STARTING AND OPERATING
STARTING THE ENGINE
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belt.
The starter should not be operated for more than 10-second
intervals. Waiting a few seconds between such intervals will
protect the starter from overheating.
WARNING!
• When leaving the vehicle, always make sure the keyless ignition node is in the "OFF" mode, remove the
key fob from the vehicle and lock the vehicle.
• Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a
vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or fatally
injured. Children should be warned not to touch the
parking brake, brake pedal or the gear selector.
• Do not leave the key fob in or near the vehicle, or in alocation accessible to children, and do not leave the
ignition of a vehicle equipped with Keyless
Enter-N-Go in the ACC or ON/RUN mode. A child
could operate power windows, other controls, or move
the vehicle.
• Do not leave children or animals inside parked vehicles in hot weather. Interior heat build-up may cause
serious injury or death.
WARNING! (Continued)
2020_DT_1500_OM_US.book Page 290

STARTING AND OPERATING 291
Automatic Transmission
Start the engine with the transmission in PARK position.
Apply the brake before shifting into any driving range.
NOTE:
• This vehicle is equipped with a transmission shift inter-
locking system. The brake pedal must be pressed to shift
out of PARK.
• If equipped with an 8-speed transmission, starting the vehicle in NEUTRAL is not possible unless the Manual
Park Release has been activated. For the Manual Park
Release operation refer to Manual Park Release in “In Case
Of Emergency”.
Tip Start Feature
Do not press the accelerator. Cycle the ignition switch briefly
to the START position and release it. The starter motor will
continue to run and will automatically disengage when the
engine is running.
Keyless Enter-N-Go — Ignition
Keyless Push Button Ignition
This feature allows the driver to operate the ignition switch
with the push of a button, as long as the Remote Start/
Keyless Enter-N-Go key fob is in the passenger compart -
ment.
5
2020_DT_1500_OM_US.book Page 291

294 STARTING AND OPERATING
If the vehicle is not in PARK and the driver turns off the
engine, the vehicle may AutoPark.
AutoPark will engage when all of these conditions are met:
• Vehicle is equipped with a rotary shifter and an 8-speedtransmission
• Vehicle is not in PARK
• Vehicle Speed is 1.2 mph (1.9 km/h) or less
• Ignition switched from RUN to ACC
NOTE:
For Keyless Enter-N-Go equipped vehicles, The engine will
turn off and the ignition switch will change to ACC mode.
After 30 minutes the ignition switches to OFF automatically,
unless the driver turns the ignition switch OFF.
If the vehicle is not in PARK and the driver exits the
vehicle with the engine running, the vehicle may Auto -
Park.
AutoPark will engage when all of these conditions are met:
• Vehicle is equipped with a rotary shifter and an 8-speed transmission
• Vehicle is not in PARK
• Vehicle speed is 1.2 mph (1.9 km/h) or less
• Driver’s seat belt is unbuckled • Driver’s door is ajar
• Brake Pedal is not depressed
The MESSAGE “
AutoPark Engaged Shift to P then Shift to
Gear ” will display in the instrument cluster.
NOTE:
In some cases the ParkSense graphic will be displayed in the
instrument cluster, causing the “ AutoPark Engaged Shift to
P then Shift to Gear ” to not be seen. In these cases, the shifter
must be returned to “P” to select desired gear.
If the driver shifts into PARK while moving, the vehicle
may AutoPark.
AutoPark will engage ONLYwhen vehicle speed is 1.2 MPH
(1.9 km/h) or less.
The MESSAGE “ Vehicle Speed is Too High to Shift to
P ”will be displayed in the instrument cluster if vehicle speed
is above 1.2 mph (1.9 km/h).
WARNING!

If vehicle speed is above 1.2 mph (1.9 km/h), the transmission will default to NEUTRAL until the vehicle
speed drops below 1.2 mph (1.9 km). A vehicle left in the
NEUTRAL position can roll. As an added precaution,
always apply the parking brake when exiting the vehicle.

