PORSCHE CAYNNE S 2006 1.G Owners Manual

Controls, Safety, Instruments
181
A- Front display – left monitoring area
B- Front display – right monitoring areaWarning indicators, signal tones, distances
The warning indicator for the front area is located
on the dashboard.
The warning indicator for the rear area is located
in the rooflining at the rear of the loadspace.
The warning indicators for the various monitoring
areas (left and right) are subdivided respectively
into one green, 4 yellow and 2 red light segments.
C- Rear display – right monitoring area
D- Rear display – left monitoring areaIf ParkAssist is activated, the green light seg-
ments of the active warning indicators are lit up
continuously.
If the vehicle approaches an obstacle that has
been detected by the sensors, one or more of the
yellow or red light segments lights up, depending
on the distance to the obstacle.If the first yellow light segment lights up, the ob-
stacle is still 48 in. (120 cm) (to the front) or 48 in.
to 59 in. (120 to 150 cm) (to the rear) away.
A brief signal tone sounds when reversing.
An intermittent tone sounds when the distance
becomes less than approx. 24 in. (60 cm). The
fourth yellow light segment lights up.
A continuous tone sounds when the distance be-
comes less than approx. 10 in. (25 cm) (on vehi-
cles with trailer coupling: approx. 14 in. (35 cm)).
The second red light segment lights up.
If the obstacle is approached even closer, the sys-
tem may not be able to recognize the obstacle any
longer.
fSet the radio volume so that the signal tones
are not drowned out.
You can have the volume of the signal tones ad-
justed to your own requirements at your author-
ized Porsche dealer.
Note on operation
If the obstacle is approached even closer after the
continuous tone sounds and the second red light
segment lights up, the system may not be able to
recognize the obstacle any longer.

182
Controls, Safety, Instruments Limits of ultrasonic measurement
– ParkAssist cannot detect sound-absorbing ob-
stacles (e.g. powder snow),
– Sound-reflecting obstacles (e.g. glass surfac-
es, flat painted surfaces),
– And very thin obstacles.
Other ultrasound sources (e.g. pneumatic brakes
of other vehicles, jackhammers) can interfere with
detection of obstacles.
Fault indication without warning tone
All red light segments of the active warning indica-
tors light up when there is a temporary fault in
ParkAssist.
Note
Correct operation is no longer ensured if there is
a temporary fault (e.g. caused by ice formation or
heavy soiling on the sensors).
The system detects the temporary fault.
All light segments light up until a speed of
9mph (14km/h) is reached.
ParkAssist is ready for operation again when the
interference has been eliminated.Fault indication with warning tone
In the event of a long-lasting fault in ParkAssist,
the red light segments of the active warning indi-
cators light up and a continuous tone sounds for
three seconds after a transmission range has
been selected.
Possible causes
– Defect or system fault.
fSwitch ParkAssist off.
When ParkAssist is switched off, the indicator
light in the button lights up.
fPlease have the fault remedied at an author-
ized Porsche dealer.Driving with a trailer
The ParkAssist rear monitoring area is switched
off when the trailer’s power supply is plugged in.

Controls, Safety, Instruments
183
A-Control switch for door mirror adjustment
C- Passenger mirror settingSwivelling down mirror glass as parking
aidWhen reverse gear is engaged, the mirror glass
on the passenger's side swivels down slightly to
show the curb area.
fPlease observe the chapter “MIRRORS” on
Page 121.Preconditions
– Vehicle must be equipped with seat memory.
–Control switch A must be turned to position C
(passenger mirror’s setting).
– Reverse gear must be engaged.
Moving mirror to its initial position
The mirror glass swivels to its initial position when:
– The car is shifted out of reverse gear or
– The position of the control switch for the door
mirror setting is changed.

184
Controls, Safety, Instruments
A- Programable keypad
B- Light-emitting diode for status identificationGarage Door OpenerThe programable garage door opener in your
Porsche replaces up to three original hand-held
transmitters used to operate a variety of devices
(e.g. garage door, gate to the property, alarm
system).
You have the option of programming each individ-
ual key in key pad A with an original hand-held
transmitter frequency.
Warning!
Risk of accident when using the garage door
opener if persons, animals or objects are
within the range of movement of the equip-
ment that is being operated.
fWhen using the garage door opener, ensure
that no persons, animals or objects are within
the range of movement of the equipment that
is being operated.
fObserve the safety notes for the original hand-held transmitter.
To operate the device in question
(e.g. garage door, gate to the property,
alarm system):
fPress the relevant button in keypad A.
Light-emitting diode B lights up during the
signal transfer.Notes on operation
fAlways use the garage door opener in the di-
rection of travel.
Otherwise, range restrictions cannot be ruled
out.
fBefore selling the vehicle, delete the pro-
gramed signals in keypad A of the garage door
opener.
fPlease read the instructions for the original
hand-held transmitter to find out whether the
original transmitter is equipped with fixed or
changeable code.

