramic roof system
Electric slide/tilt sunroof
in every t ype of weather. The
forward segment can be fully
opened or tilted upwards. An
additional sunscreen protects
the interior against direct sunlight.
Optional for all Cayenne
models.
Panoramic roof system.
With a total surface area of
approxi mately 1.4 square metres,
the panoramic roof system is
almost four times as large as the
optional slide/tilt sunroof. It
consists of t wo glass segments.
Even when closed, it provides
a unique ‘open-top’ driving experi-
ence. The panoramic view can
be enjoyed from all seat positions
Electric slide/tilt sunroof.
The electric slide/tilt sunroof
is made from tinted single-pane
safet y glass and features a
manually adjustable sunscreen
and remote closing function. It is
operated using a control located
on the roof console. As with all
electric windows, an anti-jam
facilit y is included – for added
safety.Optional for all Cayenne
models.
Explore the world.
In every direction.
Comfort and transport | Comfort · 101
100 · Comfort and transport | Comfor t

Optional for all Cayenne
models.
Comfort lighting package.
Available as an option for all
Cayenne models, this package
includes dimmable ambient light-
ing in the door panels and roof
console, practical LED reading
lights for the rear passengers,
additional courtesy lights on the exterior mirrors on the driver’s
and front passenger’s side, and a
second 12-volt socket in the rear
centre console.

Optional for all Cayenne
models.
Automatically dimming mirrors.
Another comfort- oriented feature:
automatically dimming exterior
and interior mirrors.
Standard on the Cayenne Turbo.
Optional for all other Cayenne
models.
Cruise control.
Cruise control automatically
regulates the speed of your
vehicle for added driver comfort
on longer journeys. It can be
used at speeds bet ween 30 and
240 km/ h (19 and 149 mph)
and is operated using a but ton
on one of the control stalks. Standard on all Cayenne
models.
Reversing camera.
The reversing camera (only avail-
able in conjunction with PCM)
facilitates reverse parking and
manoeuvring and also assists with
hitching a trailer. Help is provided
in the form of a high - contrast
colour image with dynamic guide-
lines on the PCM screen, which
show the predicted course of
the vehicle based on the current
position of the steering wheel.
Park Assis t.
This parking aid uses an acoustic
signal and front /rear displays to
alert the driver of any obstacles
at the front or rear of the car. Its
sensors are neatly concealed in
the front and rear aprons. The
acoustic signal is supplemented
by a visual warning in the centre
console display which provides
a graphical representation of the
vehicle’s proximit y to obstacles.Standard on the Cayenne Turbo.
Optional for all other Cayenne
models.
Seeing and being seen.
It’s all about having the right technology.
Driver assistance systems.
Reversing camera
Reversing camera display in PCM
Comfor t lighting package
Comfort and transport | Driver assistance systems · 103
102 · Comfort and transport | Driver assistance systems