2020_DT_1500_OM_US.book Page 294

STARTING AND OPERATING 299
(Continued)(Continued)
NOTE:
When parking on a hill, it is important to turn the front
wheels toward the curb on a downhill grade and away from
the curb on an uphill grade. Apply the park brake before
placing the gear selector in PARK, otherwise the load on the
transmission locking mechanism may make it difficult to
move the gear selector out of PARK. The parking brake
should always be applied whenever the driver is not in the
vehicle.
WARNING!
• Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully
when parked to guard against vehicle movement and
possible injury or damage.
• When exiting the vehicle, always remove the key fob from the ignition and lock your vehicle.
• Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a
vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or fatally
injured. Children should be warned not to touch the
parking brake, brake pedal or the gear selector.
• Do not leave the key fob in or near the vehicle, or in alocation accessible to children, and do not leave a
vehicle equipped with Keyless Enter-N-Go in the ACC
or ON/RUN mode. A child could operate power
windows, other controls, or move the vehicle.
• Be sure the parking brake is fully disengaged before driving; failure to do so can lead to brake failure and a
collision.
• Always fully apply the parking brake when leaving your vehicle, or it may roll and cause damage or injury.
Also be certain to leave the transmission in PARK.
Failure to do so may allow the vehicle to roll and cause
damage or injury.
WARNING!
• Do not rely on the parking brake to operate effectively if the rear brakes have been immersed in water or mud.
• Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully
when parked to guard against vehicle movement and
possible injury or damage.
WARNING! (Continued)
5
2020_DT_1500_OM_US.book Page 299

300 STARTING AND OPERATING
If exceptional circumstances should make it necessary to
engage the park brake while the vehicle is in motion, main-
tain upward pressure on the electric park brake switch for as
long as engagement is desired. The BRAKE telltale light will
illuminate, and a continuous chime will sound. The rear stop
lamps will also be illuminated automatically while the
vehicle remains in motion.
To disengage the park brake while the vehicle is in motion,
release the switch. If the vehicle is brought to a complete stop
using the parking brake, when the vehicle reaches approxi -
mately 3 mph, (5 km/h) the parking brake will remain
engaged.
• When exiting the vehicle, always remove the key fob
from the ignition and lock your vehicle.
• Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a
vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or fatally
injured. Children should be warned not to touch the
parking brake, brake pedal or the gear selector.
• Do not leave the key fob in or near the vehicle, or in a location accessible to children, and do not leave the
ignition of a vehicle equipped with Keyless
Enter-N-Go in the ACC or ON/RUN mode. A child
could operate power windows, other controls, or move
the vehicle.
• Be sure the parking brake is fully disengaged before driving; failure to do so can lead to brake failure and a
collision.
• Always fully apply the parking brake when leaving your vehicle, or it may roll and cause damage or injury.
Also be certain to leave the transmission in PARK.
Failure to do so may allow the vehicle to roll and cause
damage or injury.
WARNING! (Continued)CAUTION!
If the Brake System Warning Light remains on with the
parking brake released, a brake system malfunction is
indicated. Have the brake system serviced by an
authorized dealer immediately.
WARNING!
Driving the vehicle with the parking brake engaged, or
repeated use of the parking brake to slow the vehicle
may cause serious damage to the brake system. Be sure
the parking brake is fully disengaged before driving;
failure to do so can lead to brake failure and a collision.
2020_DT_1500_OM_US.book Page 300