Controls, Safety, Instruments
185
Allocating garage door opener signals to
the keysfPlease follow the operating instructions for the
original hand-held transmitter.
Before programming the keypad the first
time with garage door opener signals
This process deletes the standard codes set at
the factory. Do not repeat the process if you
program further buttons.
fKeep the two outer buttons of keypad A
depressed for approx. 20 seconds until light-
emitting diode B begins to flash.Garage door opener with fixed code system
1. Point the original transmitter at the position
marked.
2. Press the button of the original hand-held
transmitter and at the same time the button to
be allocated on keypad A.
3. Keep both buttons depressed until light-emit-
ting diode B starts to flash (first slowly and
then quickly).
Only release both keys when light-emitting
diode B flashes quickly.
The rapidly flashing light-emitting diode B
confirms that the new frequency signal was
programed successfully.
4. Repeat steps 1 to 3 to allocate signals for the
garage door opener to other keys. Garage door opener with changeable code
system
1. Allocate the required keys as for the systems
with fixed code (points 1 to 4).
2. To synchronise the system:
Press the programming button on the receiver
for the garage door actuator.
Afterwards, you usually have approx.
30 seconds to initiate step 3.
3. Press allocated button in keypad A twice
(in some devices you must press the allocated
button a third time to complete the setting).
4. Repeat the programming steps to allocate sig-
nals for the garage door opener to other but-
tons.
Note
fPlease consult your authorized Porsche dealer
if you have not been able to successfully allo-
c a t e s i g n a l s f o r t h e g a r a g e d o o r o p e n e r t o t h e
keys even though you have carefully followed
the instructions in this chapter and the operat-
ing instructions for the original hand-held trans-
mitter.

186
Controls, Safety, Instruments Reprogramming an individual button of
keypad A
1. Press the button of keypad A to be repro-
gramed. Do not release the buttons before
step 4 is executed.
2. When the light-emitting diode B flashes slowly
(after approximately 20 seconds), point the
original transmitter at the position marked.
3. Press the button of the original hand-held
transmitter and keep it depressed.
4. The light-emitting diode B first flashes slowly
and then more quickly.
Only release both buttons when light-emitting
diode B flashes quickly.
Deleting programed signals
(e.g., when selling the vehicle)
fKeep the two outer buttons of key pad A
pressed for approx. 20 seconds until light-
emitting diode B begins to flash.
All programed signals are deleted.

Controls, Safety, Instruments
187
Ashtray
Warning!
Danger of fire.
fNever use ashtray for waste paper disposal, as it could pose a fire hazard.
Ashtray, frontOpeningfPress ashtray lid briefly.EmptyingfMove unlocking button A to the right; the
ashtray insert pops out.
fOnce you have emptied the ashtray, replace
the insert and push it down until it clicks
audibly into place.
Ashtray, rearDepending on how the vehicle is equipped, an
ashtray can be installed in the rear door panels.OpeningfPress ashtray lid briefly.EmptyingfOpen ashtray cover and press carefully to the
door trim panel.
The insert is raised slightly.
fRemove and empty insert.

188
Controls, Safety, Instruments
Cigarette Lighter
Warning!
Danger of fire and burning. The cigarette
lighter is ready for use, regardless of the ig-
nition lock position.
fDo not leave children in the car unattended.
fNever touch the heating element or sides of
the lighter.
fHold the lighter by the knob only.
The cigarette lighter is ready for use regardless of
the ignition lock position.
Lighter, frontfPress ashtray lid briefly. Ashtray opens inde-
pendently.
fPress lighter into the receptacle (arrow). When
the element is red hot the lighter jumps back
to its initial position.
Lighter, rearfPress cover in the center console briefly. Cov-
er opens independently.
fPress lighter into the receptacle (arrow). When
the element is red hot the lighter jumps back
to its initial position.