STARTING AND OPERATING 425
1. Bring the vehicle to a complete stop on level ground, withthe engine running. Apply the parking brake.
2. Press and hold the brake pedal.
3. Shift the transmission to NEUTRAL. The driver's door must be closed (or the driver's seat belt buckled) so that
the transmission will remain in NEUTRAL when the
brake pedal is released.
NOTE:
If vehicle is equipped with air suspension, ensure the vehicle
is set to Normal Ride Height.
4. Using a ballpoint pen or similar object, push and hold the recessed transfer case NEUTRAL (N) button (at the center
of the transfer case switches). The NEUTRAL (N) indi -
cator light will illuminate, and remain lit, when the shift
to NEUTRAL (N) is complete. After the shift is completed
and the NEUTRAL (N) light stays on, release the
NEUTRAL (N) button. 5. Release the parking brake.
6. Shift the transmission into REVERSE.
7. Release the brake pedal for five seconds and ensure that
there is no vehicle movement.
8. Repeat steps 6 and 7 with the transmission in DRIVE.
9. Shift the transmission to NEUTRAL. Apply the parking brake. Turn OFF the engine. For vehicles with Keyless
Enter-N-Go, push and hold the ENGINE START/STOP
button until the engine shuts off. The transmission will
automatically select PARK when the engine is turned off.
10. Turn the ignition to the OFF mode.
11. Attach the vehicle to the tow vehicle using a suitable tow bar.
12. Turn the ignition to the ON/RUN mode, but do not start the engine.
13. Release the parking brake.
14. Turn the ignition OFF.
CAUTION!
It is necessary to follow these steps to be certain that the
transfer case is fully in NEUTRAL (N) before
recreational towing to prevent damage to internal parts.
5
2020_DT_1500_OM_US.book Page 425

658
Audio Systems (Radio) .......................................................... 557
Auto Down Power Windows .................................................. 95Auto Unlock, Doors ................................................................ 308
Automatic Door Locks ............................................................. 41
Automatic Headlights .............................................................. 70
Automatic High Beams ............................................................ 68
Automatic Tailgate Release ................................................... 107
Automatic Temperature Control (ATC) ................................ 91
Automatic Transmission ................................................ 304, 514 Adding Fluid ....................................................................... 514Fluid And Filter Change .................................................... 514
Fluid Change........................................................................ 514
Fluid Level Check ....................................................... 513, 514
Fluid Type .................................................................... 513, 556
Special Additives................................................................. 514
Automatic Transmission Limp Home Mode ...................... 308
Auxiliary Driving Systems .................................................... 211
Axle Fluid......................................................................... 515, 556
Axle Lubrication...................................................................... 515 B
Back-Up .................................................................................... 396
Back-Up Camera ..................................................................... 396
Battery............................................................................... 181, 491 Charging System Light....................................................... 181
Keyless Key Fob Replacement ............................................ 21
Battery Saver Feature ............................................................... 73 Belts, Seat ..................................................................................286
Blind Spot Monitoring ............................................................ 211
Body Builders Guide ................................................................14
Body Mechanism Lubrication ...............................................502
B-Pillar Location ......................................................................521
Brake Assist System ................................................................200
Brake Control System .............................................................199
Brake Fluid .......................................................................512, 556
Brake System....................................................................512, 546 Fluid Check ..........................................................................512
Master Cylinder ...................................................................512Parking ..................................................................................297
Warning Light......................................................................179
Brake/Transmission Interlock ..............................................304
Bulb Replacement ...................................................................436
Bulbs, Light ......................................................................289, 436 C
Camera...................................................................................... 396
Camera, Rear....................................................................396, 398
Camper .....................................................................................146
Capacities, Fuel........................................................................553
Caps, Filler Oil (Engine) ..................................................................487, 493
Radiator (Coolant Pressure)...............................................509
Car Washes ..............................................................................540
Carbon Monoxide Warning ...........................................286, 552
2020_DT_1500_OM_US.book Page 658

663
K
Key Fob Panic Alarm ........................................................................... 20
Programming Additional Key Fobs ............................. 24, 31
Key Fob Battery Service (Remote Keyless Entry)................. 21
Key Fob Programming (Remote Keyless Entry) .................. 24
Keyless Enter-N-Go .......................................................... 37, 291 Lock The Vehicle’s Doors................................... 566, 586, 610
Passive Entry.......................................................................... 37
Passive Entry Programming ...................................... 586, 610
Keys............................................................................................. 18 Replacement........................................................................... 32 L
Lane Change And Turn Signals .............................................. 71 Lane Change Assist .................................................................. 71
LaneSense ................................................................................. 391
Lap/Shoulder Belts ................................................................ 237
Latches ...................................................................................... 289 Hood ..................................................................................... 105
Lead Free Gasoline ................................................................. 548
Leaks, Fluid.............................................................................. 289
Life Of Tires ............................................................................. 529
Light Bulbs ....................................................................... 289, 436
Lights ........................................................................................ 289 Air Bag .................................................................. 179, 246, 287
Brake Assist Warning ......................................................... 204 Brake Warning .....................................................................179
Bulb Replacement................................................................436
Cargo .......................................................................................72
Center Mounted Stop..........................................................443
Courtesy/Reading ................................................................73
Cruise ............................................................................193, 194 Daytime Running ..................................................................67
Electronic Stability Program(ESP) Indicator ...................181
Engine Temperature Warning ...........................................181
Exterior............................................................................66, 289Fog .........................................................................................441
Hazard Warning Flasher ....................................................431
Headlights ........................................................................66, 70High Beam ..............................................................................68
High Beam/Low Beam Select .............................................68
Hill Descent Control Indicator .......................................... 205Illuminated Entry ..................................................................75
Interior ....................................................................................73
Lights On Reminder..............................................................71
Low Fuel ...............................................................................185
Malfunction Indicator (Check Engine).............................183Park........................................................................................192Passing ....................................................................................69
Seat Belt Reminder ..............................................................179
Security Alarm .....................................................................180
Service ...................................................................................436
11
2020_DT_1500_OM_US.book Page 663

666
R
Radial Ply Tires ....................................................................... 527
Radiator Cap (Coolant Pressure Cap).......................... 507, 509
Radio Operation ...................................................................... 626
Rain Sensitive Wiper System................................................... 77
Rear Axle (Differential) .......................................................... 515
Rear Camera ............................................................................ 398
Rear Cargo Area Utility Rails................................................ 144
Rear Cross Path ....................................................................... 216
Rear ParkSense System .......................................................... 361
Rear Window, Sliding .............................................................. 97
Reclining Rear Seats ................................................................. 45
Recreational Towing ............................................................... 422 Shifting Into Transfer Case Neutral (N) .......................... 424
Shifting Out Of Transfer Case Neutral (N) ..................... 426
Reformulated Gasoline .......................................................... 549
Refrigerant ............................................................................... 497
Release, Hood .......................................................................... 105
Release, Tailgate ...................................................................... 107
Reminder, Seat Belt................................................................. 236
Remote Keyless Entry .............................................................. 19 Panic Alarm ........................................................................... 20
Programming Additional Key Fobs ............................. 24, 31
Remote Starting Exit Remote Start Mode ....................................................... 29 Uconnect Customer Programmable
Features.................................................................569, 590, 612
Uconnect Settings ................................................569, 590, 612
Replacement Bulbs..................................................................436
Replacement Keys .....................................................................32
Replacement Tires ...................................................................530
Reporting Safety Defects ........................................................655
Restraints, Child ......................................................................265
Restraints, Head ........................................................................54 Rotation, Tires..........................................................................537 S
Safety Checks Inside Vehicle .................................................286
Safety Checks Outside Vehicle ..............................................289
Safety Defects, Reporting .......................................................655
Safety Information, Tire .........................................................516
Safety Tips ................................................................................285
Safety, Exhaust Gas.................................................................286
Schedule, Maintenance........................................................... 482
Seat Belt Reminder ..................................................................179
Seat Belts ...........................................................................236, 286 Adjustable Shoulder Belt....................................................241
Adjustable Upper Shoulder Anchorage...........................241
Adjustable Upper Shoulder Belt Anchorage...................241
Automatic Locking Retractor (ALR) ................................244
Child Restraints ...................................................................265Energy Management Feature ............................................243
2020_DT_1500_OM_US.book Page 666