Controls, Safety, Instruments
189
Car Audio Operation/TipsFor radio operation see your radio manual
which is included with your on-board litera-
ture.FM receptionA vehicle is not an ideal place to listen to a radio.
Because the vehicle moves, reception conditions
are constantly changing.
Buildings, terrain, signal distance and noise from
other vehicles are all working against good recep-
tion.
Some conditions affecting FM may appear to be
problems when they are not.
The following characteristics are completely nor-
mal for a given reception area, and they do not in-
dicate any problem with the radio itself.
Note
Electronic accessories should only be installed by
your authorized Porsche dealer.
Equipment which has not been tested and ap-
proved by Porsche may impair radio reception.Fading and drifting
FM range is limited to about 25 miles (40 km), ex-
cept for some high power stations.
If a vehicle is moving away from the desired sta-
tion's transmitter, the signal will tend to fade and/
or drift. This condition is more prevalent with FM
than AM, and is often accompanied by distortion.
Fading and drifting can be minimized to a certain
degree by careful attention to fine tuning or selec-
tion of a stronger signal.
Static and fluttering
When the line-of-sight link between a transmitter
and vehicle is blocked by large buildings or moun-
tains, the radio sound may be accompanied with
static or fluttering because of the characteristic of
FM.
In a similar effect, a fluttering noise is sometimes
heard when driving along a tree-lined road.
This static and fluttering can be reduced by adjust-
ing the tone control for greater bass response un-
til the disturbance has passed.Multipath
Because of the reflecting characteristics of FM, di-
rect and reflected signals may reach the antenna
at the same time (multipath) and cancel each other
out.
As a vehicle moves through these electronic dead
spots, the listener may hear a momentary flutter
or loss of reception.
Station swapping
When two FM stations are close to each other, and
an electronic dead spot, such as static or multip-
ath area, interrupts the original signal, sometimes
the stronger second signal will be selected auto-
matically until the original one returns.
This swapping can also occur as you drive away
from the selected station and approach another
station of a stronger signal.

190
Controls, Safety, Instruments
Compact disc player
Caution!
To avoid damage to compact disc player and
discs.
fUse only compact discs labeled as shown, hav-
ing no dirt, damage or warpage.
fNever attempt to disassemble or oil any part
of the player unit. Do not insert any object oth-
er than a disc into the slot.Remember there are
no user-serviceable parts inside the compact
disc player.
fDo not allow the disc to sustain any finger-
prints, scrapes or stickers on the surfaces.
This may cause poor sound quality.
Hold the disc only on the edge or center hole.
fWhen not in use, take the disc out of the player,
put the disc back into its case and store it
away from dust, heat, damp and direct sun-
light.
Leaving the disc on the dashboard in the sun
can damage the disc.fIf the disc gets dirty, clean the disc by wiping
the surfaces from the center to the outside in
a radial direction with a soft cloth.
Do not use a conventional record cleaner or
anti-static record preservative.
Disc cleaners are available in audio stores.
Car Telephone and Aftermarket Alarms Important legal and safety information re-
garding the use of cellular telephones
Some states may prohibit the use of cellular tele-
phones while driving a vehicle. Check the laws and
regulations on the use of cellular telephones in the
areas where you drive.
Danger!
Risk of an accident.
Severe personal injury or death can result in
the event of an accident.
Looking away from the road or turning your
attention away from your driving can cause
an accident and serious personal injury or
death.
When using your cellular telephone, you should al-
ways:
fGive full attention to your driving - pull off the
road and park before making or answering a
call if traffic conditions so require; andfKeep both hands on the steering wheel - use
hands-free operation (if available) - pull off the
road and park before using a hand-held tele-
phone.
It is essential to observe the instructions of
the telephone manufacturer before putting
the telephone into operation.
Any portable telephone or radio transmitter which
is used in a Porsche must be properly installed in
accordance with the technical requirements of
Porsche.
The transmission power must not exceed
10 W.
The devices must possess a type approval for
your vehicle and have an “e“ symbol.
If you should require equipment with transmission
power values greater than 10 W, please consult
your authorized Porsche dealer for this purpose.
He is familiar with the technical requirements for
installing devices of this kind.
The antennas for all radios and telephones with a
transmitting antenna must be externally mounted.
The improper installation of radios or telephones
or use of a radio or telephone with a transmitting
antenna inside the car may cause the warning
lights to come on.
Improper installation of such equipment can cre-
ate a discharged battery or excessive current
draw from added equipment.
